Belt Removal

1. Place quick release pin (weight stack selector pin) into the top weight plate. Also
place increment weight(s) onto the increment weight holder, if applicable.
2. Using a 5/16" Allen wrench, remove the screws securing clamp at one end of the
belt.
3. Remove the screws securing clamp at the other end of the belt and remove belt.

Belt Installation

1. Observe the four types of belt clamps used on the VR2 machines (shown below).
Familiarize yourself with the types you will be working with.
Sandwich Connection (Frame)
Sandwich Connection (Cam)
Cybex VR2 Owner's Manual
Weight Stack Connection
Rotary Calf Connection
