  • Page 1 ® Helios IP Verso Modular IP Intercom Installation Manual Version www.2n.cz  ...
  • Page 2 The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All development, production and distribution processes of the company are managed by this standard and guarantee a high quality, technical level and professional aspect of all our products.

  • Page 3: Table Of Contents

    Content 1. Product Overview ........4 1.1 Components and Associated Products  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  6  ...

  • Page 4: Product Overview

    Helios IP Verso is a modular system: the user determines its configuration ® according to the needs of the particular installation. Unlike other intercoms, 2N Helios IP Verso is not delivered as a compact unit. After choosing the installation mode and particular modules, the user gets separate parts to be assembled using the plug&play connections.

  • Page 5: Advantages Of Use

    PC application, etc. When necessary, more electrical outputs can be added. Numerous parameters allow for a wide spectrum of applications. ® Robustness – Helios IP Verso is designed as a vandal resistant intercom, which withstands mechanical or weather conditions with no need to purchase extra accessories.

  • Page 6: Components And Associated Products

    The basic unit installation requires two frame/box positions; the other position, however, is left for additional module installation. Frames 9155012 9155011 9155013 Flush mounting frame, 1 Flush mounting frame, 3 Flush mounting frame, 2 module modules modules ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 7 (Part No. 9155011) – 1-module flush mounting box (Part No. 9155014) 2-module frame (Part No. 9155012) – 2-module flush mounting box (Part No. 9155015) 3-module frame (Part No. 9155013) – 3-module flush mounting box (Part No. 9155016) ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 8: Extending Modules

    9155030 9155031 9155032 RFID Card Reader, 125 RFID Card Reader, 13 Infopanel Keypad 9155035 9155034 I/O 9155036 9155037 5-Button Module Electronic Buttons Wiegand Module Module 9155050 9155038 9155039 1 m interconnecting Tamper Switch Blank module cable ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 9: Mounting Accessories

    ® Helios IP A 2-module covering frame for the flush/plasterboard Verso – 9155012 mounting box. Be sure to order the flush mounting frame Flush together with the 2-module flush mounting box mounting frame modules ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 10 3 modules ® The Infopanel module helps you place such information into Helios IP the intercom installation as house number, opening hours and 9155030 Verso – similar data. The Infopanel backlight is software controlled. Infopanel ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 11 Tamper position Switch ® Helios IP Verso is designed for outdoor applications and requires no additional roof. Choose the proper frame and, if necessary, mounting box type depending on your ® particular Helios IP Verso installation needs.

  • Page 12: Power Supply

    BEFO 1211MB with mechanical momentary pin blocking Power Supply 91341481E 12 V / 2 A adapter 91378100 932928E A stabilised power supply must be used PoE injector 12 V transformer where PoE supply is not applied. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 13: Additional Modules

    Additional Modules 9137420E 9159010 9137410E External 125 kHz RFID card reader for Security relay External IP relay PC connection via USB 9134165E 9134166E RFID card, 125 kHz RFID key fob, 125 kHz ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 14: Terms And Symbols

    Warning Always abide by this information to prevent damage to the device. Caution Important information for system functionality. Useful information for quick and efficient functionality. Note Routines or advice for efficient use of the device. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 15: Description And Installation

    2.2 Electric Installation 2.3 Extending Module Connection 2.4 Completion Product Completeness Check ® Before you start please check whether the contents of the package of your new 2N Helios IP Verso complies with the following list. ® 1× 2N Helios IP Verso ®...

