Physical Description
Ethernet Connection
A standard RJ-45 connector provides connection to an Ethernet hub in a LAN
(10/100BaseT). You can set the IP address and subnet mask from the front panel.
The default IP address is: 10.0.0.1.
You can send RMCP (Remote Monitoring and Control Protocol) commands to the
device using the Ethernet interface. The commands are sent as data in a TCP/IP
stream. The used socket number is 5933. The RMCP protocol is exactly the same
as for the serial interface, with one small exception: the receiving device ignores
the RMCP address of the device (that is present in an RMCP command).
version 3.2
27
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
The RMCP general manual v1.6 explains how Newtec devices can
be remotely monitored and controlled via the serial port or via
Ethernet.
This manual is delivered on CD-ROM together with the device.
