Instruction Manual
The new
high-performance inverter
TOSVERT
500V class
600V class
690V class
1.Make sure that this instruction manual is delivered to the end user of
the inverter unit.
2.Read this manual before installing or operating the inverter unit, and
store it in a safe place for reference.
AS1
VF-
TM
1.5~500kW
2 ~700HP
2.2~630kW
NOTICE
E6581528
I I
Safety
precautions
II II
Introduction
Contents
1 1
2 2
Connection
equipment
3 3
Operations
4 4
Searching and
setting parameters
5 5
Basic
parameters
6 6
Extended
parameters
7 7
Operation with
external signal
8 8
Monitoring the
operation status
9 9
Taking measures
to satisfy the
CE/UL/CSA standards
10 10
Selection of
peripheral
devices
1 1 1 1
Table of
parameters
12 12
13 13
Before making a
service call
14 14
Inspection and
maintenance
15 15
Warranty
16 16
Disposal of
the inverter

Advertisement

   Related Manuals for Toshiba TOSVERT VF-AS1

   Summary of Contents for Toshiba TOSVERT VF-AS1

  • Page 1

    E6581528 Safety precautions II II Introduction Contents Read first Instruction Manual Connection equipment Operations The new Searching and setting parameters high-performance inverter Basic parameters TOSVERT Extended parameters Operation with external signal Monitoring the operation status Taking measures to satisfy the CE/UL/CSA standards 10 10 Selection of...

  • Page 2: I. Safety Precautions

    E6581528 I. Safety precautions The items described in these instructions and on the inverter itself are very important so that you can use the inverter safely prevent injury to yourself and other people around you as well as prevent damage to property in the area. Thoroughly familiarize yourself with the symbols and indications shown below and then continue to read the manual.

  • Page 3: General Operation

    E6581528 General Operation Warning Reference • Never disassemble, modify or repair. This can result in electric shock, fire and injury. For repairs, call your sales agency. Disassembly prohibited • Never remove the front cover when power is on or open door if enclosed in a cabinet. The unit contains many high voltage parts and contact with them will result in electric shock.

  • Page 4

    1.4.4 Operation cannot be stopped immediately by the inverter alone, thus risking an accident or injury. • All options used must be those specified by Toshiba. The use of any other option may result in an accident. 1.4.4 Caution Reference •...

  • Page 5

    E6581528 Wiring Warning Reference • Do not connect input power to the output (motor side) terminals (U/T1,V/T2,W/T3). That will destroy the inverter and may result in fire. • Do not connect resistors to the DC terminals (between PA/+ and PC/-, or between PO and PC/-).

  • Page 6

    E6581528 Operations Warning Reference • Do not touch inverter terminals when electrical power is applied to the inverter even if the motor is stopped. Touching the inverter terminals while power is connected to it may result in electric shock. • Do not touch switches when thands are wet and do not try to clean the inverter with a damp cloth.

  • Page 7: Maintenance And Inspection

    E6581528 Maintenance and inspection Warning Reference • Never replace any part by yourself. 14.2 This could be a cause of electric shock, fire and bodily injury. To replace parts, call the local sales agency. Prohibited • The equipment must be inspected frequently. If the equipment is not inspected and maintained, errors and malfunctions may not be discovered which could lead to accidents.

  • Page 8: I I. Introduction

    E6581528 II. Introduction Thank you for your purchase of the Toshiba “TOSVERT VF-AS1” industrial inverter. This instruction manual is intended for inverters with CPU version 144 or later for VFAS1-5 *** and CPU version 144 or later for VFAS1-6 *** . The CPU version will be frequently upgraded.

  • Page 10

    E6581528 - Contents - I. Safety precautions ······················································································································································ I I. Introduction ······························································································································································· Read first····························································································································································· Check the product········································································································································ Contents of the product code ······················································································································· The product classes for input voltage··········································································································· Structure of the main body ··························································································································· 1.4.1 Names and functions ···························································································································· 1.4.2 Detaching the cover ······························································································································...

  • Page 11

    E6581528 5.16 Meter setting and adjustment························································································································ E-27 5.17 PWM carrier frequency ································································································································· E-31 5.18 Trip-less intensification ································································································································· E-32 5.18.1 Auto-restart (Restart during coasting)···································································································· E-32 5.18.2 Regenerative power ride-through control/Deceleration stop during power failure/ Synchronized acceleration/deceleration······································································································· E-34 5.19 Dynamic (regenerative) braking - For abrupt motor stop ·············································································· E-37 5.20 Standard default setting ································································································································...

  • Page 12

    E6581528 6.23 Increasing the motor output torque further in low speed range ···································································· F-38 6.24 Torque control ·············································································································································· F-39 6.24.1 Torque command ·································································································································· F-39 6.24.2 Speed limits in torque control mode ······································································································ F-39 6.24.3 Torque bias and load sharing gain ········································································································ F-39 6.25 Torque limit···················································································································································...

  • Page 13

    E6581528 6.36.7 Setting of a torque command in panel operation mode ········································································· F-72 6.36.8 Torque-related parameters for panel operation······················································································ F-73 6.37 Tracing functions··········································································································································· F-73 6.38 Integral output power ···································································································································· F-76 6.39 Communication function ······························································································································· F-77 6.39.1 2-wire RS485/4-wire RS485 ·················································································································· F-77 6.39.2 Open network option······························································································································...

  • Page 14

    E6581528 Specifications ······················································································································································ 12.1 Models and their standard specifications ····································································································· 12.2 Outside dimensions and mass ····················································································································· Before making a service call- Trip information and remedies ·············································································· 13.1 Trip causes/warnings and remedies············································································································· 13.2 Method of resetting causes of trip ················································································································ 13.3 If the motor does not run while no trip message is displayed…...

  • Page 16: Read First, Name Plate, Warning Label

    E6581528 1. Read first Check the product Before using the product you have purchased, check to make sure that it is exactly what you ordered. Caution Use an inverter that conforms to the specifications of the power supply and three-phase induction motor being used.

  • Page 17

    E6581528 The product classes for input voltage The 600V series of VFAS1 has the following three kinds of voltage classes. There are 500V, 575V and 690V class. Power supply 500V 500V class) and 690V 690V class) Power supply Power supply 600V 575V class) Applicable Motor...

  • Page 18

    E6581528 The default setting of all products is 575V-60Hz. You can change it to other voltage class Inverter(500V-50Hz or 690V-50Hz) by changing the "" parameter. Title Function Adjustment range Default setting :   Factory default setting : 500V-50Hz default setting : 575V-60Hz default setting : 690V-50Hz default setting Please refer to Chapter 11 Table of parameters for the changed parameters by the ...

  • Page 19: Structure Of The Main Body

    E6581528 1. 4 Structure of the main body 1.4.1 Names and functions 1) Outside view Control circuit Operation panel terminal cover Be sure to close the cover before starting the operation to prevent persons from touching the terminal in error. Main circuit terminal cover Inverter type and...

  • Page 20

    E6581528 Operation panel Up key RUN lamp EASY key [Note 1] EASY key lamp % lamp Lights when an ON Lights when the unit Lights when the EASY Press this key to control command is issued but no is %. the function assigned key is enabled.

  • Page 21

    E6581528 2) Main circuit terminal VFAS1-5015PM-5075PM Shorting-bar M5 screw Grounding terminal (M5 screw) Screw hole for EMC plate VFAS1-6022PL-6300PL Shorting-bar Hexagon socket M10 screw Grounding capacitor switching switch R/L1 S/L2 T/L3 U/T1 V/T2 W/T3 PA/+ PC/- Grounding terminal Hexagon socket (M10 screw) Screw hole for EMC plate Grounding terminal...

  • Page 22

    E6581528 VFAS1-6370PL-6900PL Hexagon socket M6 screw M16 screw Grounding terminal (M6 screw) R/T1 S/T2 T/L3 U/T1 V/T2 W/T3 PA/+ PC/- Hexagon socket Shorting-bar M16 screw Screw hole for EMC plate Grounding terminal (M8 screw) VFAS1-6110KPC-6160KPC PA/+ PC/- Grounding M12 screw capacitor switching screw Connecting to the...

  • Page 23

    E6581528 VFAS1-6200KPC~6315KPC Connecting to the Transformer box Upper side PA/+ PC/- M12 screw Grounding capacitor switching screw M12 screw Grounding terminal M4 screw (M12 screw) Bottom side VFAS1-6400KPC-6630KPC Connecting to the Transformer box Upper side PA/+ PC/- M12 screw Grounding capacitor switching screw M4 screw...

  • Page 24: Detaching The Cover

    E6581528 3) Control circuit terminal block The control circuit terminal block is common to all equipment. (VFAS1- ***** -WN,HN) Serial 4-wire RS485 PWR-P24/PLC Shorting bar connector Control circuit terminal block screw size: M3 ⇒ For details on all terminal functions, refer to Section 2.3.2. 1.4.2 Detaching the cover Main circuit terminal cover To wire the main circuit terminal for models VFAS1-5015PM to 5075PM, remove the main circuit terminal cover in...

  • Page 25

    E6581528 Front cover To wire the main circuit terminal for models VFAS1-6022PL or more, remove the front cover. Remove the screw Main circuit terminal Control circuit terminal cover To wire the control circuit terminal, open the control circuit terminal cover in line with the steps given below. (A)...

  • Page 26

    E6581528 Charge lamp This lamp is lit when a high voltage remains in the inverter. When removing the main circuit terminal cover or opening the front cover, be sure to check that this lamp is off and follow the instructions about wiring on page 4. The mounting position of the charge lamp varies from model to model.

  • Page 27

    E6581528 1.4.3 Grounding capacitor switching method The inverter is grounded through a capacitor. The leakage current from the inverter can be reduced using the selector switch, switching bar or switching screw (depending on the model) on the main circuit terminal board. This switching device is used to detach the capacitor from the grounding circuit or to reduce its capacitance.

  • Page 28

    E6581528 VFAS1-6110KPC models and larger: Grounding capacitor switching screw «VFAS1-6110KPC~6160KPC, VFAS1-6400KPC~6630KPC» Large To change the capacitance from Small to Large, fix to part A shown in the figure on the left with the grounding capacitor switching Small screw. (Factory default position) Large To change the capacitance from Large to Small, fix to part B shown...

  • Page 29

    E6581528 1.4.4 Installing the transformers on VFAS1 As for VFAS1-6110KPC and above, the transformer unit(TRS) and Inverter are put in one packing box. The procedure that takes out TRS from a packing box and installation procedure to a panel are described by the additional manual.

