Summary of Contents for Anritsu MS2024A/MS2026A

  • Page 1 Complimentary Reference Material This PDF has been made available as a complimentary service for you to assist in evaluating this model for your testing requirements. TMG offers a wide range of test equipment solutions, from renting short to long term, buying refurbished and purchasing new. Financing options, such as Financial Rental, and Leasing are also available on application.
  • Page 2 User Guide VNA Master MS2024A/MS2026A and MS2034A/MS2036A Vector Network Analyzer 2 MHz to 6 GHz Spectrum Analyzer 9 kHz to 7.1 GHz...
  • Page 3 Model MS2024A, MS2026A, MS2034A, MS2036A Vector Network Analyzer 2 MHz to 6 GHz Spectrum Analyzer 9 kHz to 7.1 GHz Anritsu Company P/N: 10580-00166 490 Jarvis Drive Revision: C Morgan Hill, CA 95037-2809 Printed: February 2008 Copyright 2007-2008 Anritsu Company...
  • Page 4 WARRANTY The Anritsu product(s) listed on the title page is (are) warranted against defects in materials and workmanship for one year from the date of shipment. Anritsu’s obligation covers repairing or replacing products which prove to be defective during the warranty period. Buyers shall prepay transportation charges for equipment returned to Anritsu for warranty repairs.
  • Page 5 Anritsu Company. UPDATES Updates, if any, can be downloaded from the Documents area of the Anritsu web site at http://www.us.anritsu.com.
  • Page 8 CHINESE RoHS STATEMENT EPCD DIRECTIVE 2002/96/EC PRODUCT DISPOSAL...
  • Page 9 This product and its manuals may require an Export License or approval by the government of the product country of origin for re-export from your country. Before you export this product or any of its manuals, please contact Anritsu Company to confirm whether or not these items are export-controlled.
  • Page 10 SOFTWARE LICENSES VxWorks Runtime WindML Target License License 2000-1189 2000-1372 NI Device License WindRiver USB Runtime License 2000-1486 2000-1421...

  • Page 11: Safety Symbols

    Some or all of the following five symbols may or may not be used on all Anritsu equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this manual.
  • Page 12 For Safety WARNING Always refer to the operation manual when working near locations at which the alert mark, shown on the left, is attached. If the operation, etc., is performed without heeding the advice in the operation manual, there is a risk of personal injury. In addition, the equipment performance may be reduced.

  • Page 13: Table Of Contents

    Table of Contents Chapter 1 — General Information Introduction ..........1-1 Identifying the Models.
  • Page 14 Table of Contents (Continued) Front Panel Keys ..........2-5 Esc Key .
  • Page 15 Table of Contents (Continued) Chapter 3 — Vector Network Analyzer Introduction ..........3-1 VNA First Time Use .
  • Page 16 Table of Contents (Continued) VNA Key Functions......... . . 3-25 Introduction .
  • Page 17 Table of Contents (Continued) 4-11 Channel Power Measurement ........4-9 4-12 GSM Channel Power Measurement .
  • Page 18 Table of Contents (Continued) Chapter 5 — Power Meter Introduction ..........5-1 Procedure .
  • Page 19 Table of Contents (Continued) Chapter 9 — Interference Analyzer, Option 25 Introduction ..........9-1 Spectrogram Measurement .
  • Page 20 Table of Contents (Continued) Chapter 12 — GPS Receiver, Option 31 12-1 Introduction ..........12-1 12-2 Activating the GPS Feature .
  • Page 21 Table of Contents (Continued) Appendix E — Coaxial Cable Technical Data Coaxial Cable Technical Data ........E-1 Appendix F —...

  • Page 22: Ms20Xxa Vna Master Ug 10580-00166 Rev. C

    Table of Contents (Continued) Contents-10 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 23: Chapter 1 - General Information

    Chapter 1 — General Information 1-1 Introduction This chapter covers general information including a description, optional accessories, preventive maintenance. ESD verifications, and calibration requirements for the VNA Master models listed below. This user guide supports both VNA Master plus VNA Master plus Spectrum Analysis models.

  • Page 24: Identifying The Models

    1-2 Identifying the Models Chapter 1 — General Information 1-2 Identifying the Models The MS202xA is differentiated from the MS203xA by the front panel model number label. In addition, the MS203xA is larger and contains additional connections for spectrum analysis as summarized in the following pictures and table.

  • Page 25: Description

    31.5 x 21.1 x 9.71 cm (12.4 x 8.3 x 3.8 in.) 4 kg (9 lbs) 1-3 Description The Anritsu VNA Master instruments, starting with the MS202xA series, are portable handheld vector network analyzers (VNAs) featuring precise performance and essential RF capabilities. These VNA Master instruments are designed to conduct accurate vector-corrected 1-port magnitude, phase, and fault location measurements and 1-path 2-port magnitude, phase, and group delay measurements from 2 MHz to 6 GHz.

  • Page 26: Ms2024A Options

    Note 1: Units with serial numbers below 0737000 sweep down to 100 kHz only. 1-4 MS2024A Options Anritsu VNA Master options are dependent upon the model purchased, as summarized in this and the following sections. Options for the MS2024A 2-port VNA Master, 2 MHz to 4 GHz are: •...

  • Page 27: Ms2026A Options

    Chapter 1 — General Information 1-5 MS2026A Options 1-5 MS2026A Options Options for the MS2026A 2-port VNA Master, 2 MHz to 6 GHz are: • MS2026A-005 Power Monitor (requires external detector) • MS2026A-010 Built-in Bias-Tee • MS2026A-015 Vector Voltmeter • MS2024A-019 High Accuracy Power Meter (sensors not included) •...

  • Page 28: Standard And Optional Accessories

    1-8 Standard and Optional Accessories Chapter 1 — General Information 1-8 Standard and Optional Accessories The standard accessories are slightly different depending upon whether the MS202xA or the MS203xA has been purchased, as shown in the following table. These standard accessories are supplied with the VNA Master: Note Units with serial numbers below 0737000 sweep down to 100 kHz only.
  • Page 29 Chapter 1 — General Information 1-8 Standard and Optional Accessories Table 1-5. Coaxial Calibration Components (Continued) Part Number Description Precision TNC(m) Load, 18 GHz, 50 Ω 1015-55 Precision TNC(f) Open, 18 GHz, 50 Ω 1091-55 Precision TNC(f) Short, 18 GHz, 50 Ω 1091-56 Precision TNC(f) Load, 18 GHz, 50 Ω...

  • Page 30: Ms20Xxa Vna Master Ug 10580-00166 Rev. C

    1-8 Standard and Optional Accessories Chapter 1 — General Information Table 1-7. Adapters (Continued) Part Number Description 7/16 DIN(m)-N(m), DC to 7.5 GHz, 50 Ω 510-92 7/16 DIN(m)-N(f), DC to 7.5 GHz, 50 Ω 510-93 7/16 DIN(m)-7/16 DIN(m), DC to 7.5 GHz, 50 Ω 510-96 7/16 DIN(f)-7/16 DIN(f), DC to 7.5 GHz, 50 Ω...
  • Page 31 Chapter 1 — General Information 1-8 Standard and Optional Accessories Table 1-9. Port Antennas (Continued) Part Number Description SMA(m), 5725 to 5825 MHz, 50 Ω 2000-1361 SMA(m), 870 to 960 MHz, 50 Ω 2000-1473 SMA(m), 1.71 to 1.88 GHz, 50 Ω 2000-1474 SMA(m), 1920 to 1980, 2.11 to 2.17 GHz, 50 Ω...
  • Page 32 –40 dBm to +20 dBm using single cycle per sweep AC detection, and uses auto-zeroing with DC detection during the frequency sweep. Optional extender cables can be used with the VNA Master with Option 5 installed. For additional detectors, refer to the Anritsu web site, http://www.anritsu.com/.

  • Page 33: Soft Carrying Cases And Tilt Bails

    Chapter 1 — General Information 1-9 Soft Carrying Cases and Tilt Bails 1-9 Soft Carrying Cases and Tilt Bails The soft carrying cases are slightly different for the MS202xA and MS203xA because the MS203xA is larger. The tilt bail is factory-installed on the VNA Master for use with or without the soft carrying case.
  • Page 34 1-9 Soft Carrying Cases and Tilt Bails Chapter 1 — General Information 5. Close the back panel and secure it with the zipper. Figure 1-4. VNA Master Installed in Soft Case The soft carrying case includes a detachable shoulder strap that can be connected to the D-rings on the upper corners of the case as required for comfort or convenience.

  • Page 35: Vna Master Tilt Bail Stand

    Chapter 1 — General Information 1-9 Soft Carrying Cases and Tilt Bails VNA Master Tilt Bail Stand The supplied Tilt Bail can be used for desktop operation. The tilt bail provides a backward tilt for improved stability and air flow. To deploy the tilt bail, pull the bottom of the tilt bail away from the back of the unit.

  • Page 36: Preventive Maintenance

    For best results, use an Anritsu phase stable Test Port Extension Cable. Use of a typical laboratory cable to extend the VNA Master test port to the device under test, or...

  • Page 37: Esd Cautions

    Chapter 1 — General Information 1-14 ESD Cautions 1-14 ESD Cautions The MS202xA and MS203xA, like other high performance instruments, are susceptible to ESD damage. Very often, coaxial cables and antennas build up a static charge, which, if allowed to discharge by connecting directly to the MS202xA or MS203xA without first discharging the static charge, may damage the instrument input circuitry.
  • Page 38 AC-DC Adapter (40-168) or the 12 Volt DC adapter (806-141), or separately in the optional Dual Battery Charger (2000-1374). When using the Automotive Cigarette Lighter 12 VDC Adapter, Anritsu Part CAUTION: Number 806-141, always verify that the supply is rated for a minimum of 60 Watts at 12 VDC, and that the socket is clear of any dirt or debris.

  • Page 39: Chapter 2 - Quick Start Guide

    2-2 Turning the VNA Master On for the First Time The Anritsu VNA Master is capable of nearly three hours of continuous operation from a fully charged, field-replaceable battery (refer to “1-15 Battery Replacement”...

  • Page 40: Front Panel Overview

    2-3 Front Panel Overview Chapter 2 — Quick Start Guide To turn on the VNA Master, press the front panel button (Figure 2-1). On/Off On/Off Button Figure 2-1. VNA Master On/Off Button (MS2026A shown) The VNA Master requires approximately thirty-five seconds to complete the power-on cycle and load the application software.

  • Page 41: Battery Charge Led (Green)

    Chapter 2 — Quick Start Guide 2-3 Front Panel Overview The eight soft keys are located to the right of the display. They change function depending upon the current mode of operation and menu selection. The current soft key function is indicated at the top of the active function block, which is located to the right of the display.

  • Page 42: Typical Vector Network Analyzer Display

    2-4 Typical Vector Network Analyzer Display Chapter 2 — Quick Start Guide 2-4 Typical Vector Network Analyzer Display Figure 2-3 illustrates some of the key information areas of the vector network analyzer display on the VNA Master for both MS202xA and MS203xA models. The measurement and the display type may not be the same as currently shown on your instrument.

  • Page 43: Typical Spectrum Analyzer Display

    Chapter 2 — Quick Start Guide 2-5 Typical Spectrum Analyzer Display 2-5 Typical Spectrum Analyzer Display Figure 2-4 illustrates some of the key information areas of the Spectrum Analyzer display of the VNA Master. Spectrum Analyzer functions are in MS203xA models only. For more detailed key descriptions, refer to Chapter 4, “Spectrum Analyzer”.

  • Page 44: Enter Key

    2-6 Front Panel Keys Chapter 2 — Quick Start Guide Enter Key Press this key to finalize data input. Pressing the rotary knob performs this same function. Arrow Keys The four arrow keys (between the rotary knob and the key) are used to scroll up, down, left, or right.

