  • Page 1 User manual for X XMR404HD User Manual Mobile Digital Video Recorder  1-71...
  • Page 2 Notice The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products. All specifications are therefore subject to change without any notice. The purpose of this manual is to kindly aid the user for the operation for our MDVR. The user should have a basic understanding of computer operation and basic knowledge of how to connect peripherals and make some settings.
  • Page 3 Guarantee & Warnings 1) Electrical Apparatus Safety All installation and operation should comply with local electrical safety norms. 2) Transportation In the process of transportation, storage and installation, please avoid heavy stress, violent vibration, impact and water splashing. 3) Installation Install the equipment in accordance with the requirements, handle carefully.

  • Page 4: Table Of Contents

    Contents PRODUCT CHARACTERISTICS........................6 1.1. OVERVIEW............................6 1.2. SPECIFICATIONS..........................6 1.3. SYSTEM DIAGRAM..........................8 1.4. EXTERNAL INTERFACE......................... 8 1.5. HARD DISK INSTALLATION......................10 1.6. DEFINITION AND PICTURES OF EXTERNAL CABLES............10 LOCAL MANAGEMENT..........................12 2.1. LOGIN INTERFACE........................12 2.2. RECORD SEARCH:........................15 2.3. LOG SEARCH..........................
  • Page 5 3.4. MAINTENANCE..........................64 3.4.1. BASIC INFORMATION......................65 3.4.2. DEVICE MODULE........................65 3.4.3. STORAGE DEVICE........................ 66 3.4.4. VERSION INFORMATION..................... 67 3.5. CONFIGURATION...........................67 STORAGE CAPACITY CALCULATION.......................69 FAQ..................................70 5-71...

  • Page 6: Product Characteristics

    1. PRODUCT CHARACTERISTICS 1.1. OVERVIEW Streamax X3-H0204 is a functional Mobile Digital Video Recorder specially designed for vehicle video surveillance and remote monitoring. It has a high-speed processor and embedded operating system, combining with the most advanced H.264 video compression / decompression technology, 3G/4G network, GPS positioning technology, as well as WIFI.
  • Page 7 Boot up/Manual/Schedule/Alarm (sensor trigger, Recording Mode speed, acceleration, video loss, temperature) Pre-recording 0-60minutes Post-recording 0-30 minutes Mirror/Dual Recording Support Playback Channel 1 channel by local playback Playback Search Mode Date/time, channel, event 3G/4G EVDO/WCDMA/TDD-LTE/FDD-LTE WIFI 802.11b/g/n Network Ethernet RJ45 x 1(10/100M) IPC Ethernet 6-pin DJ M12(10/100M x 4, PON power supply) Locating...

  • Page 8: System Diagram

    1.3. SYSTEM DIAGRAM 1.4. EXTERNAL INTERFACE DIMENSION (Unit: mm) 8-71...
  • Page 9 FRONT PANEL Serial No. Description Hard disk module Status LED USB interface REAR PANEL 9-71...

  • Page 10: Hard Disk Installation

    Serial No. Print Description Power DC8-36V Power Input Sensor Switch Interface Serial Serial Interface A/V IN1~2 Analog Audio/Video Input 1~2 IPC1~4 PON Power Supply IPC1~4 GPS/BD Antenna Interface 3G/4G Antenna Interface WIFI Antenna Interface USB 2.0 Interface Network Interface Panel Control Panel Interface（CP4）...
  • Page 11 SERIAL PORT DEFINITION 11-71...

  • Page 12: Local Management

    2. LOCAL MANAGEMENT N9M supports 3 kinds of local setting methods: Connect monitor to mobile DVR and make sure it can play real time output image. Then connect mouse to USB interface at the front panel to have MDVR parameter setting. Connect the touch panel CP4 to mobile DVR to have MDVR parameter setting.
  • Page 13 Login Notice: Software is automatically assigned by user name and password, it can be divided into user and administrator privileges. Password options cannot be closed, but it can be set to null; when it is empty, user do not need to enter the password to login。...
  • Page 14 It will automatically switch once selecting the language. Currently, it supports Chinese and English; After switching languages, it will not restore language option when user restores the factory Settings; Default password and permission table is as follows: Default Password Related User Related Authority admin admin...

