Seat Exeo 2012 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for Seat Exeo 2012

Summary of Contents for Seat Exeo 2012

  • Page 3 Foreword This Instruction Manual and its corresponding supplements should be read carefully to familiarise yourself with your vehicle. Besides the regular care and maintenance of the vehicle, its correct handling will help preserve its value. For safety reasons, note the information concerning accessories, modifications and part replacements. If selling the vehicle, give all of the on-board documentation to the new owner, as it should be kept with the vehicle.

  • Page 5: Table Of Contents

    Remote control keys ..... . . Seat belts .......
  • Page 6 Table of Contents Trailer towing Luggage compartment lights ..........Registration light .

  • Page 7: Manual Structure

    Manual structure Manual structure What you should know before reading this manual CAUTION This manual contains a description of the equipment supplied with the ve- Texts with this symbol draw your attention to potential sources of damage hicle at the time of press. Some of the equipment hereunder described will to your vehicle.

  • Page 8: Content

    2. Operating instructions Information about the distribution of controls in the driver position of your vehicle, about the seat adjustment possibilities, about how to create a suit- able climate in the passenger compartment, etc. 3. Practical Tips Advice relating to the driving, caring and maintenance of your vehicle and certain problems you can solve yourself.

  • Page 9: Safety First

    ● Front airbags aware of for your own safety and for the safety of your passengers. ● Side airbags in the front and rear seat backrests* ● Ensure that the onboard documentation is kept in the vehicle at all ● Head-protection airbags* times.
  • Page 10 There are also a number of important safety warnings that you and your – Fasten your seat belt correctly. Make sure that your passengers passengers should always observe in order to minimise the risk of injury.
  • Page 11 Safe driving WARNING WARNING When driving safety is impaired during a trip, the risk of injury and acci- When driving safety is impaired during a trip, the risk of injury and acci- dents increases. dents increases.   What affects driving safety? Driving safety is largely determined by your driving style and the personal behaviour of all occupants.
  • Page 12 ⇒  f ig. steering wheel – Move the driver seat forwards or backwards so that you are able to press the accelerator, brake and clutch pedals to the floor with your knees still slightly angled ⇒  .
  • Page 13 ● An incorrect sitting position of the driver can lead to severe injuries. – Move the front passenger seat back as far as possible ⇒  . ● Adjust the driver seat so that there is at least 25 cm distance between ⇒  f ig.
  • Page 14 ● Always keep your feet in the footwell when the vehicle is moving; never rest them on the dash panel, out the window or on the seat. An in- – Keep both feet in the footwell in front of the rear seat.
  • Page 15 Safe driving Correct adjustment of front seat head restraints Adjust the head restraint properly in order to achieve maximum protection. Properly adjusted head restraints are an important part of – Adjust the head restraint so that its upper edge is at the same...
  • Page 16 Incorrect sitting positions substantially re- duce the protective function of seat belts and increase the risk of Lowering the head restraint injury due to incorrect seat belt position. As the driver, you are re- ⇒  f ig. 5 – Press button and lower the head restraint.

  • Page 17: Safe Driving

    ● Never put your feet out of a window. ● Never put your feet on the dash panel. ● Never put your feet on the surface of a seat. ● Do not allow anyone to travel in the footwell. ● Never travel without wearing the seat belt.

  • Page 18: Pedal Area

    Safe driving Pedal area Floor mats on the driver side Only floor mats may be used which can be securely fastened Pedals in the footwell and do not impair operation of the pedals. The operation of all pedals must never be impaired by ob- –...
  • Page 19 Before you lock the vehicle, make sure that there are no adults or children in the vehicle. ● Never transport passengers in the luggage compartment. All passen- gers must have their seat belt fastened ⇒  p age 18. Safety First Operating Instructions...

  • Page 20: Seat Belts

    Seat belt warning lamp*  WARNING The warning lamp acts as a reminder to the driver to fasten ● If seat belts are worn incorrectly or not at all, the risk of severe inju- the seat belt. ries increases. ● Properly worn seat belts can reduce severe injuries in case of sudden Before starting the vehicle: braking manoeuvres or accidents.

  • Page 21: Why Wear Seat Belts

    25 km/h to 50 km/h, for example, the kinetic energy is multiplied by four. Because the passengers in our example are not restrained by seat belts, in the case of a head-on collision all of their kinetic energy has to be absorbed ⇒ ...
  • Page 22 All occupants (including the driver) must ing a seat belt is thrown wear seat belts properly during the trip. This will reduce the risk of severe forward violently. injuries in the event of an accident – regardless of whether an airbag is fit- ted for the seat or not.
  • Page 23 Our examples describe frontal collisions. Of course, properly worn seat belts substantially reduce the risk of injury in all other types of accidents. This is why it is so important to fasten seat belts before every trip, even when "just driving around the corner".
  • Page 24 ● The belts must be kept clean, otherwise the retractors may not work properly ⇒  p age 214. ● Keep both feet in the footwell in front of your seat as long as the vehi-  cle is in motion.

  • Page 25: Seat Belts

    ● Never put the latch plate in the buckle of another seat. If you do this, the seat belt will not protect you properly and the risk of injury is in- creased.
  • Page 26 ● An incorrectly worn seat belt can cause severe injuries in the event of an accident. ● The shoulder part of the seat belt must lie on the centre of the shoul- der, never across the neck. The seat belt must lie flat and snugly on the ⇒ ...
  • Page 27 ● For pregnant women, the lap part of the seat belt must lie as low as possible over the pelvis, never across the stomach, and always lie flat so that no pressure is exerted on the abdomen.
  • Page 28 WARNING – After adjusting, pull the belt sharply to check that the catch on Never unbuckle a seat belt while the vehicle is in motion. If you do, you the guide fitting is engaged securely. increase the risk of sustaining severe or fatal injuries.

  • Page 29: Seat Belt Tensioners

    The seat belt tensioner can be triggered only once. ● The belt tensioners will only provide protection for one accident and The seat belt tensioners will not be triggered in the event of a light frontal, must be changed if they have been activated.

  • Page 30: Airbag System

    ● If you are not wearing a seat belt, if you lean forward or to the side you critical injuries. Therefore, it is essential that all passengers in the vehi- while travelling or assume an incorrect sitting position, there is a sub- cle assume a correct sitting position while travelling.
  • Page 31 WARNING ● To reduce the risk of injury from an inflating airbag, always wear the ● If a child seat is secured to the front passenger seat, the risk to the seat belt properly ⇒  p age 18. child of sustaining critical or fatal injuries in the event of an accident in- ●...
  • Page 32 In the event of an accident this could cause The warning lamp monitors all airbags and seat belt tensioners in the vehi- the airbag to inflate incorrectly or not inflate at all.
  • Page 33 Airbag system WARNING (Continued) ● Any work on the airbag system or removal and installation of the air- bag components for other repairs (such as repairs to the steering wheel) should be performed only by a specialised workshop. Specialised work- shops have the necessary tools, repair information and qualified person- nel.

  • Page 34: Front Airbags

    The airbag system is not a substitute for seat belts, but it is an integral part of the vehicle's overall passive safety system. Please bear in mind that the airbag system can only work effectively when the occupants are wearing their seat belts correctly and have adjusted the head restraints properly.
  • Page 35 ● there is a rear-end collision ● the vehicle turns over WARNING ● The seat belts and airbags can only provide maximum protection if the occupants are seated correctly ⇒  p age 10, Proper sitting position for occupants. ● If a fault has occurred in the airbag system, have the system checked immediately by a specialised workshop.
  • Page 36 Airbag system develop when the airbag deploys. This is normal and it is not an indication of fire in the vehicle.  Airbag covers when the frontal airbags are triggered Fig. 20 Airbag covers reacting when the front airbags are triggered The airbag covers fold out of the steering wheel or dash panel when the ⇒ ...

  • Page 37: Knee Airbag

    ● If you are not wearing a seat belt, if you lean forward or to the side while travelling or assume an incorrect sitting position, there is a sub- stantially increased risk of injury.
  • Page 38 See also ⇒  p age 65.  This is just one of the reasons why an airbag is not a substitute for the seat belt. The airbag system works most effectively when used with the seat belts.
  • Page 39  or if the seat is improperly positioned and you are not wearing your seat belt. The risk increases even more should the airbag deploy. ● Always make sure that the knee airbag can inflate without interfer- ence.

  • Page 40: Side Airbags

    Airbag system Side airbags* The airbag system is not a substitute for seat belts, but it is an integral part of the vehicle's overall passive safety system. Please bear in mind that the airbag system can only work effectively when the occupants are wearing their seat belts.
  • Page 41 ● Any work carried out to the doors should be made in a specialised workshop. ● The seat belts and airbags can only provide maximum protection if the occupants are seated correctly ⇒  p age 10, Proper sitting position for occupants.
  • Page 42 ● If you do not wear a seat belt, if you lean forward, or are not seated critical consequences including serious injury or death ⇒  p age 46, correctly while the vehicle is in motion, you are at a greater risk of injury Child safety.

  • Page 43: Curtain Airbags

    ⇒  p age 42, Safety notes on the operation of the cur- tain airbag system. The airbag system is not a substitute for seat belts, but it is an integral part of the vehicle's overall passive safety system. Please bear in mind that the airbag system can only work effectively when the occupants are wearing their seat belts correctly and have adjusted the head restraints properly.
  • Page 44 WARNING ● In order for the side airbags to provide their maximum protection, the prescribed sitting position must always be maintained with seat belts fastened while travelling. ● For safety reasons, the curtain airbag must be disconnected in those vehicles fitted with a passenger compartment separation screen.
  • Page 45 Airbag system WARNING (Continued) ● Any work on the curtain airbag system or removal and installation of the airbag components for other repairs (such as removal of the roof lin- ing) should only be performed by a specialised workshop. Otherwise, faults may occur during the airbag system operation.

  • Page 46: Deactivating Airbags

    Airbag system Deactivating airbags Front passenger airbag deactivation If you fit a rear-facing child seat to the front passenger seat, the front passenger airbag must be de-activated. Fig. 28 Warning lamp for deactivated passenger airbag in centre console When the passenger airbag is deactivated, only the front airbag is deactivated.
  • Page 47 ● As soon as the child seat is no longer needed on the front passenger seat, enable the front passenger airbag again.