  • Page 16: Mechanical Installation

    What you need for mounting a properly cut hole as instructed in the box package Plaster, mounting glue, mounting foam or mortar as necessary ® Helios IP Verso , flush mounting boxes and frames 1× module: box Part No. 9155014 , frame Part No.
  • Page 17 9155016 frame Part No 9155013 Surface mounting (concrete and steel structures, entry barrier columns, etc What you need for mounting ® Helios IP Verso plus the respective frames × module: frame Part No . 9155021 × modules: frame Part No .
  • Page 18 Having removed the front panel, make sure that no dirt gets inside the product (especially onto the sealing surface). ® Never turn Helios IP Verso to align the box assembly after mounting. Make sure that the flush mounting boxes have been installed accurately.
  • Page 19 The manufacturer shall not be liable for injuries in such cases! Module Installation 2.1.1 One Module Box 2.1.2 Two Modules Box 2.1.3 More Two Modules Boxes 2.1.4 Three Modules Box 2.1.5 More Three Modules Boxes 2.1.6 Tamper and I/O Module ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 20 2.1.1 One Module Box Flush mounting box mounting – classics bricks ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 21 Flush mounting box mounting – plasterboard ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 22 Flush module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 23 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 24 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 25 Surface module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 26 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 27 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 28 2.1.2 Two Modules Box Flush mounting box mounting – classics bricks ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 29 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 30 Flush mounting box mounting – plasterboard ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 31 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 32 Flush module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 33 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 34 Surface module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 35 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 36 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 37 2.1.3 More Two Modules Boxes Flush mounting box mounting – classics bricks ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 38 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 39 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 40 Flush mounting box mounting – plasterboard ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 41 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 42 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 43 Flush module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 44 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 45 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 46 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 47 Surface module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 48 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 49 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 50 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 51 2.1.4 Three Modules Box Flush mounting box mounting – classics bricks ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 52 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 53 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 54 Flush mounting box mounting – plasterboard ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 55 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 56 Flush module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 57 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 58 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 59 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 60 Surface module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 61 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 62 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 63 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 64 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 65 2.1.5 More Three Modules Boxes Flush mounting box mounting – classics bricks ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 66 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 67 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 68 Flush mounting box mounting – plasterboard ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 69 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 70 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 71 Flush module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 72 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 73 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 74 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 75 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 76 Surface module mounting ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 77 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 78 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 79 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 80 ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 81 2.1.6 Tamper and I/O Module ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 82: Electric Installation

    Power Supply Connection ® Helios IP Verso can be powered either from an external 12 V / 2 A DC source or directly from the LAN equipped with PoE 802.3af supporting network elements. Owing to different power outputs, the power supply selection affects the maximum count and applicability of the modules connected of the basic unit.
  • Page 83 12 W for feeding of the basic unit and connected modules. Combined Power Supply ® Helios IP Verso can be fed from an external power supply and PoE at the same time. In this configuration, the maximum power for the connected modules is available. LAN Connection ®...
  • Page 84 Press the RESET button shortly to restart the device. Factory Reset ® Helios IP Verso is equipped with a RESET button. Press the button shortly (< 1 s) to restart the system without changing configuration. Follow the instructions below to identify the current IP address Press and hold the RESET button.
  • Page 85 Wait until the red LED goes off (approx. 5 s). Wait until the green LED goes off and the red LED comes on again (approx. 5 s). Wait until the green LED goes off (another 5 s). Release the RESET button. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 86: Extending Module Connection

    Module Bus Interconnection ® All the Helios IP Verso modules, except for the Tamper Switch, are interconnected via a bus. The bus starts on the basic unit and goes over all the modules. The order of modules on the bus is irrelevant. And it also irrelevant which bus connector on the module is used as the input and which is used as the output.
  • Page 87 Keypad Module ® The Keyboard module is one of the Helios IP Verso intercom elements and provides a numerical input in the system. ® The module contains two Helios IP Verso bus connectors. These two connectors are fully interchangeable and can be used both as inputs from the basic unit and outputs to other modules.
  • Page 88 I/O Module ® The I/O module is one of the Helios IP Verso intercom elements and is used for extending the number of inputs and outputs. ® The module contains two Helios IP Verso bus connectors. These two connectors are fully interchangeable and can be used both as inputs from the basic unit and outputs to other modules.
  • Page 89 5-Button Module ® The 5-button module is one of the Helios IP Verso intercom elements and is used for extending the number of buttons. ® The module contains two Helios IP Verso bus connectors. These two connectors are fully interchangeable and can be used both as inputs from the basic unit and outputs to other modules.
  • Page 90 Tamper switch (9155038) input Tamper Switch Module ® The Tamper Switch module is one of the Helios IP Verso intercom elements and helps secure the system against tampering. The module contains two switches that open whenever the front frame is...

  • Page 91: Completion

    You can use silicone or some other sealant to seal the box against the wall if uneven to avoid water leakage and wall damping. Sealing, however, is unnecessary for the proper function of the intercom. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 92: Function And Use

    3. Function and Use ® This section describes the basic and extending functions of the the 2N Helios IP Verso product. Here is what you can find in this section: 3.1 Configuration 3.2 Intercom Control as Viewed by External User 3.3 Display-Equipped Intercom as Viewed by External User...

