Graphical User Interface
(GUI)

6 GRAPHICAL USER INTERFACE (GUI)

6.1

Introduction

The graphical user interface (GUI) is a web application that gives remote access to
the device and allows the client to remotely:
• Configure the device after physical installation;
• Monitor the status;
• Check past events;
• Adjust parameter settings;
• Change or create configurations.
6.2

Opening the GUI

Proceed as follows to open the GUI on your computer:
1. Open a web browser on your computer.
2. Type the IP address of your device in the address bar of the browser. Do not
forget to type http:// in front of the IP address;
3. Press Enter;
4. If the user profile guest is:
a. Not disabled and not password protected, you are automatically logged in as
a guest;
b. Disabled and/or password protected, you see a User identification dialog
box. Enter your username and password.
version 3.2
47
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
The GUI is optimized for displays with a screen resolution of
1024 x 768 or higher.
Newtec advises to use Firefox 3 (and higer) or Google Chrome as
standard browser, but the GUI can also run on other compatible
browsers like Internet Explorer 7, Safari, ...