  • Page 30

    E6581528 How to install (Example:VFAS1-6200KPC) Transformer case Transformer Front cover Remove the front cover. Mount the transformer case on an inner wall of the cabinet and secure the transformer to the case with screws. Top panel Cover Front panel Connect the transformer connector Secure the cover, front panel and top panel on the drive.

  • Page 31

    E6581528 Example of wiring of each model «VFAS1-6110KPC to 6160KPC» «VFAS1-6200KPC to 6315KPC» Unused X0 connectors set to"parke"positon Grounding strips Transformer connectors «VFAS1-6400KPC to 6630KPC» Unused X0 connectors set to “parked” position Location of transformers: VFAS1-6110KPC to 6160KPC VFAS1-6200KPC to 6315KPC VFAS1-6400KPC to 6630KPC Transformer connetors Grounding strips...

  • Page 32

    E6581528 Power consumed by the fans VFAS1 Power consumed by the fans 6110KPC, 6132KPC, 6160KPC 550 VA 6200KPC, 6250KPC, 6315KPC 1,110 VA 6400KPC, 6500KPC, 6630KPC 2,200 VA Connecting fans for a separate power supply In order to remove the link between the fans and the transformer power supply and relocate it at terminals RO, SO, TO, connectors X1 and X4 must be crossed as indicated on the diagrams below.

  • Page 33

    E6581528 VFAS1-6200KPC, 6250KPC, 6315KPC Factory wiring: Fans powered internally by R/L1, S/L2, T/L3 Terminals R0, S0, T0 Terminals R0, S0, T0 Modification for fans powered externally by R0, S0, T0 VFAS1-6400KPC, 6500KPC, 6630KPC Terminals Terminals R0, S0, T0 R0, S0, T0 Factory wiring: Modification for fans Fans powered internally by...

  • Page 34

    E6581528 Notes on the application 1.5.1 Motors Keep the following in mind when using the VF-AS1 to drive a motor. Caution Use an inverter that conforms to the specifications of power supply and three-phase induction motor being used. If the inverter being used does not conform to those specifications, not only will the three-phase induction motor not rotate correctly, but it may cause serious accidents through Mandatory overheating and fire.

  • Page 35

    E6581528 Loads that generate negative torque When combined with loads that generate negative torque the protection for overvoltage and overcurrent on the inverter will go into operation and may cause a trip. For this kind of situation, you must install a dynamic braking resistor, etc.

  • Page 36

    E6581528 1.5.2 Inverters Power supply voltage VFAS1-5015PM to 5075PM cannot be applied to input voltage 690V. It is necessary to change the parameter setting according to the power supply voltage ( 500/600/690V ). In case of VFAS1-5015PM to 5075PM Power supply Three-phase-500V:  =  Power supply Three-phase-600V: ...

  • Page 37: What To Do About The Leak Current

    E6581528 If power supply distortion is not negligible If the power supply distortion is not negligible because the inverter shares a power distribution line with other systems causing distorted waveforms, such as systems with thyristers or large-capacity inverters, install an input reactor to improve the input power factor, to reduce higher harmonics, or to suppress external surges.

  • Page 38

    E6581528 (2) Affects of leakage current across supply lines Thermal relay inverter Power supply Leakage current path across wires ○ Thermal relays The high frequency component of current leaking into electrostatic capacity between inverter output wires will increase the effective current values and make externally connected thermal relays operate improperly. If the motor cables are more than 50m long, external thermal relay may operate improperly with models having motors of low rated current because the leakage current will be high in proportion to the motor rating.

  • Page 39: Installation Environment

    E6581528 1.5.4 Installation Installation environment The VF-AS1 Inverter is an electronic control instrument. Take full consideration to installing it in the proper operating environment. Warning • Do not place any inflammable substances near the VF-AS1 Inverter. If an accident occurs in which flames are emitted, this could lead to fire. Prohibited •...

  • Page 40

    Operation cannot be stopped immediately by the inverter alone, thus risking an accident or injury. • All options used must be those specified by Toshiba. The use of any other option may result in an accident.

  • Page 41

    E6581528 Install the inverter in a well-ventilated indoor place and mount it on a flat metal plate in portrait orientation. If you are installing more than one inverter, the separation between inverters should be at least 5cm, and they should be arranged in horizontal rows.

  • Page 42

    E6581528 VFAS1-6022PL~6220PL( VFAS1-6300PL ・ Standard installation without top cover or ・ Standard installation with top cover side-by-side installation without top cover. 40°C(104°F) 100% 100% 50°C(122°F) (Factory default setting) 50°C(122°F) 60°C(140°F) 60°C(140°F) 4kHz 2.5kHz 6.0kHz 2.5kHz 4kHz 6.0kHz Carrier frequency () Carrier frequency () VFAS1-6370PL~6750PL( VFAS1-6900PL...

  • Page 43

    E6581528 Calorific values of the inverter and the required ventilation The energy loss when the inverter converts power from AC to DC and then back to AC is typically about 2.5% to 5%. In order to suppress the rise in temperature inside the cabinet when this loss becomes heat loss, the interior of the cabinet must be ventilated and cooled.

  • Page 44

    E6581528 Panel designing taking into consideration the effects of noise The inverter generates high frequency noise. When designing the control panel setup, consideration must be given to that noise. Examples of measures are given below. • Wire so that the main circuit wires and the control circuit wires are separated. Do not place them in the same conduit, do not run them parallel, and do not bundle them.

  • Page 46: Cautions On Wiring

    E6581528 2. Connection equipment Warning • Never disassemble, modify or repair. This can result in electric shock, fire and injury. For repairs, call your sales agency. Disassembly prohibited • Don't stick your fingers into openings such as cable wiring hole and cooling fan covers. This can result in electric shock or other injury.

  • Page 47

    E6581528 Caution • Do not attach devices with built-in capacitors (such as noise filters or surge absorber) to the output (motor side) terminal. This could cause a fire. Prohibited Preventing radio noise To prevent electrical interference such as radio noise, separately bundle wires to the main circuit's power terminals (R/L1, S/L2, T/L3) and wires to the motor terminals (U/T1, V/T2, W/T3).

  • Page 48: Standard Connections

    E6581528 • Refer to the table in Section 10.1 for wire sizes. • The length of the main circuit wire in Section 10.1 should be no longer than 30m. If the wire is longer than 30m, the wire size (diameter) must be increased. •...

  • Page 49

    E6581528 [Standard connection diagram – sink logic] The figure below shows an example of typical wiring in the main circuit VFAS1-5015PM to 5075PM and VFAS1-6022PL to 6900PL inverter. Main circuit power source 500/575V class :1.5(2HP)~75kW(100HP) Three-phase 500~600V-50/60Hz 690V class : 2.2~90kW Three-phase 500~690V-50/60Hz Motor...

  • Page 50

    E6581528 [Standard connection diagram - sink logic] The figure below shows an example of typical wiring in the main circuit VFAS1-6110KPC to 6315KPC inverter. Main circuit power source 500/575V class : 90(125HP)~250kW(350HP) 690V class : 110~315kW Three-phase 500~690V-50/60Hz Transformer for Fan power Supply Motor Main...

  • Page 51

    E6581528 [Standard connection diagram - sink logic] The figure below shows an example of typical wiring in the main circuit VFAS1-6400KPC to 6630KPC inverter. Main circuit power source 500/575V class : 315(500HP)~500kW(700HP) 690V class : 400~630kW Three-phase 500~690V-50/60Hz Transformer for Fan power Supply Motor NOISE...

  • Page 52

    E6581528 [Standard connection diagram - source logic] The figure below shows an example of typical wiring in the main circuit VFAS1-5015PM to 5075PM and VFAS1-6022PL to 6900PL inverter. Main circuit power source 500/575V class : 1.5(2HP)~75kW(100HP) Three-phase 500~600V-50/60Hz 2.2~90kW 690V class : Three-phase 500~690V-50/60Hz Motor Main...

  • Page 53

    E6581528 [Standard connection diagram - source logic] The figure below shows an example of typical wiring in the main circuit VFAS1-6110KPC to 6315KPC inverter. Main circuit power source 690V class : 110~315kW Three-phase 500~690V-50/60Hz Transformer for Fan power Supply Motor Main Noise circuit...

  • Page 54

    E6581528 [Standard connection diagram - source logic] The figure below shows an example of typical wiring in the main circuit VFAS1-6400KPC to 6630KPC inverter. Main circuit power source 400~630kW 690V class : Three-phase 500~690V-50/60Hz Transformer for Fan power Supply Motor NOISE Rectifi Filter...

  • Page 55: Description Of Terminals, Main Circuit Terminals, Main Circuit

    E6581528 Description of terminals 2.3.1 Main circuit terminals This diagram shows an example of wiring of the main circuit. Use options if necessary. Power supply and motor connections  VF-AS1  Connect the power Connect the motor Power supply cables to RL1, S/L2, cables to U/T1, V/T2 and T/L3.

  • Page 56: Control Circuit Terminal Block

    E6581528 2.3.2 Control circuit terminal block The control circuit terminal block is common to all equipment. (VFAS1-*****-WN,HN) Color of a label is yellow. PWR-P24/PLC Shorting bar ⇒ How to set input terminal function, refer to section 7. Terminal Input/ Function (Sink logic) Function (Source logic) Electrical specifications symbol...

  • Page 57

    E6581528 Terminal Input/ Electrical Function (Sink Source logic) Inverter internal circuits symbol output specifications PWR is the Power Removal safety function. When PWR is not connected to the 24V/PLC, P24/PLC the motor cannot be started. And if it is opened Regardless of the between the 24V/PLC and PWR during driving setting of SW1...

  • Page 58

    E6581528 Terminal Input/ Electrical Function (Sink Source logic) Inverter internal circuits symbol output specifications Common Analog input/output signal equipotential (0V) to input/ terminal for the control circuit. output Voltage:24Vdc±10% DC power input terminal for operating the Use a power supply Input control circuit.

  • Page 59

    E6581528 Sink logic/source logic (When inverter's internal power supply is used) Current flowing out turns control input terminals on. These are called sink logic terminals. The method generally used in Europe is source logic in which current flowing into the input terminal turns it on. Sink logic terminals and source logic terminals are sometimes referred to as negative logic terminals and positive logic terminals, respectively.

  • Page 60

    E6581528 Sink logic/source logic (When an external power supply is used) The P24/PLC terminal is used to connect to an external power supply or to insulate a terminal from other input or output terminals. Use the slide switch SW1 to switch between sink logic and source logic configurations. Note that the PWR terminal is designed for safety purposes to work always in source logic mode, regardless of the setting of SW1.

