2N helios ip force Installation Manual page 92

The acoustic signal
Wait until the device is restarted automatically.
Caution
The 1, 1, 1, 2, 2, 3 sequence must be entered within 30 seconds after the
first sound signal for security reasons. The inter-digit delay may be 2 s at
most.
The device will have the following network parameters after restart:
IP address – 192.168.1.100
Network mask – 255.255.255.0
Default gateway – 192.168.1.1
Dynamic IP Address Setting for 4-button models
Follow the instructions below to enable automatic getting of network parameters
from the DHCP server:
®
Connect 2N
it if already connected).
Wait for the first acoustic signal
Press buttons 2, 1, 1, 2, 2, 3 sequentially.
The acoustic signal
Wait until the device is restarted automatically.
2N TELEKOMUNIKACE a.s., www.2n.cz
indicates mode switching.
Helios IP Force to the power supply (or, disconnect and reconnect
indicates mode switching.
92/110
