2N
Helios IP Force
Connectors, PCB Version 555v4
LAN Connection
®
2N
Helios IP Force
is connected to the LAN via a RJ-45 terminated (connector X11)
UTP/STP cable (of category Cat 5e or higher). The system is equipped with the Auto-
MDIX function and so both the straight and crossed cable versions can be used.
Caution
We recommend the use of a LAN surge protection.
2N TELEKOMUNIKACE a.s., www.2n.cz
54/110