  • Page 48: Child Safety

    Depending on their age, height and weight, children trav- As the driver, you are responsible for any children you transport in elling on the rear seat must use a child seat or a seat belt. It is advisable your vehicle.
  • Page 49 However, if it is nec- ● Do not allow the seat belt to become twisted or jammed, or to rub on essary, in exceptional cases, to transport a child in the front passenger any sharp edges.

  • Page 50: Child Seats

    (the letter E in a circle with the test num- Group 0+: For babies from about 18 months old and 13 kg in weight the ber below it).
  • Page 51 Children over 7 years of age weighing between 22 and 36 kg but less than Read and always observe information and warnings concerning the use 1.5 metres tall are best protected by seat cushions with head restraints to- of child seats ⇒ ...
  • Page 52 ● The shoulder part of the seat belt must lie approximately on the cen- tre of the shoulder, never across the neck or the arm. The seat belt must lie close to the upper part of the body. The lap belt part must lie across the pelvis, not across the stomach, and always fit closely.

  • Page 53: Securing Child Seats

    You can secure a child seat to the rear seat or front passenger seat in the senger airbag ⇒  p age 44, Deactivating airbags must always be disabled following ways: and the seat adjusted to its highest position, where possible.
  • Page 54 – Slide the child seat anchorages along the plastic guides until secured in the vehicle's ISOFIX rings (when correctly closed, you will hear a “click”). The seat should also have a visual indicator ⇒  f ig. to confirm it is correctly secured –...
  • Page 55 WARNING An undue installation of the safety seat will increase the risk of injury in the event of a crash. ● Never tie the retainer strap to a hook in the luggage compartment.
  • Page 56 – Pull out the fastening belt of the child restraint seat according to the manufacturer's instructions. – Lead the Top Tether fastening belt under the rear seat head re- ⇒  f ig. 35 straint (lift the head restraint where necessary).
  • Page 57 Child safety Safety First Operating Instructions Practical Tips Technical Specifications...
  • Page 58 Cockpit Fig. 36 Some of the equipment listed in this section is only fitted on certain models or are optional extras.

  • Page 59: Operating Instructions

    ......Thumbwheel for seat heating ......
  • Page 60 Cockpit Steering wheel with: Note – Horn ● Separate Instruction Manual is enclosed if the vehicle is equipped with – Driver airbag ......... . . a factory-fitted radio or navigation system.

  • Page 61: Instruments

    Cockpit Instruments Instrument panel overview The instrument panel is the driver's information centre. Fig. 37 Overview of instrument panel Coolant temperature gauge Adjuster buttons for ....... . Rev counter incorporating digital clock and date 61, 61 –...

  • Page 62: Coolant Temperature Gauge

    Cockpit CHECK button temperatures. This is no cause for concern, provided the warning lamp  ..........does not light up in the instrument panel.

  • Page 63: Digital Clock And Date

    Cockpit Rev counter Digital clock and date The rev counter indicates the number of engine revolutions Your vehicle is equipped with a quartz clock. per minute. Fig. 40 Detailed view of the instrument panel: Fig. 39 Detailed view of Digital clock the instrument panel: Rev counter The time and date are set using the...

  • Page 64: Instrument Lighting

    Cockpit Instrument lighting Setting the date – Keep pressing the button until the date display (day) MODE The brightness of the instrument lighting can be adjusted as flashes. required. – Use the buttons to set the day. – Keep pressing the button until the month display flashes.

  • Page 65: Speedometer (Incorporating Odometer Display)

    Cockpit Speedometer with odometer Electronic immobiliser The vehicle key data is consulted when the ignition is switched on. The speedometer indicates the speed of the vehicle and the If an uncoded key is used, the message SAFE will appear in the trip recorder distance travelled.
  • Page 66 Cockpit CHECK button formation can be called up again by briefly pressing the button. For CHECK example: Switch off engine, check oil level The message will disappear from the display after about 5 seconds. Setting the speed warning button to set speed limit warning 1 ⇒  p age 83, You can press the CHECK Setting speed limit warning 1 while the vehicle is moving.

  • Page 67: Warning And Indicator Lamps

    ⇒  p age 67 Anti-lock brake system (ABS)  General description ⇒  p age 68 Seat belt warning The warning and indicator lamps indicate a number of dif-  ferent functions and possible faults. ⇒  p age 68 Left turn signals ...
  • Page 68 Cockpit Exhaust emission control system  Tyre pressure warning lamp*  The tyre pressure should be corrected as soon as possible if If the warning lamp lights up continuously you should take your vehicle to a it is too low. specialised workshop as soon as possible in order to have the fault re- paired.

  • Page 69: Trailer Turn Signals

    Cockpit The yellow warning  lamp remains on if the system is faulty or if Where a turn signal bulb does not work, either on the trailer or on the tow- ing vehicle, the turn signal bulb will not flash. the pressure is too low in at least one tyre.
  • Page 70 ESP. signal and the warning light will flash. In this case the ESP can be reactivated by switching the ignition off and  For further information on the seat belts, see ⇒  p age 23. ...

  • Page 71: Glow Plug System

    Cockpit For further information on the main beam headlights, see ⇒  p age 122. then on again. After this the warning lamp should go out to show that the  system is fully functional. The warning lamp will light up when the ignition is switched on if the bat- tery has been disconnected and then reconnected.

  • Page 72: Brake System

    Cockpit Note WARNING ● If the glow plug indicator lamp should start flashing while the vehicle is ● Before opening the bonnet and checking the brake fluid level, ob- moving, this indicates a fault in the engine management system. The en- serve the warning information in ⇒ ...

  • Page 73: Driver Information System

    Cockpit Driver information system ⇒  p age 72 CD player, radio and telephone display* ⇒  p age 72 Outside temperature display ⇒  p age 73 Gear indicator* General notes ⇒  p age 182 Selector lever positions for the 7-speed automatic gearbox* The driver information system in the instrument panel ®...

  • Page 74: Outside Temperature Display

    Cockpit CD, radio and telephone display* Outside temperature display Fig. 48 Display: addi- Fig. 49 Display: Outside tional radio information temperature display If the radio is switched on and no Priority 2 faults are indicated by the auto- The outside temperature is shown in the display when the ignition is switch- ⇒ ...
  • Page 75 Cockpit Note Note When the display shows route guidance instructions from the navigation ● The display may not recommend any gear-change while you are acceler- system, the outside temperature appears in the second line of the radio dis- ating. play. ...

  • Page 76: Digital Display With - Service Interval Display

    Cockpit Door and tailgate warning Service indicator This display reminds the driver when the next routine serv- ice is due. Fig. 51 Display: Door and tailgate warning Fig. 52 Detailed view of The door and tailgate warning symbol lights up if one or more of the doors, the instrument panel: or the bonnet or tailgate are not properly closed when the ignition is on.

  • Page 77: Auto-Check System

    Cockpit Service reminder CAUTION The instrument panel controls the distance travelled every day. It calculates The system cannot calculate the figures for the service interval display if the the average of these distances travelled and activates the service reminder battery is disconnected from the vehicle, so no service reminder can be dis- sufficiently in advance.
  • Page 78 Cockpit The red symbol indicates danger, whereas the yellow one represents a The message will disappear from the display after about 5 seconds. If re- warning. Additional messages for the driver may be shown with the red or quired, the message can be called up again by briefly pressing the CHECK yellow symbols.
  • Page 79 Cockpit Red symbols A red symbol is accompanied by three warning chimes. The symbols will keep flashing until the faults are corrected. If several Priority 1 faults are de- A red symbol warns of a danger. tected at the same time, the symbols are displayed one after the other for about 2 seconds.
  • Page 80 Cockpit – Obtain professional assistance if necessary. WARNING If the coolant level is correct, the overheating may be caused by a malfunc- ● Before opening the bonnet and checking the brake fluid level, ob- tion of the radiator fan. serve the warning information in ⇒  p age 221, Work in the engine com- partment.
  • Page 81 Cockpit Engine oil level correct ⇒  p age 80 Engine speed governing  If the  symbol flashes and the engine oil level is correct, obtain profes- sional assistance. Do not drive on! Do not continue to run the engine, even ⇒ ...
  • Page 82 Cockpit Checking the engine oil level  Yellow symbols are accompanied by one warning buzzer. The function indi- cated should be checked as soon as possible. If several Priority 2 faults are detected at the same time, the symbols are displayed one after the other for If the ...
  • Page 83 Cockpit Photosensor/rain sensor faulty  Adaptive headlights* faulty   Automatic headlights / automatic wipers faulty  Adaptive headlights faulty If the  symbol lights up, this means that the photosensor/rain sensor is This symbol  indicates that the adaptive headlight system is faulty. Take not working.

  • Page 84: Speed Warning

    Cockpit Bulb monitor  WARNING The bulb monitor checks whether the lights on the vehicle ● Bulbs are highly sensitive to pressure. The glass can break when you are working. touch the bulb, causing injury. ● The high voltage element of gas discharge bulbs* (xenon light) must If a defective bulb is detected, or if one of the lights has failed for any rea- be handled correctly.
  • Page 85 Cockpit exceeded by about 10 km/h. A warning symbol will also appear in the dis- Note ⇒  f ig. play Please bear in mind that, even with the speed warning function, it is still im- The speed warning function has two different warning speeds, which oper- portant to keep a eye on the vehicle's speed with the speedometer and to ate independently and serve slightly different purposes: observe the legal speed limits.
  • Page 86 Cockpit – Press the CHECK button for at least two seconds. – Press the CHECK button for at least two seconds. The display will show the speed limit which is currently set or, if no speed The speed warning symbol  lights up briefly in the display when the but- limit has been set, the crossed out warning symbol for speed ton is released to confirm that the selected speed has been stored.

