Summary of Contents for Seat IBIZA ST

  • Page 3 Foreword This Instruction Manual and its corresponding supplements should be read carefully to familiarise yourself with your vehicle. Besides the regular care and maintenance of the vehicle, its correct handling will help preserve its value. For safety reasons, note the information concerning accessories, modifications and part replacements. If selling the vehicle, give all of the on-board documentation to the new owner, as it should be kept with the vehicle.
  • Page 5: Table Of Contents

    Lights ........Seat belts .......
  • Page 6 Contents Vehicle maintenance and cleaning Luggage compartment light ......Jump-starting ......General notes .
  • Page 7: Manual Structure

    As this is a general manual for the IBIZA ST, some of the equipment and func- tions described in this manual are not included in all types or versions of the Note model.
  • Page 8: Content

    (e.g. “Air conditioning”). The entire manual is divided into five large parts which are: 1. Safety First Information on the vehicle equipment relating to passive safety such as seat belts, airbags, seats, etc. 2. Operating instructions Information about the distribution of controls in the driver position of your vehicle, about the seat adjustment possibilities, about how to create a suit- able climate in the passenger compartment, etc.
  • Page 9: Safety First

    The warnings that you should read and consider for both your own safety following list includes most of the safety equipment in your SEAT: and for your passengers’ safety.
  • Page 10 – Observe traffic laws and speed limits. – Ensure that the passenger in the central rear seat always has the – Always reduce your speed as appropriate for road, traffic and head restraint in the correct position for use.
  • Page 11: Proper Sitting Position For Occupants

    ⇒ fig. – Move the driver seat forwards or backwards so that you are able to press the accelerator, brake and clutch pedals to the floor with your knees still slightly angled ⇒...
  • Page 12 The airbag system and seat belts can only provide optimal protection when the back- rest is in an upright position and the driver is wearing his or her seat belt WARNING properly.
  • Page 13 Always keep your feet in the footwell when the vehicle is moving; never rest them on the dash panel, out the window or on the seat. An incorrect sitting position exposes you to an increased risk of injury in case of a WARNING sudden braking or an accident.
  • Page 14 Safe driving Correct adjustment of head restraints Adjust the head restraint properly in order to achieve maximum protection. Properly adjusted head restraints are an important part of – Adjust the head restraint so that its upper edge is at the same passenger protection and can reduce the risk of injuries in level as the top of your head or as close as possible to the same most accident situations.
  • Page 15 WARNING • never lean against the dash panel, Whenever a passenger is seated on the rear central seat, the head restraint • never lie on the rear bench, should be placed in the position for use •...
  • Page 16: Pedal Area

    • Use only floor mats which leave the pedal area free and can be securely never put your feet on the surface of a seat, • fastened on the footwell. do not allow anyone to travel in the footwell, •...
  • Page 17: Storing Objects

    Never transport passengers in the luggage compartment. All passen- – Distribute the load evenly in the luggage compartment. gers must have their seat belt fastened ⇒ page 17. – Place heavy objects as far forward as possible in the luggage compartment.
  • Page 18 • To prevent pieces of luggage or other objects from flying forward, always use appropriate retaining cords which are secured to the fastening rings. • Never secure a child seat on the fastening rings.
  • Page 19: Seat Belts

    Seat belts Brief introduction Number of seats Your vehicle has five seats, two in the front and three in the rear. Each seat is Before driving: remember your seat belt! equipped with a three-point seat belt. Wearing a seat belt properly can save your life! In some versions, your vehicle is approved only for four seats.
  • Page 20 – Fasten your seat belt securely. – Instruct your passengers to fasten their seat belts properly before driving off. – Protect children by using a child seat according to the child’s height and weight. The warning lamp  in the instrument panel lights up...
  • Page 21: Why Wear Seat Belts

    25 km/h to 50 km/h, for example, the kinetic energy is multi- plied by four. Because the passengers in our example are not restrained by seat belts, in the case of a head-on collision all of their kinetic energy has to be absorbed ⇒...
  • Page 22 It is also important for the rear passengers to wear seat belts properly, as they could otherwise be thrown forward violently in an accident. Rear passengers who do not use seat belts endanger not only themselves but also the front ⇒...
  • Page 23 • If the seat belts are worn incorrectly or not at all, the risk of severe inju- Our examples describe frontal collisions. Of course, properly worn seat belts ries increases. The optimal protection from seat belts can be achieved only substantially reduce the risk of injury in all other types of accidents.
  • Page 24: Seat Belts

    • Never allow two passengers (even children) to share the same seat belt. • Keep both feet in the footwell in front of your seat as long as the vehicle Seat belts is in motion. • Never unbuckle a seat belt while the vehicle is in motion. Risk of fatal injury.
  • Page 25 • Never put the latch plate in the buckle of another seat. If you do this, the seat belt will not protect you properly and the risk of injury is increased.
  • Page 26 • – Insert the latch plate into the buckle for the corresponding seat The lap part of the seat belt must lie across the pelvis, never across the ⇒ page 23, and push it down until it is securely locked with an audible click stomach.
  • Page 27 Read and always observe information and warnings concerning the use is not damaged of seat belts ⇒ page 21. WARNING Never unbuckle a seat belt while the vehicle is in motion. If you do, you increase the risk of sustaining severe or fatal injuries. Safety First Operating Instructions...
  • Page 28: Belt Tensioners

    Sensors will trigger the belt tensioners during severe head-on, lateral and Never attempt to repair, adjust, remove or install parts of the belt rear collisions only if the seat belt is being worn. This retracts and tightens the tensioners or seat belts.
  • Page 29: Airbag System

    • you critical injuries. Therefore, it is essential that all passengers in the vehicle If you are not wearing a seat belt, if you lean forward or to the side while assume a correct sitting position while travelling. travelling or assume an incorrect sitting position, there is a substantially increased risk of injury.
  • Page 30 • If a child seat is secured to the front passenger seat, the risk to the child of sustaining critical or fatal injuries in the event of an accident increases. The warning lamp monitors all airbags and seat belt tensioners in the vehicle, •...
  • Page 31 Airbag system Monitoring of airbag and belt tensioner system system may be damaged. In the event of an accident this could cause the airbag to inflate incorrectly or not inflate at all. Both the airbag and belt tensioner systems operation is constantly monitored electronically.
  • Page 32: Front Airbags

    The airbag system is not a substitute for seat belts, but it is an integral part Fig. 16 Driver airbag located in steering wheel of the vehicle’s overall passive safety system.
  • Page 33 WARNING • When the system is triggered, the airbags fill with a propellant gas and The seat belts and airbags can only provide maximum protection if the ⇒ fig. deploy in front of the driver and front passenger 18. The fully deployed occupants are seated correctly ⇒...
  • Page 34 • If you are not wearing a seat belt, if you lean forward or to the side while travelling or assume an incorrect sitting position, there is a substantially increased risk of injury. This increased risk of injury will be further increased if you are struck by an inflating airbag.
  • Page 35: Side Airbags

    Airbag system Side airbags The airbag system is not a substitute for seat belts, but it is an integral part of the vehicle’s overall passive safety system. Please bear in mind that the airbag system can only work effectively when the occupants are wearing their Description of side airbags seat belts.
  • Page 36 Any work carried out to the doors should be made in a specialised work- shop. • The seat belts and airbags can only provide maximum protection if the occupants are seated correctly ⇒ page 9, “Proper sitting position for occu- pants”.
  • Page 37 WARNING • If you do not wear a seat belt, if you lean forward, or are not seated correctly while the vehicle is in motion, you are at a greater risk of injury if the side airbag system is triggered in an accident.
  • Page 38 Airbag system WARNING (continued) • Any damage to the original seat upholstery or around the seams of the side airbag units must be repaired immediately by a specialised workshop. • The airbags provide protection for just one accident; replace them once they have deployed.
  • Page 39: Deactivating Airbags

    Airbag system Deactivating airbags* Front passenger airbag deactivation If you fit a rear-facing child seat to the front passenger seat, the front passenger airbag must be de-activated. Fig. 22 Warning lamp for deactivated passenger airbag in centre console When the passenger airbag is deactivated, this means that only the passenger front airbag is deactivated.
  • Page 40 Otherwise, there is a risk of death. If under exceptional circumstances it is necessary to trans- port a child in a rear-facing child seat on the front passenger seat, you must always disable the front passenger airbag.
  • Page 41: Child Safety

    Depending on their age, height and weight, children trav- As the driver, you are responsible for any children you transport in elling on the rear seat must use a child seat or a seat belt. For safety reasons, your vehicle.
  • Page 42 Never allow a child to be transported in a vehicle without being properly secured, or to stand up or kneel on a seat while travelling. In an accident, the child could be flung through the vehicle, causing possibly fatal injuries to themselves and to the other passengers.
  • Page 43: Child Seats

