- Page 1 Helios IP Documentation...
-
Page 2: Table Of Contents
IP B ELIOS ONTROLLER IP B ELIOS ONTROLLER ETTINGS WITCH ETTINGS IP B UPPORTED ELIOS ONTROLLER UPPORTED WITCH OMMANDS HELIOS IP INTEGRATION TESTS REPARATION OF NTEGRATION ESTS ECESSARY OMPONENTS EVICE REATION ENTRAL REPARATION FOR ESTING ONNECTION ASIC UNCTION ESTS TCF000A D... - Page 3 IGURE CCESS ETTINGS 3: SIP A ........................... 7 IGURE CCOUNT ETTING 4: S ........................... 8 IGURE WITCH ETTINGS 5: B ........................14 IGURE ASIC ESTING IAGRAM 6: B ........................21 IGURE ASIC ESTING IAGRAM Helios IP – Documentation Page 3...
-
Page 4: Document Update History
Ondřej Pohl Adding of integration tests 03/08/2015 Ondřej Pohl New driver adaptations 18/09/2015 Armen Hajrapetjan New driver adaptations 22/10/2015 Armen Hajrapetjan Bug fix 12/11/2015 Armen Hajrapetjan Fix default login parameters Table 1: Document Update History Helios IP – Documentation Page 4... -
Page 5: Device Connection
Device Connection The Helios IP device is connected to the Local Area Network. The intercom is supplied via PoE or an external power supply. Device Configuration API Access Make basic configuration after connecting the device to the LAN.Default access values are (Login: admin, Password: 2n). -
Page 6: Figure 2: Http Api Access Settings
Now switch the tab to Account 1 and enable the account. The HTTP API login data settings are optional and need not be completed. Select User rights in the User Settings as shown in the figure below and save the changes. Figure 2: HTTP API Access Settings Helios IP – Documentation Page 6... -
Page 7: Sip Account Setting
Set the SIP account in the intercom to enable outgoing calls to a defined phone number. Select Telephone in the Services menu. Refer to the figure below for an example of functional setting. Figure 3: SIP Account Setting Helios IP – Documentation Page 7... -
Page 8: Switch Settings
Switch Settings Set the Helios IP switch controlling parameters as shown in the figure below. Figure 4: Switch Settings Refer to the following product support web sites for more Helios IP configuration details: https://wiki.2n.cz/pages/viewpage.action?pageId=23102595 Helios IP – Documentation Page 8... -
Page 9: Driver Info
Compatibility with integration tests 03/08/2015 1.0.3 Additional test compatibility 18/09/2015 1.0.4 Adjusted for the new API 22/10/2015 1.0.5 Bug fix 12/11/2015 1.0.9 Bug fix Table 4: Driver History Hardware Components and Versions Supported firmware version: 2.13 Helios IP – Documentation Page 9... -
Page 10: Helios Ip Driver Configuration
Helios IP Driver Configuration Helios IP Bus Controller Information on Helios IP Bus Controller and switch features and configurable values. Helios IP Bus Controller Settings Feature name Meaning Default Example of value value Enabled Driver enable/disable Mobile number Phone number for outgoing calls... -
Page 11: Supported Helios Ip Bus Controller
Close Close the outgoing call. Call Start an outgoing call to a defined number. Table 7: Supported Helios IP Bus Controller Commands Just one Helios IP switch can be controlled via the driver. Supported Switch Commands Element Command Meaning Remove a switch from the list. -
Page 12: Helios Ip Integration Tests
IP INTEGRATION TESTS ELIOS Helios IP – Documentation Page 12... -
Page 13: Preparation Of Integration Tests
1. Create a bus controller with device URL and Account and Password values set according to the Helios IP HTTP API login data. 2. Create an output under the bus controller with ID as set for the Helios IP switch. Helios IP – Documentation... -
Page 14: Central Unit Preparation For Testing
Central Unit Preparation for Testing Connection Connect the Central Unit and Helios IP as shown in the diagram below. Figure 5: Basic Testing Diagram Helios IP – Documentation Page 14... -
Page 15: Basic Function Tests
1. Stop Helios PI using the Stop button. 2. Create two switches in the device. 3. Set identical Digital Output IDs for the two switches. 4. Start the Helios IP driver using the Reinitialisation button. Expected Results 1. The two switches pass into the ConfigurationFailure status. -
Page 16: Tcf010A M
The test verifies the driver in case the device configuration is incomplete. In this case, the driver has to log the Missing Device event on the nearest superior level of the device configuration tree after every event receipt. Note The test is not supported due to communication protocol limitations. Helios IP – Documentation Page 16... -
Page 17: Tcf020A Parameter Value Beyond Range
Test Procedure 1. Stop the driver if running. 2. Add a driver with an ID higher than that of Helios IP. 3. Run the device. Expected Results 1. The driver is not initialised and stops. -
Page 18: Tre000A Connection Loss
5. Wait for communication recovery. Expected Results The following events are recorded in the log: Connection lost to 'DEVICE'. Connection with 'DEVICE' restored. Number of attempts: RETRYCOUNT. Where DEVICE represents the device name. Helios IP – Documentation Page 18... -
Page 19: Tre010A Communication Loss
The test verifies the driver if communication gets lost between the LAN module and device - there is no disconnection on the transport layer. Note The test is not supported due to communication protocol limitations. Helios IP – Documentation Page 19... -
Page 20: Tfc010A Contact Activation /Deactivation
3. The following events are recorded in the log: Command ‘On’ send to ‘DEVICE’ by ‘PERSON’. ’DEVICE’ opened. Command ‘Off’ send to ‘DEVICE’ by ‘PERSON’. ’DEVICE’ closed. Where DEVICE is the switch name. PERSON represents the command entering person. Helios IP – Documentation Page 20... -
Page 21: T001 - Call Setup Check
4) Hang up the call using the Close command in the context menu. Expected Results An outgoing call is set up from Helios IP to a defined phone number. The call is set up successfully with mutual audibility. When the Close command is executed, the call is terminated. You can see the following information on the Events tab: Helios IP –...
