2N Helios IP Instruction Manual

Hide thumbs Also See for Helios IP:

Advertisement

Quick Links

Download this manual See also: Configuration Manual, Documentation
2n Helios IP
INSTRUCTION MANUAL
Versiyon1.0
www.yonnet.com.tr

Advertisement

loading

Related Manuals for 2N Helios IP

Summary of Contents for 2N Helios IP

  • Page 1 2n Helios IP INSTRUCTION MANUAL Versiyon1.0 www.yonnet.com.tr...
  • Page 2 General Assembly & Wiring Diagram ® Helios Overview and Settings I have written this script is ready written OK to extension in real time the status of negotiations. UNKNOWN those written inaccessible. INTERFACE POWER SUPPLY • Ethernet • 802.3af (PoE) 48 V / 380 mA DC •...
  • Page 3 • Perform the screen display menu settings in the phone book can be defined. This interface design process is set through 2N Helios IP Manager Program. • Numbering of the office being sought is identified In addition, it opens the door lock with a defined password.
  • Page 4 Static & DHC IP Settings Over DeviceStaticand DHCP IP settings • For static IP StandardIP:192.168.1.100 ıt is set. • 2N Helios’ power connection is made. • Work is expected that the first warning tone. • According to the model applied the following button combination.
  • Page 5 ® Helios Static & DHC IP Settings • Givetothe DHCP IP; • 2N ® Helios’power connection is made. • Work is expected that the first warning tone. • According to the model applied the following button combination. • 1 button models for;...

  • Page 6: Access Device

    IP can be found in a comfortable way.If the IP does not deploy, a system that is not performed, above static IP settings.The IP with which the device is connected to interface. User Name : admin Password : 2n Information www.yonnet.com.tr...
  • Page 7 Access Device ® Helios The first screen contains information about the device. Product name Bootloader version Hardware version Serial number MAC address Uptime RegistrationStatus:? SIP number Registration at Registration time DHCP status IP address Net mask Default gateway Primary DNS Secondary DNS Camera Display...
  • Page 8 ® Helios 2.5.1 Basic Settings Phonebook 2.5.1 www.yonnet.com.tr...
  • Page 9 ® Helios 2.5.1 Basic Settings As shown in the above image from the first 10 and the arrow keys are called even numbers going forward position. Each position corresponds to the desired each number dialed. Position enabled:Position aktif/pasif Position name : Position name E-mail The email address of the person to be searched in this section is defined...
  • Page 10 ® Helios 2.5.2 Basic Settings 2.5.2 Switch www.yonnet.com.tr...
  • Page 11 ® Helios 2.5.2 Basic Settings Switch Settings Switch enabled Used Relay active/passıve Switch mode : The setting of how to use relay.Monostrabl, relay after leaving off election will be open during the active period.BistableThe first trigger is active, the second trigger is inactive: Switch-on duration The relay is active for the duration Monostrabl.
  • Page 12 ® Helios 2.5.3 Basic Settings 2.5.3 Network www.yonnet.com.tr...
  • Page 13 ® Helios 2.5.3 Basic Settings DHCP Settings DHCP client enabled : IP also the option that you buy you automatically. Static Settings Static IP address Static given to the IP. Network mask : The subnet mask Default gateway : Default gateway Primary DNS : Primary DNS Server : Secondary DNS...

  • Page 14: Sip Settings

    ® Helios 2.5.4 Basic Settings 2.5.4 SIPSettings www.yonnet.com.tr...
  • Page 15 ® Helios 2.5.4 Basic Settings User Settings Display name User ID Identified Sip number Domain : Sip server IP address SIP Proxy Settings Proxy address SIP Server IP address SIP Proxy Registration Enable Registration : Receiving part of the approval to register the SIP servers. Registration Expires:It’...

  • Page 16: Mic & Speaker

    ® Helios 2.5.5 Basic Settings Mic & Speaker 2.5.5 Speaker Settings Master volume The general tone of the speaker settings.Calls received signals and controls the tones simultaneously. Audio volume :The setting is part of the voice conversation. Warning volume : The setting is part of the audio signal. Key beep volume Sound settings when the button is pressed Lock open volume...
  • Page 17 ® Helios 2.5.6 Basic Settings 2.5.6 Streaming www.yonnet.com.tr...
  • Page 18 ® Helios 2.5.6 Basic Settings RTSP Server RTP server It uses open RTSP protocol. Enable audio stream Making sound transmission protocols. Enable video stream Protocol to transfer video. Quality Settings Video codec Supports codec types. Video resolution Image resolution. Frame rate Second / image www.yonnet.com.tr...
  • Page 19 ® Helios 2.5.7 Basic Settings Miscellaneous 2.5.7 Outgoing Calls Ring time limit Playtime Search Call time limit Call duration. Dial cycles limit Incoming Calls Automatic Answer:Giving automatic response when a call comes. Keyboard Settings Hang up by # button call termination with key same button function The keypad can be used to quickly search through.
