Physical Description
3.2
Back Panel Description
The back panel connections available depend on the specific hardware
configuration of your device. The back panel consists of several hardware
modules. In the next paragraphs these modules are described in more detail.
Figure 6 – AZ110 with ASI Interface Back Panel Connections
3.2.1
Power Supply Unit, M&C and External 10.0 MHz Input
Figure 7 - Power Supply, Alarm and Monitoring and Control Connection Back Panel
Power Socket
This equipment is provided with a protective earthing ground incorporated in the
power cord. The mains plug shall only be inserted in a socket outlet provided with a
protective earth contact. Any interruption of the protective conductor, inside or
outside the instrument, is likely to make the instrument dangerous.
version 3.2
24
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
M&C RS232/485
ALARM
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
Ref. In
10/100Base-T
