4. Diagnostic tests are run on several functions, including circuitry, port

Boot

In addition to POST, boot includes the steps after POST is complete:
1. Universal port configuration is performed.
2. Links are initialized.
3. Fabric is analyzed. If any ports are connected to other switches, the SAN384B-2
4. The SAN384B-2 obtains a domain ID and assigns port addresses.
5. Unicast routing tables are constructed.
6. Normal port operation is enabled.

Diagnostics

Diagnostic tests are automatically run during POST to check the status of the
SAN384B-2. Any error messages generated during POST are sent to the error logs
and to the serial console, if connected.
Diagnostic tests can also be run manually to test and troubleshoot the hardware
and the firmware, including internal connections and circuitry, transceivers, and
port cables. However, diagnostic tests are generally intended for use by support
personnel.
Note: Error messages do not necessarily indicate that the SAN384B-2 requires
Each diagnostic test can be implemented by entering the related command through
a Telnet or serial session. For a list of diagnostic tests and commands, refer to the
Fabric OS Command Reference and the Fabric OS Administrator's Guide.
All diagnostic tests are run at all supported link speeds. They might temporarily
lock the transmit and receive speeds to a specific speed. Some diagnostic tests
require interconnecting the ports to each other or using loopback plugs. If ports are
interconnected, the media (cables and transceivers) at each end of the connection
must be of the same type. For example, short wavelength media must be
connected to short wavelength media, and likewise with long wavelength media
and copper media.
For more information about diagnostic tests and how to run them, refer to the
Fabric OS Administrator's Guide and the Fabric OS Command Reference. For
information about diagnostic error messages (errShow or errDump), refer to the
Fabric OS Message Reference.

General troubleshooting

Table 27 provides a list of issues, possible causes, and recommended actions.
Table 27. Troubleshooting
Issue
Entire chassis powers off
automatically.
functionality, ability to send and receive frames, all aspects of memory, parity,
statistics counters, and serialization.
participates in a fabric configuration.
maintenance.
Possible Cause
Power supplies are inadequate to
support the installed components.
Recommended Action
Add an additional power supply.
Appendix C. Diagnostics and troubleshooting