  • Page 45: Soft Keys

    Chapter 2 — Quick Start Guide 2-7 Soft Key Types Soft Keys These eight gray keys have no labels. They are arranged adjacent to the measurement display screen along the right-hand edge. They are positioned to accompany virtual soft key labels that are displayed to match instrument modes and measurement functions.

  • Page 46: Switching

    2-8 Parameter Setting Chapter 2 — Quick Start Guide Switching soft key is used to open an additional soft key menu, and it has an arrow Switching mark (-->) in the lower right corner of the virtual key face. Some soft keys become soft keys after being pressed (after becoming active).
  • Page 47 Chapter 2 — Quick Start Guide 2-9 Text Entry Refer to Figure 2-6, Figure 2-7, and Figure 2-8. Figure 2-6. Text Entry Menu – Lower Case Figure 2-7. Text Entry Menu – Upper Case MS20xxA VNA Master UG 10580-00166 Rev. C...
  • Page 48 2-9 Text Entry Chapter 2 — Quick Start Guide Rotary Knob has scrolled to letter “h” Figure 2-8. Text Entry Menu – Selecting Characters 2-10 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 49: Test Panel Connectors

    Chapter 2 — Quick Start Guide 2-10 Test Panel Connectors 2-10 Test Panel Connectors The MS202xA (shown in Figure 2-9) can be differentiated from the MS203xA by the front panel model number label as well as by major differences in the connectors on the unit top. The MS203xA shown in Figure 2-10 is slightly larger and contains additional connections for...

  • Page 50: Ms203Xa Test Panel Connectors

    2-10 Test Panel Connectors Chapter 2 — Quick Start Guide MS203xA Test Panel Connectors The connectors and indicators located on the test panel of the MS203xA are shown in Figure 2-10 and are described below. MS2034A and MS2036A Test Panel Connections External Headset Compact...

  • Page 51: Usb Interface - Usb Type Mini-B

    Chapter 2 — Quick Start Guide 2-10 Test Panel Connectors Dynamic Host Configuration Protocol (DHCP) is an Internet protocol that automates the process of setting IP addresses for devices that use TCP/IP and is the most common method of configuring a device for network use. To determine if a network is set up for DHCP, connect the VNA Master to the network and select DHCP protocol in the menu.

  • Page 52: Usb Interface - Usb Type A

    The GPS antenna connection on the VNA Master is fitted with a reverse BNC connector to help prevent damage to the GPS circuitry. A DC voltage is present on Note this connector. Do not connect anything other than the Anritsu GPS antenna (part number 2000-1410) to this port. 2-14...

  • Page 53: Compact Flash

    2-10 Test Panel Connectors Compact Flash The VNA Master accepts a 256 MB Compact Flash Memory Module, Anritsu Part Number 3-2000-1500 or other commercially available equivalent. The contents of the internal memory can be copied to and from a removable Compact Flash card. It must be a minimum of 256 MB to be able to hold the entire contents of the internal flash memory and can be as large as 512 MB.

  • Page 54: Single Sweep

    Note Use only Anritsu approved batteries, adapters, and chargers with this instrument. The battery symbol is replaced by a red plug body to indicate that the instrument is running from external power and is not charging the battery (or the battery is not present). When the...

  • Page 55: Chapter 3 - Vector Network Analyzer

    Analyzer 3-1 Introduction This chapter provides an overview of the vector network analyzer capabilities of the Anritsu VNA Master, which is available in both MS202xA and MS203xA models. The intent of this chapter is to provide the user with a starting point for making basic measurements.

  • Page 56: Setting The Frequency Range

    3-2 VNA First Time Use - Setting the Frequency Range Chapter 3 — Vector Network Analyzer The measurements included for S21 Transmission are: • Log Magnitude • Phase • Group Delay S21 Field Menu measurements include: • VSWR • Return Loss •...

  • Page 57: Calibration

    Chapter 3 — Vector Network Analyzer 3-3 Calibration - Standard Calibrations • Selecting the soft key will display the list. Signal Standard • Use the rotary knob or arrow keys to highlight the desired signal Up/Down standard. • Once highlighted, press to select the highlighted standard.

  • Page 58: 2-Port Calibration

    3-3 Calibration - 2-Port Calibration Chapter 3 — Vector Network Analyzer 2-Port Calibration The 2-port calibration is a 1-path 2-port OSLIT (open/short/load/isolation/through) calibration that removes transmission response errors and transmission source match errors in addition to reflection error terms. 1-Port Calibration Procedure (OSL) 1.

  • Page 59: 2-Port Calibration Procedure (Oslt)

    Chapter 3 — Vector Network Analyzer 3-3 Calibration - 2-Port Calibration Procedure (OSLT) soft key and use the rotary knob or Up/Down arrow keys to highlight the Connector appropriate connector and press the rotary knob or to select. Enter If none of the connectors that are shown in the DUT Connector Selector list are suitable for the application, then two selections, User 1 and User 2, can be custom defined.
  • Page 60 3-3 Calibration - 2-Port Calibration Procedure (OSLT) Chapter 3 — Vector Network Analyzer soft key and use the rotary knob or Up/Down arrow keys to highlight the Connector appropriate connector and press the rotary knob or to select. Enter If none of the connectors shown in the DUT Connector Selector list are suitable for the application, then two selections (User 1 and User 2) can be custom defined.
  • Page 61 Chapter 3 — Vector Network Analyzer 3-3 Calibration - 2-Port Calibration Procedure (OSLT) 12. Verify that calibration has been performed properly by checking that the Cal Status On message is now displayed at the top of the status window. OPTIONAL ADAPTOR FOR THROUGH CONNECTION OPEN SHORT...

  • Page 62: Using Trace Math

    3-4 Using Trace Math - Example Chapter 3 — Vector Network Analyzer 3-4 Using Trace Math The Trace Math menu (on page 3-57) is an excellent tool for comparing two traces. Traces can be uploaded by using Master Software Tools. Store those traces in memory and compare a stored trace with a more recent trace.
  • Page 63 Chapter 3 — Vector Network Analyzer 3-4 Using Trace Math - Comparing Return Loss 7. Press the soft key to look at the difference in Return Loss between Trace Minus Memory the two cables. Figure 3-3. Trace Menu Showing Trace and Memory (Field Measurement Menu Shown) MS20xxA VNA Master UG 10580-00166 Rev.

  • Page 64: Using Limit Lines

    3-5 Using Limit Lines - Setting up Non-segmented Limit Lines Chapter 3 — Vector Network Analyzer 3-5 Using Limit Lines To access the functions under the Limit menu (on page 3-35), select the key, then the Shift (6) key. Limit Two types of limit lines can be specified, lower limit lines and upper limit lines.

  • Page 65: Setting Up Segmented Limit Lines

    Chapter 3 — Vector Network Analyzer 3-5 Using Limit Lines - Setting up Segmented Limit Lines Setting up Segmented Limit Lines Segmented Limit Lines can be useful if there are different specifications for different frequency ranges. The following procedure creates segmented Limit Lines for a Return Loss Measurement.

  • Page 66: Vna Measurements

    3-6 VNA Measurements - Return Loss/VSWR Chapter 3 — Vector Network Analyzer 3-6 VNA Measurements The following sections provide detailed descriptions of the various Vector Network Analyzer measurements using the VNA Master. Return Loss/VSWR Return Loss is used to characterize RF components and systems. The Return Loss indicates how well the system is matched by taking the ratio of the reflected signal to the incident signal, measuring the reflected power in dB.
  • Page 67 Chapter 3 — Vector Network Analyzer 3-6 VNA Measurements - Return Loss/VSWR 9. Press the function hard key and select the soft key to view the match Measurement VSWR in VSWR (Field menu), or select the soft keys (VNA menu). S11 Reflection | VSWR Figure 3-6 is displaying the Measurement menu of the Field menu setting.

  • Page 68: Cable Loss (Field Menus Only)

    3-6 VNA Measurements - Cable Loss (Field Menus Only) Chapter 3 — Vector Network Analyzer Cable Loss (Field Menus Only) The transmission feed line insertion loss test verifies the signal attenuation level of the cable. This test can be done using the Cable Loss or Return Loss Measurement with a short or an open connected at the end of the system.

  • Page 69: Distance-To-Fault (Dtf)/Fault Location

    Chapter 3 — Vector Network Analyzer 3-6 VNA Measurements - Distance-To-Fault (DTF)/Fault Location 13. Press the function hard key and save the measurement. Note that the Save/Recall average Cable Loss value, (peak + valley)/2, is displayed in the instrument settings summary area of the window.
  • Page 70 3-6 VNA Measurements - Distance-To-Fault (DTF)/Fault Location Chapter 3 — Vector Network Analyzer Frequency selective devices such as TMAs (Tower Mounted Amplifiers), duplexers, filters, and quarter wave lightning arrestors will change the phase information (distance information) if they are not swept over the correct frequencies. Care needs to be taken when setting up the frequency range whenever a TMA is present in the path.
  • Page 71 Chapter 3 — Vector Network Analyzer 3-6 VNA Measurements - Distance-To-Fault (DTF)/Fault Location 5. Press the soft key and use the soft key to enter the Stop Distance. Make Back Stop Dist sure that Stop Distance is smaller than Dmax. 6.
  • Page 72 3-6 VNA Measurements - Distance-To-Fault (DTF)/Fault Location Chapter 3 — Vector Network Analyzer Figure 3-11. DTF Measurement of Good Cable With a Load Figure 3-12. DTF Measurement of Cable With a Fault Fault Resolution Fault resolution is the ability of the system to separate two closely spaced discontinuities. If the fault resolution is 10 feet and two faults are 5 feet apart, then the VNA Master will not be able to show both faults unless Fault Resolution is improved by widening the frequency span.

  • Page 73: 2-Port Gain Measurements

    Chapter 3 — Vector Network Analyzer 3-6 VNA Measurements - 2-Port Gain Measurements DMax DMax is the maximum horizontal distance that can be analyzed. The Stop Distance can not exceed D . If the cable is longer than D , then D needs to be improved by increasing the number of datapoints or by lowering the frequency span ( F).
  • Page 74 3-6 VNA Measurements - 2-Port Gain Measurements Chapter 3 — Vector Network Analyzer 8. When the Calibration is finished, should be displayed in the upper left part Cal Status On of the display, and the trace should be a flat trace at 0 dB. 9.

  • Page 75: Phase Measurements

    Chapter 3 — Vector Network Analyzer 3-6 VNA Measurements - Phase Measurements 12. Press the function hard key and turn on Marker 1 by pressing the soft key Marker Marker to select the number 1 and pressing the soft key. On/Off Figure 3-14.

  • Page 76: 2-Port Phase Measurement

    Ohm Smith Chart. When markers are used, the real and imaginary components of the Smith Chart value are displayed. Anritsu Master Software Tools includes more options and a calculator that can easily show the values of the return loss, VSWR, or reflection coefficient of a specific Smith Chart.

  • Page 77: Group Delay

    Chapter 3 — Vector Network Analyzer 3-6 VNA Measurements - Group Delay Smith Chart Measurement The following example shows how a Smith Chart can be used to measure the match of an antenna. In this example procedure, the instrument is using the VNA measurement menu. Procedure 1.
  • Page 78 3-6 VNA Measurements - Group Delay Chapter 3 — Vector Network Analyzer Procedure 1. Press the key and select the soft key. Measurement S21 Transmission S11 Reflection Figure 3-17. S21 Transmission Display with Soft Key Menu 2. Select the or the soft key.

  • Page 79: Vna Key Functions

    Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Introduction 3-7 VNA Key Functions Introduction The following section is a quick reference to the principal menus in the VNA Master. For more specific information on a particular measurement, refer to the specific chapters for the measurement being made.

  • Page 80: Amplitude Menu (Field Menu)

    3-7 VNA Key Functions - Amplitude Menu (Field Menu) Chapter 3 — Vector Network Analyzer Amplitude Menu (Field Menu) Amplitude 0.0 dB Bottom 60 dB Autoscale Figure 3-19. Amplitude Menu To access the functions under the Amplitude menu, select the function hard key.

