2N helios ip force Installation Manual page 45

Flush Mounting – Plasterboard
Use the plasterboard flush mounting box and follow the instructions included therein.
What You Need:
Plasterboard flush mounting box, Part No. 9151002
Hole: 118 × 237mm
Flush Mounting – Hollow Bricks
What You Need:
Brick flush mounting box, Part No. 9151001
Hole: (132 × 223 × 83) mm
Suppose you intend to install your
bricks. Note that the external side of the bricks gets damaged by cutting and the
dowels cannot practically be fixed into the thin internal part of the bricks. Therefore,
use the brick flush mounting box and follow the instructions included therein.
2N TELEKOMUNIKACE a.s., www.2n.cz
®
2N Helios IP Force unit into a wall made of hollow
45/110
