1-2 Identifying the Models

1-2 Identifying the Models
The MS202xA is differentiated from the MS203xA by the front panel model number label. In
addition, the MS203xA is larger and contains additional connections for spectrum analysis as
summarized in the following pictures and table.
RF In 50 Ohm
Vector Network
Analyzer Connectors
Figure 1-1. MS2024A and MS2026A Connectors
1-2
MS2024A and MS2026A
RF Out/Reflection
50 Ohm
MS20xxA VNA Master UG 10580-00166 Rev. C
Chapter 1 — General Information
GPS
Antenna
RF
Detector
