Module settings:
Refer to the Configuration Manual for details.
Connection:
Internal RFID Card Reader 125 kHz
The Internal RFID Card Reader 125 kHz (Part No. 9151011) is used for reading RFID card
®
Ids in the 125 kHz band. This module is intended for mounting into the 2N Helios IP
Force model 9151102CR, 9151102R, 9151101CRP and 9151101RP. These models have an
window, which is necessary for antenna operation. If the Internal RFID Card Reader is
installed, it is not possible to install the Additional Switch.
Function:
®
The 2N Helios IP Force Internal RFID Card Reader adds two logical inputs, two
®
additional switches and a tamper switch to the 2N Helios IP Force basic unit.