    Child seats that have been tested and approved under the ECE R44 standard Group 0: For babies from about 9 months old and 10 kg in weight the most bear the test mark on the seat (the letter E in a circle with the test number ⇒ fig.
  • Page 44 We recommend you to include the manufacturer’s Child Seat instruction Children under 7 years of age weighing between 15 and 25 kg are best manual together with the on-board documentation. protected by group 2 child seats together with properly adjusted seat belts. Group 3 child seats WARNING Children over 7 years of age weighing between 22 and 36 kg but less than 1.5...
  • Page 45 The shoulder part of the seat belt must lie approximately on the centre of the shoulder, never across the neck or the arm. The seat belt must lie close to the upper part of the body. The lap belt part must lie across the pelvis, not across the stomach, and always fit closely.
  • Page 46: Securing Child Seats

    You can secure a child seat to the rear seat or front passenger seat in the ⇒ page 37, “Deactivating airbags*” must always be disabled and the seat following ways: adjusted to its highest position, where possible.
  • Page 47 Two ISOFIX retaining rings are fitted on each rear seat. In some vehicles, the rings are secured to the seat frame and, in others, they are secured to the rear floor. The access to the “ISOFIX” rings is between the rear seat backrest and the seat cushioning.
  • Page 48 (lift the head restraint where necessary). An undue installation of the safety seat will increase the risk of injury in the – Slide the belt so that the Top Tether belt of the child restraint seat event of a crash.
  • Page 49 Safety First Operating Instructions Practical Tips Technical Specifications...
  • Page 50 Fig. 29 Dash panel...
  • Page 51: Operating Instructions

    Cockpit Operating Instructions Cockpit Overview Radio Glove compartment/Storage compartment ....Passenger airbag* ........Overview of the dash panel Switches for: −...
  • Page 52 Cockpit Steering column control lever* ......Bonnet release lever ....... . . Steering column controls for audio and telephone* .
  • Page 53: Cockpit

    Cockpit Instruments Instrument overview The instruments display the vehicle operating status. Fig. 30 Detailed view of the dash panel: instrument panel The layout of the instruments depends upon the model and the engine. Menu selection button on the instrument panel digital display Rev counter* ⇒...
  • Page 54: Digital Instrument Panel Display

    Cockpit Digital instrument panel display Rev counter The rev counter displays the engine speed in revolutions per Fuel gauge and reserve indicator minute. ⇒ page 51, fig. 30 The start of the red zone indicates the maximum engine speed operating at service temperature. However, it is advisable to change up to a higher gear, move the selector lever to D or lift your foot off the accelerator before the needle reaches the red zone.
  • Page 55 Cockpit – To set the minutes, press button again and select the minute Recommended gear display* option. Set from button “set”. This display helps to save fuel. Once the operation has been carried out, the system memorises the time. Outside temperature display The outside temperature is displayed when the ignition is switched on.
  • Page 56 Cockpit Multifunction display (MFI)* The trip memory 1 collects the travel and consumption rates from the moment the ignition is switched on until it is switched off. If the journey is The multifunction display (MFI) shows you information on the continued within two hours of switching off the ignition, the new values will be added to the existing trip recorder memory.
  • Page 57 Cockpit • Journey duration Ø l/100 km - Average fuel consumption • After turning on the ignition, average fuel consumption will be shown after Average speed • travelling approximately 100 metres. Until then dashes will appear in the Distance display. The display will be updated every 5 seconds while the vehicle is in •...
  • Page 58 The service indication is shown on the instrument panel display Gear lever position for automatic gearbox. SEAT distinguishes between services with engine oil change (e.g. Mainte- nance Service) and services without engine oil change (e.g. Inspection The position of the automatic selector lever is shown on the display Service).
  • Page 59 To calculate this (max. two years), the If the service was not performed by a SEAT dealer, the display must be reset conditions under which the vehicle is used and the individual driving style as follows: are also taken into account.
  • Page 60: Warning Lamps

    Cockpit Warning lamps Overview of the warning lamps The warning lamps indicate a number of different functions and possible faults. Fig. 37 Instrument panel indicator and warning lamps. Some of the items of equipment listed here are fitted only on certain model versions or are optional extras.
  • Page 61 Rear fog light switched on  ⇒ page 67 Electro-hydraulic steering ⇒ page 18 Seat belt warning lamp*  Fault in the emission control system ⇒ page 67 ⇒ page 63 Anti-lock brake system (ABS) * Coolant level / coolant temperature ⇒ page 67 If flashing: Electronic Stability Pro- ⇒...
  • Page 62 Cockpit Warning symbols Meaning of indicator and Further Item Symbol warning lamps information There are red warning symbols (priority 1) and yellow warning ⇒ page 64 If it stays lit: TCS disabled symbols (priority 2) ⇒ page 64 ⇒ page 68 Turn signals in operation Warning reports, Priority 1 (red) If one of these faults occurs, the warning lamp will flash or light up and will...
  • Page 63 Cockpit Priority 2 warning messages will not be shown until all Priority 1 warning --> P Warning: Place the selector lever in position P to stop the messages have been dealt with! engine. Examples of priority 2 warning messages (yellow): STARTING Warning: The engine starts automatically.
  • Page 64 Cockpit Engine management* Soot accumulation in the diesel engine particulate  filter* This warning lamp monitors the engine management system for petrol engines.  If the warning lamp lights up you should help the filter clean itself by driving in the appropriate manner. The warning lamp (Electronic Power Control) lights up when the ignition To do this, drive about 15 minutes in fourth or fifth gear (automatic gearbox:...
  • Page 65 Cockpit If the symbol flashes although the oil level is correct, do not drive on. The Anti-lock brake system (ABS)* engine must not even run at idle speed. Obtain technical assistance. A warning lamp monitors the ABS. Checking the oil level If the warning lamp is yellow the engine oil level should be checked as The indicator lamp...
  • Page 66 Cockpit lamp provides information about the disconnection status of the WARNING (continued) system: • • It stays lit when the TCS is disconnected after pressing the TCS OFF switch. If the brake fluid level is correct, the fault in the brake system may have been caused by a failure of the ABS system.
  • Page 67 Cockpit  lamp provides information about the disconnection status of the Cruise control system* system: • The warning lamp comes on when the cruise control system It stays lit when the TCS is disconnected after pressing the switch. is switched on. ...
  • Page 68 Cockpit • The tyre structure is damaged. • Note The vehicle is unbalanced because of a load. • If the battery is disconnected, the yellow warning lamp lights up after The wheels of one axle are under more pressure (for example, driving with turning the ignition on.
  • Page 69 Cockpit   Tailgate open* Emission control system* This warning lamp monitors the exhaust system.  The warning lamp should switch off when the tailgate is fully closed.  Warning lamp flashes: When there is misfiring that can damage the catalytic converter. Reduce Main beam headlights speed and drive carefully to the nearest specialised workshop to have the engine checked.
  • Page 70 Cockpit If the warning lamp lights up again after driving on for a short distance, stop You should avoid using electrical equipment that is not absolutely necessary the vehicle and switch the engine off. Contact an Authorised Service Centre because this will drain the battery. or a specialised workshop.
  • Page 71 The engine can, however, be started if the appropriate coded SEAT genuine key is used. Note A perfect operation of the vehicle can only be ensured if genuine SEAT keys are used. Depending on the model version. Safety First...
  • Page 72: General Information

    Steering column controls* Steering column controls* General information The column incorporates multifunctional modules from which to control audio and telephone functions on the vehicle. There are two versions of the multifunction module: • Audio version, to control the available audio functions from the steering wheel.
  • Page 73: Audio Control

    Steering column controls* Audio Control Fig. 39 Audio controls Short press Button Radio CD Audio AUX-IN CD MP3/USB/iPod Volume up Volume down Cycle through source FM - AM - CD - FM... Station search. Higher frequency No function Next track Station search.
  • Page 74: Audio + Telephone Control

    Steering column controls* Audio + Telephone Control Fig. 40 Audio + Tele- phone Control Short press Long press Button Radio AUX-IN Radio AUX-IN MP3/USB/iPod MP3/USB/iPod Volume up Continue volume up Volume down Continue volume down Enable voice recognition. Press to speak No specific function Station search.
  • Page 75 Steering column controls* Station search. Station search. Lower frequency Lower frequency Previous track No function Previous track No function Accept call / hang up Reject call Cycle through source FM - AM - CD - FM... Cycle through source FM - AM - CD - FM... Only for MP3 compatible radios.
  • Page 76: Central Locking