  • Page 87: Onboard Computer

    Cockpit Onboard computer Single-journey memory (onboard computer 1) The single-journey memory processes the information on a journey from the time the ignition is switched on until it is switched off. If the journey is re- Introduction sumed within two hours after the ignition is switched off, the new figures are automatically included in the calculation.
  • Page 88 Cockpit Operation Driving time warning After 2 hours of continuous driving, the display automatically switches over The onboard computer is controlled by means of two to the driving time display of 2:00 . At the same time the driving time display switches on the windscreen wiper lever.
  • Page 89 Cockpit ● Journey duration ● Distance covered ● Average fuel consumption ● Average speed The onboard computer can only be operated when the ignition is switched on. When the ignition is switched on, the display shows the function that was last selected. As well as the figures from the onboard computer (1 or 2), the display can also show information from the navigation system*.

  • Page 90: Menu Display

    Cockpit Menu display Some of your vehicle's functions can be adjusted, activated and controlled by menus. With the aid of the menus you can then also select the informa- tion you wish to see displayed on the DIS display. This is only possible when the ignition is on.

  • Page 91: Tyre Pressure Monitoring

    Cockpit Controlling the menu Use the rocker switch to select the menus and adjust various values. The se- lected values are highlighted on a red background. The menu display is called up via the button and the Reset By pressing the button, you can confirm the option you have selected Reset rocker switch on the windscreen wiper lever.
  • Page 92 Cockpit Tyre pressure monitoring display  driven and the tyre pressure will rise accordingly. Therefore, you should only adjust the tyre pressures when they are cold (i.e. approximately at ambient The tyre pressure should be corrected as soon as possible if temperature).

  • Page 93: Steering Wheel Controls

    Steering wheel controls Steering wheel controls Multifunction steering wheel* Introduction You can use the multifunction steering wheel to quickly and easily operate selected functions of the radio, CD, and tele- phone*. Fig. 65 Driver informa- tion system The functions are operated by pressing or scrolling the controls ⇒ ...
  • Page 94 Steering wheel controls Steering wheel audio version controls (Mode) (PTT) Press Press Press once: starts Long press: Station search. Station search. Radio the search. block the steering Increase frequen- Decrease fre- Volume up Volume down MUTE mode Press twice: can- wheel controls quency cels the search...
  • Page 95 Steering wheel controls Steering wheel Audio + Telephone version controls (Mode) (PTT) Press Press Press once: starts Station search. Station search. the search. Radio mode Increase frequen- Decrease fre- Volume up Volume down MUTE Press twice: can- quency cels the search Change to CD mode: next CD mode: previ-...
  • Page 96 Steering wheel controls Steering wheel controls, Navigation System* version (Mode) (PTT) Press Press Press once: starts Repetition of Station search. Station search. the search. the last naviga- Radio mode Increase frequen- Decrease fre- Volume up Volume down Press twice: can- tion order (only quency cels the search...
  • Page 97 Steering wheel controls Steering wheel controls, Navigation System + Telephone* version (Mode) (PTT) Press Press Press once: starts Repetition of Station search. Station search. the search. the last naviga- Radio mode Increase frequen- Decrease fre- Volume up Volume down Press twice: can- tion order (only quency cels the search...

  • Page 98: Unlocking And Locking

    Unlocking and locking Unlocking and locking Remote control keys Set of keys Fig. 67 Remote control key: Release button The set of keys belonging to your vehicle consists of the following items: one remote control key. Fig. 66 Set of keys sup- one key without remote control.
  • Page 99 Unlocking and locking Indicator light on the remote control key 2 remote control keys In certain European markets, vehicles with alarm are equipped with 2 re- The condition of the battery in the remote control key is mote control keys. monitored by the indicator light.
  • Page 100 Note – Insert the new battery. Make sure that the “+” symbol on the ● The engine can only be started using an original SEAT key with the cor- battery is facing downwards. The correct polarity is indicated on rect code.

  • Page 101: Central Locking

    Unlocking and locking Central locking WARNING Do not leave anyone (especially children) in the vehicle if it is locked from Description the outside and the anti-theft security system is enabled, as the doors and windows cannot then be opened from the inside. Locked doors could The central locking system enables you to lock and unlock delay assistance in an emergency, potentially putting lives at risk.
  • Page 102 Unlocking and locking – To unlock the vehicle, turn the key in the driver door to position WARNING ⇒  f ig. Do not leave anyone (especially children) in the vehicle if it is locked from – Pull the handle to open the door. the outside and the anti-theft security system is enabled, as the doors and windows cannot then be opened from the inside.
  • Page 103 Unlocking and locking Central locking switch ing locked out of the vehicle. The door has to be locked separately after it has been closed. The central locking system can be enabled from inside the ● In the event of an accident in which the airbags inflate, doors locked vehicle using the central locking switch on the driver door.
  • Page 104 Unlocking and locking Unlocking all the doors, the tailgate and the tank flap simultaneously. – Turn the key twice within five seconds, or press the unlock but- ton on the remote control twice within five seconds. The security system and the anti-theft alarm* are immediately disabled if you unlock only the driver door, without unlocking the other doors ⇒ ...

  • Page 105: Tailgate

    Unlocking and locking Tailgate Opening the tailgate – Press the centre button on the remote control key or press  ⇒  f ig. the switch* on the driver door 74. The tailgate will  Tailgate: opening and closing open. – Then lift up the tailgate. If your vehicle is equipped accordingly, the tailgate will open automatically*.

  • Page 106: Childproof Lock

    Unlocking and locking Childproof lock Remote control key Childproof locks on rear doors Description The childproof lock prevents the rear doors from being The remote control key will lock and unlock the vehicle with- opened from the inside. out having to insert the key in the lock. The following functions are available: ●...
  • Page 107 Moreover, apart from unlocking the vehicle, the seat* and mirror* memory programmed in the key is activated. The driver seat and exterior mirrors will be automatically adjusted to the positions stored in the memory.

  • Page 108: Anti-Theft Alarm System

    Unlocking and locking Anti-theft alarm system* Note ● The remote control should only be used when the doors and the tailgate are closed. Description ● The remote control should not be used when the vehicle is out of sight. The system triggers an alarm if anyone attempts to break in- ●...
  • Page 109 ● Tilt angle (tow-away protection) nected while the alarm system is enabled.  ● Ignition ● Radio (only with a factory-fitted SEAT radio) ● Interior ⇒  p age 107 Interior monitoring*  If any of these areas are entered, the alarm will be triggered.

  • Page 110: Electric Windows

    Unlocking and locking You should disable the interior monitoring if there is a possibility WARNING that the alarm could be triggered, e.g. by a pet or by an object moving inside the vehicle ⇒  . The tow-away protection feature, Do not leave anyone (especially children) in the vehicle if it is locked from which is integrated into the alarm system, should be disabled if the outside and the anti-theft security system is enabled, as the doors and windows cannot then be opened from the inside.
  • Page 111 Unlocking and locking Switches for rear electric windows Closing the windows Switch for the rear left door window – Pull the switch as far as the first stop and hold it until the win- dow has moved to the desired position. Switch for the rear right door window Safety switch –...
  • Page 112 Unlocking and locking Switches on the front passenger's door and rear doors Note Each of these doors has a switch for its own window. The windows will work for about ten minutes after the ignition has been switched off. The electric window switches are only disabled when one of the front doors is opened.

  • Page 113: Sliding/Tilting Sunroof

    Unlocking and locking The sunroof will work for about ten minutes after the ignition has been WARNING switched off. However, it is immediately disabled when one of the front doors is opened.  ● Be careful when closing the windows to ensure nobody is hurt. ●...
  • Page 114 Unlocking and locking Tilting open – Pull the switch briefly to lower the sunroof automatically to the fully closed position. If required, the sunroof can be stopped in – Turn the control to position any position by briefly pulling the control again ⇒  . –...
  • Page 115 Unlocking and locking Emergency electrical activation Closing the sunroof manually In an emergency it is possible to close the sunroof electroni- The sunroof can be closed by hand if the electrical system cally. should fail to operate. The sliding sunroof mechanism is equipped with a safety cut-out. If the roof should fail to close normally, it can be closed with the emergency function.
  • Page 116 Unlocking and locking – Carefully insert the flat end of a screwdriver at the rear of the ⇒  f ig. glass cover on the interior light – Carefully lever off the glass cover. – Take the crank handle from its mounting on the inside of the fuse box cover ⇒ ...

  • Page 117: Lights And Visibility

    Lights and visibility Lights and visibility – Press the main beam lever forward ⇒  p age 122. Lights Switching off the lights Lights: switching on and off  – Turn the light switch to position O. Daytime running lights: In vehicles for countries where daytime running lights are obligatory and in all vehicles with AFS headlights, daytime run- ning lights are turned on or off with the ignition.
  • Page 118 Lights and visibility Automatic headlight switch* (sensor-controlled) tion during the day (e.g. when driving through a tunnel), but do not disable them again, only the dipped beam headlights will come on the next time If you set the light switch to “AUTO”, the dipped headlights the lights are automatically switched on.
  • Page 119 Lights and visibility ● The warning symbol  will appear on the instrument panel if a malfunc- The symbols  and  next to the switch will light up when the rear fog light tion occurs ⇒  p age 81. is switched on.
  • Page 120 Lights and visibility Activating the function This time interval is factory-set, but you can have it changed by a qualified workshop to suit your own requirements (max. setting is 60 seconds). ⇒  f ig. 86 – Briefly press the knob to release it from its set posi- tion.
  • Page 121 Lights and visibility Instrument lighting Headlight range control  The brightness of the instrument lighting, displays and cen- When the dipped beam headlights are switched on, the tre console lighting can be varied as required. range of the headlights can be adjusted to suit the load of the vehicle.
  • Page 122 Lights and visibility Daytime running lights* All seats occupied, luggage compartment loaded Driver only, luggage compartment loaded The daytime running lights turn on automatically when the ignition is switched on. CAUTION Always adjust the headlights to avoid dazzling oncoming traffic. Make sure you lower the headlights when the vehicle is more heavily laden.
  • Page 123 Lights and visibility – Press the knob in again to prevent the setting from being nering light is controlled automatically depending on the speed and the steering wheel angle. changed unintentionally. The dipped beam headlights are regulated automatically when you drive This button activates or deactivates the daytime running lights function.
  • Page 124 Lights and visibility Turn signal   and main beam headlight lever  All four turn signals flash simultaneously when the hazard warning lights are switched on. The turn signal indicators   and the hazard warning The turn signal and main beam headlight lever also oper- light indicator ...

