Selection
3.1.7 Relay Option MCB 105
The MCB 105 option includes 3 pieces of SPDT contacts and must be fitted into option slot B.
Electrical Data:
3 3
Max terminal load (AC-1)
Max terminal load (AC-15 )
Max terminal load (DC-1)
Max terminal load (DC-13)
Min terminal load (DC)
Max switching rate at rated load/min load
1) IEC 947 part 4 and 5
When the relay option kit is ordered separately the kit includes:
•
Relay Module MCB 105
•
Extended LCP frame and enlarged terminal cover
•
Label for covering access to switches S201, S202 and S801
•
Cable strips for fastening cables to relay module
Illustration 3.5 Relay Option MCB 105
A2-A3-A4-B3
1)
IMPORTANT! The label MUST be placed on the LCP frame as
shown (UL approved).
Table 3.5 Legend to Illustration 3.5 and Illustration 3.6
54
Design Guide
1)
(Resistive load)
1)
(Inductive load @ cosφ 0.4)
1)
(Resistive load)
1) (Inductive load)
1
2
A5-B1-B2-B4-C1-C2-C3-C4
Danfoss A/S © Rev. 06/2014 All rights reserved.
240 V AC 2A
240 V AC 0.2 A
24 V DC 1 A
24 V DC 0.1 A
5 V 10 mA
-1 -1
6 min /20 s