    Unlocking and locking Unlocking and locking Central locking WARNING (continued) • Having the doors locked prevents an intrusion from getting in, for Description example when stopped at a traffic light. The central locking system enables you to lock and unlock all Note doors by just pushing the button.
  • Page 77 Unlocking and locking When the ignition is switched off, the instrument panel indicates that the Selective unlocking system* Safe system is on. This system allows unlocking either just the driver door or the Deactivation entire vehicle. Rotate the key inserted in the lock cylinder twice towards the locking direc- tion.
  • Page 78 Unlocking and locking Involuntary unlocking Deactivating the system* With the ignition on, press the unlocking key on the central locking system It is an anti-theft system and prevents the unintentional within 3 to 10 seconds. unlocking of the vehicle. In both cases, if the operation has been carried out correctly, the locking lamp ⇒...
  • Page 79 Unlocking and locking • Central locking button* The driver door cannot be locked. This avoids the user from forgetting his key inside the vehicle. • The central locking button allows you to lock and unlock the All doors can be locked separately from inside the vehicle. Do this by vehicle from the inside.
  • Page 80 Unlocking and locking Childproof lock Deactivating the childproof lock – Unlock the vehicle and open the door whose childproof lock you The childproof lock prevents the rear doors from being want to deactivate. opened from the inside. This system prevents minors from opening a door accidentally while the vehicle is running.
  • Page 81: Keys

    Unlocking and locking Keys Duplicate keys If you need a replacement key, go to an Authorised Service Centre with your vehicle identification number. Set of keys WARNING The set of keys includes a remote control, a key without a • remote control and a plastic key tab* An incorrect use of the keys can cause serious injuries.
  • Page 82: Radio Frequency Remote Control

    Unlocking and locking Radio frequency remote control* Locking and unlocking the vehicle The remote control key is used to lock and unlock the vehicle from a distance. Fig. 45 Range of the remote control ⇒ fig. 44 Using the button (arrow) on the control, the key blade is released.
  • Page 83 Unlocking and locking WARNING (continued) For the sake of the environment • Used batteries must be disposed of at an appropriate waste facility or Never leave children or disabled persons in the vehicle. In case of emer- through an authorised service, given that their components can affect the gency, they may not be able to leave the vehicle and not manage on their environment.
  • Page 84: Anti-Theft Alarm System

    Unlocking and locking • Anti-theft alarm system* Opening the bonnet • Opening the tailgate • Ignition switched on with a non-validated key. Description of anti-theft alarm system* • Movements in the driving compartment (vehicles with a volume sensor) • The anti-theft alarm triggers if unauthorised movements are Towing of the vehicle •...
  • Page 85 Unlocking and locking Interior monitoring and anti-towing alarm* trigger the alarm) or when, for example, the vehicle is transported or has to be towed with only one axle on the ground. Monitoring or control function incorporated in the anti-theft False alarms alarm* which detects unauthorized vehicle entry by means of The interior monitoring only operates correctly if the vehicle is completely ultrasound.
  • Page 86: Tailgate

    Unlocking and locking Tailgate Unlocking and locking The operation of the tailgate opening system is electric. It is activated by using the handle on the tailgate Fig. 47 Detail of the inside of the tailgate: hand grip Opening the tailgate ⇒...
  • Page 87 Unlocking and locking Emergency opening WARNING • This allows the vehicle to be opened if the central locking Always close the tailgate properly. Risk of accident or injury. • does not operate (for example, if the battery is flat) The tailgate must not be opened when the reverse or rear fog lights are lit.
  • Page 88: Windows

    Unlocking and locking Windows Buttons on the driver door Button for window in front left door Button for window in front right door Opening or closing the windows electrically* Safety switch for deactivating the electric window buttons in the rear doors The front and rear electric windows can be operated by using Button for window in rear left door...
  • Page 89 Unlocking and locking Restoring one-touch opening and closing WARNING (continued) – The automatic open and close function will not work if the battery • The electric windows will work until the ignition has been switched off has been temporarily disconnected. The function can be restored and one of the front doors has been opened.
  • Page 90 Unlocking and locking • If you try within the following 10 seconds and the window closes again Convenience opening and closing* with difficulty or there is an obstruction, the automatic closing will stop working for 10 seconds. Using the door lock* •...
  • Page 91: Panorama Tilting Sunroof

    Unlocking and locking Panorama tilting sunroof* Automatic closing of the panorama/tilting sunroof – Press button once only; the sunroof starts closing automati- cally until it is completely closed. Opening and closing the panorama/tilting sunroof Automatic opening of the panorama/ tilting sunroof The panorama/tilting sunroof is opened and closed by using –...
  • Page 92 Unlocking and locking Roll-back function of the panorama/ tilting sunroof* WARNING (continued) • Never leave children or disabled persons in the vehicle, particularly if The panorama/ tilting sunroof has a roll-back function which prevents larger they have access to the keys. Unsupervised use of a key could mean that objects getting trapped when the roof is closed.
  • Page 93: Lights And Visibility

    Lights and visibility Lights and visibility Lights Switching on the front fog lights* – Turn the switch from position to the first stop and pull it. The symbol in the light switch lights up. Switching lights on and off Switching on the rear fog light (vehicles with front fog lights) –...
  • Page 94 Lights and visibility • The use of the lighting described here is subject to the relevant statutory WARNING requirements. • Even if the automatic headlight control is switched on, the dipped headlights will not be switched on with fog. Therefore, the dipped beam must be switched on manually.
  • Page 95 Lights and visibility Instrument and switch lighting / Headlight range control Dynamic headlight range control Vehicles with gas discharge bulbs (xenon bulbs) are equipped with dynamic headlight range control. When you switch on the lights, their range regulates itself according to the vehicle load. Vehicles with gas discharge bulbs do not have headlight range control.
  • Page 96 Lights and visibility Adaptive headlights* (for driving round bends) Fog lights with cornering function* When driving around bends, the headlights will light the This is an additional light source to dipped beam headlights most important areas of the road. to light up the road as a bend is taken. The cornering light operates with the lights switched on and when driving at less than 40 Km/h.
  • Page 97 Lights and visibility – Close the doors. Heated rear window – Push the headlight lever to the main beam position – Open the driver door. In vehicles with start-stop and/or automatic headlight system As soon as the driver door is opened, the system will switch on the dipped lights for 30 seconds.
  • Page 98 Lights and visibility Hazard warning lights 7. Always take the vehicle key with you when you leave the vehicle. The hazard warning lights are used to draw the attention of Switch on the hazard warning lights to warn other road users, for example other road users to your vehicle in emergencies.
  • Page 99 Lights and visibility Turn signal and main beam headlight lever Switching main beam on and off – Turn the light switch to position The turn signal and main beam lever also operates the ⇒ fig. 58 parking lights and the headlight flasher. –...
  • Page 100: Interior Lights

    Lights and visibility • Interior lights The main beam headlights can only be switched on if the dipped beam headlights are already on. The warning lamp then comes on in the instru- ment panel. • Front interior light The headlight flasher comes on for as long as you pull the lever – even if no other lights are switched on.
  • Page 101: Visibility

    Lights and visibility Luggage compartment light* Note If not all the vehicle doors are closed, the interior lights will be switched off The light is activated when the tailgate is open, even when the ignition and after approx. 10 minutes, providing the key has been removed and the cour- lights are turned off.
  • Page 102: Windscreen Wipers

    Lights and visibility Switching off the wipers Note – Move the lever to position Incorrect use of the sun visors (e.g. pulling them downwards once they are open) may result in broken hinges. This damage is not covered by the vehicle Interval wipe warranty.
  • Page 103 Lights and visibility Rain sensor* WARNING • The rain sensor controls the frequency of the windscreen Worn and dirty wiper blades reduce visibility and safety levels while wiper intervals, depending on the amount of rain. driving. • In cold conditions, you should not use the wash / wipe system unless you have warmed the windscreen with the heating and ventilation system.
  • Page 104 Lights and visibility Switching off the interval wipe function Note – Pull the lever back from position towards the steering wheel. • Do not put stickers on the windscreen in front of the sensor. This may The wiper will continue to function for a short period if you switch cause sensor disruption or faults.
  • Page 105: Rear View Mirrors

    Lights and visibility Headlight washer* Interior mirror The headlight washers clean the headlight lenses. It is dangerous to drive if you cannot see clearly through the rear window. The headlight washers are activated automatically when the windscreen washer is used and the windscreen wiper lever is pulled towards the steering Manual anti-dazzle function for interior mirror wheel for at least 1.5 seconds –...
  • Page 106 Lights and visibility Switching on the anti-dazzle function Electric exterior mirrors* ⇒ page 103, fig. – Press button 65. The indicator lamp turns The exterior mirrors can be adjusted using the rotary knob in the driver door. Anti-dazzle function The anti-dazzle function is activated every time the ignition is switched on. The green indicator lamp lights up in the mirror housing.
  • Page 107 Lights and visibility – The mirrors demist for some minutes to prevent draining the Note battery. • If the electrical adjustment ever fails to operate, the mirrors can be – If necessary, press the button again to repeat the function. adjusted by hand by lightly pressing the edge of the mirror glass.
  • Page 108: The Importance Of Correct Seat Adjustment