  • Page 61: Serial Rs485 Communication Connector

    E6581528 2.3.3 Serial RS485 communication connector The VF-AS1 is equipped with two connectors: a two-wire RS485 connector (on the operation panel) and a four-wire RS485 connector. The two wire RS485 connector is used to connect an external option (such as remote keypad or computer) to the inverter.

  • Page 62

    E6581528 3. Operations This section explains the basics of operation of the inverter. Check the following again before starting operation. 1) Are all wires and cables connected correctly? 2) Does the supply voltage agree with the rated input voltage? Danger •...

  • Page 63: Status Monitor Mode

    E6581528 Setting/monitor modes The VF-AS1 has the following three setting/monitor modes. Standard monitor mode The standard inverter mode. This mode is enabled when inverter power goes on. This mode is for monitoring the output frequency and setting the frequency reference value. If also displays information about status alarms during running and trips.

  • Page 64

    E6581528 Simplified operation of the VF-AS1 On of three operation modes can be selected: terminal board operation, operation panel and combination of both. ⇒ For other operation modes, refer to Section 5.5. Terminal board mode :Operation by means of external signals Operation panel mode :Operation by pressing keys on the operation panel Operation panel + terminal board mode...

  • Page 65

    E6581528 Frequency setting 1) Setting the frequency using potentiometer Potentiometer The operation frequency by potentiometer (1~10kΩ- 1/4W ) for setting ⇒ Refer to Section 7.3 for details of adjustment. :Frequency settings 60Hz RR/S4 With potentiometer Frequency [Parameter setting] Set the “basic parameter frequency setting mode selection 1” parameter  to . (There is no need to set this parameter before the first use after purchase.) 2) Setting the frequency using input voltage (0~10V) Voltage signal...

  • Page 66

    E6581528 4) Setting the frequency using input voltage (0~10Vdc) Voltage signal Voltage signal (0~10V) for setting the operation frequency ⇒ Refer to Section 7.3 for details of adjustment. VI/II :Voltage signal 0-10Vdc 60Hz Frequency 10Vdc 0Vdc [Parameter setting] Set the “extended parameter analog input VI/II voltage/current switching” parameter ...

  • Page 67

    E6581528 [Example of setting: To set the frequency by applying a current of 4(0)-20mAdc via the VI/II terminal.] Key operated LED display Operation Displays the operation frequency. (Perform during operation stopped.)  (When standard monitor display selection =[Output frequency])  Displays the first basic parameter “History function ().”...

  • Page 68

    E6581528 3.2.2 Panel operation This section describes how to start/stop the motor, and set the operation frequency with the operating panel. :Set frequency Example of basic connection MCCB Motor :Motor starts R/L1 U/T1 Power S/L2 V/T2 :Stop the motor supply STOP T/L3 W/T3...

  • Page 69

    E6581528 Example of operation panel control Key operated LED display Operation The running frequency is displayed. (When standard monitor display  selection = [Output frequency]) Set the operation frequency.  Press the ENTER key to save the operation frequency. and the ⇔...

  • Page 70: Searching And Setting Parameters

    E6581528 4. Searching and setting parameters There are two types of setting mode quick mode and standard setting mode. Quick mode : EASY key: ON Eight frequently used basic parameters are just displayed (Factory default position). Quick mode (EASY) Title Function ...

  • Page 71: How To Set Parameters

    E6581528 How to set parameters This section explains how to set parameters, while showing how parameters are organized in each setting monitor mode. 4.1.1 Setting parameters in the selected quick mode To place the inverter in this mode, press the key (the LED lights up), and then press the key.

  • Page 72: Setting Parameters In The Standard Setting Mode

    E6581528 4.1.2 Setting parameters in the standard setting mode Press the key to place the inverter in this mode. MODE How to set basic parameters Selects parameter to be changed. (Press the key.) Reads the programmed parameter setting. (Press the key.) Change the parameter value.

  • Page 73: Functions Useful In Searching For A Parameter Or Changing A Parameter Setting

    E6581528 Adjustment range and display of parameters : An attempt has been made to assign a value that is higher than the programmable range. Or, as a result of changing other parameters, the programmed value of the parameter that is now selected exceeds the upper limit....

  • Page 74: Basic Parameters

    E6581528 5. Basic parameters This parameter is a basic parameter for the operation of the inverter. ⇒ Refer to Section 11, Table of parameters. History function  : History function • Function Automatically searches for 5 latest parameters that are programmed with values different from the standard default setting and displays them in the .

  • Page 75

    E6581528 Setting acceleration/deceleration time  : Automatic acceleration/deceleration  : Acceleration time 1  : Deceleration time 1 • Function 1) For acceleration time 1  programs the time that it takes for the inverter output frequency to go from 0Hz to maximum frequency .

  • Page 76: Increasing Starting Torque, Automatic Torque Boost

    E6581528 5.2.2 Manually setting acceleration/deceleration time Set acceleration time from 0 (Hz) operation frequency to maximum frequency  and deceleration time as the time when operation frequency goes from maximum frequency  to 0 (Hz). Output frequency [Hz]  = (Manual setting) Time [s] ...

  • Page 77

    E6581528 1) Increasing torque automatically according to the load Set the automatic torque boost = (automatic torque boost+auto-tuning 1) Automatic torque boost = detects load current in all speed ranges and automatically adjusts voltage output from inverter. This gives steady torque for stable runs. Note 1: The same characteristic can be obtained by setting the V/f control mode selection parameter ...

  • Page 78: Setting Parameters By Operating Method

    E6581528 Setting parameters by operating method  : Automatic function setting • Function Automatically programs all parameters (parameters described below) related to the functions by selecting the inverter's operating method. The major functions can be programmed simply. [Parameter setting] Title Function Adjustment range Default setting...

  • Page 79: Selection Of Operation Mode

    E6581528 Frequency setting with operation panel and operation with terminal board This setting is used to set the frequency using the operation panel and to perform operation control using the terminal board. Use the keys to set the frequency. In sink logic mode: PWR-P24/PLC ON: Standby (ON (short-circuited) by default), F-CC ON: Forward run, R-CC ON: Reverse run.

  • Page 80

    E6581528 <Frequency setting mode selection> [Parameter setting] Title Function Adjustment range Default setting :VI/II (voltage/current input) :RR/S4 (potentiometer/voltage input) :RX (voltage input) :Operation panel input enabled (including LED/LCD option input) :2-wire RS485 communication input :4-wire RS485 communication input Frequency setting mode ...

  • Page 81

    E6581528 The functions assigned to the following control input terminals (contact input: ⇒ Refer to Section 7.2) are always activated regardless of the settings of the command mode selection  and frequency setting mode selection 1 . • Reset terminal (default setting: RES, valid only for tripping) •...

  • Page 82

    E6581528 2) Setting the run and stop frequencies (forward run, reverse run and coast stop) by means of external signals and setting the operation frequency with the operation panel Title Function Example of setting Run/stop : ON/OFF of terminals F-CC/R-CC (Standby: connection of terminals ...

  • Page 83

    E6581528 4) Setting the run, stop and operation frequencies (forward run, reverse run and coast stop) by means of external signals (default setting) Title Function Example of setting Run/stop :ON/OFF of terminals F-CC/R-CC Command mode Speed command :External signal input ...

  • Page 84: Selecting Control Mode

    E6581528 Selecting control mode  : V/f control mode selection • Function With “VF-AS1,” the V/f controls shown below can be selected. 0: Constant torque characteristics 1: Voltage decrease curve 2: Automatic torque boost (*1) 3: Sensorless vector control 1 (*1) 4: Sensorless vector control 2 5: V/f 5-point setting PM control...

  • Page 85

    E6581528 2) Decreasing output voltage Setting of V/f control mode selection = (Voltage decrease curve This is appropriate for load characteristics of such things as fans, pumps and blowers in which the torque in relation to load rotation speed is proportional to its square. Base frequency voltage 1 ...

  • Page 86

    Setting of V/f control mode selection =,  (Sensorless vector control 1, 2) Using sensorless vector control with a Toshiba standard motor will provide the highest torque at the lowest speed ranges. The effects obtained through the use of sensorless vector control are described below.

  • Page 87

    E6581528 Base frequency V/f 5-point setting  voltage 1      [V]/[%]  Output frequency [Hz]       Base frequency 1 Note 1: Restrict the amount of torque to boost () to 3% or so. Boosting the torque too much may impair the linearity between points.

  • Page 88

    30m, be sure to perform the auto-tuning (=) mentioned above, even when using a standard motor recommended by Toshiba. 2) The sensorless vector control exerts its characteristics effectively in frequency areas below the base frequency ().

  • Page 89: Base Frequency

    E6581528 Manual torque boost–increasing torque boost at low speeds  : Manual torque boost 1 • Function If torque is inadequate at low speeds, increase torque by raising the torque boost rate with this parameter.  Base frequency voltage 1 ...

  • Page 90: Maximum Frequency, Upper Limit And Lower Limit Frequencies

    E6581528 Maximum frequency  : Maximum frequency • Function 1) Programs the range of frequencies output by the inverter (maximum output values). 2) This frequency is used as the reference for acceleration/deceleration time. Output frequency [Hz] In case of  =80Hz •...

  • Page 91: Setting Frequency Command Characteristics

    E6581528 5.11 Setting frequency command characteristics  ~  ,  : VI/II point setting  ~  ,  : RR/S4 point setting  ~  : RX point setting  ~  :  ~  : It sets up, when using the optional circuit board. ...

  • Page 92

    E6581528 Example of preset speed contact input signal : ON –: OFF (Speed commands other than preset speed commands are valid when all are OFF) Preset speed Terminal S1-CC – – – – – – – S2-CC – – – –...

  • Page 93

    E6581528 Below is an example of 7-step speed operation.  Output frequency [Hz]       Time F-CC S1-CC S2-CC S3-CC Example of 7-step speed operation 4) Setting the operation mode An operation mode can be selected for each preset speed. Operation mode setting Title Function...

  • Page 94

    E6581528 5.13 Selecting forward and reverse runs (operation panel only)  : Forward/reverse run selection • Function Program the direction of rotation of the motor when the running and stopping are made using the RUN key and STOP key on the operation panel. Valid when ...

  • Page 95: Setting The Electronic Thermal

    E6581528 5.14 Setting the electronic thermal  : Motor electronic thermal protection level 1  : Electronic thermal protection characteristic selection  : OL reduction starting frequency  : Motor 150%-overload time limit  : Temperature detection • Function This parameter allows selection of the appropriate electronic thermal protection characteristics according to the particular rating and characteristics of the motor.

