Graphical User Interface
(GUI)
6.4.2

Parameters in the GUI

6.4.2.1 Parameter Interface Types
The GUI contains different types of parameter dialog boxes to set up all
parameters of a configuration.
Dialog box
Example
type
Drop-down
list box
Data field
Checkbox
Table
Functional
group
Table 9 – Parameter Interface Type Examples
version 3.2
62
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
If you want to change one of the parameters in a functional group
check and/or adjust all parameters in that group.