  • Page 125: Interior Lights

    Lights and visibility Main beam headlights  CAUTION – Press the lever forward to switch on the main beams. Never use the main beam headlights or the headlight flasher if this would dazzle oncoming traffic.  – Pull the lever back towards you to switch the main beam head- lights off again.
  • Page 126 Lights and visibility Ambient lighting* Interior light switched on – Move switch to position I. The ambient lighting illuminates a number of important controls. Interior light switched off – Move switch to position O. Front reading lights  – Press one of the switches to turn the left and right reading lights on and off.

  • Page 127: Luggage Compartment Light

    Lights and visibility Rear reading lights Luggage compartment light Fig. 96 Detailed view of the top of the luggage Fig. 95 Detail of headlin- compartment: luggage er: rear reading lights compartment lighting The reading lights are switched on and off with the switches The light is in the upper part of the luggage compartment.

  • Page 128: Visibility

    Lights and visibility Visibility The exterior mirror heating is not activated in temperatures above approxi- mately 20 °C. Heated rear window  For the sake of the environment Switch off the heated rear window as soon as the rear window has demis- The rear window heating clears the rear window of conden- ted.

  • Page 129: Sun Blind

    Lights and visibility light switches itself off when the cover is closed and when the sun visor is pushed back up.  Sun blind* Sun blinds are provided for the rear window and the rear side windows. Fig. 100 Switch for elec- tric sun blind on rear win- Sun blind (rear side windows) –...

  • Page 130: Windscreen Wipers

    Lights and visibility Short wipe Note – Move the lever down to position to give the windscreen a ● An overload cut-out may be triggered if the sun blind for the rear window short wipe. is operated repeatedly. There will then be a short delay before the blind can be operated again.
  • Page 131 Lights and visibility If you stop briefly, e.g. at traffic lights, the wiper speed will automatically be WARNING reduced. The rain sensor* will automatically be set to the intermittent wipe function. ● For correct visibility and safe driving, the wiper must be in perfect condition ⇒ ...

  • Page 132: Rear View Mirrors

    Lights and visibility Headlight washer system Rear view mirrors Interior mirror with manual anti-dazzle setting Normal setting – Point the lever at the bottom of the mirror forwards. Anti-dazzle setting for the interior mirror – Point the lever at the bottom of the mirror to the rear. ...

  • Page 133: Exterior Mirrors

    Lights and visibility Switching off the anti-dazzle function Note ⇒  f ig. – Press button 103. Indicator lamp goes off. ● The interior mirror automatic anti-dazzle function* will only work proper- ly if the sun blind* for the rear window is retracted and if there are no other Switching on the anti-dazzle function objects preventing light from reaching the mirror.
  • Page 134  In vehicles with memory function for the driver seat, the setting of the exte- rior mirrors is automatically stored together with the seat position ⇒  p age 137.

  • Page 135: Manual Adjustment Of The Front Seats

    WARNING The driver seat must only be moved forwards and backwards when the vehicle is at a standstill. Failure to do so could result in an accident.  Adjusting the seat height* Raising the seat ⇒ ...
  • Page 136 Seats and storage compartments WARNING ● The height of the driver seat must not be adjusted while driving. Fail- ure to do so could result in an accident. ● Be careful when adjusting the seat height. Injuries can be caused if the seat height is adjusted without due care and attention.

  • Page 137: Electric Adjustment Of Front Seats

    Fig. 107 Front seat: Seat adjustment switches The adjustment switches for the seat and backrest correspond with the layout, design and operation of the seat. The seats can be ad- justed merely by pressing the corresponding switch in the required direction.

  • Page 138: Lumbar Support

     ● The electrical seat adjustment also works when the ignition is off or when the key is not in the ignition. To avoid accidental injuries, never leave children unattended in the vehicle.

  • Page 139: Driver Seat Memory

    (only STOP visible when the lights are switched on). The stored settings will all remain in the memory. However, the seat and the exterior mirrors can now only be adjusted using the conventional electrical adjustment. Use of the button is recommended to disable the memory STOP ...
  • Page 140 At the same time, press one MEMO The seat adjustment will have to be called up using the memory buttons if of the memory buttons for at least a second. the driver door is not opened within 10 minutes after unlocking the vehicle with the remote control.

  • Page 141: Head Restraints

    In combination with properly worn seat belts, the head re- straints offer effective protection, provided they are properly Assigning the remote control key to a memory button adjusted to suit the height of the occupant.
  • Page 142 The height of the head restraints is adjustable. They should be set to suit – Pull the head restraint up as far as it will go. the height of the occupant. In combination with the seat belts, the head re- straints offer effective protection, provided they are properly adjusted.

  • Page 143: Armrests

    Seats and storage compartments Rear seat central head restraint When the rear seats are not occupied the head restraints should be moved to the lowest position so that they do not obstruct the driver's field of vi- sion.  Armrests The armrest can be adjusted to several positions and incor- porates a storage compartment.

  • Page 144: Luggage Compartment

    Seats and storage compartments ⇒  f ig. Opening the storage compartment – Position heavy items as far forward as possible 115. ⇒  f ig. – Press the release lever 114. WARNING Please note that the armrest can restrict the driver's movements when it is lowered.
  • Page 145 CAUTION When returning the backrest to an upright position, make sure that the seat belts for the outer rear seats are in their guides, so that they cannot be caught up and damaged in the catches for the backrest.
  • Page 146 – Close the inside cover of the load-through hatch from the pas- senger compartment. Fig. 118 Securing the WARNING ski bag on the centre seat belt buckle on the The ski bag must be secured in place with the fastening belt after it has rear seat bench been loaded. ...

  • Page 147: Roof Rack

    We recommend using the ba- points for basic support sic support units from the range of genuine SEAT accessories. units ● These basic supports are the base of a complete roof rack system. For...

  • Page 148: Drink Holder

    Seats and storage compartments Drink holder If less resistant systems are used, the roof rack must not be loaded to the maximum weight permitted. If less resistant systems are used, these must only be loaded to the maximum weight permitted indicated in the assembly instructions.

  • Page 149: Ashtray*, Cigarette Lighter* And Electric Sockets

    Seats and storage compartments Drink holder in the rear armrest* WARNING ● Do not put any hot drinks in the drink holder while the vehicle is mov- ing. You can be scalded if the hot liquid is spilt. ● Do not use hard china cups or glasses. These could cause injury in the event of an accident.
  • Page 150 Seats and storage compartments Removing the ashtray Removing the ashtray ⇒  f ig. 122 ⇒  f ig. 123 – Take hold of the sides of the ashtray and lift it – Take hold of the lid and lift out the ashtray. out.
  • Page 151 Seats and storage compartments Using the cigarette lighter Note – Press in the cigarette lighter button. The use of electrical appliances with the engine switched off will cause a battery discharge.  – Wait for the lighter to pop out slightly. –...
  • Page 152 Seats and storage compartments The 230 Volt socket can only be used when the engine is running WARNING ⇒  . The electrical sockets and, therefore, any appliances connected to them In vehicles with folding cover: will only work when the ignition is switched on. –...
  • Page 153 Seats and storage compartments perature is very high, even if the power consumption is normal. The inverter WARNING will switch on again automatically after it has cooled down. Appliances con- nected to the socket, and which have been left switched on, will automati- ●...

  • Page 154: Compartments

    Seats and storage compartments Compartments Glove compartment The lockable glove compartment is equipped with a light. Overview There are several storage compartments at various points in the vehicle. Your vehicle has the following storage compartments: First-aid kit* Emergency triangle* ⇒  p age 152 Glove compartment Storage compartment in the centre console On-board documentation compartment*...
  • Page 155 Seats and storage compartments Compartments in the door trim Coat hooks Storage compartments are provided in the door trims. There is a coat hook above each of the rear doors. Fig. 128 Door trim with Fig. 129 Area above the storage compartment rear doors: Coat hooks WARNING...
  • Page 156 Seats and storage compartments Compartments in the front seats* There is a storage compartment with a lid at the front of each front seat. Opening – Pull the handle to open the compartment. Closing – Close the lid and push it in until it engages.

  • Page 157: Air Conditioning

    Air conditioning Air conditioning 2C-Climatronic The humidity of the air is automatically reduced when the system cools the interior of the vehicle. This helps to prevent condensation on the windows. If the humidity and temperature outside the vehicle are high, condensation Description can drip off the evaporator in the air cooling system and form a pool under- neath the vehicle.
  • Page 158 Air conditioning CAUTION ● If you suspect that the air conditioner system is damaged, switch over to ECON mode to prevent further damage and have the system checked by a qualified workshop. ● Repairs to the air conditioner require specialist knowledge and special tools.
  • Page 159 Air conditioning Controls This overview will help you become quickly familiar with the controls for the air conditioner. Fig. 130 Air conditioner controls The left-hand display shows the temperature selected for the left-hand side Button(s) Meaning and the right-hand display the temperature for the right-hand side. ...
  • Page 160 Air conditioning output and the temperature is not regulated automatically. The temperature Button(s) Meaning is not regulated.   (in the centre) Adjusts blower speed Note  Air to the windows By keeping the button on the driver side pressed for several seconds, AUTO the temperature of the passenger side can be set to the temperature of the ...
  • Page 161 Air conditioning Defrosting ● When driving through a tunnel or in traffic congestions, to prevent ex-  haust gas entering the interior of the vehicle. The windscreen and side windows are defrosted or demisted as quickly as possible. WARNING ⇒  f ig. 130 Do not drive for too long with the air recirculation mode enabled because, –...
  • Page 162 Air conditioning – Press the button or AUTO Note – Press button If the diode on the ECON button continues to light up when the ECON mode  has been switched off (i.e. the air conditioner has been switched on) this is due to a defect in one of the air conditioner components.
  • Page 163 Air conditioning Switching the temperature display from °C to °F and vice – Press the button or AUTO versa – Press one of the air distribution buttons    The temperature display can be switched from °C (degrees The air conditioner also starts to operate if one of the blower or temperature Celsius) to °F (degrees Fahrenheit) and vice versa.

