8.6 Setting Alarm Response Actions

Purpose:
The alarm response actions will be activated when an exception occurs, including Full Screen Monitoring, Audible Warning, Notify
Surveillance Center, and Send Email.
Full Screen Monitoring
When an alarm event (motion detection/video tampering detection/video loss detection) is triggered, the local monitor (VGA or BNC
monitor) display in full screen the video image from the alarming channel configured for full screen monitoring.
If alarms are triggered simultaneously in several channels, their full-screen images will be switched at an interval of 10 seconds (de-
fault dwell time). A different dwell time can be set by going to Menu> Configuration>Live View>Full Screen Monitoring Dwell Time.
Auto-switch will terminate once the alarm stops and you will be taken back to the Live View interface.
For motion detection alarm, you must select the channel(s) you want to make full screen monitoring (Menu>Camera>Mo-
tion>Handling>Trigger Channel).
Audible Warning
Trigger an audible beep when an alarm is detected.
Notify Surveillance Center
Sends an exception or alarm signal to remote alarm host when an event occurs. The alarm host refers to the PC installed with Re-
mote Client.
The alarm signal will be transmitted automatically at detection mode when remote alarm host is configured. Please refer to Chap-
ter 9.2.5 for details of alarm host configuration.
Send Email
Send an email with alarm information to a user or users when an alarm event is detected.
Please refer to Chapter 9.2.9 for details of Email configuration.
Trigger Alarm Output
Trigger an alarm output when an alarm is triggered.
Steps:
1. Enter Alarm Output interface.
Menu> Configuration> Alarm> Alarm Output
Select an alarm output and set alarm name and dwell time.
If "Manually Clear" is selected in the dropdown list of Dwell Time, you can clear it only by going to Menu> Manual> Alarm and
clicking Clear All.
Figure 8.17 Alarm Output Settings Interface
2. Set arming schedule of the alarm output.
Click to set the arming schedule of alarm output. Choose one day of a week and up to 8 time periods can be set within
each day.
Time periods shall not be repeated or overlapped.
82
