Chapter 7 — Built-In Bias Tee, Option 10

Bias Tee Menu Soft Keys

Bias Tee On/Off
This soft key toggles the bias tee function On and Off.
Bias Tee Voltage ##.# V
Allows entry of the Bias Tee voltage to be placed on the center conductor of the RF In
port. Values can be between 12.0 and 24.0 V in increments of 0.1 V.
Current Low/High
This soft key toggles the bias tee current between Low and High.
Back
Use this soft key to return to the Sweep menu.