    Always keep your feet on the footwell when the vehicle is moving; never Proper seat adjustment optimises the level of protection rest them on the dash panel, out of the window or on the seat. This is also offered by seat belts and airbags.
  • Page 109: Head Restraints

    Fig. 68 Side view: head restraints and seat belts correctly adjusted – Adjust the head restraint so that the top is at the same level as the top of your head or as close as possible to the same level as ⇒...
  • Page 110 Please observe the safety warnings in ⇒ page 107, “Correct adjust- Adjusting height (rear seats) ment of head restraints”. – Press the button on the side and pull upwards to the desired position. Note • To fit and remove the rear head restraints, gently tilt the seat backrest forwards.
  • Page 111: Front Seats

    WARNING Front seats • Never adjust the driver or front passenger seat while the vehicle is in motion. While adjusting your seat, you will assume an incorrect sitting Adjustment of the front seats position. Risk of fatal accidents. Adjust the driver or front passenger seat only when the vehicle is stationary.
  • Page 112 Heated seats* Caution The front seat cushions and backrests can be heated electri- To avoid damaging the heating elements, please do not kneel on the seat or apply sharp pressure at a single point to the seat cushion and backrest. cally.
  • Page 113: Rear Seats

    – Pull the release button in the direction of the arrow and fold the backrest forwards – Insert the head restraints in the spaces on the rear of the seat cushion which are visible when the seat cushion is lowered. Folding seat forward –...
  • Page 114: Storage Compartment

    Do no trap or damage seat belts when raising the backrest. • After raising the backrest, check it has engaged properly in position. Do this by pulling on the central seat belt or directly on the backrest and check that the position lever is in the neutral position. •...
  • Page 115 Seats and storage compartments Navigator bracket on dash panel* Note • Your vehicle can be equipped with a portable navigator The storage compartment cooling is only activated when the air condi- tioning is running with the cooling mode selected. mounting bracket. •...
  • Page 116 There is a storage pocket on the rear of the front seats. Fig. 78 Storage compart- ment under the front seat To open – The compartment is opened by pulling on the lever and assisting it with your hand.
  • Page 117 Seats and storage compartments Front drink holder* Rear drink holder* Fig. 80 Front cup holders Fig. 81 Cup holder in the in the centre console centre console There are two cup holders in the centre console in front of the gear lever On the rear part of the centre console, behind the hand brake, there is a cup ⇒...
  • Page 118: Ashtrays, Cigarette Lighter And Power Socket

    Seats and storage compartments Ashtrays, cigarette lighter and power socket Cigarette lighter* Ashtray* Fig. 83 Lighter ⇒ fig. 83 to activate it ⇒ – Press on the cigarette lighter Fig. 82 Ashtray – Wait for the lighter to pop out slightly. Opening and closing the ashtray –...
  • Page 119 Seats and storage compartments • Power socket Before using any electrical accessories, see the instructions in ⇒ page 181. Power socket in the luggage compartment* Electrical equipment can be connected to the 12 volt socket. Fig. 84 Front power socket The 12 Volt cigarette lighter power socket can also be used for other electrical components with a power rating of up to 120 Watt.
  • Page 120 Seats and storage compartments AUX/USB input connection* Note • The power sockets will only work with the ignition on. • The use of electrical appliances with the engine switched off will cause a battery discharge. Auxiliary audio input connection (AUX)* Fig.
  • Page 121: First-Aid Kit, Warning Triangle, Fire Extinguisher

    Seats and storage compartments First-aid kit, warning triangle, fire First-aid kit and fire extinguisher* extinguisher Warning triangle* Fig. 89 Housing for the first-aid kit in the luggage compartment. Fig. 88 Housing for the The first-aid kit can go in the storage compartment which is located under the emergency warning luggage compartment floor.
  • Page 122: Luggage Compartment

    Seats and storage compartments • Before acquiring accessories and emergency equipment see the instruc- – Secure the load with a luggage net* or with non-elastic straps tions in “Accessories and spares” ⇒ page 181. secured to the fastening rings ⇒ page 121. WARNING Luggage compartment •...
  • Page 123 Seats and storage compartments Fastening rings Luggage net* There are four fastening rings in the luggage compartment, The luggage net can be used to secure and retain light items which can be used to secure loads. in the luggage compartment. Fig.
  • Page 124 Seats and storage compartments Rear shelf Note • Ensure that, when placing items of clothing on the luggage compartment cover, rear visibility is not reduced. Fig. 93 Rear shelf Removing the shelf ⇒ fig. 93 – Unhook the loops from housings –...
  • Page 125: Roof Rack

    Seats and storage compartments Rear shelf with storage compartment* To remove the storage compartment – Remove the rear shelf and pull the storage compartment ⇒ fig. upwards holding it by the edges The storage compartment can be accessed from the rear seats by lifting the ⇒...
  • Page 126 Seats and storage compartments • For safety reasons, only luggage racks and accessories approved by SEAT should be used. • It is essential that you follow the assembly instructions included with the bars exactly, being especially careful to position the front and rear luggage compartment cover bars on the special housings on the longitudinal bars.
  • Page 127: Air Conditioning

    Air conditioning Air conditioning Heating is needed to defrost the windows quickly, is only available when the engine has reached its operating temperature. Blower Controls The air flow can be set at four speeds with switch . The blower should always be set at the lowest speed when driving slowly.
  • Page 128 Air conditioning – Set the airflow to the desired direction using air distribution WARNING (continued) control • In air recirculation mode, no cold air from the outside enters the vehicle – Open the relevant air outlets. interior. The windows can quickly fog over if the heating is switched off. Therefore, never leave the air recirculation mode switched on for a long Interior heating time (risk of accident).
  • Page 129 Air conditioning – Close outlets Heating Maximum heat output, which is needed to defrost the windows quickly, is – Open and turn outlets towards side windows only available when the engine has reached its operating temperature. Once the windows are demisted and as a preventive measure, the control Note ...
  • Page 130: Air Conditioning

    Air conditioning Air conditioning* Air distribution Switch on symbol Main air output through outlets: Controls 1, 2   1, 2, 5  3, 4 Outlets can be closed or opened separately and the air flow directed as required. Fig. 99 Air conditioning controls on the dash panel The air conditioning system only works when the engine is running...
  • Page 131 Air conditioning – Turn the fan control to one of the two levels depending on the Vehicle interior heating or cooling system speed required. – Rotate the temperature control to the desired level of comfort. – Close outlets – Open and turn outlets towards side windows Temperature selector ⇒...
  • Page 132 Air conditioning  – Turn the temperature control switch until the desired interior Air recirculation temperature is reached. Air recirculation mode prevents fumes or unpleasant smells – Turn the blower switch to any of of the settings 1-4. from coming from the outside. –...
  • Page 133: Climatronic

    Air conditioning • Climatronic If the function is not deactivated by pressing the button, this will deacti- vate after approx. 20 min. Control switches Economic use of the air conditioning When the air conditioning is switched on, the compressor consumes engine power and has influence on fuel consumption.
  • Page 134 Air conditioning AC indicator (Cooling connected) Automatic mode Interior temperature indicator selected In automatic mode air temperature, air flow and distribution Air flow direction indicator are automatically regulated so that a specified temperature is Fan speed increase attained as quickly as possible, and then maintained. Fan speed decrease Interior temperature increase Switching on automatic mode...
  • Page 135 Air conditioning Manual mode Switching the air conditioning on and off Pressing the button the air cooling system can be switched off in order to In manual mode the air temperature, flow, and the desired air save fuel. The temperature continues to self-regulate. The set temperature distribution can be adjusted.
  • Page 136: General Notes

    Air conditioning WARNING (continued) Note • over. Therefore, never leave the air recirculation mode switched on for a If the humidity and temperature outside the vehicle are high, condensa- long time (risk of accident). tion can drip off the evaporator in the cooling system and so forming a puddle underneath the vehicle.
  • Page 137: Steering

    • Adjust the driver seat or steering wheel so that there is a distance of at ⇒ fig. least 25 cm between the steering wheel and your chest 102. If you fail to observe the minimum distance, the airbag will not protect you.
  • Page 138: Safety