  • Page 15: Record Search

    Main interface 2.2. RECORD SEARCH: Video search interface contains video file search, video data backup and video playback function. When there is a hard disk or SD card, enter the video search interface. Following is the REC Search interface: 15-71...
  • Page 16 In the calendar, the color below the dates means: No color means no video. Green means common video. Red means alarm video. Yellow means there are alarms and the video files are automatically lock (lock video). Source: select the source of the video, there are main video, sub video and mirror video. The main record means HDD record while sub record and mirror record are dual-stream records.
  • Page 17 Video type: User can choose all record, alarm record or normal record. Channel: The channel is optional and mark with color that has record. The channel with gray cannot be chosen if there is no record. As to different record type, it will show different relates. Click search button in the record search detail page, user can enter then record search result page.

  • Page 18: Log Search

    middle of screen can switch the channels. The image stops and it will not exit automatically when playing to the last video of the day. Time period settings: Click the time setting button, select start time and end time, it will back up or playback the video in the selected time period.
  • Page 19 Log Search interface instruction: Calendar: the date with log will be marked on the calendar with green color. Remark: There is no color classification in the “log mark”, and all are green ones. 19-71...
  • Page 20 Log search interface instruction: Start time: the start time for searching log files End time: the end time for searching log files Log types: classification of log search, including the operation log and alarm log and locking log Operation log search interface instruction Log includes the following information: Log time: the time when event is triggered Log name: event content...

  • Page 21: System Status

    When lock the video file, system will record alarm log and lock log. The locked video file can only be unlocked from alarm log. 2.4. SYSTEM STATUS User can login the interface with no access restrictions. System- Version information  System- Modules ...
  • Page 22  System - Environment System-Storage:  22-71...

  • Page 23: Basic Setup

    2.5. BASIC SETUP Click setup button and enter the following interfaces: 2.5.1. REGISTER INFOMATION (SETUP VEHICLE INFORMATION) Register information-Device info:  Device ID: Currently, it is not useful.  Register information- Vehicle info 23-71...

  • Page 24: Time Setup

    Vehicle Number：When connected with PAD, the vehicle number is needed. Vehicle plate：Input manually. Line number：Input manually. Register information—Driver info:  Driver number: Input manually. Driver name: Input manually. 2.5.2. TIME SETUP  Time setup-General Date format: Setup the date format of device Time format: 24 hours or 12 hours 24-71...
  • Page 25 Time zone: Range from -12 district ~ +13 district  Time-Time Sync Date/Time: Device time, from 2000-01-01 to 2036-12-31 Satellite: Synchronize time with GPS satellite. Once GPS signal changes to valid, device will synchronize time Center Server: synchronize time with center server NTP sync: synchronize time with NTP server Remark: Synchronize time according to time zone...

  • Page 26: Start Up

    Enable: Select to enable Offset: After enabling DST, adjust the hour manually Mode: Setup DST according to week or date Start: Time to start DST End: Time to end DST 2.5.3. START UP  Startup-ON/OFF ON/OFF mode: 3 modes, including ignition, timer and ignition or timer. Ignition: Input ignition delay time for shutdown delay function Timer: When setup the start mode as Timer, please setup the start time and end time 26-71...

  • Page 27: User Setup

    Under this mode, MDVR’s start up or shut down time will not affect the ignition. Remark: If use setup as Ignition or Timer Mode, Ignition ON or Timer start time can trigger MDVR start up. And only when Ignition off and Timer end time, MDVR will shut down. Start-Sleep ...
  • Page 28 User name: The default ones are admin and user. User Group: It is divided into administrator and ordinary user. It supports delete user function. Select the user and click "Delete User" button. Please be noted that the administrator cannot be deleted. It supports add user function.