  • Page 96

    Note: The motor overload starting level is fixed at 30Hz. If necessary, set  to , ,  or . (See the following section.) Even if the inverter is used with a Toshiba standard motor, the load may need to be reduced at frequencies of...

  • Page 97

    E6581528 Setting of motor electronic thermal protection level 1  If the capacity of the motor is smaller than the capacity of the inverter, or the rated current of the motor is smaller than the rated current of the inverter, adjust the electronic thermal protection level 1  so that it fits the motor's rated current.

  • Page 98

    E6581528 3) Inverter overload characteristics Set to protect the inverter unit. Cannot be turned off by parameter setting. The inverter has two overload detecting functions, which can be switched from one to another using parameter  (temperature detection). [Parameter setting] Title Function Adjustment range...

  • Page 99

    E6581528 5.15 Changing the display unit % to A (ampere)/V (volt)   : Current/voltage unit selection • Function These parameters are used to change the unit of monitor display. % ⇔A (ampere)/V (volt) Current 100% = Inverter’s rated current Voltage 100% = 500Vac ( if ...

  • Page 100: Meter Setting And Adjustment

    E6581528  5.16 Meter setting and adjustment   : FM terminal meter selection   : FM output filter   : FM terminal meter adjustment   : AM terminal meter   : Constant at the time of filtering selection...

  • Page 101

    E6581528 [Terminal FM-related parameters] Adjustment Title Function Adjustment range Default setting level  :  Output frequency  :  Frequency command value  :  Output current  :  Input voltage (DC detection)  :  Output voltage ...

  • Page 102

    E6581528 [Terminal AM-related parameters] Title Function Adjustment range Default setting AM terminal meter selection Same as  (  :AM output disabled)   AM terminal meter adjustment –  AM output gradient  :Negative gradient (downward-sloping),   characteristic ...

  • Page 103

    E6581528 Meter adjustment Fixed output 1 Fixed output 2 Fixed output 3 Adjustment level  (  ) =  (  ) =  (  ) =  185% 100% 150% 250% 135% 100% Note: The 100% value of input/output power is the product of 3 ×...

  • Page 104

    E6581528 Gradient bias adjustment of analog monitor output Here is an example of the adjustment of output from 0-20mA → 20-0mA, 4-20mA using the FM terminal.   =  ,  =   =  ,  =  (mA) (mA) 100%...

  • Page 105

    E6581528 Note 3: If you change the carrier frequency, you may need to reduce the inverter’s continuous output current. ⇒ Refer to Section 1.4.4, “Current reduction curve.” Note 4: If the motor becomes overloaded when  is set to  or  (carrier frequency not decreased automatically), an overload trip occurs.

  • Page 106

    E6581528 2) Restarting motor during coasting (Motor speed search function) Motor speed F-CC S3 (ST operation standby signal) -CC =: This function operates after the S3-CC terminal connection has been opened first and then connected again. Title Function Adjustment range Default setting Example of setting :Disabled...

  • Page 107

    E6581528 5.18.2 Regenerative power ride-through control/Deceleration stop during power failure/Synchronized acceleration/deceleration  : Regenerative power ride-through control  : Non-stop control time/Deceleration time during power failure  : Synchronized deceleration time  : Synchronized acceleration time  : Under voltage detection level ...

  • Page 108

    E6581528 [If momentary power failure occurs] Input voltage Motor speed Non-stop control Normal acceleration An example of setting when = Input voltage Motor speed Time Deceleration stop • Even after the recovery from an input power failure, the motor continues slowing down to a stop. If the voltage in the inverter main circuit falls below a certain level, however, control will be stopped and the motor will coast.

  • Page 109

    E6581528 An example of setting when = Synchronized deceleration if a synchronized acceleration/deceleration signal is impressed or if a power failure occurs, or synchronized acceleration if the synchronized acceleration/deceleration signal is canceled. Input voltage Synchronized acceleration/dece leration signal Inverter 1 (S1 terminal) Motor speed ...

  • Page 110

    Note 1: The time set using  is the time for which the resistor sustains an overload. (Enter the time elapsed before the inverter trips if a load 10 times as large as the allowable continuous braking resistance specified using  is applied.) There is no need to change resistance settings recommended by Toshiba (except DGP resistance setting).

  • Page 111

    E6581528 VF-AS1 with ratings of up to 160kW have built-in dynamic braking transistor as standard equipment. If the rating of your inverter falls within this range, connect the resistor, as shown in Figure a) below or Figure b) on the next page. If your inverter has a power rating of 200kW or more, connect a resistor, as shown in Figure c).

  • Page 112

    E6581528 b) When a using braking resistor without thermal fuse An external braking resistor (optional) * If no power supply is provided TH - Ry for the control circuit MCCB PA/+ Motor Three-phase R/L1 U/T1 main circuit V/T2 S/L2 power supply W/T3 T/L3 Depression...

  • Page 113

    E6581528 c) VFAS1-6200KPC or more TH - Ry An external braking resistor (optional) * If no power supply is Dynamic braking unit (optional) provided for the control circuit MCCB PA/+ PC/- Motor R/L1 Three-phase U/T1 main circuit S/L2 V/T2 power supply T/L3 W/T3 Depression...

  • Page 114

    E6581528 Minimum resistance of connectable braking resistors The minimum allowable resistance values of the externally connectable braking resistors are listed in the table below. Do not connect braking resistors with smaller resultant resistance than the listed minimum allowable resistance values. (For 200kW or greater models, a dynamic braking resistor drive unit (optional separate unit) is needed.) Inverter Resistance...

  • Page 115: Standard Default Setting, Factory Default Setting

    E6581528 5.20 Standard default setting  : Factory default setting • Function This parameter is to set two or more parameters at a time for different commands. Using this parameter, all parameters can be also return to their respective default settings by one operation, and save or set specific parameters individually.

  • Page 116

    E6581528 60Hz default setting (=) Setting  at  causes all the following parameters to be set for operation using a base frequency of 60Hz. (This does not change the settings of any other parameters.) • Maximum frequency  : 60Hz •...

  • Page 117

    E6581528 Reset of user-defined parameters (=) Setting  to  returns all parameters to the settings saved by setting the parameter =. * The above settings  and  allows you to have your own default parameter settings. Cumulative fan operation time clear (=) Setting ...

  • Page 118

    E6581528 690V-50Hz default setting(=) Setting  tocauses default value is to be set for 690V-50Hz. When  to be set after setting default value is to be set for 690V-50Hz (same value as ) Setting  tocauses all the following parameters to be changed from factory shipment (setting) •...

  • Page 119: Searching For All Reset Parameters And Changing Their Settings

    E6581528 5.21 Searching for all reset parameters and changing their settings  : Automatic edit function • Function Automatically searches for only those parameters that are programmed with values different from the standard default setting and displays them in the user parameter group . Parameter setting can also be changed within this group.

  • Page 120: Easy Key Function

    E6581528 5.22 EASY key function  ~   : Registered parameter display selection Quick registration parameter 1~32  : EASY key function selection • Function The following three functions can be assigned to the EASY key for easy operation by means of a single key. •...

  • Page 121

    E6581528 [How to select parameters] Select the desired parameters as parameters 1 to 32 (~). Note that parameters should be specified by communication number. For communication numbers, refer to Table of parameters. In the quick mode, only parameters registered as parameters 1 to 32 are displayed in order of registration. By default, parameters are set as shown in the table below.

  • Page 122: Extended Parameters

    E6581528 6. Extended parameters Extended parameters are provided for sophisticated operation, fine adjustment and other special purposes. ⇒ Refer to Section 11, Table of parameters. Input/output parameters 6.1.1 Low-speed signal  : Low-speed signal output frequency • Function When the output frequency exceeds the setting of  an ON signal will be generated. This signal can be used as an electromagnetic brake excitation/release signal.

  • Page 123

    E6581528 6.1.2 Putting out signals of arbitrary frequencies  : Speed reach setting frequency  : Speed reach detection band • Function When the output frequency becomes equal to the frequency set by  ± , an ON or OFF is generated.

  • Page 124: Input Signal Selection

    E6581528 Input signal selection 6.2.1 Priority when forward/reverse run commands are entered simultaneously  : Priority when forward/reverse run commands are entered simultaneously • Function This parameter allows you to select the direction in which the motor runs when a forward run (F) command and a reverse run (R) command are entered simultaneously.

  • Page 125

    E6581528 6.2.2 Assigning priority to the terminal board in the operation panel and operation mode  : Input terminal priority selection • Function This parameter is used to give priority to certain external commands entered from the terminal board in operation panel and operation mode.

  • Page 126

    E6581528 Output frequency [Hz] Forward run Set frequency Forward run 0 Panel key STOP STOP STOP S3-CC (Jog run) 6.2.3 Analog input signal switching  : Analog input VI/II voltage/current switching  : Analog input AI2 (optional circuit board) voltage/current switching •...

  • Page 127: Terminal Function Selection

    E6581528 Terminal function selection 6.3.1 Keeping an input terminal function always active (ON)  ,  ,  : Always ON function selection 1~3  • Function This parameter specifies an input terminal function that is always kept active (ON). (Only one function selectable) [Parameter setting] Title...

  • Page 128

    E6581528 Connection method 1) a-contact input Inverter a-contact switch Sink setting Input This function is activated when the input terminal and CC terminal (common) are short-circuited. Use this function to specify forward/reverse run or a preset speed operation. 2) Connection with transistor output Inverter Programmable controller Input...

  • Page 129

    E6581528 6.3.3 Using the servo lock function  : Input terminal function selection 4 (RES)  : Starting frequency setting • Function As with the operation of a server motor, these parameters allow you to operate the motor at 0Hz by simply issuing an operation signal.

  • Page 130

    E6581528 6.3.5 Response time of input/output terminals  : Input terminal 1 response time selection  : Input terminal 2 response time selection  : Input terminal 4 response time selection  : Input terminal 5~12 response time selection  : Input terminal 13~20 response time selection ⇒...

  • Page 131

    E6581528 Setting of switching terminals The V/f1, V/f2, V/f3 and V/f4 switching function is not yet assigned to any terminal. Therefore, it is necessary to assign them to unused terminals. Ex.) Assigning the V/f switching 1 function to S1 and the V/f switching 2 function to S2. Title Function Adjustment range...