  • Page 164: Air Outlets

    Air conditioning Air outlets Fig. 132 Dash panel: Location of air outlets ⇒  f ig. 132 The air outlets can be operated as follows: Note The cool air provided by the air conditioner is mainly issued from outlets Outlets . To ensure adequate cooling, outlets should therefore –...
  • Page 165 Air conditioning Air directed to windows  For the sake of the environment This setting directs all the air to outlets 1 and 2. Unlike in setting , the  By saving fuel you also reduce the amount of pollutants emitted from your volume of air delivery remains the same.

  • Page 166: Seat Heating

    The heating is switched off when the thumbwheel is set to 0. The tempera- ture settings range from 1 to 6. CAUTION To avoid damaging the heating elements of the seat heating, please do not kneel on the seat or apply sharp pressure to a single point. ...

  • Page 167: Driving

    Driving Driving Steering WARNING ● Never adjust the position of the steering wheel when the vehicle is Adjusting the steering wheel position moving, as this could cause an accident. ● For safety reasons, the lever must always be securely engaged when The height and reach of the steering wheel can be freely ad- the vehicle is moving, so that the position of the steering wheel cannot justed to suit the driver...

  • Page 168: Ignition Lock

    Driving The Electronic Stability Programme (ESP) contains the electronic differential WARNING lock (EDL) and the traction control system (TCS). The ESP function works to- gether with the ABS. If a fault in the ABS occurs, both warning lamps light ● The Electronic Stability Programme (ESP) cannot defy the laws of up, but if the ESP fails, only the ESP warning lamp lights up.

  • Page 169: Starting And Stopping The Engine

    Starting the engine After the engine has started, the ignition key returns to position by itself. The engine can only be started with an original SEAT key. The ignition key has to be turned back to position before re-starting the engine.
  • Page 170 Driving Vehicles with a petrol engine: If the engine fails to start straight away, stop after 10 seconds and try again after about half a minute. – Use the foot brake. Glow plug system* – Manual gearbox: Push the clutch pedal all the way down. To assist starting at low temperatures, diesel engines are equipped with a glow plug preheating system.

  • Page 171: Handbrake

    Driving Stopping the engine Handbrake ⇒  f ig. – Turn the ignition key to position 137. Handbrake The handbrake should be applied firmly to prevent the vehi- WARNING cle from accidentally rolling away. ● Never switch the engine off until the vehicle is stationary. ●...

  • Page 172: Parking Aid Acoustic System

    The following points will ensure there is no risk of the vehi- The SEAT Parking System gives an acoustic warning if there are any obsta- cle rolling away accidentally after it is parked: cles behind your vehicle ⇒ ...
  • Page 173 SEAT Parking System Plus* The volume of the warning beeps will be gradually reduced after about 4 SEAT Parking System Plus is an acoustic parking aid. seconds if the vehicle remains at a constant distance from a detected obsta- cle (it does not affect the permanent acoustic signal).
  • Page 174 . This function may not be guaran- – Switch off the ignition or teed on towing brackets that are not factory fitted. This results in the follow- ing restrictions: – Disengage the reverse gear. SEAT Parking System* There is no distance warning. ...

  • Page 175: Cruise Speed* (Cruise Control System)

    Driving SEAT Parking System Plus* WARNING There is no rear distance warning. The system will still give a warning when obstacles are detected while driving forward. For safety reasons, the cruise control system should not be used in dense ...
  • Page 176 Driving Setting the speed Adjusting the stored speed The desired cruising speed has to be stored in the memory. The desired cruising speed can be adjusted up or down as required. Acceleration ⇒  f ig. 140 – Move the lever up towards –...
  • Page 177 Driving Deactivating the cruise control temporarily WARNING Retrieve the programmed speed only if this is not excessive for the cur- rent traffic conditions. Failure to do so could result in an accident.  Deactivating the cruise control While driving ⇒  f ig. 140 –...

  • Page 178: Manual Gearbox

    Driving Manual gearbox WARNING ● When the engine is running, the vehicle will start to move as soon as Driving with a manual gearbox a gear is engaged and the clutch released. ● Never select the reverse gear when the vehicle is in motion. Risk of accident.

  • Page 179: Driving Instructions

    Driving Driving instructions The gearbox selects the gear ratio and shifts up or down automatically ac- cording to the gear change programmes stored in the control unit ⇒  p age 181. The gears are changed automatically. If desired, you can also select the gears manually (tiptronic mode) ⇒ ...
  • Page 180 Driving Selector lever positions – To prevent the vehicle from rolling away, apply the parking brake before moving off on steep gradients ⇒  . This section covers all the selector lever positions. Parking the vehicle – Press and hold the brake pedal ⇒  . –...
  • Page 181 Driving To move the selector lever to position R, press in the interlock button and at WARNING (Continued) the same time press the brake pedal. Depending on the model, one or two to “creep”. The throttle must on no account be opened inadvertently (for reverse lights will come on in selector lever position R (when ignition is instance by hand from the engine compartment) when a gear is engaged switched on).
  • Page 182 Driving Selector lever lock The selector lever lock only works if the vehicle is stationary or driving at speeds up to 5 km/h. At higher speeds the selector lever lock in the N posi- The selector lever lock prevents gears from being engaged tion is disengaged automatically.
  • Page 183 Driving Vehicles with tiptronic gearbox Vehicles with multitronic® gearbox: the gearbox continuously adapts the gear ratios to gradients. If the brake pedal is pressed on a downhill gradient When the accelerator pedal is pressed right down past the point of resist- the gearbox automatically shifts to a lower gear ratio.
  • Page 184 Driving Manual gear selection (tiptronic mode) Switching over to the manual programme – Move the selector lever from the position D to the right-hand With the manual shift programme (tiptronic) the driver can side. As soon as the selector lever has entered the tiptronic rail, manually select pre-programmed gears.
  • Page 185 Driving Back-up programme Steering wheel with paddle levers A back-up system is in place if a fault should occur in the The paddle levers on the steering wheel enable the driver to control system. manually select pre-programmed ratios or gears. The automatic gearbox switches to the back-up programme if a fault should occur in the control system.

  • Page 186: Practical Tips

    Intelligent technology Practical Tips Intelligent technology Electronic Stability Programme (ESP) The anti-lock brake system (ABS), the electronic differential lock (EDL) and the traction control system (TCS) are all integrated into the Electronic Stabil- ity Programme. General notes How it works The Electronic Stability Programme increases the vehicle's The ESP control unit processes data from the three integrated systems.
  • Page 187 Intelligent technology If required, the ESP can also be enabled and disabled manually by briefly How the ABS works ⇒  f ig. pressing the button 149. The ESP warning lamp lights up when The system runs an automatic self-check when the vehicle reaches a road the system is switched off, see ⇒ ...
  • Page 188 Intelligent technology Brake assist system How it works The EDL works automatically, without the driver's involvement. With the aid The brake assist system helps the driver to achieve optimum of the ABS sensors, the system monitors the rotational speed of the drive braking effect.
  • Page 189 Intelligent technology Note If the ABS warning lamp lights up, this can also mean there is a fault in the EDL. Take the vehicle to a specialised workshop as soon as possible.  Traction control system (TCS) The traction control system prevents the drive wheels from spinning when the vehicle is accelerating.

  • Page 190: Brakes

    Intelligent technology Brakes If the brakes are not used frequently, or if rust has formed on the disks, it is advisable to clean off the pads and disks by braking firmly a few times at a moderately high speed ⇒  General notes Faults in the brake system If the brake pedal travel should ever increase suddenly, this may mean that...

  • Page 191: Power Steering

    Intelligent technology Power steering does not work if the engine is off. In this case the steering Note wheel requires much more force to turn. If you wish to equip the vehicle with accessories such as a front spoiler or If the steering is held at its turning limit when the vehicle is stationary, this wheel covers, it is important that the flow of air to the front wheels is not will place an excessive load on the power steering system.
  • Page 192 Intelligent technology If a fault should occur in the servotronic system, the power steering will still operate. The degree of power assistance will, however, no longer adapt to different speeds. If the electronic regulating system is not working properly, this is most noticeable when turning the steering wheel at low speeds (for instance when parking), as more effort will be required than usual.

  • Page 193: Driving And The Environment

    Driving and the environment Driving and the environment Running-in Braking capacity and braking distance The braking capacity and braking distance are influenced by Running in a new engine driving situations and road conditions. The engine needs to be run in over the first 1500 km. The efficiency of the brakes depends directly on the brake pad wear.

  • Page 194: Exhaust Gas Purification System

    Driving and the environment – For engine oil changes, do not replenish with too much engine WARNING (Continued) oil ⇒  p age 224. ● On steep slopes, if brakes are excessively used, they will overheat. Before driving down a long steep slope, it is advisable to reduce speed –...

  • Page 195: Economical And Environmentally Friendly Driving

    Driving and the environment Diesel engine particulate filter* Economical and environmentally friendly driving The diesel engine particulate filter eliminates soot produced by burning diesel. Economical and environmentally friendly driving The diesel engine particulate filter eliminates most of the soot from the ex- haust gas system.
  • Page 196 A badly serviced engine can consume up to 10% more fuel than necessary. of components that use a lot of electricity are: the fan at high speeds, the rear window heating or the seat heaters*. Avoid short journeys To reduce the consumption and emission of polluting gases, the engine and...

  • Page 197: Environmental Friendliness

    ● Nearly all materials used can be recycled SEAT importers and distributors will gladly provide information about the ● Similar types of plastics grouped together for easy recycling technical preparations that you vehicle requires and also about necessary ●...

  • Page 198: Trailer Towing

    Trailer towing Trailer towing Trailer towing Notes on towing There are a number of points which need to be checked be- Technical requirements fore towing a trailer or caravan. The towing bracket must meet certain technical require- – Observe the maximum permitted trailer weights ⇒  p age 290. ments.
  • Page 199 Trailer towing Notes on towing Where possible, operate the trailer with the maximum permitted drawbar load on the ball joint of the towing bracket, but do not exceed the specified Towing a trailer involves additional attention by the driver. limit. Tyre pressure Weight distribution Check the tyre pressures on your vehicle, and adjust for “full load”...
  • Page 200 Equipment and accessories mounted on the towing bracket Before mounting equipment and accessories (e.g. bicycle SEAT recommends that you only mount equipment (e.g. bicycle rack) on the rack) please observe the following notes. towing bracket which has been officially approved.. If you wish to attach other equipment please make sure that it has been approved by the manu- facturer for use on the towing bracket.