  • Page 81: Calibration Menu

    Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Calibration Menu Calibration Menu Figure 3-20. Calibration Menu To access the Calibration Menu, press the key, then the (2) key. Shift Calibration Start Cal Press this soft key to begin the VNA calibration process for the current sweep settings – calibration type, power, DUT connector and frequency settings.
  • Page 82 3-7 VNA Key Functions - Calibration Menu Chapter 3 — Vector Network Analyzer Cal Mode Standard/FlexCal Toggles between a Standard calibration and a FlexCal. Standard calibration will calibrate 551 data points evenly spaced between the current start and stop frequencies. After a Standard cal, the VNA Master will only make measurements at these calibrated frequency points.

  • Page 83: File Menu

    Measurements may be saved to the internal memory, an external Type-1 Compact Flash module, or a USB Flash Drive. Anritsu recommends saving to external storage if a large number of measurements are to be saved. The instrument is shipped with a Compact Flash module and a USB Flash Drive.
  • Page 84 3-7 VNA Key Functions - File Menu Chapter 3 — Vector Network Analyzer Save Measurement Initiates a dialog box to name and save the active trace. The saved measurement trace can be named using the keypad to select numbers, the rotary knob to highlight a number or character and pressing the knob to select, or by selecting the soft key for each letter.
  • Page 85 Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - File Menu Recall Measurement This function brings up a selection box that allows recall of a previously stored measurement trace. Use the rotary knob or the arrow keys to highlight Up/Down the saved measurement trace, and press , the rotary knob, or the...
  • Page 86 3-7 VNA Key Functions - File Menu Chapter 3 — Vector Network Analyzer Delete ALL Mode Files Deletes all measurements of the type saved in the current operating mode of the instrument. In addition all jpg and setup files (regardless of the mode) are deleted.

  • Page 87: Freq/Dist Menu

    Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Freq/Dist Menu Freq/Dist Menu Figure 3-22. Freq/Dist Menu The tuning frequency range for the VNA Master can be entered in several different ways depending upon what makes the most sense for the user or for the application. The center frequency and span can be specified, the start and stop frequencies can be entered, or a signal standard and channel number can be selected from the built-in list.
  • Page 88 3-7 VNA Key Functions - Freq/Dist Menu Chapter 3 — Vector Network Analyzer Center Frequency Press the key followed by the soft key and enter the desired frequency Freq Center Freq using the keypad, the arrow keys, or the rotary knob. If entering a frequency using the keypad, then the soft key labels change to .

  • Page 89: Limit Menu

    Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Limit Menu Limit Menu Limit Edit Limit Limit Move Limit Upper Lower Frequency 2.000 MHz Point Value Limit Edit 45.0 dBm --> Limit Alarm Point Delete Point Next Point Left Next Point...
  • Page 90 3-7 VNA Key Functions - Limit Menu Chapter 3 — Vector Network Analyzer Limit Upper/Lower This soft key selects which limit line will be active for editing. The limit line that is currently selected for editing is underlined. On/Off This soft key turns the active limit line (upper or lower) on or off. Limit Edit The submenu that is displayed by this soft key allows creating or editing of single limit lines or multi-segment limit lines.
  • Page 91 Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Limit Menu Delete Point This soft key deletes the currently active point. The active point becomes the one immediately to the left of the point that was deleted. Next Point Left This soft key selects the limit point immediately to the left of the active point, making it active for editing or deletion.

  • Page 92: Marker Menu

    3-7 VNA Key Functions - Marker Menu Chapter 3 — Vector Network Analyzer Marker Menu Marker Marker 2 3 4 5 6 Delta Peak Search Valley Search Marker Table All Markers Figure 3-24. Marker Menu To access the functions under the Marker menu, select the function hard key.
  • Page 93 Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Marker Menu Peak Search This soft key places the currently active marker on the highest signal amplitude currently displayed on screen. Valley Search This soft key places the currently active marker on the lowest signal amplitude currently displayed on screen.

  • Page 94: Measurement Menus (Field And Vna)

    3-7 VNA Key Functions - Measurement Menus (Field and VNA) Chapter 3 — Vector Network Analyzer Measurement Menus (Field and VNA) The VNA Measurement Menu lists the following measurement types: • S11 Reflection • S21 Transmission S11 Reflection The S11 Reflection measurement choices are: •...
  • Page 95 Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Measurement Menus (Field and VNA) Procedure To select the Measurement Menu, press the function hard key, or press the Measurement Shift key and then the (4) key. Measure To change the Measurement Menu between the Field Menu and the VNA Menu: 1.

  • Page 96: Measurement Menu (Vna Menus)

    3-7 VNA Key Functions - Measurement Menu (VNA Menus) Chapter 3 — Vector Network Analyzer Measurement Menu (VNA Menus) Figure 3-25. VNA Measurement Menu While the VNA Master is in VNA mode and is set for the VNA Measurement application option, press the function hard key or press the key then the...
  • Page 97 Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Measurement Menu (VNA Menus) Phase Directs the instrument to make a 1-port measurement and display the phase result in degrees. Measured data is formatted such that the result is between +180 degrees and –180 degrees.
  • Page 98 3-7 VNA Key Functions - Measurement Menu (VNA Menus) Chapter 3 — Vector Network Analyzer Auto Reference Plane Extension Will use the current data to automatically determine the best length to mathematically extend the reference plane (plane of calibration) to remove cable length from the measurement, based on the current value of Propagation Velocity (see description for “Prop Velocity #”...

  • Page 99: Measurement Menu (Field Menus)

    Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Measurement Menu (Field Menus) Measurement Menu (Field Menus) Measurement Measurement VSWR 1-Port Phase Return Loss 2-Port Phase Cable Loss Return Loss DTF VSWR 2-Port Gain Smith Chart Back Next -->...
  • Page 100 3-7 VNA Key Functions - Measurement Menu (Field Menus) Chapter 3 — Vector Network Analyzer DTF Return Loss and DTF VSWR The DTF measurement displays return loss (or VSWR) values versus distance. If the frequency measurements fail or indicate a problem in the system, then the DTF measurement can be used to identify and pinpoint the exact location of the problem.

  • Page 101: Mode Menu

    Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Mode Menu Mode Menu To access the Mode Menu, press the key, then the (9) key. The window Shift Mode Mode Selector opens. A sample list of Mode Selector choices: •...

  • Page 102: Preset Menu

    3-7 VNA Key Functions - Preset Menu Chapter 3 — Vector Network Analyzer Preset Menu Preset Preset Save Setup Recall Setup Figure 3-27. Preset Menu To access the Preset Menu, press the key, then the (1) key. The Preset menu is Shift Preset used to preset the VNA Master.

  • Page 103: Save/Recall Menu

    Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Save/Recall Menu Save/Recall Menu For more information on the Save/Recall menu, see “File Menu” on page 3-29. Scale Menu (VNA Menus) Scale Resolution Per Div 6.0 dB Reference Value 30.0 dB Reference Line Autoscale...
  • Page 104 3-7 VNA Key Functions - Scale Menu (VNA Menus) Chapter 3 — Vector Network Analyzer Aperture (Group Delay measurements only) This soft key appears only when Group Delay has been selected in the measurement menu. Group delay is a measurement of “Change in phase / change in frequency.” The aperture setting is used by the VNA Master to determine how large a change in frequency to use in this calculation.

  • Page 105: Sweep Menu

    Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Sweep Menu Sweep Menu Figure 3-29. Sweep Menu To access the Sweep Menu, press the key then the (3) key. All of the variables that Shift Sweep affect the sweep can be found in this menu. Run/Hold Press this soft key to select .
  • Page 106 3-7 VNA Key Functions - Sweep Menu Chapter 3 — Vector Network Analyzer RF Immunity Press the soft key to select . The VNA Master uses a special dithering High Normal technique to improve immunity to interfering signals. Selecting turns the High dithering on.
  • Page 107 Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - Sweep Menu Averaging Factor Press the soft key, then use the arrow keys, the keypad, or the rotary knob to set the averaging factor. Press the key or the rotary knob to enter the value. Enter Restart Press this soft key to start a new averaging sequence.

  • Page 108: System Menu

    3-7 VNA Key Functions - System Menu Chapter 3 — Vector Network Analyzer System Menu System Recall Status Measurement Self Delete GPS Info Test --> Application Self Test --> App Options Reset Meas Menu Field Back Application Back Options --> System Options -->...
  • Page 109 Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions - System Menu To access the System Menu, press the key, then the (8) key. The System menu is Shift System used to interact with the system attributes of the VNA Master. Self Test, GPS, Application Options, and System Options can be found in this menu.
  • Page 110 Update OS Via Ethernet This soft key should only be used in conjunction with Anritsu Master Software Tools to update the instrument operating system using an Ethernet connection. Use this soft key only as instructed by MST.

  • Page 111: Trace Menu

    Chapter 3 — Vector Network Analyzer 3-7 VNA Key Functions Trace Menu Trace Recall Trace Copy Trace To Display Memory Trace Math Trace Plus Memory Trace Minus Memory Show Memory Figure 3-31. Trace Menu To access the Trace Menu, press the key, then the (5) key.
  • Page 112 3-7 VNA Key Functions Chapter 3 — Vector Network Analyzer then the recalled trace disappears, and only the active sweep is displayed. The system sweep settings (that were in effect before the trace was recalled) are restored. Pressing loads the sweep settings that are associated with the recalled trace, and the VNA Enter Master begins making measurements using those sweep settings.

  • Page 113: Introduction

    Chapter 4 — Spectrum Analyzer 4-1 Introduction Spectrum analyzer measurements include the use of additional functions beyond frequency, span, amplitude and marker functions. The first section of this chapter presents the soft key menus available when Spectrum Analyzer mode is selected. The next section focuses on resolution bandwidth, video bandwidth, sweep, and attenuator functions.

  • Page 114: Making Spectrum Analyzer Measurements

    4-3 Making Spectrum Analyzer Measurements Chapter 4 — Spectrum Analyzer 4-3 Making Spectrum Analyzer Measurements Required Equipment • Anritsu MS203xA VNA Master • Optionally, an antenna that is appropriate for the frequency range to be measured Making a Measurement To make a measurement, locate and display the signals of interest by selecting the desired frequency, span, and amplitude value, as explained below.

  • Page 115: Selecting A Signal Standard

    Chapter 4 — Spectrum Analyzer 4-3 Making Spectrum Analyzer Measurements 8. Press the soft key and use the arrow keys or the keypad to enter the Scale Up/Down desired scale. Press to set the scale. Enter Press the soft key and select coupling of the attenuator setting Amplitude Auto Atten...
  • Page 116 4-3 Making Spectrum Analyzer Measurements Chapter 4 — Spectrum Analyzer Auto coupling of the VBW links the video bandwidth to the resolution bandwidth, so that the wider the RBW, the wider the VBW. Auto coupling is indicated on the left side of the display .

  • Page 117: Resolution Bandwidth

    Chapter 4 — Spectrum Analyzer 4-4 Resolution Bandwidth 4-4 Resolution Bandwidth Resolution Bandwidth is determined by the intermediate frequency (IF) filter bandwidth. The spectrum analyzer traces the shape of the IF filter as it tunes past a signal. If more than one IF filter is used in a spectrum analyzer, the narrowest one dominates and is considered the resolution bandwidth.

  • Page 118: Sweep Limitations

    “smeared” look to it, with the spectral lines being wider than normal and shifted to the right. Fortunately, the Anritsu VNA Master is designed to relieve the user from having to calculate the sweep speed or experiment to discover a sweep speed that yields accurate results. When changing the RBW and VBW with VNA Master, the sweep speed automatically changes to the fastest sweep speed that will yield accurate results.
  • Page 119 Chapter 4 — Spectrum Analyzer 4-8 Preamplifier Operation Figure 4-1. Preamplifier Off Figure 4-2. Preamplifier On MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 120: Field Measurements

    Chapter 4 — Spectrum Analyzer 4-9 Field Measurements In Spectrum Analyzer mode, smart one-button measurements are built into the Anritsu VNA Master for field strength, occupied bandwidth, channel power, adjacent channel power ratio, and carrier to interference ratio (C/I) tests. In addition, AM/FM/SSB demodulation is available to aid in the identification of interfering signals.

