Chapter 3 — Vector Network Analyzer

Save/Recall Menu

For more information on the Save/Recall menu, see
Scale Menu (VNA Menus)
Figure 3-28. Scale Menu
Press the
function key to access the Scale menu. The Scale menu is used to set the
Scale
measurement display for optimum viewing.
Resolution Per Div
Sets the number of units displayed between horizontal graticules. Use the Up/Down
arrow keys, the keypad, or the rotary knob to set this parameter, then press the
key or the rotary knob.
Reference Value
Sets the value of the Reference Line. Use the Up/Down arrow keys, the keypad, or the
rotary knob to set this parameter, then press the
Reference Line
Sets which horizontal graph graticule is at the reference value. The reference line is
indicated by a small red triangle along the right edge of the graph. Use the Up/Down
arrow keys, the keypad, or the rotary knob to set this parameter, then press the
key or the rotary knob.
Autoscale
Press the
Autoscale
values so that the trace for the current measurement is shown in the middle of the
display.
MS20xxA VNA Master UG 10580-00166 Rev. C
Scale
Resolution Per Div
6.0 dB
Reference Value
30.0 dB
Reference Line
5
Autoscale
Aperture
2.00%
soft key to automatically adjust the Top and Bottom amplitude
3-7 VNA Key Functions - Save/Recall Menu
"File Menu" on page
(Group
Delay
only)
key or the rotary knob.
Enter
3-29.
Enter
Enter
3-49
