How to Manage
5.2.2.1 Read / Set the Device IP Address
The front panel can be used to set or read out the device IP address.
Open the following menu on the front panel:
Unit >> Setup >> Ethernet Settings >> Device IP address

Device IP Address: 10.0.0.1

5.2.2.2 For example change the Front Panel Screensaver
The front panel screensaver is useful to identify a number of units if you have more
than one unit.
Activate the screensaver in the following menu:
AZ110 >>Unit>>Setup>>Display settings

• Enter the screensaver delay;
• Enter the screensaver message (for example Channel 01 Modulator 01).
Once the screensaver delay is reached without any key action on the front panel a
message is displayed as follows.
AZ110

Channel 01

5.2.2.3 How to Log in as Expert
Proceed as follows to log in as Expert:
 Open the following menu on the front panel
Unit >> Setup >> Device: Normal

 Press OK
Normal <=Expert>

 Press OK
Enter Password: ***

 Enter the number of the device
 Press OK to confirm.
version 3.2
40
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
Modulator 01
