4-23 File
Directory Management
For information on the Directory Management soft key and menu, see
Management" on page
Delete
Brings up a selection box that shows the first 1000 stored setups and traces in the
currently selected location (see
the setup and measurement names, the type (stp for a saved setup, spa for a saved
trace, jpg for a JPEG file) and the date and time the information was saved. Use the
rotary knob or the Up/Down arrow keys to highlight the file to be deleted, and press
Enter, or the Delete soft key to delete. Press the Esc key to cancel the operation. Note
that there is no mechanism to retrieve deleted files.
Delete Selected File
Use the up and down arrow buttons or the rotary knob to select the file that is to
be deleted. Press Enter to confirm that you want to delete the file or Esc to exit
without deleting.
Delete ALL Measurements
Deletes all measurements of the current mode in the currently selected storage
location. The memory from which measurements will be deleted is set in the
Directory Management menu and is the Current Location.
Delete ALL Mode Files
Deletes all measurements of the type saved in the current operating mode of the
instrument. In addition all jpg and setup files (regardless of the mode) are
deleted.
Delete ALL Contents
Deletes all measurements, jpg files and setup files of all measurement types. All
contents of external devices are deleted (CF and USB memory). For internal
memory, all user files are deleted. Use with caution.
Back
The Back key returns to the previous menu.
Directory Management
This soft key brings up the Directory Management menu. Note that the Directory
Management menu is available from both the Recall and Save menus.
Sort Method Name Type Date
File lists can be sorted by the name of the file, the type of file (SPA file, STP file,
etc.) or by the date that the file was saved.
Sort Ascending Descending
Selects whether the selected sort is sorted from lowest to highest (ascending) or
highest to lowest (descending). When sorting by name, the sort will place file
names that start with numbers before file names that start with letters (an
ASCII sort).
Current Location Int USB CF
This choice lets you select where measurements and setups will be saved.
Pressing the soft key toggles between storing files on the internal memory, USB
flash drive or a Compact Flash memory module. The "current location" and the
"copy to destination" may not be the same. Changing the current location to save
4-32
4-32.
"Directory Management" on page
MS20xxA VNA Master UG 10580-00166 Rev. C
Chapter 4 — Spectrum Analyzer
"Directory
4-32). The list shows
