Graphical User Interface
(GUI)
6.3

Main Windows of the GUI

When the GUI application opens five areas are visible.
Figure 17 – GUI
The table below gives an overview of the areas of the GUI (see Figure 17).
Area No.
1
2
3
4
5
Table 4 – General Monitor and Control Screen Areas
version 3.2
49
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
Area
Banner
Central stage window
Alarm list window
Function controls window
Status bar