  • Page 201: Removable Towing Bracket

    To prevent damage to the ball joint from unsuitable equipment, we recommend that equipment for the towing bracket be purchased through Introduction your SEAT Dealer. Also see ⇒  p age 215. Special care is required when fitting and removing the tow- ing bracket.
  • Page 202 Trailer towing Fitting the ball joint (step 1) Fitting the ball joint (step 2) Fig. 152 Rear bumper: Fig. 153 Removable tow- Open the cover piece ing bracket: Ball joint ⇒  f ig. 152 – Remove the cover piece on the mounting fixture below the bumper as far as it will go.
  • Page 203 Trailer towing Fitting the ball joint (step 3) Make sure the ball joint is clean and undamaged – Check the locking pin , release pin , shaft section ⇒  f ig. 153 knob on the ball joint to make sure they are clean and undamaged.
  • Page 204 Trailer towing Fitting the ball joint (step 4) – Pull out the knob in direction , hold and turn in direction until the locking pin engages and the release pin moves out visibly ⇒  . Inserting the ball joint – With the spring mechanism in the ready position, insert the ball ⇒ ...
  • Page 205 Trailer towing Removing the ball joint – Check that the knob is directly against the ball joint, so that there is no gap between the knob and the ball joint -arrow-. – Check that the ball joint is locked and the key is removed so that the knob cannot be pulled out ⇒ ...
  • Page 206 Trailer towing – Take hold of the ball joint and pull out the knob in direction – Keep hold of the knob and turn it as far as it will go in direction – Release the knob. The spring mechanism will remain in the ready position ⇒ ...
  • Page 207 Trailer towing If a towing bracket is to be fitted after the vehicle is purchased, this must be WARNING completed according to the instructions of the towing bracket manufacturer. The towing brackets should be fitted at a specialised workshop. The attachment points for the towing bracket are on the lower part of the vehicle.

  • Page 208: Vehicle Maintenance And Cleaning

    Vehicle maintenance and cleaning Vehicle maintenance and cleaning General notes WARNING Regular washing and care help maintain the value of your ● Car care products can be toxic. Because of this, they must always be kept closed in their original container. Keep them out of the reach of chil- vehicle.

  • Page 209: Care Of The Vehicle Exterior

    Vehicle maintenance and cleaning Care of the vehicle exterior – Clean your vehicle from top to bottom with a soft sponge, a glove or a brush. Use very light pressure. Automatic car wash tunnel – Rinse the sponge or glove often with clean water. –...
  • Page 210 Vehicle maintenance and cleaning – After washing, avoid sudden and sharp braking. “Dry” the CAUTION brakes by braking several times ⇒  p age 191. ● Never remove dirt, mud or dust if the vehicle surface is dry. Never use a dry cloth or sponge for cleaning purposes.
  • Page 211 Vehicle maintenance and cleaning Polishing the paintwork Cleaning windows and exterior mirrors Polishing brings back gloss to the paintwork. Cleaning windows – Moisten the windows with commercially available, alcohol Polishing is only necessary if the paint has lost its shine, and the gloss can- based glass cleaner.
  • Page 212 Vehicle maintenance and cleaning Caring for rubber seals will also prevent premature ageing and leaks. The CAUTION doors will be easier to open. If rubber seals are well looked after, they will ● Never use warm or hot water to remove snow and ice from windows and not freeze so quickly in winter.

  • Page 213: Underbody Protection

    Vehicle maintenance and cleaning Use an industrial cleaner to remove brake dust. Any damage to the paint on WARNING steel wheel rims should be repaired before starting to rust. ● Never wash tyres with a cylindrical jet. Even at large spraying distan- ces and short cleaning times, visible and invisible damage can occur to WARNING the tyres.

  • Page 214: Vehicle Interior Maintenance

    Vehicle maintenance and cleaning Cleaning the engine compartment WARNING (Continued) ● Moisture, ice and salt on the brakes may affect braking efficiency. Take special care when cleaning the engine compartment. Risk of accident. Directly after washing, avoid sudden and sharp braking. ●...
  • Page 215 Cloth seat covers and fabric trim on the doors, headlining etc. can be etc. so a degree of care is required in everyday use and when looking after cleaned with a special interior cleaner or with dry foam and a soft brush.
  • Page 216 If large stains form on the belts, it will not retract correctly into the automat- ic belt retractor. WARNING ● Do not use chemical cleaning agents on the seat belts, as this can im- pair the strength of the webbing. Ensure that belts do not come into con- tact with corrosive fluids.

  • Page 217: Accessories, Parts Replacement And Modifications

    (e.g. cruise control system or electronically-con- ® ised Technical Service using Genuine SEAT Spare Parts.  trolled suspension) must be approved by SEAT and bear the e mark (the Eu- ropean Union's authorisation symbol). Safety First Operating Instructions Practical Tips...

  • Page 218: Mobile Phones And Two-Way Radios

    Accessories, parts replacement and modifications Athermic windscreen* WARNING Incorrectly performed modifications or other kind of work on your vehicle can lead to malfunctions and cause accidents.  Mobile phones and two-way radios First consult your Authorised Service Centre if you wish to use a mobile tele- phone or a two-way radio with a transmitting power output in excess of 10 watts.

  • Page 219: Checking And Refilling Levels

    Checking and refilling levels Checking and refilling levels Refuelling Closing the tank cap – Screw the tank cap clockwise into the filler opening until it you The tank flap is released manually. The tank holds approxi- hear it click into position. mately 70 litres.

  • Page 220: Petrol

    Checking and refilling levels take longer than normal (up to one minute) for the engine to start firing. WARNING This is due to the fact that the fuel system has to purge itself of air before starting. ● Fuel is highly flammable and can cause serious burns and other inju- ries.

  • Page 221: Diesel

    Checking and refilling levels Diesel CAUTION ● Petrol with standard EN 228 may be mixed with small quantities of etha- nol. However, bioethanol fuels available at commercial establishments with Diesel* reference E50 or E85, which contain a high percentage of ethanol, may not be used, as they will damage the fuel system.

  • Page 222: Bonnet

    Checking and refilling levels Winter driving Bonnet Diesel can thicken in winter. Releasing the bonnet Winter-grade diesel The bonnet is released from inside the vehicle. When using summer-grade diesel fuel, difficulties may be experienced at sub-zero temperatures because the fuel thickens due to wax separation. Therefore, winter-grade diesel fuel is available in some countries during the cold months.
  • Page 223 Checking and refilling levels Opening the bonnet Work in the engine compartment Extra caution is necessary when working on components in the engine compartment. Always be aware of the danger of injury and scalding as well as the risk of accident or even fire when working in the engine compartment (e.g.

  • Page 224: Engine Oil

    Checking and refilling levels Closing the bonnet WARNING (Continued) ● If any tests have to be performed with the engine running, there is an – To close the bonnet, push it down until it overcomes the spring added safety risk from the rotating parts (e.g. drive belts, alternator, ra- pressure.
  • Page 225 Checking and refilling levels We recommend that the oil change, indicated in the Maintenance Pro- ● In exceptional circumstances, if the engine oil level is too low ⇒  p age 224 and you cannot obtain the oil specified for your vehicle, you gramme, be performed by an Authorised Service Centre or a specialised workshop.
  • Page 226 Checking and refilling levels Engine oil additives – Pull out the dipstick. Wipe the dipstick with a clean cloth and insert it again, pushing it in as far as it will go. No type of additive should be mixed with the engine oil. The deterioration caused by these additives is not covered by the warranty.

  • Page 227: Cooling System

    Checking and refilling levels Topping up the engine oil  CAUTION ● The oil level must never be above area . This could damage the cata- lytic converter or the engine. Contact a qualified workshop to drain the en- gine oil if necessary. ●...
  • Page 228 Checking and refilling levels The cooling system is filled at the factory with the correct amount of anti- CAUTION freeze for the country concerned. ● It is advisable to have the cooling system checked before the winter sea- In most cases, the mixture consists of 60% water and 40% antifreeze. This son to make sure that the antifreeze concentration is adequate for the con- mixture gives the required antifreeze protection at temperatures down to ditions to be expected.
  • Page 229 Checking and refilling levels ⇒  f ig. 168 – Check the coolant level on coolant fluid expansion tank – Cover the cap on the expansion tank with a cloth, ⇒  f ig. and carefully unscrew the cap anti-clockwise ⇒  . 168.

  • Page 230: Washer Fluid And Windscreen Wiper Blades

    Checking and refilling levels Radiator fan Washer fluid and windscreen wiper blades The radiator fan can start running spontaneously. Windscreen washer system The auxiliary fan can continue to run for as long as 10 minutes after stop- Plain water is not sufficient for the windscreen washer sys- ping the engine, even after the ignition is switched off.
  • Page 231 Checking and refilling levels CAUTION ● Never put radiator antifreeze or other additives into the windscreen washer fluid. ● Never use washer fluid which contains paint thinners or solvents as it can damage the paintwork.  Changing windscreen wiper blades If the windscreen wiper blades are in perfect condition, you will benefit from an improved visibility.

  • Page 232: Brake Fluid

    Checking and refilling levels Brake fluid If the windscreen wipers smear, they should be replaced if they are dam- aged, or cleaned if they are soiled. If this does not produce the desired results, the setting angle of the wind- Checking the brake fluid level screen wiper arms might be incorrect.

