1-4 MS2024A Options

Table 1-3. Measurement Capabilities
Model Number
MS2024A Handheld
VNA Master
MS2034A Handheld
VNA Master plus
Spectrum Analysis
MS2026A Handheld
VNA Master
MS2036A Handheld
VNA Master plus
Spectrum Analysis
Note 1: Units with serial numbers below 0737000 sweep down to 100 kHz only.
1-4 MS2024A Options
Anritsu VNA Master options are dependent upon the model purchased, as summarized in
this and the following sections. Options for the MS2024A 2-port VNA Master, 2 MHz to
4 GHz are:
• MS2024A-005 Power Monitor (requires external detector)
• MS2024A-010 Built-in Bias-Tee
• MS2024A-015 Vector Voltmeter
• MS2024A-019 High Accuracy Power Meter (sensors not included)
• MS2024A-031 GPS Receiver (includes GPS antenna)
1-4
VNA SPA
Frequency Frequency
2 MHz to N/A
4 GHz
2 MHz to 9 kHz to
4 GHz 4 GHz
2 MHz to N/A
6 GHz
2 MHz to 9 kHz to
6 GHz 7.1 GHz
Chapter 1 — General Information
Return loss, cable loss, VSWR, 1-port
phase, 2-port phase, smith chart, 2-port
gain, group delay, Distance-to-Fault
MS2024A measurements plus high
performance spectrum analysis, channel
scanner, and interference analysis.
(See Note 1 below.)
Return loss, cable loss, VSWR, 1-port
phase, 2-port phase, smith chart, 2-port
gain, group delay, Distance-to-Fault
MS2026A measurements plus high
performance spectrum analysis, channel
scanner, and interference analysis.
(See Note 1 below.)
