About this manual
Options
AZ 110 Broadcast Satellite Modulator
Default
Configuration
DVB Modulator, SNMP
Modulation & Baud rate: DVB-S 5Mbaud
Input interface: ASI interface + Rate adaptor
Output interface: L-band ( 950-1750 MHz)
Configuration
Options
Category
Input Interface ASI
ASI + Optical ASI
Output Interface L-band (950-1750 MHz)
IF (50-180 MHz)
L-band + 10MHz for BUC
L-band + 10MHz + 24Vdc for BUC
L-band + 10MHz + 48Vdc for BUC
Extended L-band ( 950-2150 MHz)
IF+ L-band
L + C-band (5,85-7,05 GHz)
L+ Ku-band (12,75-13,25 GHz )
L+ Ku-band (13,75-14,50 GHz)
L + DBS-band (17,30-18,10 GHz)
L + DBS-band (17,60-18,40 GHz)
Additional
Options
10MHz reference
In/Out
High stability
Very high stability
Predistortion

Equalink *

Encryption BISS (**)
BISSM (**)
Security AES 64 bit encryption *
Input frame Baseband frame (only with Ethernet interface)
version 3.2
xiii
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
Ordering
n°
AZ110
Max. 1 option per
category
Default
AG-02
Default
AA-02
AA-03
AA-12
AA-13
AA-18
AA-06
AA-14
AA-08
AA-09
AA-10
AA-11
Max. 1 option per
category
GR-01
GR-02
AC-01
AD-01
AD-02
AS-01
AV-01