    Driving Safety WARNING • The Electronic Stability Programme (ESP) cannot defy the laws of Electronic Stability Programme (ESP)* physics. This should be kept in mind, particularly on slippery and wet roads and when towing a trailer. ESP helps make driving safer in certain situations. •...
  • Page 139 The engine can only be started using a genuine SEAT key with its correct code. Every time the vehicle is started again, the ignition key must be turned to position .
  • Page 140: Starting And Stopping The Engine

    Never use “cold start sprays”, they could explode or cause the engine Starting petrol engines to run at high revs. Risk of injury. The engine can only be started using a genuine SEAT key with Caution its correct code. •...
  • Page 141 Driving ⇒ page 136, fig. 104 – Turn the ignition key to position . The Caution indicator lamp will light for engine pre-heating. • When the engine is cold, you should avoid high engine speeds, driving at – When the warning lamp turns off, turn the key to position full throttle and over-loading the engine.
  • Page 142: Start-Stop Function

    The temperature of the passenger compartment exceeds the convenience status of the Start-Stop function 106. limits ( button). • If the airflow is increased by more than 3 presses. Start-Stop function conditions • • Temperature setting HI or LO is selected. The driver seat belt must be buckled.
  • Page 143 Driving • The engine coolant temperature is insufficient. Switching the Start-Stop function on and off • The alternator is faulty, for example the V-belt has ruptured. • If any of the conditions described in the previous section are not fulfilled. WARNING Never allow the vehicle to move with the engine off for any reason.
  • Page 144: Manual Gearbox

    Driving Manual gearbox Driver messages Driving with a manual gearbox Fig. 106 Display on the instrument panel during Start-Stop function operation. Fig. 107 Centre Console: gear shift pattern of a 5- speed manual gearbox When the engine is turned off by the Start-Stop function, this is displayed on the instrument panel.
  • Page 145: Automatic Gearbox

    Driving Automatic gearbox* The reverse lights light up when the reverse gear is selected and the ignition is on. Gearbox programmes WARNING • The automatic gearbox has got two gearbox programmes. When the engine is running, the vehicle will start to move as soon as a gear is engaged and the clutch released.
  • Page 146 Driving If you select the sport programme, S, you will drive in a sporty mode, i.e. a programme in which shifts into high gears are postponed in order to use the full power of the engine. Selector lever lock functions The selector lever lock in position P or N prevents gears from being engaged inadvertently, which would cause the vehicle to move.
  • Page 147 Driving Driving a car with an automatic gearbox Stopping briefly – If stopping for a short time, keep the vehicle stationary by The gearbox changes gear ratios automatically as the vehicle pressing the foot brake hard to prevent the car moving back- moves.
  • Page 148 Driving – With a selected gear, accelerate slowly and at the same time, WARNING (continued) release the handbrake. • Before driving down a long, steep slope, it is advisable to reduce speed and change into a lower gear. The steeper the slope, the lower the needed gear. This increases the braking •...
  • Page 149 Driving Changing gear in tiptronic mode* General information about driving in tiptronic mode The tiptronic system allows the driver to select gears manu- Changing gear in tiptronic mode ally – Press the selector lever from position D to the right into the tiptronic selector gate.
  • Page 150 Driving Changing gears in the normal or sport programme using the steering wheel Selector lever positions paddle levers The selected gear is displayed on the side of the selector lever and on the ⇒ page 147, fig. 113 If the paddle levers are used in the normal or sport instrument panel screen.
  • Page 151 Driving N - Neutral (idling) WARNING (continued) If this position is selected, the gearbox is in neutral. Power is not transmitted • to the wheels and the engine does not have a braking function. As a driver, you should never leave your vehicle if the engine is running and a gear is engaged.
  • Page 152: Handbrake

    Driving WARNING (continued) WARNING (continued) • • Never remove the key from the ignition if the vehicle is in motion. The You should use the kickdown feature only when traffic and weather steering lock could suddenly engage, and you would not be able to steer conditions allow it to be used safely.
  • Page 153 Driving Applying the handbrake Parking ⇒ fig. – Pull the handbrake lever up firmly 115. The handbrake should always be firmly applied when the vehicle is parked. Releasing the handbrake – Pull the lever up slightly and press the release knob in the direc- Always note the following points when parking the vehicle: ⇒...
  • Page 154: Acoustic Parking Aid System

    Driving WARNING (continued) WARNING (continued) • • Never park where the hot exhaust system could ignite inflammable If the engine stalls, depress the brake pedal or use the hand brake materials, such as dry grass, low bushes, spilt fuel etc. immediately.
  • Page 155 Driving Reverse gear WARNING The distance warning will begin as soon as an obstacle is detected by the • system. The frequency of the bleeps emitted by the system will increase The sensors have blind spots in which obstacles may not be detected. •...
  • Page 156: Cruise Control

    Driving Cruise control* Switching the cruise control system on and off Description The cruise control system is able to maintain the set speed in the range of 30 km/h to 180 km/h. Once the speed setting has been saved, you may take your foot off the accel- erator.
  • Page 157 Driving Setting speed* Adjusting set speed* The speed can be altered without touching the accelerator or the brake. Fig. 117 Turn signal and main beam headlight lever: switch and rocker switch for the cruise Fig. 118 Turn signal and control main beam headlight lever: switch and rocker switch for the cruise...
  • Page 158 Driving • When you increase speed with the accelerator and then release the pedal, the if the clutch pedal is depressed, • system will automatically restore the set speed. This will not be the case, if the vehicle is accelerated to over 180 km/h, •...
  • Page 159 Driving Vehicles with a manual gearbox The system is completely turned off by moving the control all the way to the right hand side (OFF engaged), or when the vehicle is stationary, ignition off. Vehicles with an automatic gearbox To completely disengage the system, the selector lever must be placed in one of the following positions: P, N, R or 1 or with the vehicle stopped and the ignition turned off.
  • Page 161: Practical Tips

    Intelligent technology Practical Tips Intelligent technology Brakes Hydraulic Brake Assist (HBA)* The Hydraulic Brake Assist function (HBA) is only included in Brake servo vehicles with ESP. In an emergency, most drivers brake in time, but not with maximum force. The brake servo increases the pressure you apply to the brake pedal. It works This results in unnecessarily long braking distances.
  • Page 162: Anti-Lock Brake System And Traction Control Abs

    Intelligent technology However, ABS will not necessarily guarantee shorter braking distances in all WARNING (continued) conditions. The braking distance could even be longer if you brake on gravel • or on fresh snow covering a slippery surface. The brake assist system cannot defy the laws of physics. Slippery and wet roads are dangerous even with the brake assist system! Therefore, it is essential that you adjust your speed to suit the road and traffic conditions.
  • Page 163: Electronic Stability Programme (Esp)

    Intelligent technology The TCS is switched on automatically when the engine is started. If necessary, XDS* it may be turned on or off by briefly pushing the ESP button on the centre Driveshaft differential console. When the TCS is off, the warning lamp is lit.
  • Page 164 Intelligent technology Electronic Stability Programme (ESP)* Anti-lock brake system (ABS) ESP reduces the danger of skidding by braking the wheels individually. The anti-lock brake system prevents the wheels locking during braking The system uses the steering wheel angle and road speed to calculate the ⇒...
  • Page 165 Intelligent technology WARNING (continued) • Always adapt your driving style to suit road conditions and the traffic situation. Do not let the extra safety afforded by EDL tempt you into taking any risks when driving, this can cause accidents. Caution Modifications to the vehicle (e.g.
  • Page 166: Driving And The Environment

    Driving and the environment Driving and the environment Running-in Running in tyres and brake pads New tyres should be run-in carefully for the first 500 km. New Running in a new engine brake pads should be run-in carefully for the first 200 km. The engine needs to be run in over the first 1500 km.
  • Page 167: Exhaust Gas Purification System

    Driving and the environment Exhaust gas purification system If you drive with wet brakes, for example, after crossing areas of water, in heavy rainfall or even after washing the vehicle, the effect of the brakes is lessened as the brake discs are wet or even frozen (in winter). In this case the brakes should be dried by pressing the brake pedal several times.
  • Page 168 Driving and the environment Your vehicle is fitted with a DPF (Diesel particulate filter) if the vehicle data Caution sticker (back cover of the “Maintenance Programme”) lists the PR code 7GG ⇒ fig. or 7MG 121. Never run the fuel tank completely dry because the irregularity of the fuel supply may cause ignition problems.
  • Page 169: Economical And Environmentally Friendly Driving

    Driving and the environment Economical and environmentally friendly Avoid idling It is worthwhile switching off the engine when waiting in a traffic jam, at level driving crossings or at traffic lights with a long red phase. The fuel saved after only 30 - 40 seconds is greater than the amount of fuel needed to restart the engine.
  • Page 170 Environmental protection is a top priority in the design, choice of materials Avoid unnecessary weight and production of your new Seat. Every kilo of extra weight will put up the fuel consumption, so it is worth checking the luggage compartment occasionally to make sure that no unnec- Design measures for economical recycling •...
  • Page 171: Driving Abroad