  • Page 132: Speed Command Switching

    E6581528 V/f 5-point setting  : V/f 5-point setting VF1 frequency  : V/f 5-point setting VF4 frequency  : V/f 5-point setting VF1 voltage  : V/f 5-point setting VF4 voltage  : V/f 5-point setting VF2 frequency  : V/f 5-point setting VF5 frequency ...

  • Page 133

    E6581528 2) Automatic switching by means of switching frequencies (=) Command selected Operation frequency with  command Command selected with  A: If the frequency set with  is higher than that set with  ························· Priority is given to the command set with .

  • Page 134: Operation Frequency

    E6581528 Operation frequency 6.7.1 Start frequency/Stop frequency  : Start frequency setting  : Stop frequency setting • Function The frequency set with the parameter  is put out as soon as operation is started. Use the  parameter when a delay in response of starting torque according to the acceleration/deceleration time is probably affecting operation.

  • Page 135

    E6581528 Output frequency [Hz]  The inverter begins accelerating after the frequency command value has reached point B.   Deceleration stop begins when the frequency command value decreases  below point A.   – 100% Operation frequency command value 6.7.3.

  • Page 136

    E6581528 Note:During DC braking, the DC braking current may be adjusted Output frequency [Hz] automatically to prevent the overload LED display protection function from being  displayed activated and causing the inverter to Set frequency trip. DC braking The DC braking current may be adjusted automatically to prevent tripping.

  • Page 137

    E6581528 [Priority to DC braking during forward/reverse operation] (Forward/reverse run DC braking priority control =[Enabled])    = = Output frequency [Hz] : DC braking      Set frequency  Time [s] Reference frequency   Forward run signal (F-CC) Reverse run signal (R-CC) (4) During normal forward/reverse run (=) : Not recognized as a stop command, so that the DC...

  • Page 138: Function Of Issuing A 0hz Command During A Halt

    E6581528 LED display  is displayed. Output frequency [Hz]  is displayed. Set frequency   DC braking start frequency Time [s] Output current [A]  Operation signal (F-CC) Operation standby signal (S3-CC) Note 1: If the motor shaft fixing control parameter  is set at  (enabled) when the output frequency is below the DC braking start frequency ...

  • Page 139

    E6581528 Auto-stop in case of lower-limit frequency continuous operation   : Time limit for lower-limit frequency operation • Function If operation is carried out continuously at a frequency below the lower-limit frequency () for the period time set , theinverter will automatically slow down the motor to a stop. “”...

  • Page 140: Jog Run Mode

    E6581528 6.10 Jog run mode   : Jog run frequency   : Jog run stop pattern   : Operation panel jog run mode • Function Use the jog run parameters to operate the motor in jog mode. Input of a jog run signal generates a jog run frequency output at once, irrespective of the designated acceleration time.

  • Page 141

    E6581528 [Setting of jog run setting terminal (S3-CC)] Assign control terminal S3 ([: preset speed 3] in default setting) as the jog run setting terminal. Title Function Adjustment range Example of setting  ~  (Jog run setting terminal) Input terminal function selection 7 (S3) Note: During the jog run mode, there is LOW (low speed detection signal) output but no RCH (designated frequency reach signal) output, and PID control does not work.

  • Page 142

    E6581528 Adjustment with continuous signals (Parameter setting example 1) Set parameters as follows to adjust the output frequency up or down in proportion to the frequency adjustment signal input time: Panel frequency incremental gradient = / setting time Panel frequency decremental gradient = / setting time Set parameters as follows to adjust the output frequency up or down almost in synchronization with the adjustment by the panel frequency command: ...

  • Page 143

    E6581528 If two signals are input simultaneously • If a clear single and an up or down signal are input simultaneously, priority will be given to the clear signal. • If up and down signals are input simultaneously, the frequency will be increased or reduced by the difference between the settings of ...

  • Page 144: Preset Speed Operation Frequencies

    E6581528 [Parameter setting] Title Function Adjustment range Default setting  ~ Hz  Jump frequency 1  ~ Hz  Jumping width 1  ~ Hz  Jump frequency 2  ~ Hz  Jumping width 2  ~ Hz ...

  • Page 145

    E6581528 6.14 Trip-less intensification 6.14.1 Retry function  : Retry selection (selecting the no. of times) Warning • Stand clear of motors and equipment. The motor and equipment stop when the alarm is given, selection of the retry function will restart them suddenly after the specified time has elapsed.

  • Page 146: Avoiding Overvoltage Tripping, Overvoltage Limit Operation

    E6581528 Even when trip retention selection parameter () is set to , the retry function is enabled by  setting. During retry the blinking display will alternate between  and the monitor display specified by parameter monitor display selection parameter . The number of retries will be cleared if the inverter is not tripped for the specified period of time after a successful retry.

  • Page 147

    E6581528 [Parameter setting] Title Function Adjustment range Default setting Base frequency voltage 1 ⇒ Refer  ~ V (output voltage to page K-2. adjustment) :Without voltage compensation (limitless output voltage) Base frequency voltage : With voltage compensation (limitless output voltage) selection ...

  • Page 148: Drooping Control

    E6581528 6.14.4 Reverse run prohibition  : Reverse run prohibition selection • Function This function prevents the motor from running in the forward or reverse direction when it receives the wrong operation signal. [Parameter setting] Title Function Adjustment range Default setting :Permit all, :Prohibit reverse run ...

  • Page 149

    E6581528 • The error in drooping insensitive torque increases in the frequency range above the base frequency, and it is therefore recommended that these functions be used at frequencies below the base frequency. • During drooping control, the output frequency is not restricted by the maximum frequency (). The change in frequency at the time of drooping can be calculated, as described below: a) Gain by internal torque reference (Gain1) If internal torque reference (%) ≧...

  • Page 150: Braking Function

    E6581528 6. 17 Braking function  : Braking mode selection  : Brake release time  : Load portion torque input  : Creeping frequency  : Creeping time selection  : Hoisting torque bias input  : Braking time learning function ...

  • Page 151

    E6581528 Stopping procedure At the stop command, the operation frequency is decreased to the creep frequency set with parameter  and the creep frequency is maintained for the creep time set with . While the creep frequency is maintained, the brake release signal is put out through the braking signal output terminal to apply the brake.

  • Page 152

    E6581528 6.18 Acceleration/deceleration suspend function  : Acceleration/deceleration  : Deceleration suspend frequency  : Deceleration suspend time suspend function  : Acceleration suspend frequency  : Acceleration suspend time • Function Using these parameters, acceleration or deceleration can be suspended to let the motor run at a constant speed.

  • Page 153

    E6581528 If the stall control function is activated during constant-speed rotation The frequency drops momentarily as a result of stall control, but the time for which the frequency drops is included in the suspend time. Output frequency [Hz]   Time [s] ...

  • Page 154: Pid Control

    E6581528 [Timing chart (example)] Commercial power switching frequency  holding time Detection time Commercial power/inverter switching frequency  Set frequency Inverter-side switching waiting  time MC output for inverter operation Commercial power/inverter switching output 1 (P24-OUT1) Commercial power-side switching  waiting time MC output for commercial power operation Commercial power/inverter switching output 2...

  • Page 155: Simple Positioning

    E6581528 6.21 Stop position control function   : V/f control mode selection  : Number of PG input pulses   : PID control switching  : Selection of number of PG   : PID control feedback control input phases...

  • Page 156

    Operation in automatic torque boost mode or vector control mode (=, , , , ) Is the motor Toshiba standard four-pole motor with the same capacity rating as the inverter? Is the motor cable 30m or less in length? *1 Set the following parameters, as specified on the motor nameplate.

  • Page 157

    :Motor constant auto calculation ( after execution) =: Resets  (motor constant 1),  (motor constant 2),  (motor constant 3) and  (motor constant 4) to their factory default settings (constant of a Toshiba standard four-pole motor with the same capacity as the inverter).

  • Page 158: Setting Motor Constants

    E6581528 Examples of setting the motor constants Inverter : VFAS1-6150PL Motor : 15kW-6P-50Hz 1) Set the V/f control mode selection  at  (Sensorless vector control). 2) Set , , ,  and , as specified on the motor nameplate. 3) Set the auto-tuning 1() at .

  • Page 159: Increasing The Motor Output Torque Further In Low Speed Range

    E6581528 6.23 Increasing the motor output torque further in low speed range  : Exciting strengthening coefficient  : Stall prevention factor The output torque of the motor can adjusted using the parameters described in 6.22 in most cases, but if a finer adjustment is required, use these parameters.

  • Page 160

    E6581528 6.24 Torque control ⇒ For details, refer to Instruction Manual (E6581331) specified in Section 6.42. 6.24.1 Torque command  : V/f control mode selection  : Torque command selection  : VI/II input point 1 setting  : VI/II input point 1 rate ...

  • Page 161

    E6581528 For a crane/hoist, an elevator application, as lifted Reverse run up and down at controlled speeds, the direction of rotation is frequently reversed. In such cases, the Forward run load can be started smoothly, by adding load torque into the torque reference equivalent to the additional torque, when starting acceleration after releasing the brake.

  • Page 162: Torque Limit

    E6581528 6.25 Torque limit 6.25.1 Torque limit switching  : Power running torque limit 1  : Power running torque limit 3 selection level  : Power running torque limit 1  : Regenerative braking torque level limit 3 level ...

  • Page 163

    E6581528 [Parameter setting] Title Function Adjustment range Default setting :VI/II (voltage/current input) :RR/S4 (potentiometer/voltage   Power running torque limit 1 selection input) :RX (voltage input) :  ~ %  %:Disabled  % Power running torque limit 1 level :VI/II (voltage/current input) :RR/S4 (potentiometer/voltage Regenerative braking torque limit 1...

  • Page 164

    E6581528 RX-CCA RR/S4 -CCA, VI-CCA 100% +100% Torque produced Torque produced by motor by motor -10V +10V II-CCA -100% 100% Torque produced by motor 20mA [Parameter setting] Title Function Adjustment range Default setting :VI/II (voltage/current input) :RR/S4 (potentiometer/voltage   Power running torque limit 1 selection input) :RX (voltage input)

  • Page 165

    E6581528 (1) = (In sync with acceleration/deceleration) The increase in operation frequency is inhibited by the activation of the torque limit function. In this control mode, therefore, the actual speed is always kept in sync with the operation frequency. The operation frequency restarts to increase when torque decreases as a result of the release of the mechanical brake, so the time required for the specified speed to be reached is the sum of the delay in operation of the mechanical brake and the acceleration time.

  • Page 166: Stall Prevention Function, Power Running Stall Continuous Trip Detection Time

    E6581528 6.26 Stall prevention function 6.26.1 Power running stall continuous trip detection time  : Power running stall continuous trip detection time • Function A function for preventing lifting gear from failing accidentally. If the stall prevention function is activated in succession, the inverter judges that the motor has stalled and trips.