  • Page 121: Channel Power Measurement

    Chapter 4 — Spectrum Analyzer 4-11 Channel Power Measurement 7. Press the key then the (4) key followed by the soft key. Choose the Shift Measure OCC BW measurement method ( ) by pressing the soft key. The dBc Down % Down Method selected method is underlined.

  • Page 122: Gsm Channel Power Measurement

    Minimum Shift Keying (GMSK) modulation method. Required Equipment • MS203xA VNA Master • Test Port extension cable, Anritsu 15NNF50 - 1.5C Procedure 1. Using the test port extension cable, connect the signal source to the test port of the RF In Anritsu MS203xA VNA Master.

  • Page 123: Gsm Adjacent Channel Power Measurement

    Required Equipment • Anritsu MS203xA VNA Master • 30 dB, 50 watt, Bi-Directional, DC - 18 GHz, N(m) - N(f), Attenuator, Anritsu 42N50A-30 (if required for the power level being measured) • Test Port extension cable, Anritsu 15NNF50 - 1.5C Procedure 1.

  • Page 124: Out-Of-Band Spurious Emission Measurement

    4-14 Out-of-Band Spurious Emission Measurement Required Equipment • MS203xA VNA Master • Test Port extension cable, Anritsu 15NNF50 - 1.5C Procedure 1. Using the test port extension cable, connect the signal source to the test port of the RF In MS203xA.

  • Page 125: In-Band/Out-Of-Channel Measurements

    Chapter 4 — Spectrum Analyzer 4-15 In-Band/Out-of-Channel Measurements 10. Repeat Step #8. Step #9. for the remaining spurs. Use either Marker 1 again, or choose another marker. Figure 4-4 shows a simulated out-of-band spurious signal 21.000 MHz from the carrier using a delta marker. Figure 4-4.

  • Page 126: In-Band Spurious Measurement

    4-16 In-Band Spurious Measurement Required Equipment • MS203xA VNA Master • 30 dB, 50 watt, Bi-Directional, DC - 18 GHz, N(m) - N(f), Attenuator, Anritsu 42N50A-30 • Test Port extension cable, Anritsu 15NNF50 - 1.5C Procedure 1. Using the test port extension cable and 30 dB, 50 watt, Bi-directional attenuator, connect the MS203xA to appropriate transmit test port.
  • Page 127 Chapter 4 — Spectrum Analyzer 4-16 In-Band Spurious Measurement Figure 4-5 shows a simulated in-band spur at 1.627272 MHz from the carrier frequency (f ) of 444.001820 MHz and is measured by M1. The delta marker on M1 shows the signal at + 1.627272 MHz to be 60.60 dB down from the carrier.

  • Page 128: Field Strength

    Select an antenna from the standard list available in the MS203xA, or use the Note Antenna Editor feature of Anritsu Master Software Tools to define a custom antenna and upload the antenna information to the MS203xA antenna list. 3. Connect the antenna to the MS203xA.

  • Page 129: Antenna Calculations

    Chapter 4 — Spectrum Analyzer 4-17 Field Strength Antenna Calculations The following is a list of various antenna calculations should you find it necessary to convert from one to another: Conversion of Levels from W to V Conversion of signal levels from W to V in a 50 ohm system: ------ - where: P = power in Watts...

  • Page 130: Am/Fm/Ssb Demodulation

    4-18 AM/FM/SSB Demodulation Chapter 4 — Spectrum Analyzer 4-18 AM/FM/SSB Demodulation The VNA Master built-in demodulator for AM, narrowband FM, wideband FM and single sideband (selectable USB and LSB) allows a technician to hear an interfering signal to ease identification. The demodulated signal can be heard using either the built-in speaker, or through a monaural headset connected to the 2.5-mm jack on the test panel.

  • Page 131: Carrier To Interference Ratio Measurement

    Chapter 4 — Spectrum Analyzer 4-19 Carrier to Interference Ratio Measurement 4-19 Carrier to Interference Ratio Measurement Carrier to Interference Ratio (C/I) Measurement is a two-step process, first measuring the carrier level and then, with the carrier turned off, measuring the remaining signals and noise in the band of interest.
  • Page 132 4-19 Carrier to Interference Ratio Measurement Chapter 4 — Spectrum Analyzer The following figures show the C/I measurement steps, ready to measure the carrier, with the carrier measured, and the measurement results. Figure 4-6. C/I Measurement, Ready to Measure the Carrier Figure 4-7.
  • Page 133 Chapter 4 — Spectrum Analyzer 4-19 Carrier to Interference Ratio Measurement Figure 4-8. C/I Measurement, Results MS20xxA VNA Master UG 10580-00166 Rev. C 4-21...

  • Page 134: Spa Function Menu Tree

    4-20 SPA Function Menu Tree Chapter 4 — Spectrum Analyzer 4-20 SPA Function Menu Tree Introduction This chapter describes the VNA Master keys and how to use them. The major key sections are arranged in alphabetical order. The soft key menus under those key selections are listed in the order that they appear on the instrument, from top to bottom.

  • Page 135: Amplitude

    Chapter 4 — Spectrum Analyzer 4-21 Amplitude 4-21 Amplitude Description hard key is located below the display. The Amplitude menu soft keys are shown Amplitude Figure 4-9. Figure 4-9. Amplitude Menu Soft Keys Reference Level The reference level is the top graticule line on the display, and can be set from +30 dBm to –150 dBm.
  • Page 136 4-21 Amplitude Chapter 4 — Spectrum Analyzer Auto Atten On/Off Input attenuation can be either tied to the reference level (On) or manually selected (Off). When input attenuation is tied to the reference level, attenuation is increased as higher reference levels are selected to make sure the instrument input circuits are not saturated by large signals that are likely to be present when high reference levels are required.
  • Page 137 Chapter 4 — Spectrum Analyzer 4-21 Amplitude Peak This method causes the largest measurement point to be shown for each display point, and assures that a narrow peak is not missed. This method performs a root-mean-square calculation of all the measurement points in each display point.

  • Page 138: Bw (Bandwidth)

    4-22 BW (Bandwidth) Chapter 4 — Spectrum Analyzer 4-22 BW (Bandwidth) hard key is located below the display. The BW menu soft keys are shown in Figure 4-10. 3 MHz Auto RBW 1 MHz Auto VBW RBW/VBW Span/RBW Figure 4-10. BW Menu Soft Keys The current resolution bandwidth value is displayed in this soft key.
  • Page 139 Chapter 4 — Spectrum Analyzer 4-22 BW (Bandwidth) Span/RBW This soft key displays the ratio between the span width and the resolution bandwidth. The default value is 300, meaning that the span width is approximately 300 times the resolution bandwidth. The value is approximate because resolution bandwidth filters come in discrete steps while span width can be set to any value up to the maximum frequency of the instrument.

  • Page 140: File

    Measurements may be saved to the internal memory, an external Type-1 Compact Flash module, or a USB Flash Drive. Anritsu recommends saving to external storage if a large number of measurements are to be saved. The instrument is shipped with a Compact Flash module and a USB Flash Drive.
  • Page 141 Chapter 4 — Spectrum Analyzer 4-23 File Save Setup Opens a dialog box to name and save the current operating settings, allowing them to be recalled later to return the instrument to the state it was in at the time the setup was saved. The saved setup can be named using the keypad to select numbers, the rotary knob to highlight a number or character and pressing the knob to select, or by selecting the soft key for each letter.
  • Page 142 4-23 File Chapter 4 — Spectrum Analyzer measurement is automatically saved at the end of the sweep. The saved measurement is named “LIM” followed by the date and time in the format: LIMyyyymmddhhmmss. The time value in the file name will generally be slightly earlier than the measurement time stamp shown in the file list, since the file name is created at the time the limit violation is noted and the time stamp is the time at which the measurement file is actually saved.
  • Page 143 Chapter 4 — Spectrum Analyzer 4-23 File the measurement after entering the file name. The file is saved in the internal memory with the specified name, with .jpg appended. If a measurement has been previously saved, the Save Measurement dialog box will open with the previously saved name displayed.
  • Page 144 4-23 File Chapter 4 — Spectrum Analyzer Directory Management For information on the Directory Management soft key and menu, see “Directory Management” on page 4-32. Delete Brings up a selection box that shows the first 1000 stored setups and traces in the currently selected location (see “Directory Management”...
  • Page 145 Chapter 4 — Spectrum Analyzer 4-23 File files causes the “copy to destination” to be automatically changed if the selected storage location is the same as the selected current location. Copy to Destination Int USB CF This choice lets you select where measurements and setups in the “current location”...

  • Page 146: Freq (Frequency)

    4-24 Freq (Frequency) Chapter 4 — Spectrum Analyzer 4-24 Freq (Frequency) The tuning frequency range for the VNA Master can be entered in several different ways depending on what makes the most sense for the user or for the application. The center frequency and span can be specified, the start and stop frequencies can be entered, or a signal standard and channel number can be selected from the built-in list.
  • Page 147 Chapter 4 — Spectrum Analyzer 4-24 Freq (Frequency) Center Frequency Press the key followed by the soft key and enter the desired frequency Freq Center Freq using the keypad, the arrow keys, or the rotary knob. If entering a frequency using the keypad, the soft key labels change to .
  • Page 148 4-24 Freq (Frequency) Chapter 4 — Spectrum Analyzer Signal Standard Use the arrow keys or the rotary knob to highlight a signal standard and press Up/Down to select. Enter When a signal standard is selected, the center frequency and span for the first channel of the particular standard is automatically tuned.

  • Page 149: Limit

    Chapter 4 — Spectrum Analyzer 4-25 Limit 4-25 Limit To access the functions under the Limit menu, select the Shift key, then the Limit (6) key. The Limit menu soft keys are: Figure 4-13. Limit Menu Soft Keys Two types of limit lines can be specified, lower limit lines and upper limit lines. Limit lines can be used for visual reference only, or for pass/fail criteria using the limit alarm.
  • Page 150 4-25 Limit Chapter 4 — Spectrum Analyzer Limit Edit This soft key displays a submenu that allows creating or editing of single or multi-segment limit lines. The currently active limit point is marked by a red circle on the display. Move Limit Limit/Point Selects whether activity from the Frequency and Amplitude soft keys (described below) affect the entire limit or only the active limit point.
  • Page 151 Chapter 4 — Spectrum Analyzer 4-25 Limit the previously active point, until the selected active point is on the left side of the display. Next Point Right This soft key selects the limit point that is immediately to the right of the current active point, making this newly selected point active for editing or deletion.
  • Page 152 4-25 Limit Chapter 4 — Spectrum Analyzer Upper Points, ## (if Upper Limit is selected) Lower Points, ## (if Lower Limit is selected) Use this soft key to define how many inflection points you want for the selected upper or lower limit envelopes. The value can be between 2 and 41. Note that the upper and lower limit lines do not need to have the same number of points.
  • Page 153 Chapter 4 — Spectrum Analyzer 4-25 Limit Figure 4-14. Example Limit Envelope, Square Limit Advanced The advanced limit line section offers several useful functions. In this section, you can create either an absolute limit line (which is one based upon the frequencies that are entered for each inflection point) or a relative limit line (which is based upon the delta frequencies between the center frequency and the inflection points).
  • Page 154 4-25 Limit Chapter 4 — Spectrum Analyzer desired value. The entire line moves by the amount that is entered. The limit line can also be moved by using the rotary knob. Turn the rotary knob clockwise to move the line to higher power levels. Move Limit, ## Hz Pressing this soft key allows you to adjust the frequencies of the limit line.

