1-8 Standard and Optional Accessories
Table 1-7. Adapters (Continued)
Part Number
510-92
510-93
510-96
510-97
513-62
1091-315
1091-324
1091-325
1091-317
1091-318
1091-323
1091-326
Table 1-8. Test Port Cables Armored
Part Number
15NN50-1.5C
15NN50-3.0C
15NN50-5.0C
15NNF50-1.5C
15NNF50-3.0C
15NNF50-5.0C
15ND50-1.5C
15NDF50-1.5C
Table 1-9. Port Antennas
Part Number
2000-1030
2000-1031
2000-1032
2000-1035
2000-1200
1-8
7/16 DIN(m)-N(m), DC to 7.5 GHz, 50 Ω
7/16 DIN(m)-N(f), DC to 7.5 GHz, 50 Ω
7/16 DIN(m)-7/16 DIN(m), DC to 7.5 GHz, 50 Ω
7/16 DIN(f)-7/16 DIN(f), DC to 7.5 GHz, 50 Ω
Adapter, TNC(f) to N(f), 18 GHz, 50 Ω
Adapter, TNC(m) to N(f), 18 GHz, 50 Ω
Adapter, TNC(f) to N(m), 18 GHz, 50 Ω
Adapter, TNC(m) to N(m), 18 GHz, 50 Ω
Adapter, TNC(m) to SMA(f), 18 GHz, 50 Ω
Adapter, TNC(m) to SMA(m), 18 GHz, 50 Ω
Adapter, TNC(f) to TNC(f), 18 GHz, 50 Ω
Adapter, TNC(m) to TNC(m), 18 GHz, 50 Ω
1.5 meters, N(m)-N(m), 6 GHz, 50 Ω
3.0 meters, N(m)-N(m), 6 GHz, 50 Ω
5.0 meters, N(m)-N(m), 6 GHz, 50 Ω
1.5 meters, N(m)-N(f), 6 GHz, 50 Ω
3.0 meters, N(m)-N(f), 6 GHz, 50 Ω
5.0 meters, N(m)-N(f), 6 GHz, 50 Ω
1.5 meters, N(m)-7/16 DIN(m), 6 GHz, 50 Ω
1.5 meters, N(m)-7/16 DIN(f), 6 GHz, 50 Ω
Individual Antennas
SMA(m), 1.71 to 1.88 GHz, 50 Ω
SMA(m), 1.85 to 1.99 GHz, 50 Ω
SMA(m), 2.4 to 2.5 GHz, 50 Ω
SMA(m), 896 to 941 MHz, 50 Ω
SMA(m), 806 to 869 MHz, 50 Ω
Description
TNC Adapters
Description
Description
