CYBEX VR2 Owner's And Service Manual page 117

Increment
Weight Rod
SHCS
SHCS
(adjustment for
height of incre-
ment weight rod)
Figure 10
D. Lift top weight and insert all three
increment weights onto the increment
weight rod (attached to the frame) then
carefully lower the top weight.
E. Verify increment weight rods are at the
same height by sliding the increment
weights from one increment weight rod to
the other.
Delivery
& Installation
Page 5-6
Cybex VR2 Owner's Manual
5. Install weight plate decals.
NOTE:Place weight plate decals (weight in
A. Slowly and carefully peel off back side of
Figure 11
B. Align holes in decal with appropriate holes in
C. Insert a guide pin through each hole of the
D. Carefully align decal and rub it onto weight
E. Carefully remove front side, leaving decals
Figure 12
pounds for standard units or if desired,
number of weight plates for International
units) on weight plates according to steps
listed below and Figures 11 and 12.
decal. NOTE: When peeling off back cover,
make sure that the decals remain attached to
the front sticker.
weight stack. NOTE: Do not allow the
adhesive to touch weight stack at this time.
template. NOTE: A guide pin can be any-
thing that fits through the weight stack hole,
such as a weight stack selector pin.
plates.
adhering to weight plates.
Guide Pin
Decal