    If the trailer has a 7-pin plug you will need to use an adapter cable. This is carry out limited repairs. available in any SEAT dealer. SEAT importers and distributors will gladly provide information about the Trailer weight / drawbar load technical preparations that you vehicle requires and also about necessary Never exceed the authorised trailer weight.
  • Page 172 Driving and the environment figures for your specific model, which may be lower than these figures for the Ball coupling of towing bracket* towing bracket, are given in the vehicle documents or in ⇒ Section “Tech- nical Data”. The ball coupling is provided with instructions on fitting and removing the ball coupling of the towing bracket.
  • Page 173 Driving and the environment Always brake in due course. If the trailer has an overrun brake, apply the brakes gently at first and then, firmly. This will prevent the jerking that can be caused by the trailer wheels locking. Select a low gear in due course before going down a steep downhill.
  • Page 174: Vehicle Maintenance And Cleaning

    Vehicle maintenance and cleaning Vehicle maintenance and cleaning General notes WARNING (continued) lems or damage the vehicle. The use of certain products may produce Regular washing and care help maintain the value of your noxious vapours; they should be used in well ventilated areas. vehicle.
  • Page 175: Care Of The Vehicle Exterior

    Vehicle maintenance and cleaning Care of the vehicle exterior Washing by hand Vehicle washing Automatic car washing tunnel – First soften the dirt and rinse it off with water. The vehicle paintwork is so durable that the vehicle can normally be washed –...
  • Page 176 Vehicle maintenance and cleaning – Increase the spraying distance for soft materials and painted WARNING (continued) bumpers. • Water, ice and salt on the brakes can reduce braking efficiency. Risk of – Do not use a high pressure cleaner to remove ice or snow from accident.
  • Page 177 Vehicle maintenance and cleaning Good quality hard wax products are available at your Authorised Service Caring for plastic parts Centre. Solvents damage plastic parts. Regular wax applications help to protect the paintwork from environmental contaminants ⇒ page 172. It is also effective in protecting against minor If normal washing fails to clean plastic parts, clean them with approved scratches.
  • Page 178 Vehicle maintenance and cleaning If possible, use a de-icing spray to remove ice. If you use an ice scraper, push Rubber seals maintenance it in one direction only without swinging it. If rubber seals are well looked after, they will not freeze so Use window cleaner or a silicone remover to clean rubber, oil, grease and sili- quickly.
  • Page 179 Vehicle maintenance and cleaning If this does not provide satisfying results, use a specialist chrome cleaning Alloy wheels product. Chrome cleaning products will remove stains from the surface. Every two weeks Caution – Wash salt and brake dust from alloy wheels. To prevent scratching chrome surfaces: •...
  • Page 180 Vehicle maintenance and cleaning Underbody protection The anti-corrosion protection is usually removed if the engine compartment is cleaned with grease removing solutions, or if you have the engine cleaned. The vehicle underbody is coated to protect it from chemical On commissioning this work, ensure that all surfaces, seams, joints and components in the engine compartment are given anti-corrosion treatment.
  • Page 181: Vehicle Interior Maintenance

    Vehicle interior maintenance Cloth seat covers and fabric trim cleaning Cloth seat covers and fabric trim on the doors, headlining etc. can be cleaned Plastic parts and dash panel cleaning with a special interior cleaner or with dry foam and a soft brush.
  • Page 182 • so a degree of care is required in everyday use and when looking after the Do not use chemical cleaning agents on the seat belts, as this can leather. impair the strength of the webbing. Ensure that belts do not come into contact with corrosive fluids.
  • Page 183: Accessories, Parts Replacement And Modifications

    Due to the way the electronic components Despite a continuous observation of the market, SEAT is not able to assess are linked together in networks, other indirect systems may be affected by the the reliability, safety and suitability of those parts SEAT has not approved. For faults.
  • Page 184: Roof Aerial

    You will require an external aerial for mobile phones and two- • transmitting power output in excess of 10 watts. way radios. SEAT has approved for your vehicle the use of mobile telephones and two-way radios providing under the following conditions:...
  • Page 185: Fitting A Towing Bracket

    Accessories, parts replacement and modifications The distance between the centre of the ball coupling and the ground should Note never be lower than the indicated value, even with a fully loaded vehicle and including the maximum drawbar load. Please observe the operating instructions of your mobile telephone / two-way radio.
  • Page 186 Accessories, parts replacement and modifications Caution • If the power socket is incorrectly installed, this could cause damage to the vehicle's electrical system. Note Due to the specific design of the exhaust, the fitting of a conventional towing bracket is not recommended for some sports versions. Please consult your Dealer.
  • Page 187: Checking And Refilling Levels

    Checking and refilling levels Checking and refilling levels Refuelling – Turn the key in the lock, without releasing the cap, clockwise through 180°. The tank flap is released manually. The tank holds approxi- – Remove the key and close the flap until it clicks into place. The mately 45 litres.
  • Page 188: Petrol

    Checking and refilling levels Petrol WARNING (continued) − Insert the fuel nozzle into the mouth of the canister as far as Petrol types possible. − If the spare fuel canister is made of metal, the filling nozzle must be The correct petrol types are listed on a sticker inside the fuel in contact with the canister during filling.
  • Page 189: Diesel

    Checking and refilling levels • Petrol additives The diesel engine has been designed to be used exclusively with diesel fuel conforming to standard EN 590. Never refuel or use petrol, kerosene, fuel Petrol additives improve the quality of the petrol. oil or any other type of fuel.
  • Page 190: Working In The Engine Compartment

    • Protect face, hands and arms by covering the cap with a large, thick batteries, are being constantly developed. SEAT provides a constant flow of cloth to protect against escaping coolant and steam. information to the Authorised Service Centres concerning modifications. For •...
  • Page 191 Checking and refilling levels find spots of oil or other fluids, have your vehicle inspected at a specialised WARNING (continued) workshop. • If any work has to be performed when the engine is started or with the engine running, there is an additional, potentially fatal, safety risk from the rotating parts, such as the drive belts, alternator, radiator fan, etc., and from the high-voltage ignition system.
  • Page 192 Checking and refilling levels Opening the bonnet Before opening the bonnet ensure that the windscreen wipers are in rest position. The bonnet is released from inside the vehicle. – To release the bonnet, pull the lever under the dash panel ⇒...
  • Page 193: Engine Oil

    Checking and refilling levels The correct oil specifications for your engine are listed in ⇒ page 192, “Oil If the bonnet does not close, do not press downwards. Open it once more and let it fall as before. properties”. Service intervals WARNING Service intervals can be flexible (LongLife service) or fixed (dependent on time/distance travelled).
  • Page 194 Checking and refilling levels Vehicles with diesel particulate filter* Engine oil additives The “Maintenance Programme” states whether your vehicle is fitted with a No type of additive should be mixed with the engine oil. The deterioration diesel particulate filter. caused by these additives is not covered by the warranty. Only VW 507 00 engine oil, with reduced ash formation, may be used in diesel engines equipped with particulate filter.
  • Page 195 Checking and refilling levels – Briefly run the engine at idle speed until the service temperature Caution is reached and stop. If the oil level is above the area do not start the engine. This could result – Wait two minutes. in damage to the engine and catalytic converter.
  • Page 196 Checking and refilling levels – To avoid over-filling with engine oil, you should top-up using Changing engine oil small quantities, wait a while and check the oil level before The engine oil must be changed at the intervals given in the adding any more oil.
  • Page 197: Coolant

    Checking and refilling levels • Never pour oil down drains or into the ground. WARNING (continued) • Use a suitable container when draining the used oil. It must be large • enough to hold all the engine oil. The G 12++ additive must be added in sufficient quantities to provide anti-freeze protection at the coldest ambient temperatures that can be expected.
  • Page 198 Checking and refilling levels  Checking the coolant level and topping up – If the level is below the “MIN” mark, top up with coolant. The correct coolant level is important for fault-free func- Topping up coolant tioning of the engine cooling system. –...
  • Page 199: Washer Fluid And Windscreen Wiper Blades

    Checking and refilling levels The windscreen washer and the headlight washers are supplied with fluid Caution from the windscreen washer fluid container in the engine compartment. The • container holds approx. 2 litres; in vehicles with headlight washers* it holds If you notice a change in the colour of the liquid because it has been in approx.
  • Page 200 Checking and refilling levels Changing windscreen wiper blades – Press on the securing tab. If the windscreen wiper blades are in perfect condition, you – Extract the wiper blade from the wiper arm. will benefit from an improved visibility. Damaged wiper Fitting the wiper blade blades should be replaced immediately.
  • Page 201 Checking and refilling levels Fitting the wiper blade Note – Insert the wiper blade onto the windscreen wiper arm until it • The wiper arms can be moved to the service position only when the clicks into place. bonnet is properly closed. Check the condition of the wiper blade regularly.
  • Page 202: Brake Fluid

