Physical Description
Option
AA-10
AA-11
AA-18
For example:
When option AA-12 is ordered the following back panels are used to assemble the
device:
Figure 11 - Example Back Panel Combination
version 3.2
34
User Manual for AZ110 Broadcast Satellite Modulator with ASI interface
Back Panel Combination
BP 01
BP 02
BP 07
BP 01
BP 02
BP 07
BP 01
BP 02
SHAPING THE FUTURE SATELLITE OF COMMUNICATIONS
Connectors Not Used
BP-<number>/<connector>,<connector>
BP 01/3,4
BP 02/1,3,4
BP 01/3,4
BP 02/1,3,4
BP 01/3,4
BP 02/1
