Appendix C – Technical
Specifications
Very High Stability (optional)
• Stability: ±2x10 over 0°C to 65°C;
• Ageing:
Generic
Monitor and control interfaces
• Web based GUI;
• Diagnostics report, alarm log • RMCP over TCP-IP/UDP and RS232/RS485;
• SNMP v2c.
Alarm interface
• Electrical dual contact closure alarm contacts;
• Connector 9-pin sub-D (F);
• Logical interface and general device alarm.
Physical
• 1RU, width: 19", depth 51 cm, 6 k;
• Power supply:
90-130 & 180-260 Vac, 105 VA, 47-63 Hz;
-
- Temperature - Operational: 0°C to 40°C - Storage: -40 to +70°C;
• Humidity: 5% to 85% non-condensing;
• CE label.
version 3.2
105
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
± 0.5 ppb/day ± 500 ppb/10 year.