    ⇒ page 241. The brake fluid reservoir has a black It is important that you use only brake fluid compliant with US standard FMVSS 116 DOT 4. We recommend the use of Genuine SEAT brake fluid. and yellow cap.
  • Page 203: Vehicle Battery

    The brake pads and fluid must be collected and disposed of according the Always be aware of the danger of injury and chemical burns as well as the applicable regulations. The SEAT Technical Service network has the necessary risk of accident or fire when working on the battery and the electrical...
  • Page 204 Checking and refilling levels • Do not expose the battery to direct sunlight over a long period of time, as WARNING (continued) the intense ultraviolet radiation can damage the battery housing. • charge. Never short the battery terminals. High-energy sparks can cause If the vehicle is left standing in cold conditions for a long period, protect injury.
  • Page 205: Wheels

    The battery has been developed to suit the conditions of its location and has special safety features. Storing tyres Genuine SEAT batteries fulfil the maintenance, performance and safety spec- – When you remove the tyres, mark them in order to maintain the ifications of your vehicle.
  • Page 206 Checking and refilling levels The tread depth of new tyres may vary, according to the type and make of tyre 2. The tyre pressures should only be checked when the tyres are and the tread pattern. cold. The slightly raised pressures of warm tyres must not be reduced.
  • Page 207 Checking and refilling levels Tyre service life Wear indicators The original tyres on your vehicle have 1.6 mm high tread wear indicators The service life of tyres is dependent on tyre pressure, driving ⇒ page 205, fig. 133, running across the tread. Depending on the make, style and fitting.
  • Page 208 Tyres should be replaced at least in pairs and not individually (i.e. both front We recommend that you use only wheels and tyres which have been approved by SEAT for your model. Failure to do so could impair vehicle tyres or both rear tyres together). A knowledge of tyre designations makes it...
  • Page 209 This can also apply to wheels of the same model. The use of The prescribed tightening torque for wheel bolts for steel and alloy wheels is wheels or tyres which have not been approved by SEAT for use with your 120 Nm.
  • Page 210 Checking and refilling levels Winter tyres must be fitted on all four wheels. For the sake of the environment Information on permitted winter tyre sizes can be found in the vehicle's regis- Fit your summer tyres again as soon as possible. They are quieter, do not wear tration documents.
  • Page 211 Checking and refilling levels Caution Remove the snow chains to drive on roads without snow. Otherwise they will impair handling, damage the tyres and wear out very quickly. Note In some countries, the speed limit for using snow chains is 50 km/h. The legal requirements of the country should be followed.
  • Page 212: If And When

    If and when If and when Vehicle tools, spare wheel WARNING (continued) • The factory-supplied jack is only designed for changing wheels on this Vehicle Tools model. On no account attempt to use it for lifting heavier vehicles or other loads.
  • Page 213: Changing A Wheel

    If and when Snow chains Note For technical reasons, snow chains must not be used on the compact tempo- • Seek professional assistance if the repair of a tyre puncture is not rary spare wheel. possible with the sealing compound. If you have a puncture on one of the front wheels when using snow chains, fit the compact temporary spare in place of one of the rear wheels.
  • Page 214 If and when After changing a wheel WARNING After changing the wheel there are still tasks to complete. Switch on the hazard warning lights and place the warning triangles in position. This is for your own safety and also warns other road users. –...
  • Page 215 If and when Wheel covers* Loosening the wheel bolts The wheel covers must be removed for access to the wheel The wheel bolts must be loosened before raising the vehicle. bolts Fig. 136 Changing the wheel: loosen the wheel bolts Fig.
  • Page 216 If and when WARNING Loosen the wheel bolts only about one turn before raising the vehicle with the jack, otherwise there is a risk of accident. Note • Do not use the hexagonal socket in the screwdriver handle to loosen or tighten the wheel bolts.
  • Page 217 If and when a large and stable base, if necessary. On a hard, slippery surface (such as Removing a wheel tiles) use a rubber mat or similar to prevent the jack from slipping. – Unscrew the bolts using the hexagonal tool in the handle of the screwdriver (vehicle tool) and place them on a clean surface ⇒...
  • Page 218: Tyre Repair Kit (Tyre-Mobility-System)

    If and when Anti-theft wheel bolts* Tyres with directional tread pattern A special adapter is required to turn the anti-theft wheel Tyres with directional tread pattern must be fitted so that they bolts. This is found in the tool box. rotate in the correct direction.
  • Page 219 If you have to dispose of a sealant can, go to a specialised waste service or to a SEAT Technical Service, where the product can be recycled in an appropriate – Take the tyre repair kit out of the luggage compartment.
  • Page 220: Fuses

    If and when Fuses Tyre repair The following sections describe the procedures for repairing Changing a fuse a tyre. Blown fuses must be replaced Using the sealing compound – The instructions on the container give detailed information on how to use the sealing compound. Inflating the tyre.
  • Page 221 Always keep some spare fuses in the vehicle. These are available from behind a cover at the left-hand end of the dash panel. When the steering SEAT dealers. wheel is on the right, the fuses are on the right-hand side of the dash panel, behind a cover.
  • Page 222 If and when Number Consumer Amps Number Consumer Amps Left-hand AFS headlights Fuel control unit / Bi-turbo engine supply Right-hand AFS headlights 12V power socket in luggage compartment Vacant Main beam headlight, right Number plate light /Dimmer /Side light indicator Main beam headlight, left/Coming Home light Electric fan motor...
  • Page 223 If and when Fuses in engine compartment above battery Number Consumer Amps Rear window wiper Dipped beam headlight (right side) Dipped beam headlight (left side) Fuses below steering wheel in relay holder PTC fuses Number Consumer Amps Supplementary electrical heating using air Fig.
  • Page 224: Bulbs

    On this type of headlight, the bulb changes must be made by the SEAT dealer, given The Xenon bulbs discharge 2.5 times the light flux and have an average lifespan of 5...
  • Page 225: Changing Bulbs. Double Headlights

    If and when Changing bulbs. Double headlights Main beam and side lights Double headlights summary Fig. 144 Main beam headlights Fig. 143 Double head- lights Main beam Side lights Dipped beam headlights Side lights Turn signal Fig. 145 Main beam headlights –...
  • Page 226 If and when – Move the loop in the direction of the arrow and remove the ⇒ page 223, fig. cover 144. ⇒ page 223, fig. 145 – Remove connector by pulling outward. – Extract the bulb and fit the replacement so that it sits correctly into the cut-out on the reflector.
  • Page 227: Changing Bulbs. Single Headlight

    If and when Changing bulbs. Single headlight Turn signal bulb Single headlights summary Fig. 148 Turn signal – Raise the bonnet. Fig. 149 Single headlight ⇒ fig. 148 – Rotate the bulb holder to the left and pull. Dipped/main beam headlights –...
  • Page 228 If and when ⇒ fig. 150 Dipped/main beam headlights – Remove the loop in the direction of the arrow and remove the cover. ⇒ fig. 151 – Remove the connector from the bulb. ⇒ fig. 151 – Unclip the retainer spring pressing inwards to the right.
  • Page 229: Changing The Rear Lights (On The Wing)

    If and when ⇒ page 226, fig. 152 Changing the rear lights (on the wing) – Remove the bulb holder outwards. – Replace the bulb by pulling it out and inserting the replacement. Overview of tail lights – Installation is done in the reverse order. Tail lights on side panel •...
  • Page 230: Changing The Rear Lights (On The Tailgate)

    If and when Changing the rear lights (on the tailgate) – Remove the lid with a flat screwdriver, placing it in notch ⇒ page 227, fig. 154. Overview of tail lights Changing bulbs Lights on the tailgate • Reverse lights •...
  • Page 231: Side Turn Signals

    If and when Side turn signals – Remove the lid with a flat screwdriver, placing it in notch ⇒ page 228, fig. 156. Changing bulbs Fig. 158 Side turn signals – Press the turn signal to the left or to the right to remove the bulb. Fig.
  • Page 232: Number Plate Light

    If and when Number plate light Interior light and front reading lights Fig. 159 Remove the Fig. 160 Front reading number plate light. light – Insert the flat part of a screwdriver into the special slot and To remove the glass remove the number plate light from its moulding.
  • Page 233: Additional Brake Lights

