2N helios ip force Installation Manual page 79

Security Relay
®
The 2N Helios IP
between the intercom and the connected electric lock. The 2N
Relay is designed for any
higher. It significantly enhances security of the connected electric lock as it prevents
lock opening by forced intercom tampering.
Function:
®
The 2N Helios IP Security Relay
the secured area) and the electric lock (inside the secured area). The 2N
Security Relay includes a relay that can only be activated if the valid opening code is
received from the intercom.
Specifications:
Passive switch: NO and NC contacts, up to 30 V / 1 A AC/DC
Active switch output: 9 to 12 V / 700 mA transistor switched output. Depends
on power supply (PoE: 9 V or power supply voltage minus 1 V).
Dimensions: (56 × 31 × 24) mm
Weight: 20 g
Installation:
®
Install the 2N Helios IP Security Relay
and the electric lock inside the area to be secured (typically behind the door). The
device is powered and controlled via this two-wire cable and so can be added to an
existing installation. Thanks to its compact dimensions, the device can be installed into
a standard mounting box.
2N TELEKOMUNIKACE a.s., www.2n.cz
Security Relay (Part No. 9159010) is used for enhancing security
2N Helios IP
is a device installed between an intercom (outside
intercom model with firmware versions 1.15 and
onto a two-wire cable between the intercom
®
Helios IP Security
®
Helios IP
79/110
