Graphical User Interface
(GUI)
 Click Basic report or Full report.
Figure 35 - Diagnostic Report Generation
Figure 36 - Diagnostic Report Ready
 Click download to store the diagnostics report as an html file or click here to open
the report in another browser window.
The following screenshot displays an extract of a basic diagnostics report.
Figure 37 – Part Diagnostics Report