    If and when – First fit the glass with the fastening tabs over the frame of the switch. Next press the front part until the two long tabs click on the support. Additional brake lights* Given the difficulty involved in the replacement of this light it should be done by the Technical Service.
  • Page 234 If and when Jump leads Jump leads must comply with standard DIN 72553 (see manufacturer’s docu- mentation). The wire cross section must be at least 25 mm for petrol engines and at least 35 mm for diesel engines. Note • The vehicles must not touch each other, otherwise electricity could flow as Fig.
  • Page 235 If and when 6. Connect the other end of the black jump lead to a solid metal WARNING component bolted to the engine block or to the engine block • itself of the vehicle with the flat battery. Do not connect it to a Please note the safety warnings referring to working in the engine compartment ⇒...
  • Page 236: Towing And Tow-Starting

    If and when Towing and tow-starting Comments Please observe the following points if you use a tow-rope: Tow-starting* Notes for the driver of the towing vehicle The use of jump leads is preferable to tow-starting. – Drive slowly at first until the tow-rope is taut. Then accelerate We recommend that you do not tow-start your vehicle.
  • Page 237 If and when • Do not pull too hard with the towing vehicle and take care to avoid jerking the The steering wheel is locked when the vehicle has no electrical power. The tow-rope. When towing on an unpaved road, there is always a risk of over- vehicle must then be towed with the front wheels raised.
  • Page 238 If and when Rear towing eye Fig. 166 Rear towing ring There is a towing eye at the rear on the right below the rear bumper.
  • Page 239: Technical Specifications

    Description of specifications Technical Specifications Description of specifications Important information Abbreviations used in the Technical Specifications section Abbreviation Meaning Important Kilowatt, engine power measurement. Pferdestärke (horsepower), formerly used to denote engine The information in the vehicle documentation always has power. precedence.
  • Page 240 Description of specifications Vehicle identification data Vehicle data The data sticker is placed on the inside of the spare wheel recess in the The most important information is given on the identification luggage compartment. plate and the vehicle data sticker. ⇒...
  • Page 241: Information On Fuel Consumption

    Description of specifications Information on fuel consumption WARNING • Please note that the centre of gravity may shift when transporting Fuel consumption heavy objects; this may affect the vehicle’s handling and lead to an acci- dent. Always adjust your speed and driving style to suit road conditions The consumption and emission details shown on the vehicle and requirements.
  • Page 242: Wheels

    Description of specifications If the maximum permissible drawbar load cannot be met (e.g. with small, 175/70R14 Chains with links not exceeding 15 mm (including the empty and light-weight single axle trailers or tandem axle trailers with a 185/60R15 chain closure) wheelbase of less than 1 metre), at least 4% of the actual trailer weight is a legal stipulation for a drawbar load.
  • Page 243: Technical Specifications

    Technical Specifications Technical Specifications Checking fluid levels Overview You will find further explanations, instructions and restrictions on the tech- nical specifications as of ⇒ page 237. From time to time, the levels of the different fluids in the vehicle must be checked. Never fill with incorrect fluids, otherwise serious damage to the engine may be caused.
  • Page 244: Petrol Engine 1.2 51 Kw (70 Ps)

    Technical Specifications Petrol engine 1.2 51 kW (70 PS) Engine specifications Power output in kW (PS) 51 (70)/ 5400 Maximum torque in Nm at rpm 112/ 3000 No. of cylinders/ capacity 3/ 1198 in cm Fuel Super 95 RON /Normal 91 RON Research-Octane-Number = Anti-detonation rating of the petrol.
  • Page 245: Petrol Engine 1.4 63 Kw (85 Ps)

    Technical Specifications Engine oil capacity Approximate engine oil capacity with oil filter change 2.75 litres Petrol engine 1.4 63 kW (85 PS) Engine specifications Power output in kW (PS) 63 (85)/ 5000 Maximum torque in Nm at rpm 132/ 3800 No.
  • Page 246: Petrol Engine 1.2 Tsi 77 Kw (105 Ps)

    Technical Specifications Trailer weight Trailer without brakes Trailer with brakes, gradients up to 8% 1200 Trailer with brakes, gradients up to 12% 1000 Engine oil capacity Approximate engine oil capacity with oil filter change 2.8 litres Petrol engine 1.2 TSI 77 kW (105 PS) Engine specifications Power output in kW (PS) 77 (105)/5000...
  • Page 247: Petrol Engine 1.2 Tsi 77 Kw (105 Ps) Start&Stop

    Technical Specifications Weights Manual Automatic Gross vehicle weight in kg 1585 1605 Weight in running order (with driver) in kg 1145 1165 Gross front axle weight in kg Gross rear axle weight in kg Permitted roof load in kg Trailer weight Manual Automatic Trailer without brakes...
  • Page 248 Technical Specifications Performance Maximum speed in km/h Acceleration from 0-80 km/h in sec. Acceleration from 0-100 km/h in sec. 10.2 Weights Gross vehicle weight in kg 1590 Weight in running order (with driver) in kg 1150 Gross front axle weight in kg Gross rear axle weight in kg...
  • Page 249: Diesel Engine 1.2 Tdi Cr 55 Kw (75 Ps) Dpf Start&Stop Ecomotive

    Technical Specifications Diesel Engine 1.2 TDI CR 55 kW (75 PS) DPF Start&Stop Ecomotive Engine specifications Power output in kW (PS) 55 (75)/ 4200 Maximum torque in Nm at rpm 180/ 2000 No. of cylinders/ capacity 3/ 1199 in cm Fuel Min.
  • Page 250: Diesel Engine 1.2 Tdi Cr 55 Kw (75 Ps) Dpf

    Technical Specifications Engine oil capacity Approximate engine oil capacity with oil filter change 4.1 litres Diesel engine 1.2 TDI CR 55 kW (75 PS) DPF Engine specifications Power output in kW (PS) 55 (75)/ 4200 Maximum torque in Nm at rpm 180/ 2000 No.
  • Page 251: Diesel Engine 1.6 Tdi Cr 66 Kw (90 Ps) Dpf

    Technical Specifications Trailer weight Trailer without brakes Trailer with brakes, gradients up to 8% 1200 Trailer with brakes, gradients up to 12% 1000 Engine oil capacity Approximate engine oil capacity with oil filter change 4.1 litres Diesel engine 1.6 TDI CR 66 kW (90 PS) DPF Engine specifications Power output in kW (PS) 66 (90)/ 4200...
  • Page 252: Diesel Engine 1.6 Tdi Cr 77 Kw (105 Ps) With/Without Dpf

    Technical Specifications Weights Gross vehicle weight in kg 1665 Weight in running order (with driver) in kg 1225 Gross front axle weight in kg Gross rear axle weight in kg Permitted roof load in kg Trailer weight Trailer without brakes Trailer with brakes, gradients up to 8% 1200 Trailer with brakes, gradients up to 12%...
  • Page 253 Technical Specifications Performance Maximum speed in km/h Acceleration from 0-80 km/h in sec. Acceleration from 0-100 km/h in sec. 10.9 Weights Gross vehicle weight in kg 1665 Weight in running order (with driver) in kg 1225 Gross front axle weight in kg Gross rear axle weight in kg...
  • Page 254: Dimensions And Capacities

    Technical Specifications Dimensions and capacities Dimensions Length, width 4227 mm/ 1682 mm Height at kerb weight (with bars) 1453 mm Front and rear projection 847 mm/ 913 mm Wheelbase 2466 mm Turning circle 10.7 m Front Rear Track width 1463 mm 1457 mm Capacities Fuel tank...
  • Page 255: Index

    Index Index Anti-theft alarm Biodiesel ......187 Switching off ......82 Biodiesel fuel .
  • Page 256 Control lighting ......49 Child seat ....... 41 Unlocking .
  • Page 257 Avoiding pollution ....186 Seat belt tensioners ....26 Electronic differential lock .
  • Page 258 HBA ........159 Front seat adjustment Memory displays ..... . 54 Head restraints Lumbar support .
  • Page 259 Index Mirrors Exterior mirrors ..... . 104 Leather cleaning ......179 Interior mirror .
  • Page 260 Tyres ....... 164 Seat belts ....... 17 Rear seats .
  • Page 261 Comments ......234 front seat ......114 Towing .
  • Page 262 Maintenance ......174 Products for vehicle maintenance ..172 Why wear seat belts? ....17, 19, 27 Vehicle tools Windows .
  • Page 263 SEAT S.A. is permanently concerned about continuous development of its types and models. For this reason we ask you to understand, that at any given time, changes regarding shape, equipment and technique may take place on the car delivered. For this reason no right at all may derive based on the data, drawings and descriptions in this current handbook.

This manual is also suitable for:

Ibiza sc 2011

Table of Contents

Save PDF
