Graphical User Interface
(GUI)
To navigate more easily in the tree structure, expand or collapse a branch of the
tree or the complete tree with the buttons in the navigation bar above the tree.
Figure 21 – Tree Navigation Bar
The following table describes the function of each button in the tree navigation bar
(Refer to Figure 21):
Button
No.
1
2
3
4
Table 6 – Tree Navigation Bar Buttons
version 3.2
53
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
Button
Description
function
Expand Expands the selected branch of the tree structure.
Collapse Collapses the selected branch of the tree structure.
Expand All
Expands the complete tree structure.
Collapse All Collapses the complete tree structure.