  • Page 167

    E6581528 6.27.2 Prevention of motor current oscillation at light load : Prevention of motor current oscillation at light load. • Function When a motor is in unstable condition with light load,you can change the motor to stable condition by this parameter.

  • Page 168: Fine Adjustment Of Frequency Setting Signal, Operating A Synchronous Motor

    E6581528 6.28 Fine adjustment of frequency setting signal  : VI/II input bias  : RX input gain  : VI/II input gain  : Optional AI1 input bias  : RR/S4 input bias  : Optional AI1 input gain ...

  • Page 169

    E6581528 6.30 Acceleration/deceleration 2 6.30.1 Setting acceleration/deceleration patterns and switching acceleration/deceleration patterns 1, 2, 3 and 4  : Acceleration time 2  : Deceleration S-pattern upper limit adjustment  : Deceleration time 2  : Acceleration time 3  : Acceleration/deceleration 1 pattern ...

  • Page 170

    E6581528 2) Switching by frequencies - Automatically switching acc/dec times at certain frequencies Title Function Adjustment range Default setting  ~ Hz  Acceleration/deceleration switching frequency 1  ~ Hz  Acceleration/deceleration switching frequency 2  ~ Hz  Acceleration/deceleration switching frequency 3 Note: Regardless of the sequence of input of frequencies, acc/dec times are switched from 1 to 2 at the lowest frequency, from 2 to 3 at the middle frequency and from 3 to 4 at the highest frequency.

  • Page 171

    E6581528 Setting parameters a) Operating method: Terminal input Set the command mode selection  to . b) Use the S2 and S3 terminals for switching. (Instead, other terminals may be used.) S2: Acceleration/deceleration switching signal 1 S3: Acceleration/deceleration switching signal 2 Title Function Adjustment range...

  • Page 172: Pattern Operation

    E6581528 3) S-pattern acceleration/deceleration 2 Select this pattern to obtain slow acceleration in a demagnetizing region with a small motor acceleration torque. This pattern is suitable for high-speed spindle operation. Output frequency [Hz] Output frequency [Hz] Maximum frequency Maximum frequency ...

  • Page 173

    E6581528 <Basic operating> Step Setting Parameter = (Disabled) Set the pattern operation selection  (Pattern operation enabled, setting in seconds) parameter at “Enabled.”  (Pattern operation enabled, setting in minutes) ~ Set all necessary operation frequencies. (Preset speed operation frequencies 1~7) ~...

  • Page 174: Preset Speed Mode

    E6581528 Pattern operation switching output (output terminal function: , ) If the pattern operation switching output function is selected (activated), a signal is put out on completion of all the predetermined patterns of operation. When there is no operation command left to be entered or the pattern operation selection signal changes, the output terminals are turned off.

  • Page 175: Protection Functions

    E6581528 6.33 Protection functions 6.33.1 Setting of stall prevention level  : Stall prevention level Warning • Do not set the stall prevention level () extremely low. If the stall prevention level parameter () is set at or below the no-load current of the motor, the stall preventive function will be always active and increase the frequency when it judges that regenerative Prohibited braking is taking place.

  • Page 176

    E6581528 6.33.3 Emergency stop  : Emergency stop  : Emergency DC braking control time • Function Emergency stop mode can be selected. At emergency stop, a trip message (“”) is displayed. FL relay can be deactivated using the output function selection. 1) Emergency stop by terminal operation Emergency stop can be performed with the a or b-contact.

  • Page 177: Ol Reduction Starting Frequency

    E6581528 6.33.4 Output phase failure detection  : Output phase failure detection mode selection • Function This parameter detects inverter output phase failure. If the inverter detects an open phase failure, the tripping function and the FL relay will be activated. At the same time, the trip information  will also be displayed.

  • Page 178

    E6581528 6.33.8 Control mode for low current  : Low current detection hysteresis width  : Low current trip selection  : Low current detection current  : Low current detection time • Function If the current is lower than  level and passes for a time longer than , the inverter trips. Trip information is displayed as “.”...

  • Page 179

    E6581528 6.33.9 Detection of output short circuit  : Selection of short circuit detection at starting • Function Detects a short-circuit on the output side of the inverter. Title Function Adjustment range Default setting :Each time (standard pulse) :Only one time after power is turned on :Each time (short pulse) Selection of short circuit ...

  • Page 180: Cooling Fan Control Selection, Cumulative Operation Time Alarm Setting

    E6581528 Note: To put out signals to the terminal OUT2, select the parameter . Overtorque signal output less than     -  Torque [%] Time [sec] When = (tripping), the inverter will trip if overtorque lasts for the period of time set with . In such a case, the overtorque signal remains ON.

  • Page 181

    E6581528 6.33.13 Abnormal speed detection  : Abnormal speed detection time  : Overspeed detection frequency upper band  : Overspeed detection frequency lower band • Function These parameters allow you to set the inverter so that, when it is in sensor speed control mode (=, ), it always monitors the rotational speed of the motor, even when the motor is at rest, and if the speed remains out of the specified limits for the specified length of time, it outputs an error signal.

  • Page 182: Braking Answer Waiting Time

    E6581528 Note: For , 100% corresponds to a voltage of 500V (for 500V class), 575V (for 575V class) or 690V(for 690V class). 6.33.16 Regenerative power ride-through control level  : Regenerative power ride-through control level • Function This parameter is used to set the operation level of the regenerative power ride-through control and the deceleration stop.

  • Page 183: Rush Current Suppression Relay Activation Time

    E6581528 6.33.19 Guide to time of replacement  : Annual average ambient temperature • Function You can set the inverter so that it will calculate the remaining useful life of the cooling fan, main circuit capacitor and on-board capacitor from the ON time of the inverter, the operating time of the motor, the output current (load factor) and the setting of ...

  • Page 184

    E6581528 6.33.23 Selection of a restart condition for the motor stopped with a mechanical brake  : Brake-equipped motor restart condition selection • Function With this function, the motor can be restarted immediately after a stop if it is operated at a frequency of more than 10Hz (20Hz or less) and stopped with a mechanical brake.

  • Page 185

    E6581528 =: If control power is not backed up with an external backup device: Select this setting if an external backup device is not connected to the inverter’s control terminals +SU and CC. =: If control power is backed up with an external backup device (alarm signal output): Be sure to select this setting if an external backup device is connected to the inverter’s control terminals +SU and CC, and if the main power supply is turned on and off endlessly for reasons of sequence, as shown below, in the event the external power backup device fails.

  • Page 186

    E6581528 6.34 Override  : Override addition input selection  : Override multiplication input selection • Function These parameters are used to adjust reference frequencies by means of external input. Title Function Adjustment range Default setting :Disabled :VI/II (voltage/current input) :RR/S4 (potentiometer/voltage input) :RX (voltage input) :Operation panel input enabled (including...

  • Page 187

    E6581528 Ex.1: = (VI/II input), = (disabled) Output frequency = Reference frequency + Override (VI/II input [Hz]) Ex.2: = (VI/II input), = (disabled) Output frequency = Reference frequency + Override (VI/II input [Hz]) 2) Multiplicative override In this mode, each output frequency is multiplied by an externally override frequency. [Ex.1: RR/S4 (Reference frequency), VI/II (Override input)] [Ex.2: RX (Reference frequency), VI/II (Override input)] Output frequency...

  • Page 188: Adjustment Parameters

    E6581528 6.35 Adjustment parameters 6.35.1 Pulse train output for meters  : Logic output/pulse output selection (OUT1)  : Pulse output function selection  : Selection of number of pulses • Function Pulse trains can be sent out through the OUT1-NO output terminals. To do so, it is necessary to select a pulse output mode and specify the number of pulses.

  • Page 189

    E6581528 6.35.2 Setting of optional meter outputs  ~  ,  ~  : Meter output settings ⇒ For details, refer to Instruction Manual (E6581341) specified in Section 6.42. 6.35.3 Calibration of analog outputs  : FM voltage/current output switching ...

  • Page 190: Operation Panel Parameter

    E6581528 6.36 Operation panel parameter 6.36.1 Prohibition of key operations and parameter settings  : Parameter write protect selection  : Operation panel frequency setting prohibition selection  : Operation panel emergency stop operation prohibition selection  : Operation panel reset operation prohibition selection ...

  • Page 191

    E6581528 6.36.2 Displaying the rotational speed of the motor or the line speed  : Frequency free unit display magnification  : Frequency free unit conversion selection  : Free unit display gradient characteristic  : Free unit display bias •...

  • Page 192

    E6581528 An example of setting: When  is  , and  is  =, = =, = Panel indication Panel indication 1000   80(Hz) 80(Hz) Output frequency Output frequency =, = Panel indication  Output frequency 80 (Hz) 6.36.3 Changing the steps in which the value displayed changes ...

  • Page 193

    E6581528 6.36.4 Changing the standard monitor display  : Standard monitor display selection  ~  : Status monitor 1~8 display selection These parameters are used to select the item to be displayed when the power turned on and also to change items ⇒...

  • Page 194: Tracing Functions

    E6581528 6.36.8 Torque-related parameters for panel operation  : Operation panel tension torque bias  : Operation panel load sharing gain These parameters are used to specify the torque bias and how to share the load. ⇒ For details, refer to Instruction Manual (E6581331) specified in Section 6.42. 6.37 Tracing functions ...

  • Page 195

    E6581528 1) To acquire trace data at the occurrence of tripping: = (Examples of current date output) Trip Monitor value of output current Failure FL signal :Trace data Trace data 1 2) To acquire trace data at the time of triggering: = Trigger input Trace data 1 Ex.) When using the RR/S4 terminal as the tracing back trigger signal terminal...

  • Page 196

    E6581528 [Setup values of ~] Communication Communication Default setting Trace (monitor) function unit at tracing  FD00 Output frequency 0.01Hz  FD02 Frequency command value 0.01Hz  FD03 Output current 0.01%  FD04 Input voltage (DC detection) 0.01%  FD05 Output voltage 0.01% ...

  • Page 197

    E6581528 Trace data communication number Communication Minimum setting Function Setting/readout range Default setting /readout unit ~  E000 Trace data 1~4 pointer 1 / 1 ~  E100 Data 1 of trace data 1 1 / 1  ~  Data 2~99 of trace data 1 1 / 1 ~...