  • Page 155: Marker

    Chapter 4 — Spectrum Analyzer 4-26 Marker 4-26 Marker Press the Marker function hard key to open the Marker menu. The Spectrum Analyzer is equipped with six markers. Any or all markers can be employed simultaneously. The Marker hard key is located below the display. The Marker menu soft keys are: Marker &...
  • Page 156 4-26 Marker Chapter 4 — Spectrum Analyzer On/Off This soft key makes the marker selected by the Marker soft key above active for editing. If the marker is currently active for editing, pressing the On/Off key causes the marker, and any associated Delta marker, to be turned off. Delta On/Off If the Delta marker is on, but not active for editing, pressing this soft key makes the Delta marker active for editing.
  • Page 157 Chapter 4 — Spectrum Analyzer 4-26 Marker Marker to Ref Lvl Sets the amplitude of the currently active marker to the top graticule line as the reference level. Peak Threshold This soft key allows the user to specify how far above the average noise floor a signal must rise before it is considered a peak.
  • Page 158 4-26 Marker Chapter 4 — Spectrum Analyzer Marker 1 Reference On Off This soft key selects whether Marker 1 is the reference for all six delta markers, or whether each of the six reference markers has an associated delta marker. When Marker 1 Reference is turned ON, Marker 1 is set to the current frequency.

  • Page 159: Measure

    Chapter 4 — Spectrum Analyzer 4-27 Measure 4-27 Measure To access the functions under the Measure menu, select the key, then the Shift Measure key. The Measure menu soft keys are shown in Figure 4-17. Figure 4-17. Measure Menu Soft Keys Field Strength This measurement allows the use of an antenna with known gain characteristics and measures the field strength over the frequency range of the antenna in units of...
  • Page 160 4-27 Measure Chapter 4 — Spectrum Analyzer Antenna This soft key brings up a dialog box that lists all the antennas for which the instrument has data, including both standard antennas and custom antenna that have been added using Master Software Tools. Use the Up/Down arrow keys or the rotary knob to select the desired antenna and press Enter Back...
  • Page 161 Chapter 4 — Spectrum Analyzer 4-27 Measure ACPR Accesses a menu of Adjacent Channel Power Ratio measurement options: On Off Begins or ends the ACPR measurement. Main Ch BW Sets the bandwidth of the main channel for ACPR measurement. Use the keypad, the directional arrow keys or the rotary knob to enter the a specific frequency.
  • Page 162 4-27 Measure Chapter 4 — Spectrum Analyzer instrument sweeps one time for every demodulation period. Sweeping pauses during the demodulation time. Set Demod Freq to Current Marker Freq Sets the demodulation frequency to the frequency of the current marker. Beat Freq Osc Sets the beat frequency of the oscillator to exactly set the demodulation frequency of USB and LSB signals.

  • Page 163: Mode

    Chapter 4 — Spectrum Analyzer 4-28 Mode 4-28 Mode To access the functions under the Mode menu, select the key, then the (9) key. The Shift Mode mode list in a particular instrument depends upon the options that are purchased for that instrument.

  • Page 164: Span

    4-30 Span Chapter 4 — Spectrum Analyzer 4-30 Span The Span menu is used to set the frequency range over which the instrument will sweep. For the MS2034A, the span can be set from 10 Hz to 4.0 GHz. For the MS2036A, the span can be set from 10 Hz to 7.1 G.
  • Page 165 Chapter 4 — Spectrum Analyzer 4-30 Span Full Span Pressing this button sets the span to cover the entire tunable spectrum of the instrument. Zero Span This soft key sets zero span. In this mode the display shows amplitude changes at a single frequency.

  • Page 166: Sweep

    4-31 Sweep Chapter 4 — Spectrum Analyzer 4-31 Sweep To access the functions under the Sweep menu, select the key, then the (3) key. Shift Sweep The Sweep menu soft keys are shown in Figure 4-20. Detection Peak Sweep Sweep Single Continuous Trigger Manual...
  • Page 167 Chapter 4 — Spectrum Analyzer 4-31 Sweep Reset Sweep This soft key stops the current sweep, clears trace averaging results, clears the maximum hold results, if selected, and restarts the sweep at the left side of the screen. Detection Several detection methods tailor the performance of the instrument to meet specific measurement requirements.
  • Page 168 4-31 Sweep Chapter 4 — Spectrum Analyzer External A TTL signal applied to the BNC input connector causes a single External Trigger sweep to occur. This mode is used in zero span, and triggering occurs on the rising edge of the signal. After the sweep is complete, the resultant trace is displayed until the next trigger signal arrives.

  • Page 169: System

    Chapter 4 — Spectrum Analyzer 4-32 System 4-32 System To access the functions under the System menu, select the key, then the (8) key. Shift System The System menu soft keys are shown in Figure 4-21. Figure 4-21. System Menu Soft Keys MS20xxA VNA Master UG 10580-00166 Rev.
  • Page 170 This soft key presents a menu to select application options. Impedance 50 Ohm/75 Ohm/Other Select either 50 ohm, 75 ohm, or other impedance value. Selecting 75 ohm selects the 7.5 dB loss of the Anritsu 12N50-75B or 12N75B adapter. For other adapters, select and enter the appropriate loss.
  • Page 171 Chapter 4 — Spectrum Analyzer 4-32 System Ethernet Configuration This soft key brings up a dialog box to set the IP address of the instrument. Type Manual/DHCP This softkey selects whether the address will be entered manually, or supplied automatically by a network DHCP server. If Manual is selected, use the soft keys or the Left/Right arrow keys to select the field to be modified.
  • Page 172 Update OS Via Ethernet This soft key should only be used in conjunction with Anritsu Master Software Tools (MST) to update the instrument operating system using an Ethernet connection. Use this soft key only as instructed by MST.

  • Page 173: Trace

    To access the functions under the Trace menu, select the Shift key and then the Trace (5) key. The Anritsu VNA Master is capable of displaying up to six traces. Trace A shows live data, Traces B and C can show stored or trace math data, and the Recalled A-C traces allow the user to see three recalled traces without overwriting the three current traces.
  • Page 174 4-33 Trace Chapter 4 — Spectrum Analyzer Trace A Operations Allows the user to select from the operations that can be applied to Trace A. Normal -> A The trace displays current data for the current sweep. Max Hold -> A The trace shows the cumulative maximum value of each display point over many sweeps.
  • Page 175 Chapter 4 — Spectrum Analyzer 4-33 Trace Max Hold -> C The trace shows the cumulative maximum value of each display point over many sweeps Min Hold -> C The trace shows the cumulative minimum value of each display point over many sweeps.
  • Page 176 4-33 Trace Chapter 4 — Spectrum Analyzer Recalled Traces Brings up the Recalled Traces menu with available operations for measurement traces that have been recalled from a storage device. Use Recalled Setups Pressing this soft key will change the instrument sweep state from its current settings to those that apply to Trace Recalled A.

  • Page 177: Introduction

    Chapter 5 — Power Meter 5-1 Introduction The Internal Power Meter is a standard feature on the VNA Master. The VNA Master can display measured power in dBm, dBV, dBmV, dBµV, Volts, or Watts. No external sensor is required. The internal Power Meter frequency span can be set from 1 kHz to 100 MHz. The Full Band soft key conveniently sets the frequency range to 100 MHz on the current center frequency to simulate a broadband measurement.

  • Page 178: Set The Limit Lines

    5-2 Procedure Chapter 5 — Power Meter Figure 5-1. Sample Power Meter Display Set the Limit Lines Maximum and minimum limits can be set. The following is the procedure for setting the limits. 1. On the VNA Master, select the function hard key, or select the key, then the Limit...
  • Page 179 Chapter 5 — Power Meter 5-2 Procedure If the power is between the limits, then the measurement display is green. Figure 5-2. Power Meter Display, Passed If the power is not between the limit lines, then the measurement display is red. Figure 5-3.

  • Page 180: Power Meter Mode Menus

    5-3 Power Meter Mode Menus Chapter 5 — Power Meter 5-3 Power Meter Mode Menus There are four Power Meter Mode menus: • Amplitude Menu • Average Menu • Freq (Frequency) Menu • Limit Menu Each is described in greater detail in the sections below. 5-4 Amplitude Menu Amplitude Units...
  • Page 181 Chapter 5 — Power Meter 5-4 Amplitude Menu Sets the maximum value on the display. Sets the minimum value on the display. Offset A value of ± 100 dB can be entered. Relative Selects whether relative power is on or off. This measurement shows the relative level of the desired base power level input to the VNA Master.

  • Page 182: Average Menu

    5-5 Average Menu Chapter 5 — Power Meter 5-5 Average Menu RMS Averaging Acquisition Fast Med Slow Running Averages Figure 5-5. Power Meter Mode Average Menu Acquisition Sets the measurement speed. Choose either Fast, Medium or Slow. Running Average Sets the average of the number of traces. Enter the desired number using the keypad, rotary knob or the arrow keys.

  • Page 183: Freq (Frequency) Menu

    Chapter 5 — Power Meter 5-6 Freq (Frequency) Menu 5-6 Freq (Frequency) Menu Freq Span Center Freq Span 7.100 GHz 3.500 GHz Start Freq Span Up 1-2-5 3.000 Hz Stop Freq Span Down 1-2-5 4.000 GHz Span Full Span --> Freq Step Min Span 1.000 MHz...
  • Page 184 5-6 Freq (Frequency) Menu Chapter 5 — Power Meter Stop Freq Enter a stop frequency by using the keypad, rotary knob or the arrow keys. If the entered stop frequency is lower than the current start frequency, then the start frequency is automatically adjusted to be 1 kHz less than the stop frequency (max span).

  • Page 185: Limit Menu

    Chapter 5 — Power Meter 5-7 Limit Menu 5-7 Limit Menu Limit Limit Upper Limit 8.0 dBm Lower Limit -8.0 dBm Figure 5-7. Power Meter Mode Limit Menu Limit Turns the limits on or off. Upper Limit Sets the upper limit. Lower Limit Sets the lower limit.
  • Page 186 5-7 Limit Menu Chapter 5 — Power Meter 5-10 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 187: Introduction

    Chapter 6 — Power Monitor, Option 5 6-1 Introduction When equipped with Option 5, Power Monitor, the VNA Master can be used for making power measurements with broadband RF detectors, such as those listed in Table 1-16 on page 1-10. The power monitor displays the measured power results in dBm or Watts.

  • Page 188: Display Power In Dbm Or In Watts

    6-2 Procedure Chapter 6 — Power Monitor, Option 5 3. Press the key to complete the entry. Enter D U T A T T E N U A T O R R F D E T E C T O D U T D U T D U T...
  • Page 189 Chapter 6 — Power Monitor, Option 5 6-2 Procedure Figure 6-2. Power Monitor Display MS20xxA VNA Master UG 10580-00166 Rev. C...
  • Page 190 6-2 Procedure Chapter 6 — Power Monitor, Option 5 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 191: Introduction

    Chapter 7 — Built-In Bias Tee, Option 10 7-1 Introduction Option 10 provides a bias tee that is installed inside the VNA Master. The bias arm is connected to a 12 VDC-to-24 VDC power source that can be turned on as needed to place the voltage on the center conductor of the RF In port.

  • Page 192: Port Gain Measurements

    7-2 2-Port Gain Measurements Chapter 7 — Built-In Bias Tee, Option 10 7-2 2-Port Gain Measurements Two power levels are available with 2-port measurements: High (0 dBm) and Low (-35 dBm). The low power setting should be used when making direct gain measurements of amplifiers. This will ensure that the amplifier is operating in the linear region.
  • Page 193 Chapter 7 — Built-In Bias Tee, Option 10 7-2 2-Port Gain Measurements 13. Connect an attenuator between the test port extension cable and the port. RF In Figure 7-2. S21 Log Magnitude (VNA Measurement Menu) MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 194: Bias Tee Menu

    7-3 Bias Tee Menu Chapter 7 — Built-In Bias Tee, Option 10 7-3 Bias Tee Menu To access the Bias Tee menu, press the key then the (3) key. Press the soft Shift Sweep Bias Tee key to open the Bias Tee menu. Figure 7-3.