  • Page 233: Vehicle Battery

    It is best to have the brake fluid changed by a professional. The brake pads and fluid must be collected and disposed of according the applicable regulations. The SEAT Technical Service network has the neces- sary equipment and qualified personnel for collecting and disposing of this Brake fluid absorbs moisture.
  • Page 234  ing. It must also have the same dimensions as the original, factory-fitted gloves and eye protection! battery and have sealed caps. The SEAT batteries which have been specially Fires, sparks, open flames and smoking are prohibited!  developed fulfil the maintenance, performance and safety specifications for your vehicle.
  • Page 235 Checking and refilling levels Charging the battery WARNING (Continued) ● A highly explosive mixture of gases is released when the battery is A fully-charged battery is important for reliable starting. under charge. The batteries should be charged in a well-ventilated room only.
  • Page 236 Checking and refilling levels A flat battery can freeze at temperatures of around 0 °C. The battery must be defrosted before charging ⇒  . It is advisable to replace the battery if it has frozen, because the ice can crack the battery casing and allow the battery acid to escape.

  • Page 237: Wheels And Tyres

    Wheels and tyres Wheels and tyres Wheels Concealed damage Damage to tyres and rims is often not readily visible. If you notice unusual vibrations or the vehicle pulling to one side, this may indicate that one of General notes the tyres is damaged. The tyres should be checked immediately by an Au- thorised Service Centre.
  • Page 238 Wheels and tyres Tyre pressure monitoring* 2. The tyre pressures should only be checked when the tyres are cold. The slightly raised pressures of warm tyres must not be re- The tyre pressure monitoring system constantly checks the duced. pressure of the tyres. 3.
  • Page 239 Wheels and tyres Significant tyre pressure loss The tyre pressure monitoring system makes use of the ABS sensors to com- pare the rolling circumference and the frequency characteristics of the wheels. If the rolling circumference or frequency characteristic changes on The tyre symbol ...
  • Page 240 Wheels and tyres Tyre pressure warning lamp on Note When you switch on the ignition, the tyre pressure warning lamp  will If you did not press the button for the tyre pressure monitoring system to light up for about 2 seconds. There is a fault in the system if the indicator confirm a new tyre pressure setting after making changes to the tyre pres- stays on permanently after switching on the ignition.
  • Page 241 Wheels and tyres Tyre service life Wear indicators The original tyres on your vehicle have 1.6 mm high “tread wear indicators” The service life of tyres is dependent on tyre pressure, driv- ⇒  f ig. 174, running across the tread. Depending on the make, there will be ing style and fitting.
  • Page 242 Wheels and tyres Run-flat tyres* Wheel balance The wheels on new vehicles are balanced. However, various factors encoun- Run-flat tyres allow you to continue driving even with a tered in normal driving can cause them to become unbalanced, which re- punctured tyre, in the majority of cases.
  • Page 243 ● If one of the tyres has been severely damaged in an accident, etc. If a tyres and rims approved by SEAT are specially matched to the characteris- tyre has been badly damaged there is a risk that parts of the tread can be tics of the vehicle and make a major contribution to good road holding and thrown off and cause damage to the fuel lines, brake pipes or fuel filler.
  • Page 244 This can also apply to wheels of the same model. The use of wheels or tyres which have not been approved by SEAT for use with your The manufacturing date is also indicated on the tyre sidewall (possibly only model may invalidate the vehicle's type approval for use on public roads.
  • Page 245 Wheels and tyres The speed rating code ⇒  p age 241, New tyres and wheels determines the WARNING following speed limits for winter tyres: ⇒  If the wheel bolts are not tightened correctly, the wheel could become max. 160 km/h loose while driving.
  • Page 246 Wheels and tyres 205/55 R16 15 mm chains 225/45 R17 9 mm chains 225/40 R18 7 mm chains Remove wheel hub covers and trim rings before fitting snow chains. For safety reasons cover caps, available in any Authorised Service Centre, must then be fitted over the wheel bolts.

  • Page 247: If And When

    If and when If and when Tools, tyre repair kit and spare wheel – Take out the tools or jack. – Replace the floor panel before closing the tailgate. Tools The tool kit includes: The tools and jack are stored under the floor panel in the ●...
  • Page 248 If and when Tyre mobility system Spare steel rim wheel The tyre mobility system is stored under the floor panel in The spare steel rim wheel is carried in the wheel well under the luggage compartment. the floor panel in the luggage compartment. It is only inten- ded for temporary use over short distances.

  • Page 249: Changing A Wheel

    If and when Changing a wheel wheels fitted on the vehicle because of the wheel/tyre dimensions, rubber composition, tread pattern, etc. Therefore, note the following restrictions: ● The spare steel wheel is designed only for your vehicle model. Do not Preparation work attempt to mount the wheel on any vehicle but your own.
  • Page 250 If and when – The inflation pressure of the newly fitted spare tyre must be Note checked as soon as possible. Please observe legal requirements when doing so.  – Have the tightening torque of the wheel bolts checked as soon as possible with a torque wrench.
  • Page 251 If and when Loosening and tightening the wheel bolts WARNING The wheel bolts must be loosened before raising the vehicle. Loosen the wheel bolts only about one turn before raising the vehicle with the jack. Failure to do so could result in an accident. Note ●...
  • Page 252 If and when Raising the vehicle – Position the vehicle jack under the door sill at the jacking point ⇒  f ig. 180 closest to the wheel being changed -arrows-. In order to remove the wheel, the vehicle must be raised –...
  • Page 253 If and when Removing and fitting the wheel Anti-theft wheel bolts* For removal and fitting the wheel, the following tasks must A special adapter is required to turn the anti-theft wheel be completed. bolts. After loosening the wheel bolts and raising the vehicle with the jack, change the wheel as described below: Removing a wheel –...

  • Page 254: Tyre Repair* (Tyre-Mobility-System)

    If and when Tyres with directional tread pattern Tyre repair* (Tyre-Mobility-System) Tyres with directional tread pattern must be fitted so that General information and safety notes they rotate in the correct direction. Repaired tyres are only suitable for temporary use over a A directional tread pattern can be identified by arrows on the sidewall that short period.
  • Page 255 If you have to dispose of a sealant can, go to a specialised waste service or ● Vehicle handling could be impaired. to a SEAT Technical Service, where the product can be recycled in an appro- priate waste container. ● Tyres which have been sealed using the Tyre Mobility System are only suitable for temporary use over a short period.
  • Page 256 If and when Repairing a tyre – Stick the “max. 80 km/h” adhesive, which is included with the tyre sealant can, onto the instrument panel where the driver will see it. Filling the tyre – Shake the tyre sealant can well. –...
  • Page 257 If and when pressure is still lower than the specification the tyre is too badly Note damaged and cannot be repaired using the tyre sealant. ● Do not use the compressor for longer than 6 minutes. Otherwise, it might overheat. When the compressor has cooled down, you can use it Final check again.

  • Page 258: Fuses

    If and when Fuses – Switch off the ignition and its failed electrical component. ⇒  f ig. – Remove the fuse cover using a screwdriver 185. Changing fuses – Identify the fuse corresponding to the damaged electric con- sumer ⇒  p age 257, Fuse assignment. If a fuse has blown, it must be replaced.
  • Page 259 Some of the electrical items listed in the table are only fitted on certain models or are optional extras. Vacant Vacant The electric windows and electric seat adjusters are protected by circuit Vacant breakers. These reset automatically after a few seconds when the overload (caused for example by frozen windows) has been corrected.

  • Page 260: Bulbs

    If and when The name of many of the lamps fitted by SEAT ends in "LL". This means Long Note Life. These lamps are used for functions with a long service time (dipped Please note that the above list contains all data at the time of going to beam, side lights, daylight driving, etc.).

  • Page 261: Changing Bulbs. Halogen Headlights

    If and when Changing bulbs. Halogen headlights For the sake of the environment Please ask your specialist retailer how to dispose of used bulbs in the prop- er manner. Types of bulbs Note You must only replace a bulb with a bulb of the same type. The name can be found on the base of the bulb holder.
  • Page 262 If and when Removing the air duct Fitting the air duct The air duct has to be removed to gain access to the bulbs Once the bulb(s) for the right-side headlight have been for the right-side headlight. changed, the air duct must be re-installed. Fig.
  • Page 263 If and when Halogen headlight bulbs Changing the turn signal bulb The procedure for changing the bulb is the same on both sides. Fig. 189 Halogen bulbs Main beam headlights Fig. 190 Turn signal Side lights Dipped beam headlights – Switch off the ignition and the lights. Side lights –...
  • Page 264 If and when Note ⇒  f ig. 193 Although it is not necessary, previously remove the rigid cover easier turn signal bulb changes.  Changing the main headlight bulb The procedure for changing the bulb is the same on both sides.
  • Page 265 If and when Changing the dipped beam headlight bulb – Raise the bonnet. ⇒  f ig. 193 – Move the brace in the direction of the arrow and The procedure for changing the bulb is the same on both remove the rigid cover, separating the brace side and then re- sides.
  • Page 266 If and when Changing the side light bulb (outside of vehicle) – Raise the bonnet. ⇒  f ig. 195 – Move the brace in the direction of the arrow and The procedure for changing the bulb is the same on both remove the rigid cover, separating the brace side and then re- sides.

  • Page 267: Changing Bulbs. Bi-Xenon Afs Headlights

    If and when Changing the side light bulb (inside of vehicle) – Raise the bonnet. ⇒  f ig. 197 – Move the brace in the direction of the arrow and The procedure for changing the bulb is the same on both remove the rigid cover, separating the brace side and then re- sides.
  • Page 268 If and when ● Main headlight lamps: Xenon ⇒  lights. ● Before changing a bulb, make sure you have the correct new bulb. ● Sources of the DRL (daylight) light unit and position. ● Do not touch the glass part of the bulb with your bare hands, use a cloth or paper towel instead.
  • Page 269 If and when Fitting the air duct Bi-Xenon AFS headlight bulbs Once the bulb(s) for the right-side headlight have been changed, the air duct must be re-installed. Fig. 201 Bi-Xenon AFS headlight bulbs Turn signal Fig. 200 Air duct on right side of vehicle Xenon headlight (dipped beam/main beam) ...
  • Page 270 If and when Changing the turn signal bulb – Raise the bonnet. ⇒  f ig. 202 – Pull the rubber cap to remove it. The procedure for changing the bulb is the same on both sides. – Remove the bulb holder by pulling on the grip and turning it an- ⇒ ...

