How to Manage
5.5

Protocols used to Monitor and Control the Device

There are two protocols that can be used to manage Newtec devices.

• Remote Monitor and Control Protocol (RMCP);

• Simple Network Management Protocol (SNMP).
5.5.1 Remote Monitor and Control Protocol (RMCP)
This is possible via the serial interface (RS232/485) or over Ethernet. The
commands are described in the Reference Manual of the device.
5.5.1.1 RMCP over Ethernet
RMCP commands are send towards the modulator via the Ethernet interface. The
commands are sent as data in a TCP/IP stream. The used socket number is 5933.
When RMCP commands are send over Ethernet, the receiving device ignores the
RMCP address of the device present in an RMCP command.
The Ethernet interface needs to be configured.
Navigate to the following menu to configure the Ethernet settings:
AZ110 >> Unit >> Setup >> Ethernet settings
•
Figure 15 - Ethernet Settings
version 3.2
45
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
The RMCP general manual v1.6 explains how Newtec devices
can be remotely monitored and controlled via the serial port or via
Ethernet.
This manual is delivered on CD-ROM together with the device.