  • Page 195: Bias Tee Menu Soft Keys

    Chapter 7 — Built-In Bias Tee, Option 10 7-3 Bias Tee Menu Bias Tee Menu Soft Keys Bias Tee On/Off This soft key toggles the bias tee function On and Off. Bias Tee Voltage ##.# V Allows entry of the Bias Tee voltage to be placed on the center conductor of the RF In port.
  • Page 196 7-3 Bias Tee Menu Chapter 7 — Built-In Bias Tee, Option 10 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 197: Introduction

    Chapter 8 — Vector Voltmeter, Option 15 8-1 Introduction When equipped with option 15, the VNA Master is a convenient tool for ensuring phase match between RF cables, especially in the field where access to AC power is typically limited. This mode is called Vector Voltmeter mode (VVM) because it can replace a vector voltmeter, which is becoming obsolete.

  • Page 198: Using Vector Voltmeter Mode For The First Time

    8-3 Using Vector Voltmeter Mode for the First Time Chapter 8 — Vector Voltmeter, Option 15 8-3 Using Vector Voltmeter Mode for the First Time Before conducting a measurement in vector voltmeter mode, select a CW frequency and perform a calibration. During calibration, choose between a 1-port or 2-port calibration depending upon whether return or insertion type measurements, respectively, are desired.
  • Page 199 Chapter 8 — Vector Voltmeter, Option 15 8-4 Simple Measurement Using CW Display OPEN CALIBRATION SHORT LOAD TEST PORT CABLE (OPTIONAL) RFOUT/REFLECTION TEST PORT Figure 8-2. 1-Port Calibration MS20xxA VNA Master UG 10580-00166 Rev. C...
  • Page 200 8-4 Simple Measurement Using CW Display Chapter 8 — Vector Voltmeter, Option 15 OPTIONAL ADAPTOR FOR THROUGH CONNECTION OPEN SHORT LOAD TEST PORT CABLE (OPTIONAL) LOAD TEST PORT CABLE (OPTIONAL) RF OUT TEST PORT RF IN TEST PORT Figure 8-3. 2-Port Calibration 10.
  • Page 201 Chapter 8 — Vector Voltmeter, Option 15 8-4 Simple Measurement Using CW Display 11. Connect the DUT for measurement. The display should appear similar to the image in Figure 8-4. Figure 8-4. Continuous Wave Menu 12. Specify to be for a 1-port DUT. After a 2-port calibration, both Measurement Type Return measurement types can be viewed.

  • Page 202: Simple Relative Measurements Using Cw Display

    8-5 Simple Relative Measurements using CW Display Chapter 8 — Vector Voltmeter, Option 15 8-5 Simple Relative Measurements using CW Display The operations for relative measurements are described in the following steps. 1. From the menu, preset the Vector Voltmeter Mode for relative measurements by pressing the soft key.

  • Page 203: Vector Voltmeter Measurements Using Table Display

    Chapter 8 — Vector Voltmeter, Option 15 8-6 Vector Voltmeter Measurements Using Table Display 8-6 Vector Voltmeter Measurements Using Table Display The Vector Voltmeter includes a convenient table display for comparing up to five cables. With this feature, the user can save the first cable measurement as a reference, can view the differences among the other cables, and can output a final report showing both absolute and relative values of all the cables.
  • Page 204 8-6 Vector Voltmeter Measurements Using Table Display Chapter 8 — Vector Voltmeter, Option 15 to display the difference between the current measurement and the saved reference measurement. Figure 8-7. Vector Voltmeter Relative Measurement Table 8. Before disconnecting the first DUT, save the results in the current row by using the soft key to move to another row in the table.

  • Page 205: Vector Voltmeter Mode Menus

    Chapter 8 — Vector Voltmeter, Option 15 8-7 Vector Voltmeter Mode Menus - CW Menu 8-7 Vector Voltmeter Mode Menus In the Vector Voltmeter mode, the function hard keys display the following labels: “CW”, The fifth function hard key has no function in the Vector Volt “Table”, “Save/Recall”, “Cal”.
  • Page 206 8-7 Vector Voltmeter Mode Menus - CW Menu Chapter 8 — Vector Voltmeter, Option 15 Measurement Type: Return – Insertion Press the soft key to toggle between return and insertion. Measurement Type Return Meas Format: dB – VSWR – Imped Press the soft key toggle among dB, VSWR, and Imped (impedance).

  • Page 207: Table Menu

    Chapter 8 — Vector Voltmeter, Option 15 8-7 Vector Voltmeter Mode Menus - Table Menu Table Menu Table CW Frequency 2.710 GHz Measurement Type Return Insertion Select Cable 3 4 5 Save Reference Clear Reference Figure 8-9. Table Menu CW Frequency #.### GHz, MHz, kHz, GHz Press this soft key to set the desired measurement frequency.

  • Page 208: Save/Recall Menu

    8-7 Vector Voltmeter Mode Menus - Save/Recall Menu Chapter 8 — Vector Voltmeter, Option 15 Save/Recall Menu For a description of the soft keys in the Save/Recall menu, refer to “Save/Recall Menu” on page 3-49 Chapter 3, “Vector Network Analyzer”. Calibration Menu For description of the Calibration menu items and options, refer to “Calibration Menu”...

  • Page 209: Introduction

    Chapter 9 — Interference Analyzer, Option 25 9-1 Introduction Many wireless networks operate in complicated signal environments. Three or four base station antennas may be located onto the same tower and can create interference problems, which can affect system capacity and coverage. The Interference Analyzer option adds three measurement capabilities to the VNA Master: •...
  • Page 210 9-2 Spectrogram Measurement Chapter 9 — Interference Analyzer, Option 25 7. Press the function hard key and the soft key twice. Measurements Spectrogram 8. Set the time between sweeps by selecting the soft key, or set the total time Sweep Interval for a full spectrogram by selecting the soft key.
  • Page 211 Chapter 9 — Interference Analyzer, Option 25 9-2 Spectrogram Measurement 13. Press the key to place up to six markers on the signal and display the power and Marker frequency at each marker position. Figure 9-1. Interference Analyzer Mode Sample Spectrogram Display MS20xxA VNA Master UG 10580-00166 Rev.

  • Page 212: Signal Strength

    For field strength measurements, antenna factors are included. Antenna factors for all antennas offered by Anritsu are stored in the unit. Custom antenna factors can be created and downloaded into the instrument using Anritsu Master Software Tools software.
  • Page 213 Chapter 9 — Interference Analyzer, Option 25 9-3 Signal Strength 7. If necessary, press the soft key to set the speaker or headphone volume to a Volume comfortable level. Use the Up/Down arrow keys to adjust the volume. Figure 9-2. Interference Analyzer Mode Signal Strength Display MS20xxA VNA Master UG 10580-00166 Rev.

  • Page 214: Rssi (Received Signal Strength Indicator)

    9-4 RSSI (Received Signal Strength Indicator) Chapter 9 — Interference Analyzer, Option 25 9-4 RSSI (Received Signal Strength Indicator) The Received Signal Strength Indicator, RSSI. is useful for observing signal strength at a single frequency over time. Procedure The following procedure demonstrates a common Interference Analyzer RSSI setup. To select Interference Analyzer mode: 1.
  • Page 215 Chapter 9 — Interference Analyzer, Option 25 9-4 RSSI (Received Signal Strength Indicator) Figure 9-3. Interference Analyzer Mode RSSI Display MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 216: Freq (Frequency) Menu

    9-5 Freq (Frequency) Menu Chapter 9 — Interference Analyzer, Option 25 9-5 Freq (Frequency) Menu Freq Span Center Freq Span 7.100 GHz 3.550 GHz Start Freq Span Up 1-2-5 0 Hz Stop Freq Span Down 1-2-5 7.100 GHz Span Full Span -->...
  • Page 217 Chapter 9 — Interference Analyzer, Option 25 9-5 Freq (Frequency) Menu Center Freq Press the key followed by the soft key and enter the desired frequency Freq Center Freq using the keypad, the arrow keys, or the rotary knob. If entering a frequency using the keypad, then the soft key labels change to .
  • Page 218 9-5 Freq (Frequency) Menu Chapter 9 — Interference Analyzer, Option 25 Freq Step Press the key followed by the soft key to enter the desired frequency step Freq Freq Step size. The frequency step specifies the amount by which a frequency will change when arrow key is pressed.

  • Page 219: Amplitude Menu

    Chapter 9 — Interference Analyzer, Option 25 9-6 Amplitude Menu 9-6 Amplitude Menu Amplitude Units Reference Level 10.0 dBm Scale 10 dB/div Auto Atten dBmV Atten Lvl dbuV 30.0 dB RL Offset Volt 0.0 dB Units Watt --> Detection Pre Amp Peak Detection Back...
  • Page 220 9-6 Amplitude Menu Chapter 9 — Interference Analyzer, Option 25 Reference Level The reference level is the top graticule line on the display, and can be set from +30 dBm to -150 dBm. A negative value may be entered from the key pad, using the ± key as the minus sign.

  • Page 221: Bw (Bandwidth) Menu

    Chapter 9 — Interference Analyzer, Option 25 9-7 BW (Bandwidth) Menu 9-7 BW (Bandwidth) Menu 3 MHz Auto RBW 1 MHz Auto VBW RBW/VBW Span/RBW Figure 9-6. Interference Analyzer Mode BW Menu The current resolution bandwidth value is displayed in this soft key. The RBW can be changed using the keypad, the arrow keys, or the rotary knob.
  • Page 222 9-7 BW (Bandwidth) Menu Chapter 9 — Interference Analyzer, Option 25 Span/RBW This soft key displays the ratio between the span width and the resolution bandwidth. The default value is 300, meaning that the span width is approximately 300 times the resolution bandwidth.

  • Page 223: Measurements Menu

    Chapter 9 — Interference Analyzer, Option 25 9-8 Measurements Menu 9-8 Measurements Menu Measurements Spectrum --> Spectrogram --> Signal Strength --> RSSI --> Figure 9-7. Interference Analyzer Mode Measurements Menu The red circle on the soft key indicates the currently active measurement. The Note arrow does not appear on the soft key until after the key has been pressed and the function has become active.

  • Page 224: Spectrum Menu

    9-9 Spectrum Menu Chapter 9 — Interference Analyzer, Option 25 9-9 Spectrum Menu F Strength OCC BW Method Antenna % Down dBc Down Measure Field 99.00 % Strength --> OCC BW --> Channel Pwr Channel ACPR Power --> Center Freq ACPR -->...
  • Page 225 Chapter 9 — Interference Analyzer, Option 25 9-9 Spectrum Menu Field Strength This measurement allows the use of an antenna with known gain characteristics and measures the field strength over the frequency range of the antenna in units of dBm/meter , dbV/meter , dBmV/meter , dBµV/meter...
  • Page 226 9-9 Spectrum Menu Chapter 9 — Interference Analyzer, Option 25 keypad, the directional arrow keys or the rotary knob to enter the integration bandwidth. Span Sets the channel span for channel power measurement. Use the keypad, the directional arrow keys or the rotary knob to enter the channel span. Back Returns to the previous menu.
  • Page 227 Chapter 9 — Interference Analyzer, Option 25 9-9 Spectrum Menu FM Wide Band FM Narrow Band Demod Freq Use the keypad, the directional arrow keys or the rotary knob to enter the center frequency of the signal to be demodulated. This frequency does not have to be within the current frequency sweep range to which the instrument is set.
  • Page 228 9-9 Spectrum Menu Chapter 9 — Interference Analyzer, Option 25 Carrier Signal Type Opens a menu to select the carrier signal type. NB FHSS (Narrow Band Frequency Hopping Spread Spectrum) Use this setting when the signal being measured is 802.11b. WB FHSS (Wide Band Frequency Hopping Spread Spectrum) Use this setting when the signal being measured is 802.11a or 802.11g.