  • Page 29: Network

    Modify the user name and password to confirm the operation temporarily. There is no need to verify the old password, Administrator user name cannot be modified. 2.5.5. NETWORK In the basic settings, click Network Settings, enter the following interface, user can set network parameters.
  • Page 30 WEB port No.: The default is 80.  Network- WIFI Enable: Select to enable WIFI ESSID: Manually input the address of AP Encryption: It supports NONE, WEP and WPA Password: Manually input Static IP: Select to use static IP, or MDVR will get dynamic IP ...
  • Page 31 When entering the dialing setup interface, it searches the wireless module type automatically. It shows No Service when there is no module. Network type: The default one is Mix, 2G/3G and 2G/3G/4G optional. Dialing parameter：It includes access point, user name, password, data service number, and enter SIM parameters provided by the manufacturer.

  • Page 32: Application

    Protocol type: The default one is N9M. Enable network: There is local, WIFI and module optional Register server address: To run the registration server address. Registration server port: To run the registration server port. Media server address: To run the media server address. Media server port: To run the media server port.

  • Page 33: Surveillance

    Server: To run FTP server address. Port: To run FTP server port. (The default one is 21.) User name/password: The accounts distributed by FTP server. 2.6. SURVEILLANCE 2.6.1. LIVE VIEW Live view-->Preview  Real-time Setting Interface: Preview audio: Enable the audio when live view the video. Image setup: Set the live-view parameters, including brightness, contrast, etc.
  • Page 34 Screen: Totally 32 screens can be added. Mode: 1x1, 2x2, 3x3 optional. Channel: Included channel number. Duration: Duration for each screen. Edit: Delete or Edit. Add screen: Add polling screen Auto polling: Enable the auto pulling  Live view-Live OSD : It displays the information on screen, such as time, speed, license plate, GPS...

  • Page 35: Record

    2.6.2. RECORD Record-->General  Video type: Default is PAL, NTSC optional Overwrite: The earliest recording file will be deleted while the HDD or SD card is full to realize loop recording. Lock duration: Protect the record file to be deleted by fault, default is 7 days. Pre-recording: Pre-record before the alarm happens.
  • Page 36 Channel: The total channel numbers of the device, including analog and digital channels. Channel name: Change the name manually. Enable: Enable the main stream record function Resolution: The analog channel supports D1/HD1/CIF/WD1/WHD1/WCIF while the digital one supports 720P. Frame Rate: Frame Rate of the recording. Quality: Picture Quality of the recording.
  • Page 37 I frame: Enable to let the frame rate invalid, record file that does not have alarm is I frame only. Alarm quality: The alarm image is different from the normal recording image. Encode mode: It supports VBR and CBR modes. ...

  • Page 38: Ipc Setup

    Sub stream channel: It is selectable according to recording mode. Record-->OSD  Embedded key information to video file for easily check when playback. 2.6.3. IPC SETUP  IPC setup: 38-71...
  • Page 39 Channel: It includes the analog channels and IPC channels. Analog channel will not be shown if it connects to network camera. Enable: Enable to operate IPC. IP and port: Display channel details after searching. Setup: Search and edit IP camera recording parameters Fast setup: Search all the IP cameras in LAN network, and auto assign IP address to IP camera.

  • Page 40: Ptz

    2.6.4. PTZ Channel: It includes analog channels and IPC channels. Enable: Enable PTZ. Operate: It includes serial, N9M and ONVIF. It supports Pelco-D and Pelco-P PTZ protocols with serial mode. Address: It is valid with serial mode. Test: It is to test PTZ is available or not. Click it to pop up PTZ control panel. 2.7.
  • Page 41 Sensor number: The total alarm input numbers of MDVR. Sensor name: IO sensor name, it can set manually. The sensor name of alarm setting interface will update synchronously after setting. OSD name: The information embedded to video image. Copy: Copy the configuration and use it for other sensors. General-->Serial port: ...