  • Page 198

    E6581528 6.39 Communication function 6.39.1 2-wire RS485/4-wire RS485  : Communication speed (2-wire RS485)  : Parity (common to 2-wire RS485 and 4-wire RS485)  : Inverter number (common)  : Communications time-out time (common to 2-wire RS485 and 4-wire RS485) ...

  • Page 199

    (common to 2-wire RS485) master) :Master (sends a frequency command) :Master (sends an output frequency) :Master (sends a torque command) :Master (sends an output torque command)  :TOSHIBA, :MODBUS  Protocol selection (2-wire RS485) F-78...

  • Page 200

    E6581528 Title Function Adjustment range Default setting :Disabled :2-wire RS485  Frequency point selection  :4-wire RS485 :Communication add option  Point 1 setting ~ %   Point 1 frequency ~ Hz   Point 2 setting ~ % ...

  • Page 201

    E6581528 2) 4-wire RS485 The 4-wire RS485 device included as standard equipment, allows you to connect the inverter to a higher-level system (host) and to set up a network for data communications between inverters. It makes it possible for the inverter to be linked to a computer and to carry out data communications with other inverters.

  • Page 202

    E6581528 <Broadcast> When an operation frequency command is broadcasted from the host computer to inverters : Wiring : Data (host → INV) Host computer No.00 No.01 No.02 No.03 No.29 No.30 : Use the terminal board to branch the cable. (1) Data is sent from the host computer. (2) Data from the computer is received at each inverter and the inverter numbers are checked.

  • Page 203

    (4-wire RS485) master) :Master (sends a frequency command) :Master (sends an output frequency) :Master (sends a torque command) :Master (sends an output torque command) :TOSHIBA   Protocol selection (4-wire RS485) :MODBUS :Disabled :Command information 1 :Command information 2 ...

  • Page 204

    E6581528 Title Function Adjustment range Default setting :Deselect :Status information :Output frequency :Output current :Output voltage :Alarm information :PID feedback value :Input terminal board monitor :Output terminal board monitor :VI/II terminal board monitor  Block read data 1  :RR/S4 terminal board monitor :RX terminal board monitor :Input voltage (DC detection) :Speed feedback frequency...

  • Page 205: Traverse Function

    E6581528 6.41 Traverse function   : Traverse selection : Traverse step   : Traverse acceleration time : Traverse jump step  : Traverse deceleration time ⇒ For details, refer to Instruction Manual (E6581337) specified in Section 6.42. Instruction manuals for optionally available devices and special 6.42 functions For details, refer to the instruction manual for each optional device or function.

  • Page 206: Operation With External Signal, External Operation

    E6581528 7. Operation with external signal External operation The inverter can be freely controlled externally. Parameters must be differently set depending on the operation method. Make sure of the operation method before setting parameters, and set parameters properly to the operation mode according to the procedure mentioned below. [Steps in setting parameters] Check of external signal conditions Operation signal:...

  • Page 207

    E6581528 Applied operation with input and output signals (operation by terminal board) 7.2.1 Functions of input terminals (in case of sink logic) Use the above parameters to send signals from an external programmable controller to various control input terminals to operate and/or set the inverter. The desired contact input terminal functions can be selected from 120 types.

  • Page 208

    E6581528 3) Connection with transistor output Inverter Programmable controller Input terminal The inverter can be controlled by connecting the input terminal with output (contactless switch) of a programmable controller. Use this function to specify forward/reverse run or a preset speed operation. Use a transistor that operates on 24Vdc, 5mA power.

  • Page 209

    E6581528 Table of setting of contact input terminal function Parameter setting Parameter setting Function Function Positive Negative Positive Negative logic logic logic logic No function is assigned Servo lock signal     F: Forward run command Simple positioning (positioning loop) ...

  • Page 210

    E6581528 Sink logic/source logic Switching between sink logic and source logic (input/output terminal logic) is possible. ⇒ For details, refer to the Section 2.3.2. 7.2.2 Functions of output terminals (incase of sink logic) Use the above parameters to send various signals from the inverter to external equipment. By setting parameters for the OUT1, OUT2 and FL (FLA, FLB and FLC) terminals on the terminal board, you can use 0~255 functions and functions obtained by combining them.

  • Page 211

    E6581528 Output terminal function (open collector, relay outputs) setting and detection levels For the open connector output terminals (OUT1, OUT2) and the relay output terminals (FLA, FLB and FLC), functions can be selected from 0 to 255 functions. The selectable functions and detection levels are listed in the table below. Up to 7 output terminals can be used if add-on options are used in combination with the inverter, while up to 3 output terminals can be used if no add-on option is used.

  • Page 212

    E6581528 Parameter setting Function Operation output specifications (in case of positive logic) Positive Negative logic logic ON:The state that torque component is  ,  set value Over-torque detection   or larger continued more than  set value. ON:A certain rate of braking resister overload trip (  ) Braking resistor ...

  • Page 213

    E6581528 Parameter setting Function Operation output specifications (in case of positive logic) Positive Negative logic logic Specified data output   Specified data output   Specified data output   Specified data output Output of the designated data in 7-bit. ...

  • Page 214

    E6581528 7.2.3 Setup of input terminal operation time •Function The input/output terminal operation time setup function is used to extend response time if there is something malfunctioning because of noise or chattering of input relay. Setup of response time Title Function Adjustment range Default setting...

  • Page 215

    E6581528 Setup of external speed command (analog signal) Function of analog input terminals can be selected from four functions (external potentiometer, 0 to 10Vdc, 4 (0) to 20mAdc, -10 to +10Vdc). The selective function of analog input terminals gives system design flexibility. ⇒...

  • Page 216

    E6581528 7.3.1 Setup by analog input signals (RR/S4 terminal) If a potentiometer (1~10kΩ-1/4W) for setting up frequency is connected with the RR/S4 terminal, the inverter can be run and stopped with external commands. For bringing this function into practice, connect a potentiometer to the terminals of PP, RR/S4 and CC so as to divide the reference voltage (10Vdc) at the terminal PP and to input 0 to 10Vdc of divided voltage between the RR/S4 and CC terminals.

  • Page 217

    E6581528 7.3.2 Setup by analog input signals (VI/II terminal) Connect current signal (4 (0) to 20mAdc) or voltage signal (0 to 10Vdc) to the terminal II so that the inverter can be run and stopped with external commands. Adjustment Example of setting Title Function Default setting...

  • Page 218

    E6581528 7.3.3 Setup by analog input signals (RX terminal) Connect voltage signal (0 to ±10Vdc) to the terminal RX so that the inverter can be run and stopped with external commands. Title Function Adjustment range Default setting Example of setting ...

  • Page 220: Monitoring The Operation Status, Screen Composition In The Status Monitor Mode

    E6581528 8. Monitoring the operation status Screen composition in the status monitor mode The status monitor mode is used to monitor the operation status of the inverter. ⇒ For modes available and instructions about how to switch them, refer to section 3.1. Here is the screen composition in the status monitor mode.

  • Page 221: Monitoring The Status, Status Monitor Under Normal Conditions

    E6581528 Monitoring the status 8.2.1 Status monitor under normal conditions In this mode, you can monitor the operation status of the inverter. To monitor the inverter when it is normally running, press the key twice and the current status is indicated on MODE the LED display.

  • Page 222

    E6581528 (Continued) Commun ication Item displayed Description operated display [Note 5] ⇔ FE10 Past trip 1 Past trip 1 (displayed alternately at 0.5-sec. intervals)  ⇔ [Note 5] FE11 Past trip 2 Past trip 2 (displayed alternately at 0.5-sec. intervals) [Note 5] ⇔...

  • Page 223

    E6581528 Input terminal information Data bit of communication No. FE 06 :  : 0 Input terminal 1 (F) :  : 1 Input terminal 2 (R) When there is signal input :  : 3 Input terminal 4 (RES) When there is no signal input : ...

  • Page 224: Display Of Detailed Information On A Past Trip

    E6581528 8.2.2 Display of detailed information on a past trip Details on a past trip (of trips 1 to 4) can be displayed, as shown in the table below, by pressing the key when the trip record is selected in the status monitor mode. Unlike the "...

  • Page 225: Changing Status Monitor Function

    E6581528 Changing status monitor function Changing the display format while power is on The item displayed in the standard monitor mode (*1 on the left side of table on page H-2), for example, operation frequency which is displayed by default in this way: “=” when power is on or “” when power is off, can be changed to any item shown on page H-7.

  • Page 226

    E6581528 [Setup values of monitor indication parameters (~)] Default Unit Communication Item displayed Marking Unit (Panel) setting (Communication)   Depends on  FD00 Output frequency 0.01Hz   Depends on  FE02 Frequency command value 0.01Hz  Output current ...

  • Page 227: Display Of Trip Information

    E6581528 Display of trip information 8.4.1 Trip code display If the inverter trips, an error code is displayed to suggest the cause. In the status monitor mode, the status when the inverter trip is held. Display of trip information Communication/Error code Error code Description Communication No.:FC90...

  • Page 228

    E6581528 (Continued) Communication/Error code Error code Description Communication No.:FC90  Speed error (Over speed)  Analog input disconnection  Abnormal CPU2 communication  V/f control error  CPU1 fault  Abnormal logic input voltage  Add-on option 1 error  Add-on option 2 error ...

  • Page 229: Monitor Display At Tripping

    E6581528 8.4.2 Monitor display at tripping At the occurrence of a trip, the same information as that displayed in the mode described in 8.2.1, “Status monitor under normal conditions,” can be displayed, as shown in the table below, if the inverter is not turned off or reset. To display trip information after turning off or resetting the inverter, follow the steps described in 8.2.2, “Display of detailed information a past trip.”...

  • Page 230

    E6581528 (Continued) Commun Item displayed Description ication operated display  ⇔  [Note 7] FE10 Past trip 1 Past trip 1 (displayed alternately at 0.5-sec. intervals)  ⇔  Past trip 2 (displayed alternately at 0.5-sec. intervals) FE11 Past trip 2 [Note 7] ...

  • Page 231

    E6581528 Display of alarm, pre-alarm, etc. When the inverter alarm, pre-alarm, etc. occurred, the contents are displayed. (Some are not displayed.) Listed below ones can be monitored via communication (FC91). Refer to 13.1 for the other alarms. Description Panel indication ...

  • Page 232: Measures To Satisfy The Standards, How To Cope With The Ce Standard, Emc Directive

    The CE mark must be put on every final product that includes an inverter(s) and a motor(s). The VF-AS1 series of inverters complies with the EMC directive if an EMC filter recommended by Toshiba is connected to it and wiring is carried out correctly.