  • Page 229: Spectrogram Menu

    Chapter 9 — Interference Analyzer, Option 25 9-10 Spectrogram Menu 9-10 Spectrogram Menu Spectrogram Sweep Interval Auto Time Span Auto Auto Save Time Cursor Reset/ Restart Measurement Back Figure 9-9. Interference Analyzer Mode Spectrogram Menu Sweep Interval Press the Sweep Interval soft key and use the rotary knob or keypad to set the time from 1 millisecond to 60 seconds.
  • Page 230 9-10 Spectrogram Menu Chapter 9 — Interference Analyzer, Option 25 Auto Save When the Time Span is set to an interval other than Auto, the spectrogram plots can be automatically saved when the waterfall display is full by pressing the soft Auto Save key.

  • Page 231: Signal Strength Menu

    Chapter 9 — Interference Analyzer, Option 25 9-11 Signal Strength Menu 9-11 Signal Strength Menu Signal Strength F Strength Auto Scale Max Level Antenna -40.0 dBm Min Level -140.0 dBm Speaker Volume Field Back Strength --> Back Figure 9-10. Interference Analyzer Mode Signal Strength Menu Auto Scale Press the soft key to automatically scale the display range.
  • Page 232 9-11 Signal Strength Menu Chapter 9 — Interference Analyzer, Option 25 Field Strength This measurement allows the use of an antenna with known gain characteristics and measures the field strength over the frequency range of the antenna in units of dBm/meter , dbV/meter , dBmV/meter...

  • Page 233: Rssi (Received Signal Strength Indicator) Menu

    Chapter 9 — Interference Analyzer, Option 25 9-12 RSSI (Received Signal Strength Indicator) Menu 9-12 RSSI (Received Signal Strength Indicator) Menu RSSI Time Interval 70 ms Time Span Auto Auto Scale Auto Save Reset/ Restart Measurement Back Figure 9-11. Interference Analyzer Mode RSSI Menu Time Interval Press the soft key to set the time between adjacent measurement points.
  • Page 234 9-12 RSSI (Received Signal Strength Indicator) Menu Chapter 9 — Interference Analyzer, Option 25 Auto Save On/Off To store the RSSI data, press the soft key to turn on data logging. The Auto Save On/Off data is named Log - followed by the time at which the data was stored. Each screen full of 551 data points will be stored as a separate display, and can be saved for up to seven days.

  • Page 235: Marker Menu

    Chapter 9 — Interference Analyzer, Option 25 9-13 Marker Menu 9-13 Marker Menu Marker & Peak Recall Peak Search Measurement Marker(2/2) Marker(1/2) Marker Noise Next Peak Marker Delete Left 2 3 4 5 6 --> Copy All Next Peak Marker Table External Card Right Copy All...
  • Page 236 9-13 Marker Menu Chapter 9 — Interference Analyzer, Option 25 Peak Search This soft key places the currently active marker on the highest signal amplitude currently displayed on screen. Marker Freq to Center This soft key changes the center frequency to place the currently active marker at the center of the display.
  • Page 237 Chapter 9 — Interference Analyzer, Option 25 9-13 Marker Menu More Opens a submenu of further Marker options. Marker Noise This marker option turns the markers into noise markers with units of dBm/Hz. When this option is selected, the detection method is automatically changed to RMS and the displayed value is compensated for the noise bandwidth of resolution bandwidth filter.
  • Page 238 9-13 Marker Menu Chapter 9 — Interference Analyzer, Option 25 9-30 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 239: Introduction

    Chapter 10 — Channel Scanner, Option 27 10-1 Introduction This chapter presents Channel Scanner information and procedures. The Channel Scanner option (Option 27) measures the signal power of multiple transmitted signals. The power can be displayed as either a bar graph or a text display showing the channel power of selected channels for a given air interface standard, or the manually entered channels.

  • Page 240: Sample Channel Scanner Setup Procedure

    10-2 Sample Channel Scanner Setup Procedure Chapter 10 — Channel Scanner, Option 27 10-2 Sample Channel Scanner Setup Procedure The following procedure demonstrates a common channel scanner setup. 1. On the VNA Master, select the key, then the (9) key. Shift Mode 2.

  • Page 241: Custom Setup

    Chapter 10 — Channel Scanner, Option 27 10-3 Custom Setup 10-3 Custom Setup Procedure 1. On the VNA Master, select the key, then the (9) key. Shift Mode 2. Use the directional arrow keys or the rotary knob to highlight and press Channel Scanner key to select.

  • Page 242: Custom Setup Example

    10-3 Custom Setup Chapter 10 — Channel Scanner, Option 27 Custom Setup Example This example explains how to monitor several signals, plus a potential intermodulation product, to see if there is a correlation between the nearby signals and an intermittent interference problem.

  • Page 243: Scanner Menu

    Chapter 10 — Channel Scanner, Option 27 10-4 Scanner Menu 10-4 Scanner Menu Scanner Channel Scan Recall Scan Signal Standard Measurement Channels --> Freq Scan Scan Channel Delete Recall Start Freq Frequencies --> --> Measurement 825.030 MHz Copy All Scan Number of Channels External Card Freq Step Size...
  • Page 244 10-4 Scanner Menu Chapter 10 — Channel Scanner, Option 27 Channel Step Size # Sets the number of channels to skip between displayed channels. Back Returns to the previous menu. Scan Frequencies Select scan frequencies to activate the scan frequencies menu: Start Freq ###.### GHz, MHz, kHz, Hz Sets the center frequency of the first channel to be displayed.

  • Page 245: Amplitude Menu

    Chapter 10 — Channel Scanner, Option 27 10-5 Amplitude Menu 10-5 Amplitude Menu Amplitude Reference Level 10.0 dBm Scale 15 dB/div Figure 10-2. Channel Scanner Mode Amplitude Menu Reference Level Activates the amplitude reference level function which sets the amplitude at the top of the display.

  • Page 246: Custom Setup Menu

    10-6 Custom Setup Menu Chapter 10 — Channel Scanner, Option 27 10-6 Custom Setup Menu Custom Scan Recall Edit List Measurement Number of Channels Delete --> Back Figure 10-3. Channel Scanner Mode Custom Setup Menu Edit List Edit the Signal Standard, Channel, Frequency and Bandwidth for selected item. Number of Channels Sets the number of channels to be displayed (1 to 20).

  • Page 247: Measurements Menu

    Chapter 10 — Channel Scanner, Option 27 10-7 Measurements Menu 10-7 Measurements Menu Measurements Display Graph Table Max Hold On 5 sec Off Channel Units Channel Freq Units Display Current Color Code Single Dual Figure 10-4. Channel Scanner Mode Measurements Menu MS20xxA VNA Master UG 10580-00166 Rev.
  • Page 248 10-7 Measurements Menu Chapter 10 — Channel Scanner, Option 27 Display Graph/Table Toggles the display between table and graph formats (refer to Figure 10-5 Figure 10-6). Figure 10-5. Channel Scanner Mode Sample Graph Display Figure 10-6. Channel Scanner Mode Sample Table Display 10-10 MS20xxA VNA Master UG 10580-00166 Rev.
  • Page 249 Chapter 10 — Channel Scanner, Option 27 10-7 Measurements Menu Max Hold On/5 sec/Off Turns on or off small yellow lines for every channel/frequency on the display that indicate the highest level that channel or frequency has reached. The option holds 5 sec the small yellow line at the highest level in the last 5 seconds.
  • Page 250 10-7 Measurements Menu Chapter 10 — Channel Scanner, Option 27 10-12 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 251: Introduction

    Chapter 11 — High Accuracy Power Meter 11-1 Introduction The VNA Master with Option 019 is available on all VNA Master models and sensors PSN50 or MA24106A can be used to make High Accuracy Power Measurements from 50 MHz to 6 GHz.

  • Page 252: Getting Started With Hapm

    11-2 Getting Started with HAPM Chapter 11 — High Accuracy Power Meter 11-2 Getting Started with HAPM High Accuracy Power Meter (HAPM) Mode To prepare for High Accuracy Power Meter measurements, the VNA Master must be configured for High Accuracy Power Meter mode, as follows: 1.

  • Page 253: Hapm Operation Procedure

    Chapter 11 — High Accuracy Power Meter 11-3 HAPM Operation Procedure 11-3 HAPM Operation Procedure Turn on the VNA Master and the Sensor 1. Connect the USB A/mini-B cable between the High Accuracy Power Sensor and the VNA Master. Figure 11-1. High Accuracy Power Meter Setup Example 2.
  • Page 254 11-3 HAPM Operation Procedure Chapter 11 — High Accuracy Power Meter Changing the Scale of the Analog Display 1. Press the key. Amplitude 2. Press the soft key to align the needle in the middle of the analog display. The Auto Scale maximum and minimum values align accordingly.

  • Page 255: Saving The Measurement

    Chapter 11 — High Accuracy Power Meter 11-3 HAPM Operation Procedure Saving the Measurement 1. Press the key, then the (7) key. Shift File 2. Select the soft key. Save 3. Press the soft key and use the soft keys to enter the desired Save Measurement Text Entry file name.

  • Page 256: Hamp Menus

    11-4 HAMP Menus - Zero/Cal Menus Chapter 11 — High Accuracy Power Meter 11-4 HAMP Menus Zero/Cal Menus The Zero/Cal menu choices are shown in the following illustrations. Figure 11-2. Zero/Cal Menu Figure 11-3. Cal Factor Menu 11-6 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 257: Amplitude Menu

    Chapter 11 — High Accuracy Power Meter 11-4 HAMP Menus - Amplitude Menu Amplitude Menu Figure 11-4. Amplitude and Units Soft Key Menus MS20xxA VNA Master UG 10580-00166 Rev. C 11-7...
  • Page 258 11-4 HAMP Menus - Amplitude Menu Chapter 11 — High Accuracy Power Meter Figure 11-5. Units Menu 11-8 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 259: Averages Menu

    Chapter 11 — High Accuracy Power Meter 11-4 HAMP Menus - Averages Menu Averages Menu Figure 11-6. Averages Soft Key Menu Figure 11-7. Averages Menu MS20xxA VNA Master UG 10580-00166 Rev. C 11-9...

  • Page 260: Limits Menu

    11-4 HAMP Menus - Limits Menu Chapter 11 — High Accuracy Power Meter Limits Menu Figure 11-8. Limits Menu Figure 11-9. Limits Menu 11-10 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 261: Mode Menu

    Chapter 11 — High Accuracy Power Meter 11-4 HAMP Menus - Mode Menu Mode Menu To access the functions under the Mode menu, select the key, then the (9) key. Use Shift Mode the Up/Down arrow keys or the rotary knob to highlight the selection, and press the Enter to select.
  • Page 262 11-4 HAMP Menus - Mode Menu Chapter 11 — High Accuracy Power Meter 11-12 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 263: Introduction

    The GPS antenna connection on the VNA Master is fitted with a reverse BNC connector to help prevent damage to the GPS circuitry. There is a DC voltage Note present on this connector. Do not connect anything other than the Anritsu GPS antenna to this port. 1. Press the key, then the (8) key.

  • Page 264: Gps Menu

    12-3 GPS Menu Chapter 12 — GPS Receiver, Option 31 4. When the GPS receiver has tracked at least three satellites, the GPS icon will change to GREEN. Latitude and Longitude information is displayed in the white bar on top of the display.

  • Page 265: Gps Info Window

    Chapter 12 — GPS Receiver, Option 31 12-4 GPS Info Window 12-4 GPS Info Window Figure 12-4. GPS Info Window window provides the following GPS information: GPS Info Tracked Satellites Shows the number of tracked satellites (three are required to retrieve latitude and longitude, four are required to resolve altitude).

