Chapter 1 — General Information
Table 1-5. Coaxial Calibration Components (Continued)
Part Number
1015-55
1091-55
1091-56
1015-54
23L50
23LF50
24L50
24LF50
28L50R
28LF50R
2000-767
2000-768
Table 1-6. Precision Adapters
Part Number
34NN50A
34NFNF50
Table 1-7. Adapters
Part Number
1091-26
1091-27
1091-80
1091-81
510-102
510-90
510-91
MS20xxA VNA Master UG 10580-00166 Rev. C
Precision TNC(m) Load, 18 GHz, 50 Ω
Precision TNC(f) Open, 18 GHz, 50 Ω
Precision TNC(f) Short, 18 GHz, 50 Ω
Precision TNC(f) Load, 18 GHz, 50 Ω
Precision 3.5 mm Components
Precision 3.5 mm(m) Short, 9 GHz
Precision 3.5 mm(f) Short, 9 GHz
Precision 3.5 mm(m) Open, 9 GHz
Precision 3.5 mm(f) Open, 9 GHz
Precision 3.5 mm(m) Load, 9 GHz
Precision 3.5 mm(f) Load, 9 GHz
Precision Open/Short/Load Components
Precision Open/Short/Load, 7/16(m), 4.0 GHz
Precision Open/Short/Load, 7/16(f), 4.0 GHz
N(m)-N(m), DC to 18 GHz, 50 Ω
N(f)-N(f), DC to 18 GHz, 50 Ω
N to SMA Adapters
N(m)-SMA(m), DC to 18 GHz, 50 Ω
N(m)-SMA(f), DC to 18 GHz, 50 Ω
N(f)-SMA(m), DC to 18 GHz, 50 Ω
N(f)-SMA(f), DC to 18 GHz, 50 Ω
N(m)-N(m), 90º right angle, DC to 11 GHz, 50 Ω
7/16 DIN(f)-N(m), DC to 7.5 GHz, 50 Ω
7/16 DIN(f)-N(f), DC to 7.5 GHz, 50 Ω
1-8 Standard and Optional Accessories
Description
Description
Description
N Adapters
DIN Adapters