  • Page 42: Snap Setting

    Model X3, X5 and X7 equip 4 serial ports, while model M1 and X1 equip only one RS232 port, but it can realize the following features: expansion, control panel, 485 bus, GPS data, three axis sensor, PTZ and integrated printer. ...
  • Page 43 Start time: Start to snap. End time: Stop snapping. Setup: Delete and set. Time snap: Enable to snap at the setting time. Add: To add snap period, and it supports 8 pieces at most. Snap Setting--> Trigger snap  43-71...

  • Page 44: Eco-Driving

    Trigger snap: It snaps when alarm is trigger. 2.7.3. ECO-DRIVING (It is still developing.) 44-71...

  • Page 45: Alarm

    2.8. ALARM 2.8.1. BASE Base-->Speed alarm  45-71...
  • Page 46 Name: The current name is over speed Enable：Enable or disable, tick to enable Alarm type: It includes the following types, important and general. Trigger: Over speed pre alarm difference: To set the pre alarm data. For example, if speed is 60 km/hour, and over speed pre alarm difference is 10 km/hour, TSS sends over speed alarm broadcast and records when it reaches 50 km/h.
  • Page 47 Channel: Link to recording channel, optional. Post recording: It means the recording duration after the alarm has been removed. Lock: Enable to link recording lock when there is alarm. 3G network: When it is set as sensor trigger dial mode, it enables 3G network as it triggers alarm. Linkage IO output: Enable to link alarm output when alarm is triggered.
  • Page 48 Name: The current name is panic. Enable：Enable to panic button. Alarm type: Important type and general type optional. Trigger: Click any button to delay the time till it reaches the setting time to alarm. Linkage: When alarm is triggered, link to business operation. 48-71...
  • Page 49 Channel: Link to recording channel, optional. Post recording: It means the recording duration after the alarm has been removed. Lock: Enable to link recording lock when there is alarm. 3G network: When it is set as sensor trigger dial mode, it enables 3G network as it triggers alarm. Linkage IO output: Enable to link alarm output when alarm is triggered.
  • Page 50  Base – IO alarm interface: Name: From Sensor1 to Sensor8 (It includes all the alarm input numbers.) Enable: Enable the sensor alarm. Alarm type: Important type and general type optional. Trigger: Low and high optional. It triggers alarm when it is low as default. Linkage: When alarm is triggered, link to business operation.
  • Page 51 Channel: Link to recording channel, optional. Post recording: It means the recording duration after the alarm has been removed. Lock: Enable to link recording lock when there is alarm. 3G network: When it is set as sensor trigger dial mode, it enables 3G network as it triggers alarm. Linkage IO output: Enable to link alarm output when alarm is triggered.

  • Page 52: Video

    2.8.2. VIDEO Video-Video loss  Name: The default name is video loss. Enable: Enable the video loss. Alarm type: Important type and general type optional. Trigger: 52-71...
  • Page 53 Video loss set: It includes all video channels that can be selected. Set period: Set the checking period when video loss alarm is triggered. Linkage: When alarm is triggered, link to business operation. 53-71...
  • Page 54 Channel: Link to recording channel, optional. Post recording: It means the recording duration after the alarm has been removed. Lock: Enable to link recording lock when there is alarm. 3G network: When it is set as sensor trigger dial mode, it enables 3G network as it triggers alarm. Linkage IO output: Enable to link alarm output when alarm is triggered.

  • Page 55: Advance

    2.8.3. ADVANCE Name: The default name is ACC alarm. Enable: Enable the ACC alarm. Trigger: Set the threshold value of X/Y/Z. Linkage: When alarm is triggered, link to business operation. 55-71...

  • Page 56: Maintenance

    Channel: Link to recording channel, optional. Post recording: It means the recording duration after the alarm has been removed. Lock: Enable to link recording lock when there is alarm. 3G network: When it is set as sensor trigger dial mode, it enables 3G network as it triggers alarm. Linkage IO output: Enable to link alarm output when alarm is triggered.

