Newtec AZ110 User Manual page 60

Graphical User Interface
(GUI)
6.3.4.2 Configuration Tab
Figure 26 - Configuration Function Controls Tab
The icons behind the configuration names support to:
• Save the current configuration to persistent memory (
example;
• Load a stored configuration (
The Import and Export buttons below the list of different configurations support to:
• Import configurations from a ".cfg" file from the local PC. Refer to paragraph
6.4.7;
• Export all saved configurations to a ".cfg" file to a local PC.
It is possible to Edit the name of an existing configuration by double clicking on the
configuration name that must be renamed.
Example:
Suppose to save the current configuration of the device under the third
configuration slot as Newtec_example.
1. Click the Configuration tab;
2. Click the Save button next to the third configuration slot;
3. Double-click the Name field of the third configuration slot. You can now enter a
new name for the configuration;
4. Type Newtec_example and click outside the text field.
version 3.2
59
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
After power up the boot configuration (the first configuration) is
loaded on the device..
If a configuration is not saved to persistent memory it will be lost
when the device powers down.
);
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
). We refer also to the