  • Page 271: Changing Tail Light Bulbs (On Side Panel)

    If and when Changing tail light bulbs (on side panel) Overview of tail lights. LED lamps Overview of tail lights Fig. 205 Overview of tail lights Tail lights on side panel Fig. 204 Overview of tail lights ● Brake light and side light ●...
  • Page 272 If and when Removing the tail light A special retaining screw is used to secure and guide the tail light. – Check which of the bulbs is defective. To change the bulbs you must remove the tail light assem- bly. Removing the light requires a certain degree of practical –...
  • Page 273 If and when Remove the bulb holder Changing bulbs When changing a bulb, you must first remove the bulb hold- All bulbs can be changed easily in the bulb holder. Fig. 209 Position of the bulbs in the bulb holder. Example: Left tail light in Fig.
  • Page 274 If and when Position of the bulbs – Fit the new bulb, pressing it into the bulb holder and turn it to the right as far as it will go. Pos. Bulb function ⇒  f ig. 209 – Use a cloth to remove any fingerprints from the glass part of the Brake light and side light P21W LL bulb.
  • Page 275 If and when ⇒  f ig. 211 Fitting the tail light unit – First place the tail light unit in arrow in the hous- ing. The tail light unit is easy to fit. – Gently press the tail light unit against the housing, first in posi- tion and then in position , until that the clips engage firm-...

  • Page 276: Changing Tail Light Bulbs (On Tailgate)

    If and when Changing tail light bulbs (on tailgate) Overview of tail lights. LED lamps Overview of tail lights Fig. 214 Overview of tail lights Tail lights on the tailgate Fig. 213 Overview of tail lights ● Side lights ● Rear fog light Tail lights on the tailgate ●...
  • Page 277 If and when Remove the bulb holder – Check which of the bulbs is defective. – Insert a screwdriver into the opening in the cover from the top The tailgate must be open to change the bulbs. ⇒  f ig. 215 and use it as a lever to detach the cover.
  • Page 278 If and when Changing bulbs. LED lamps The bulbs are secured with a bayonet fastener. The table below gives an overview of the bulb positions. All bulbs can be changed easily in the bulb holder. – Lightly press the defective bulb into the bulb holder, then turn it to the left and remove it.

  • Page 279: Side Turn Signals

    If and when Side turn signals Position of the bulbs Pos. Bulb function ⇒  f ig. 218 Reverse light P21W LL  Fitting the bulb holder The bulb holder is easy to fit. – Check that the seal is seated correctly on the bulb holder. –...

  • Page 280: Luggage Compartment Lights

    If and when Luggage compartment lights – Remove the protective cover and remove the bulb from the ⇒  f ig. housing 221.  Fig. 220 Luggage com- partment light Fig. 221 Luggage com- partment light – Remove the tulip-shaped fitting by pressing on its inside edge using the flat side of a screwdriver.

  • Page 281: Registration Light

    If and when Registration light – Remove the bulb, moving it in the direction of the arrow and ⇒  f ig. outwards 223. – Installation is done in the reverse order.  Fig. 222 Number plate light Fig. 223 Number plate light ⇒ ...

  • Page 282: Sun Visor Light

    If and when Sun visor light – Use a screwdriver to remove the protective cover. – Remove the bulb, moving it in the direction of the arrow and ⇒  f ig. outwards 225.  Jump-starting Jump leads The jump lead must have a sufficient wire cross section. If the engine fails to start because of a discharged battery, the battery can Fig.
  • Page 283 If and when How to jump start: description the engine block itself of the vehicle with the flat battery. Do not connect it to a point near the battery ⇒  . 5. Position the leads in such a way that they cannot come into contact with any moving parts in the engine compartment.
  • Page 284 If and when WARNING ● Please note the safety warnings referring to working in the engine compartment ⇒  p age 221. ● The battery providing assistance must have the same voltage as the flat battery (12V) and approximately the same capacity (see imprint on battery).

  • Page 285: Towing And Tow-Starting

    If and when Towing and tow-starting General notes Please observe the following points if you use a tow-rope: Tow-starting Notes for the driver of the towing vehicle The use of jump leads is preferable to tow-starting. – Drive slowly at first until the tow-rope is taut. Then accelerate gradually.
  • Page 286 If and when Do not pull too hard with the towing vehicle and take care to avoid jerking ● The steering wheel is locked when the vehicle has no electrical power. the tow-rope. When towing on an unpaved road, there is always a risk of The vehicle must then be towed with the front wheels raised.
  • Page 287 If and when Rear towing eye There is a towing eye at the rear on the right below the rear bumper.  Safety First Operating Instructions Practical Tips Technical Specifications...

  • Page 288: Technical Specifications

    Description of specifications Technical Specifications Description of specifications Important information Abbrevia- Meaning tion Cetane number, indication of the diesel combustion power. Important Research octane number, indication of the knock resistance of petrol. The information in the vehicle documentation always has ...

  • Page 289: Vehicle Identification Data

    Description of specifications Vehicle identification data Vehicle data The data sticker is placed on the inside of the spare wheel well, in the lug- The most important information is given on the identifica- gage compartment and on the rear cover of the Maintenance Programme. tion plate and the vehicle data sticker.

  • Page 290: Information On Fuel Consumption

    Description of specifications Information on fuel consumption Weights Kerb weight refers to the basic model with a fuel tank filled to 90% capacity Fuel consumption and without optional extras. The figure quoted includes 75 kg to allow for the weight of the driver. The consumption and emission details shown on the vehicle For special versions and optional equipment fittings or for the addition of data sticker differ from one vehicle to another.

  • Page 291: Wheels

    Description of specifications Drawbar load Consult the chapter “wheels” of this manual. The maximum permitted drawbar load on the ball joint of the towing bracket Wheel bolts must not exceed 75 kg. After the wheels have been changed, the tightening torque of the wheel bolts should be checked as soon as possible with a torque wrench ⇒ ...

  • Page 292: Technical Specifications

    Technical specifications Technical specifications Engine specifications Coolant expansion tank Windscreen washer fluid container Hydraulic fluid reservoir for power steering Checking fluid levels The checking and refilling of service fluids are carried out on the compo- From time to time, the levels of the different fluids in the ve- nents mentioned above.
  • Page 293 Technical specifications Petrol engine 1.8 88 kW (120 PS) Engine specifications Power output in kW (PS) 88 (120) / 3650-6200 Maximum torque in Nm at rpm 230 / 1500-3650 No. of cylinders/capacity in cm 4 / 1798 Fuel Super 95 RON / Super 91 RON Research Octane Number = Anti-detonation rating of the petrol.
  • Page 294 Technical specifications Petrol engine 1.8 118 kW (160 PS) Engine specifications Power output in kW (PS) 118 (160) / 4500-6200 Maximum torque in Nm at rpm 250 / 1500-4500 No. of cylinders/capacity in cm 4 / 1798 Fuel Super 95 RON / Super 91 RON Research Octane Number = Anti-detonation rating of the petrol.
  • Page 295 Technical specifications Petrol engine 2.0 147 kW (200 PS) Engine specifications Power output in kW (PS) 147 (200) / 5100-6000 Maximum torque in Nm at rpm 280 / 1800-5000 No. of cylinders/capacity in cm 4 / 1984 Fuel Super 98 RON /Super 95 RON Research Octane Number = Anti-detonation rating of the petrol.
  • Page 296 Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 4.5 litres  Petrol engine 2.0 155 kW (211 PS) Engine specifications Power output in kW (PS) 155 (211) / 4600-6000 Maximum torque in Nm at rpm 320 / 1500-4600 No.
  • Page 297 Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 4.6 litres  Diesel engine 2.0 TDI CR 88 kW (120 PS) Engine specifications Power output in kW (PS) 88 (120) / 4000 Maximum torque in Nm at rpm 290 / 1750-2500 No.
  • Page 298 Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 4.3 litres  Diesel engine 2.0 TDI CR 105 kW (143 PS) Engine specifications Power output in kW (PS) 105 (143) / 4200 Maximum torque in Nm at rpm 320 / 1750-2500 No.
  • Page 299 Technical specifications Trailer weight Manual Automatic Trailer without brakes in kg Trailer with brakes, gradients up to 8% in kg 1800 1900 Trailer with brakes, gradients up to 12% in kg 1400 1700 Engine oil capacity Approximate engine oil capacity with oil filter change 4.3 litres ...
  • Page 300 Technical specifications Trailer weight Trailer without brakes in kg Trailer with brakes, gradients up to 8% in kg 1800 Trailer with brakes, gradients up to 12% in kg 1600 Engine oil capacity Approximate engine oil capacity with oil filter change 4.3 litres ...

  • Page 301: Dimensions And Capacities

    Technical specifications Dimensions and capacities Dimensions Length, width 4661-4741 mm/ 1772 mm Height at kerb weight 1430 mm Front and rear projection 976 mm/ 1043-1123 Wheelbase 2642 mm Turning circle 11.2 m Front Rear Track width 1522 mm 1523 mm Capacities Fuel tank 70 l.

  • Page 303: Index

    Index Index Numbers and Symbols Economical use ..... 163 Automatic gearbox Key settings ......163 Dynamic gear control programme .
  • Page 304 Car care Child seat ......48 Malfunction ......78 Exterior .
  • Page 305 Dynamic gear control programme ..181 senger seat ......29 Locking the doors manually if the central Dash panel cleaning .
  • Page 306 Consumption ..... . . 224 Rear seat ......141 Petrol .
  • Page 307 Locks ....... . . 210 Settings for the driver seat ... . 139...
  • Page 308 Rear fog light ......117 SEAT Parking System ....171 Rear side window sun blind .
  • Page 309 Tailgate Seat belts ......18 Sliding/tilting sunroof ....111 Central locking system .
  • Page 310 Ventilation slits ......17 Why wear seat belts? ....18, 19, 28 Tyre mobility system .
  • Page 311 Index Windscreen washer system ....228 Windscreen wiper blades Cleaning ......210 Windscreen wipers .
  • Page 312 SEAT S.A. is permanently concerned about continuous development of its types and models. For this reason we ask you to under- stand, that at any given time, changes regarding shape, equipment and technique may take place on the car delivered. For this reason no right at all may derive based on the data, drawings and descriptions in this current handbook.

Table of Contents
