• Max. Bitrate Mode: Set the mode to General or Customize (32-3072Kbps).
• Max Bitrate (Kbps): Select or customize the maximum bitrate for recording.
• Max. Bitrate Range Recommended: A recommended Max. bitrate range is provided for
reference.
4) Configure the pre-record, post-record time and expired time.
•
Pre-record: The time you set to record before the scheduled time or event. For example, when an alarm triggered the
recording at 10:00, if you set the pre-record time as 5 seconds, the camera records it at 9:59:55.
•
Post-record: The time you set to record after the event or the scheduled time. For example, when an alarm triggered
the recording ends at 11:00, if you set the post-record time as 5 seconds, it records till 11:00:05.
•
Expired Time (day): The expired time is the longest time for a record file to be kept in the HDD, if the deadline is
reached, the file will be deleted. You can set the expired time to 0, and then the file will not be deleted. The actual
keeping time for the file should be determined by the capacity of the HDD.
•
Record Audio: Check the checkbox to record the sound, or uncheck to record the image without sound.
•
Enable 960 Mode: Enable the encoding at WD1 (PAL: 960×576, NTSC: 960×480) resolution. You can also uncheck
the checkbox to disable it.
5) If you want to copy the current main stream settings to other camera (s), click Copy to enter the Copy Camera interface.
Select the camera (s) and click OK to finish the copy settings.
6) On the Record settings interface, click Apply to save the settings.
You can click the Restore button to restore the current main stream settings to the default parameters.
3. Set encoding parameters for sub-stream
1) Click the Substream tab to enter the Substream settings interface.
2) Configure the parameters for the sub-stream. Refer to the steps of main stream settings.
3) Click Apply to save the settings.
You can click the Restore button to restore the current sub-stream settings to the default parameters.
4) If you want to copy the current sub-stream settings to other camera (s), click Copy to enter the Copy Camera interface.
Select the camera (s) and click OK to finish the copy settings.

5.2 Configuring Record Schedule

Purpose:
Set the record schedule, and then the camera automatically starts/stops recording according to the configured schedule.
Steps:
1. Enter the Record Schedule interface.
Menu>Record>Schedule
2. Configure Record Schedule
34
Figure 5.4 Copy Camera Settings
Figure 5.5 Encoding Parameters-Sub-stream
