6 Spare parts

6.1 Spare part list

Item no. Item designation
Controller:
122973 Controller excl. Teach Pendant CB3.1 UR3 (With cabinet)
124903 Controller OEM CB3.1 UR3 (Without Teach Pendant and cabinet)
122091 Teach Pendant incl. Touch Screen & power cable UR3, UR5 & UR10
180001 Stylus Pen
171010 USB Flash 2 GB for UR system SW
122650 Motherboard kit CB3.1
172290 Safety Control board kit
177002 Power Supply Unit 12V
177003 Power Supply Unit 48V
172080 Current Distributor PCB
122745 Energy-eater incl. fan
164228 Connector Epic w. cable UR3 (Controller output connector to robot arm)
171031 RAM module DDR3L
177503 Filter kit for controller
106800 Euromap E67 kit CB3
122671 Euromap E67 Bypass Plug
122673 Euromap E67 module CB3
123670 Euromap E67 cable 6 m
Robot arm:
122030 Base Mounting Bracket incl. Cable 6 m UR3
124122 Joint Size 2 Base UR3
124222 Joint Size 2 Shoulder UR3
124321 Joint Size 1 Elbow UR3
104003 Elbow counterpart and Lower arm kit UR3
124120 Joint Size 0 Wrist 1 UR3
124220 Joint Size 0 Wrist 2 UR3
124320 Joint Size 0 Wrist 3 UR3
122020 Tool Mounting Bracket UR3
103303 Sealing set UR3, external. Visible flat rings between joints
103413 Lid set complete UR3 incl. seal in the lids
