Electric Installation - 2N helios ip force Installation Manual

2.3 Electric Installation

This subsection describes how to connect
Network (LAN) and how to connect supply voltage and the electric lock.
PCB Connectors
LAN Connection
External Power Supply Connection
Electric Lock Connection
Factory Default Resetting (PCB version 555v3 and higher)
Factory Default Resetting (PCB version 555v2)
Grounding
Mounting Completion
Available Switches
PCB Connectors
Picture shows the lay-out of connectors on the
board (PCB). Cables, accessories and other system components are connected to
connectors X1 through X22.
Connectors description:
X1 – Loudspeaker
X2 – Button 2
X3 – Button 3
X4 – Camera module
X5 – Button 1
SW1 – Reset button (version 555v3 and higher)
X6 – Configuration jumpers
X7 – Induction loop output
X8 – Extending module (RFID card reader or additional switch)
X10 – Buttons 1 through 4
X11 – LAN
X12 – Servicing connector
X13 – Keypad module
X15 – Left-hand microphone
X16 – Right-hand microphone
X17 – Relay NO and NC contact max. 30 V / 1 A AC/DC
