Modulation &
Baud rate DVB-S Q/8PSK, 16QAM 5Mbaud
DVB-S Q/8PSK, 16QAM 15Mbaud*
DVB-S Q/8PSK, 16QAM 30Mbaud*
DVB-S Q/8PSK, 16QAM 45Mbaud*
DVB-S/S2 QPSK 5Mbaud*
DVB-S/S2 QPSK 15Mbaud*
DVB-S/S2 QPSK 30Mbaud*
DVB-S/S2 QPSK 45Mbaud*
DVB-S/S2 Q/8PSK 5Mbaud*
DVB-S/S2 Q/8PSK 15Mbaud*
DVB-S/S2 Q/8PSK 30Mbaud*
DVB-S/S2 Q/8PSK 45Mbaud*
DVB-S/S2 Q/8PSK, 16QAM, 16APSK 5Mbaud*
DVB-S/S2 Q/8PSK, 16QAM, 16APSK 15Mbaud*
DVB-S/S2 Q/8PSK, 16QAM, 16APSK 30Mbaud*
DVB-S/S2 Q/8PSK, 16QAM, 16APSK 45Mbaud*
DVB-S/S2 Q/8PSK, 16QAM, 16/32APSK 5Mbaud*
DVB-S/S2 Q/8PSK, 16QAM, 16/32APSK 15Mbaud*
DVB-S/S2 Q/8PSK, 16QAM, 16/32APSK 30Mbaud*
DVB-S/S2 Q/8PSK, 16QAM, 16/32APSK 45Mbaud*
Additional
Options
Category
10MHz reference
In/Out High stability
Very high stability
Predistortion Equalink *
Encryption BISS (**)
BISSM (**)
Security AES 64 bit encryption *
Baseband frame (only with Ethernet interface)
Input frame
Services
Category
Assistance Care Pack Basic
Care Pack Extended
(*) upgrade via license key (**) Not available with
DualFlow options
Option AA-06 IF+Lband: Switching the IF frequency from 70 to 140MHz or
140MHz to 70MHz has no impact on the L-band frequency.