  • Page 93: Configuration

    Press the quick dial button on the basic unit five times. ® Helios IP Verso will read its IP address. If the address is 0.0.0.0, it means that the intercom has not obtained the IP address from the DHCP server.
  • Page 94 Dynamic/Static IP Address Switching ® Take the following steps to switch the dynamic and static IP address mode in 2N Helios IP Verso ® Connect (or, if connected, disconnect and reconnect) Helios IP Verso the power supply. Wait for the first sound signal Press the quick dial button on the basic unit fifteen times.
  • Page 95 ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 96: Intercom Control As Viewed By External User

    Miscellaneous subsection in the Configuration Manual. Calling to Phone Book Position ® Helios IP Verso Phone Book can contain up to 1999 programmable positions. The quick dial buttons can only be used for positions 1 through 146, depending on the number of actually installed buttons.
  • Page 97 Press * to answer the call and # to reject the call. Door Opening (Switch Activation) by Code ® Helios IP Verso is equipped with a door unlocking switch. Enter the valid code (refer to the Miscellaneous subsection in the Configuration Manual) using the numeric keypad to activate this switch.

  • Page 98: Display-Equipped Intercom As Viewed By External User

    3.3 Display-Equipped Intercom as Viewed by External User The electronic button unit is unavailable yet. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 99 ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 100: Intercom Control As Viewed By Internal User

    Configuration Manual. Door Opening (Switch Activation) by Code ® Helios IP Verso is equipped with a door unlocking switch. Enter the valid code (refer to the Miscellaneous subsection in the Configuration Manual) using your phone keypad to activate this switch.
  • Page 101 Procedure: Enter the profile activating/deactivating code using your phone keypad and press * for confirmation. A valid code is signalled by the sound according to the code type. An invalid code is signalled by the sound. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 102: Maintenance

    Do not use aggressive detergents (such as abrasives or strong disinfectants). Prevent water from getting inside the intercom. Clean the device in dry weather so that waste water can evaporate quickly. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 103: Technical Parameters

    Amplifier: 2 W (class D) amplifier Speaker: 2 W / 8 Ω Output LINE OUT: 1 VRMS / 600 Ω Volume control: Adjustable with automatic adaptive mode Full duplex: Yes (AEC) Audio stream Protocols: RTP/RTSP Codecs: G.711, G.729 ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 104: Rfid Card Reader

    Supported cards, 13.56 MHz ISO14443A Mifare Classic 1k & 4k, DESFire EV1, Mini, Plus S&X, SmartMX, Ultralight, Ultralight C, SLE44R35, my-d move (SLE66Rxx), PayPass, Legic Advant ISO14443B Calypso, CEPAS, Moneo, SRI512, SRT512, SRI4K, SRIX4K, PicoPass, HID iCLASS ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 105 2 moduls: 108 (W) x 238 (H) x 45 (D) mm 3 moduls: 108 (W) x 343 (H) x 45 (D) mm Weight – Max net weight: 2 kg / max gross weight: 2.5 kg - based on configuration Covering level – IP54 ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 106: Supplementary Information

    5. Supplementary Information Here is what you can find in this section: 5.1 Troubleshooting 5.2 Directives, Laws and Regulations 5.3 General Instructions and Cautions ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 107: Troubleshooting

    5.1 Troubleshooting For the most frequently asked questions refer to faq.2n.cz ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 108: Directives, Laws And Regulations

    5.2 Directives, Laws and Regulations Europe ® Helios IP Verso conforms to the following directives and regulations: Directive 1999/5/EC of the European Parliament and of the Council, of 9 March 1999 – on radio equipment and telecommunications terminal equipment and the mutual...
  • Page 109 Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 110: General Instructions And Cautions

    The manufacturer also assumes no responsibility for additional costs incurred by the consumer as a result of making calls using a line with an increased tariff. ® TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 111: Electric Waste And Used Battery Pack Handling

    Make sure that the devices to be disposed of are complete. Do not throw battery packs into fire. Battery packs may not be taken into parts or short-circuited either. ® TELEKOMUNIKACE a.s., www.2n.cz...
  • Page 112 2N TELEKOMUNIKACE a.s. Modřanská 621, 143 01 Prague 4, Czech Republic Phone: +420 261 301 500, Fax: +420 261 301 599 E-mail: sales@2n.cz Web: www.2n.cz 2060v1.1 ® TELEKOMUNIKACE a.s., www.2n.cz...