  • Page 266: Almanac Complete

    Short/Open message is displayed, then remove and replace the GPS antenna. If the message persists, then try another Anritsu GPS antenna (part number 2000–1410). If the message persists, then contact your nearest Anritsu Service Center. 12-5 Saving and Recalling Traces with GSP Information Saving Traces with GPS Information The GPS coordinates of a location can be saved along with a measurement trace.
  • Page 267 Tools 13-1 Introduction This chapter provides a description of the Anritsu Master Software Tools program. Master Software Tools is a suite of Microsoft Windows programs for transferring saved measurements (along with markers and limit lines) to a PC display. The programs provide...

  • Page 268: System Requirements

    13-4 Installation To install the Master Software Tools program, insert the Anritsu Master Software Tools disk in the CDROM drive. Follow the instructions in the installation program to install the software. If the autorun feature is disabled in your computer, then click on the Windows...

  • Page 269: A-1 Signal Standards

    Appendix A — Signal Standards A-1 Signal Standards This appendix provides a list of the signal standards included in the VNA Master. The standards displayed depend upon the operating mode selected. Center Span Signal Standard Valid Channels (MHz) (MHz) AMPS / EIA 553 - Uplink 1-799, 990-1023 AMPS / EIA 553 - Downlink 1-799, 990-1023...
  • Page 270 A-1 Signal Standards Appendix A — Signal Standards Center Span Signal Standard Valid Channels (MHz) (MHz) cdma2000 Class 4, Korea PCS - Downlink 1810 0-599 cdma2000 Class 5, (NMT-450-20 kHz) - Uplink 472.5 1039-1473, 1792-2016 cdma2000 Class 5, (NMT-450-20 kHz) - 1039-1473, 1792-2016 472.5 Downlink...
  • Page 271 Appendix A — Signal Standards A-1 Signal Standards Center Span Signal Standard Valid Channels (MHz) (MHz) NMT-450-25 kHz - Uplink 1-300 NMT-450-25 kHz - Downlink 1-300 NMT-470-20 kHz - Uplink 486.5 1972-2016 NMT-470-20 kHz - Downlink 486.5 1972-2016 NMT-900 - Uplink 1-1000 NMT-900 - Downlink 1-1000...
  • Page 272 A-1 Signal Standards Appendix A — Signal Standards MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 273: B-1 Introduction

    See the accessories section for a list available band pass filters from Anritsu. Out of band frequencies can often be detected by increasing the SPAN to maximum in peak detect mode of operation. Another resolution may be to Reset to factory defaults with...
  • Page 274 See the accessories section for a list of available band pass filters from Anritsu. Out of band frequencies can often be detected by increasing the Span to maximum in the peak detect mode of operation. Another resolution may be to reset to factory defaults with either Factory Defaults, ESC+ON, or MASTER RESET, System+ON.

  • Page 275: B-3 Operation Error Messages

    Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. Cannot change average for Recalled/Inactive Traces Cannot set Delta Detection modes or other elements like RBW/VBW, averaging etc.
  • Page 276 Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. EEPROM TEST: UNKNOWN ERROR Hardware communications between modules has failed. Insure that the battery level is adequate for operation or that temperature is within acceptable limits.
  • Page 277 Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. Fatal error, no SPA board connected Hardware communications between modules has failed.
  • Page 278 Factory Defaults, ESC+ON. Caution: Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center.
  • Page 279 System+ON. Caution: Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. Lock failure One or more of the Phase Lock Loops cannot keep the frequency controlled accurately. Insure that the battery level is adequate for operation and that the temperature is within acceptable limits.
  • Page 280 Defaults, ESC+ON, or MASTER RESET, System+ON. Caution: Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center.
  • Page 281 Use of MASTER RESET, System+ON, will erase all user saved setups and measurement traces and return the unit to a fully Factory Default condition. If the error persists, then contact your Anritsu Service Center. Use Demod type USB or LSB to use Beat Frequency Osc An attempt to use the Beat Frequency Oscillator while not in Upper or Lower Sideband Demodulation mode.

  • Page 282: B-4 Interference Analyzer Information Messages

    B-4 Interference Analyzer Information Messages Appendix B — Error Messages B-4 Interference Analyzer Information Messages ADC Over range: Increase Reference Level Attempting to lock to ext ref Attempting to lock to External ref Attempting to lock to Internal ref Attenuation has been changed Cannot change scale in Linear mode Cannot turn on delta marker because Ref Marker is a counter Marker Changing Active trace to A...
  • Page 283 Appendix B — Error Messages B-4 Interference Analyzer Information Messages Startup Selftest successful Successfully locked Sweep Stopped After Saving On Event Turning off Delta Marker Units has been changed to dBm Use Min/Max buttons under the Signal Strength Sub-Menu to change display range Use Min/Max buttons under the Signal Strength Sub-Menu to change measure range Valid Attenuations with Preamp on are 0dB and 10dB...

  • Page 284: B-5 Interference Analyzer Error Messages

    B-5 Interference Analyzer Error Messages Appendix B — Error Messages B-5 Interference Analyzer Error Messages Auto Save not available when Time Span is Auto Cannot change average for Recalled/Inactive Traces Cannot set Delta Mkr Freq to Demod Freq Current measurement is stopped when Cursor is not zero DDC Failure DSP Memory Failure Fatal error not decoded by DSP...
  • Page 285 Appendix B — Error Messages B-5 Interference Analyzer Error Messages Only HOLD is valid for Trace C when trace C is not being updated from A Operation not Permitted in Recall Mode Operation not Permitted in this Mode OVER POWER ERROR Pretune Calibration Failure The Freq range of the Antenna is invalid for this setup.

  • Page 286: B-6 Channel Scanner Information Messages

    B-6 Channel Scanner Information Messages Appendix B — Error Messages B-6 Channel Scanner Information Messages Attempting to lock to ext ref Attempting to lock to External ref Attempting to lock to Internal ref Press ESC to clear Recall Trace Reference Locked Successfully Startup DSP Memory test successful Startup Selftest successful B-14...

  • Page 287: B-7 Channel Scanner Error Messages

    Appendix B — Error Messages B-7 Channel Scanner Error Messages B-7 Channel Scanner Error Messages ADC Over range: Increase Reference Level Error Recalling Measurement Mixer Saturation: Increase Attenuation Not Available when Max Hold is OFF Operation not Permitted in Recall Mode MS20xxA VNA Master UG 10580-00166 Rev.
  • Page 288 B-7 Channel Scanner Error Messages Appendix B — Error Messages B-16 MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 289: C-1 Introduction

    Appendix C — Windowing C-1 Introduction The theoretical requirement for inverse FFT is for the data to extend from zero frequency to infinity. Side lobes appear around a discontinuity due to the fact that the spectrum is cut off at a finite frequency. Windowing reduces the side lobes by smoothing out the sharp transi-tions at the beginning and at the end of the frequency sweep.
  • Page 290 C-2 Windowing Examples Appendix C — Windowing Figure C-2. Nominal Side Lobe Windowing Example Figure C-3. Low Side Lobe Windowing Example MS20xxA VNA Master UG 10580-00166 Rev. C...
  • Page 291 Appendix C — Windowing C-2 Windowing Examples Figure C-4. Minimum Side Lobe Windowing Example MS20xxA VNA Master UG 10580-00166 Rev. C...
  • Page 292 C-2 Windowing Examples Appendix C — Windowing MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 293: D-1 Introduction

    Appendix D — Tower Mounted Amplifiers D-1 Introduction A Tower Mounted Amplifier (TMA) can be used to amplify the received signal. There are different types of TMA depending on the system requirements. Three commonly used types are: • TMA-D - A duplex tower mounted amplifier that combines transmit and receive ports from the radio system and connects to a single antenna.
  • Page 294 D-1 Introduction Appendix D — Tower Mounted Amplifiers MS20xxA VNA Master UG 10580-00166 Rev. C...

  • Page 295: E-1 Coaxial Cable Technical Data

    Appendix E — Coaxial Cable Technical Data E-1 Coaxial Cable Technical Data The table below provides a list of common coaxial cables. Prop. Loss Loss Loss Mfgr. Cable Freq 1 Freq 2 Freq 3 Andrew FSJ1-50A (6 GHz) 0.84 1000 0.196 2500 0.313...
  • Page 296 E-1 Coaxial Cable Technical Data Appendix E — Coaxial Cable Technical Data Prop. Loss Loss Loss Mfgr. Cable Freq 1 Freq 2 Freq 3 Andrew LDF5-50B 0.91 1000 0.041 2000 0.061 2500 0.07 Andrew LDF6-50 0.89 1000 0.028 2000 0.042 2500 0.048 Andrew...
  • Page 297 Appendix E — Coaxial Cable Technical Data E-1 Coaxial Cable Technical Data Prop. Loss Loss Loss Mfgr. Cable Freq 1 Freq 2 Freq 3 Eupen EC4.5-50 5/8 0.88 1000 0.056 2000 0.083 2500 0.094 Eupen EC5-50 7/8 0.88 1000 0.04 2000 0.058 2500...
  • Page 298 E-1 Coaxial Cable Technical Data Appendix E — Coaxial Cable Technical Data Prop. Loss Loss Loss Mfgr. Cable Freq 1 Freq 2 Freq 3 Times LMR1700 0.89 1000 0.033 2000 0.049 2500 0.057 310801 0.821 1000 0.115 1000 0.115 1000 0.115 311201 0.82...

  • Page 299: F-1 Vna Master Formulas

    Appendix F — Formulas F-1 VNA Master Formulas The following formulas can be used with the VNA Master. Reflection Coefficient Reflection coefficient is the ratio of the amplitude of the reflected wave to the incident wave. Reflection Coefficient ρ where: 0 ≤...

  • Page 300: Propagation

    F-1 VNA Master Formulas Appendix F — Formulas Propagation Propagation is the propagation velocity expressed as a ratio to the speed of light. Propagation Constant ------ ε ≤ < where: Cable Loss Return Loss (dB) Cable Loss ---------------------------------------------- - Peak Valley Cable Loss Average ---------------------------------------------...

  • Page 301: G-1 Introduction

    Appendix G — More About DHCP G-1 Introduction DHCP stands for Dynamic Host Configuration Protocol. This protocol allows a server to dynamically assign IP addresses to devices that are connected to the network. Most networks include a DHCP server to manage IP addresses. When a DHCP server is available on the network, DHCP is the preferred IP address mode.

  • Page 302: Subnet Mask

    Windows 2000 IP Configuration Ethernet adapter Local Area Connection: Connection-specific DNS Suffix. : us.anritsu.com IP Address ... . : 172.26.202.172 Subnet Mask ... : 255.255.252.0 Default Gateway .

  • Page 303: Ping Tool

    Appendix G — More About DHCP G-4 Operating System Tools Ping Tool Another tool that can find out if a selected IP address is already on the network is . Ping is ping a harmless way to determine if an address is found on the network and, if it is found, for it to reply.
  • Page 304 G-4 Operating System Tools Appendix G — More About DHCP MS20xxA VNA Master UG 10580-00166 Rev. C...
  • Page 305 Index attenuation S21 measurement Bias Tee ......7-2 ACPR ......9-18 attenuation VNA ACPR measurement cable loss, field meas .
  • Page 306 D to F field measurement ....4-8 VNA stop, DTF measurement ..3-17 measurement description ..4-19 distance VNA spectrum analyzer .
  • Page 307 G to M function overview ....2-11 IP address ....2-12 4-59 functions overview VNA configuration .
  • Page 308 O to R SPA introduction ....4-2 relative ..... 5-1 SPA set amplitude .
  • Page 309 S to V VNA field measurement ...3-40 sweep menu ..... . 4-54 RSSI .
  • Page 310 Z to Z selection (Field versus VNA) ..3-1 volume screen display, spectrum menu ..9-19 setting, interference analyzer ..9-5 setting, VNA ....3-56 volume, measure menu .

This manual is also suitable for:

Ms2034a/ms2036a

Table of Contents
