CYBEX VR2 Owner's And Service Manual page 14

Single-Axis Lat Pulldown - Product No. 4516
Machine Weight
614 lbs.
279 kg
• Open-style bar design encourages a user pull to the center rather than
"behind the neck".
• Handles are angled for optimal position throughout the movement.
• Sliding 5-LB increment weights allow the user to fine-tune resistance levels.
Fly - Product No. 4545
Machine Weight
473 lbs.
215 kg
• "Floating arm" design accommodates users of all sizes, eliminating the
tendency of the pads to "roll" or "scoot" on the arm.
• "Virtual pivot" axis allows the handles to float into optimal position
throughout the range of motion.
• Start range of motion adjustment eliminates the most hazardous
characteristic of most fly machines, the danger of excessive stretch.
• Sliding 5-LB increment weights allow the user to fine-tune resistance levels.
Lateral Raise - Product No. 4530
Machine Weight
439 lbs.
199 kg
• Horizontal input arms allow the user to vary position for better alignment of
the middle deltoid against the resistance.
• Elimination of the standard chest pad allows the user to lean forward for
enhanced positioning.
• Sliding 5-LB increment weights allow the user to fine-tune resistance levels.
Arm Curl - Product No. 4535
Machine Weight
410 lbs.
186 kg
• Rotating handles accommodate the user's ability to achieve supination
relative to their goal and are angled slightly for proper wrist/grip alignment.
• The arm pad is angled for stability and the axis or pivot point is properly
positioned to allow alignment of the elbow joint.
• Sliding 5-LB increment weights allow the user to fine-tune resistance levels.
Technical
Specifications
Page 1-8
Cybex Strength Systems Specifications
Weight Stack
305 lbs. inches = 53 W x 61 L x 76 H
139 kg cm = 135 W x 155 L x 193 H
Weight Stack
205 lbs. inches = 53 W x 37 L x 55 H
93 kg cm = 135 W x 94 L x 140 H
Weight Stack
205 lbs. inches = 40 W x 52 L x 67 H
93 kg cm = 101 W x 132 L x 170 H
Weight Stack
205 lbs. inches = 38 W x 50 L x 55 H
93 kg cm = 97 H x 127 L x 140 H
Size
Size
Size
Size