  • Page 57: Configuration

    After login, click setup>Maintenance, and then enter into the page as follow. 2.9.1. CONFIGURATION In the configuration page, user can export and import the configuration file. Insert flash drive to export the configuration file to the root folder, the file name is ConfigFile Insert flash drive to import configuration file into MDVR, and it will display the notice when import successfully.

  • Page 58: Upgrade

    2.9.3. UPGRADE In the page of upgrade, user can upgrade software. Put the upgrade file in flash drive. Currently, device firmware, microcontrollers firmware, CP4 firmware and IPC firmware can be put inside. Insert flash drive and enter the upgrade interface, click software upgrade and it will indicate that upgrade file is importing.

  • Page 59: Storage

    Remark: Make sure don’t power off during upgrading. Put the upgrade file into the folder “upgrade”, which is at the root directory if the USB drive It support upgrade firmware, LOGO, MCU, and MCU for CP4. Firmware and MCU will package in one file, and it will upgrade MCU first, and then firmware. The name of the LOGO are: logo_update(10.12.15).jpg and logo_cvbs(11.12.15).jpg Please don’t put many files in the same folder when it is upgrading, otherwise, it will upgrade one randomly.

  • Page 60: Default

    2.9.5. DEFAULT In this page, you can click the default button to reset the parameters to factory settings. Click reset to restore the original data. Remark: For, language, MAC address, register info, CMS server info, speed adaption parameter will not change during default settings.

  • Page 61: Main Interface

    3.2. MAIN INTERFACE 61-71...

  • Page 62: Playback

    Icons: quad, 9-split, preview, next page, sound, capture and video parameters. Stream switch: main stream, sub-stream and network transmission sub stream. Log out: log out and come to the log in interface 3.3. PLAYBACK 62-71...
  • Page 63 If the date is marked as color green, it means there is recording. 63-71...

  • Page 64: Maintenance

    Recording playback window: Video window, play time-line, play control button, window switch... Record list: It displays all the record. Click backup download video file to local computer hard disk. 3.4. MAINTENANCE 64-71...

  • Page 65: Basic Information

    3.4.1. BASIC INFORMATION Basic information: It contains the current state & history state of channel video and storage. 3.4.2. DEVICE MODULE Device module: It is about the current state of module, WIFI module and satellite location module. 65-71...

  • Page 66: Storage Device

    3.4.3. STORAGE DEVICE Storage device: There are the volume information & format operation of storage (hard disk/flash drive/SD card), and the path of snap & record backup. 66-71...

  • Page 67: Version Information

    3.4.4. VERSION INFORMATION Version information: There are device type, name, firmware version, MCU version, CP3/4 version, upgrade, configuration file export and configuration file import.  Log: There is Log type (operation log, alarm log and locked log), operation type (IO alarm, panel alarm, speed alarm, video loss and ACC alarm) date, and log export.
  • Page 68 The parameter setting is the same as the local setting. User can view the operation at the local setting. 68-71...

  • Page 69: Storage Capacity Calculation

    4.STORAGE CAPACITY CALCULATION Image Quality & Streams Resolution Image quality 720P 6144 4800 4128 3456 2784 2112 1440 2662 1997 1599 1331 1170 1040 WHD1 1664 1248 Stream WCIF 1040 Kbps 2048 1536 1230 1024 1280 Record File Size Calculation Rec.

  • Page 70: Faq

    5.FAQ The system can’t start? Usually this problem results from the incorrect power connection. Please follow below steps to check the power connection: Check the input power, whether the power wire is connected correctly, whether the ground wire is connected back to the battery, and whether the fuse on the power wire is in good condition. Check whether the ACC signal wire input to the power is with voltage higher than 7 V.
  • Page 71 of the task table. Which IP waterproof level does Streamax device support? Currently, X7 and X5-E0804 support waterproof IP 54. How to install the WIFI antenna? The antenna must be installed on unobstructed place of the roof, and be fixed with glue. The device cannot be shut down when in ignition ON/OFF mode.