  • Page 233: Measures To Satisfy The Emc Directive

    E6581528 9.1.2 Measures to satisfy the EMC directive Concrete measures for EMC directive of CE markings are shown below. Models with a built-in EMC filter (1) 690V class: VFAS1-6022PL to 6630KPC The above mentioned models install EMC noise filter inside. So the conducted and radiated noise can be reduced, optional EMC noise filters are not needed.

  • Page 234

    Fig. 1 9.1.3 Low-voltage directive The low-voltage directive provides for the safety of machines and systems. All Toshiba inverters are CE-marked in accordance with the standard IEC61800-5-1 specified by the low-voltage directive, and can therefore be installed in machines or systems and imported without a problem to European countries.

  • Page 235: Caution In Installing The Inverter, Caution In Wiring And Rated Current

    E6581528 (2) Do not connect two or more wires to the main circuit earth terminal of the inverter. If necessary, install an additional earth terminal on the EMC plate on which the inverter is installed and connect another cable to it. (Refer to Fig.

  • Page 236: Caution As To The Protection Of Motors From Overload

    E6581528 Table 5 AIC, Fuse and Wire sizes Input wire Output wire Applicable AIC (A) UL-fuse 600V class Earth output current sizes of sizes of motor (Interrupting and current Inverter model power circuit power circuit (HP) capacity) AWG14 AWG14 AWG14 VFAS1-5015PM 22000 Class J 10A max...

  • Page 237: Compliance With Safety Standards

    E6581528 Compliance with safety standards The VFAS1 inverter has the “power removal” safety function that complies with safety standards. To ensure safety performance, however, the mechanical system with which the VFAS1 inverter is used has to adhere to such standards as a whole. The PWR input terminal on the control terminal board has power removal safety function.

  • Page 238

    E6581528 Safety category1: EN954-1 category1, IEC/EN61508, SIL1 Stop category1: IEC/EN60204-1 Coast stop under the control of the MC in the main circuit (1) An example of connection for operation in sink mode (common: CC) • In this connection, the PWR terminal is not used. This connection falls under Stop Category 0 defined in IEC/EN60204-1.

  • Page 239

    E6581528 Safety category1: EN954-1 category1, IEC/EN61508, SIL1 Stop category0: IEC/EN60204-1 Coast stop under the control of the MC in the main circuit (2) An example of connection for operation in source mode (common: P24) • In this connection, the PWR terminal is not used. This connection falls under Stop Category 0 defined in IEC/EN60204-1.

  • Page 240

    E6581528 Safety category3: EN954-1 category3, IEC/EN61508, SIL2 Stop category0: IEC/EN60204-1 Coast stop under the control of PWR (1) An example of connection for operation in sink mode (common: CC) • In this connection, the PWR terminal is used to connect a safety device. The emergency stop circuit is supervised by the external safety relay.

  • Page 241

    E6581528 Safety category3: EN954-1 category3, IEC/EN61508, SIL2 Stop category0: IEC/EN60204-1 Coast stop under the control of PWR (2) An example of connection for operation in source mode (common: P24) • In this connection, the PWR terminal is used to connect a safety device. The emergency stop circuit is supervised by the external safety relay.

  • Page 242

    E6581528 Safety category3: EN954-1 category3, IEC/EN61508, SIL2 Stop category1: IEC/EN60204-1 Deceleration stop under the control of PWR (1) An example of connection for operation in sink mode (common: CC) • In this connection, the PWR terminal is used to connect a safety device. The emergency stop circuit is supervised by the external safety relay.

  • Page 243

    E6581528 Safety category3: EN954-1 category3, IEC/EN61508, SIL2 Stop category1: IEC/EN60204-1 Deceleration stop under the control of PWR (2) An example of connection for operation in source mode (common: P24) • In this connection, the PWR terminal is used to connect a safety device. The emergency stop circuit is supervised by the external safety relay.

  • Page 244: Selection Of Peripheral Devices, Selection Of Wiring Materials And Devices

    E6581528 10. Selection of peripheral devices Warning • When using the inverter without the front cover, be sure to place the inverter unit inside a cabinet. If they are used outside the cabinet, it may cause electric shock. Mandatory • Be sure to ground every unit. If not, it may cause electric shock or fire on the occasion of failure, short-circuit or electric leak.

  • Page 245

    E6581528 Power supply voltage 600V Wire size Applicable Main circuit Inverter model motor DC terminal Earth cable Input terminal Output terminal (HP) (R/L1, S/L2, T/L3) (U/T1, V/T2, W/T2) VFAS1-5015PM VFAS1-5022PM VFAS1-5040PM VFAS1-5055PM 7.5HP VFAS1-5075PM 10HP VFAS1-6150PL 15HP VFAS1-6185PL 20HP VFAS1-6220PL 25HP VFAS1-6300PL 30HP...

  • Page 246

    E6581528 Power supply voltage 500V No-fuse breaker (MCCB) Magnetic contactor (MC) Input current[A] Without With Without With Applicable Reactor Reactor Reactor Reactor motor Inverter model Operationl Operationl (kW) Without With Rated current Rated current current [A] current [A] Reactor Reactor AC-1 AC-1 VFAS1-5015PM...

  • Page 247

    E6581528 Power supply voltage 690V No-fuse breaker (MCCB) Magnetic contactor (MC) Input current[A] Without With Without With Applicable Reactor Reactor Reactor Reactor motor Inverter model Operationl Operationl (kW) Without With Rated current Rated current current [A] current [A] Reactor Reactor AC-1 AC-1 VFAS1-6022PL...

  • Page 248: Installation Of A Magnetic Contactor, Installation Of An Overload Relay

    () or appropriate to the motor used should be installed between the inverter and the motor. • When using a motor with a current rating different to that of the corresponding Toshiba general-purpose motor • When operating a single motor with an output smaller than that of the applicable standard motor.

  • Page 249: Application And Functions Of Options

    E6581528 10.4 Application and functions of options Separate type options shown below are prepared for the inverter VF-AS1 (200kW models and larger) (3) Braking resistor/Braking unit (2) Zero-phase reactor (3) Braking resistor ferrite core type radio No-fuse noise filter breaker Magnetic Power supply (MCCB)

  • Page 250

    E6581528 RS485/USB More than one inverter can be controlled with a personal computer and so on if this unit is communication used for connection between inverters and personal computer. converter unit • Computer link: Since this unit makes it possible to connect inverters with higher-class (for communication with computer, FA computer, etc., a data communication network can be multiple inverters)

  • Page 251

    E6581528 Selection table of separate-type options Applicable Input AC Dynamic brake Motor end Sinusoidal Control Zero-phase Motor (*6) Inverter reactor drive circuit surge voltage output power Core model (PFL) (GTR7) suppression Voltage filter supply ( *1 ) 500V 600V 690V (*4,5) (*2) filter (*3,5)

  • Page 252: Optional Internal Devices

    E6581528 10.5 Optional internal devices Here are the internal devices optionally available. There are two types of optional devices: Add-on type and Plug-in type. Table of optional devices Type of Option name Function, purpose Model installation (1) Expansion I/O card1 option ETB003Z Add-on (Logic input/output + PTC input)

  • Page 253

    E6581528 (2) Expansion I/O card2 option (Function of optional card 1 + Analogue input/output + Pulse input) Function Description Multifunction programmable contact No-voltage contact input (24Vdc-5mA or less) input (4 points) Sink logic input (at a common voltage of 24V) Source logic input ON: Less than 10Vdc ON: 11Vdc or more...

  • Page 254

    E6581528 How to install Add-on type devices and insertion type devices are installed in different ways. Install them correctly, as shown in the figures below. Add-on type Plug-in type Up to two Add-on type devices and one Plug-in type device can be installed at the same time. Note, however, that two identical optional devices and two identical optional communication devices cannot be connected and used.

  • Page 255

    E6581528 10.6 Connection of a DC power terminals Keep the following in mind when using the inverter with DC coupling (PA/+ and PC/- terminals), Line contactor Fuse 2 PC/- PC/- PA/+ PA/+ PC/- PA/+ L1. 1 L1. 1 R S T U V W R S T U V W...

  • Page 256

    E6581528...

  • Page 257

    E6581528...

  • Page 258

    E6581528...

  • Page 259

    E6581528...

  • Page 260

    E6581528...

  • Page 261

    E6581528...

  • Page 262

    E6581528...

  • Page 263

    E6581528...

  • Page 264

    E6581528...

  • Page 265

    E6581528 K-10...

  • Page 266

    E6581528 K-11...

  • Page 267

    E6581528 K-12...

  • Page 268

    E6581528 K-13...

  • Page 269

    E6581528 K-14...

  • Page 270

    E6581528 K-15...

  • Page 271

    E6581528 K-16...

  • Page 272

    E6581528 K-17...

  • Page 273

    E6581528 K-18...

  • Page 274

    E6581528 K-19...

  • Page 275

    E6581528 K-20...

  • Page 276

    E6581528 K-21...

  • Page 277

    E6581528 K-22...

  • Page 278

    E6581528 K-23...

  • Page 279

    E6581528 K-24...

  • Page 280

    E6581528 K-25...

  • Page 281

    E6581528 K-26...

  • Page 282

    E6581528 K-27...

  • Page 283

    E6581528 K-28...

  • Page 284

    E6581528 K-29...

  • Page 285

    E6581528 K-30...

  • Page 286

    E6581528 K-31...

  • Page 287

    E6581528 K-32...

  • Page 288

    E6581528 K-33...

  • Page 289

    E6581528 K-34...

  • Page 290

    E6581528 K-35...

  • Page 291

    E6581528 K-36...

  • Page 292

    E6581528 K-37...

  • Page 293

    E6581528 K-38...

  • Page 294

    E6581528 K-39...

  • Page 295

    E6581528 K-40...

  • Page 296

    E6581528 K-41...

  • Page 297

    E6581528 K-42...

  • Page 298

    E6581528 K-43...

  • Page 299

    E6581528 K-44...

  • Page 300

    E6581528 K-45...

  • Page 301

    E6581528 K-46...

  • Page 302

    E6581528 K-47...

  • Page 304: Specifications, Models And Their Standard Specifications

    E6581528 12. Specifications 12.1 Models and their standard specifications 1) Standard specifications (Power supply is based on 500V) Item Specification Voltage class 500V class Applicable motor (kW) 18.5 Type VFAS1- Form 5015PM 5022PM 5030PM 5040PM 5055PM 5075PM 6150PL 6185PL 6220PL 6300PL 6370PL 6450PL 6550PL 6750PL 6900PL Output capacity (kVA) [Note 1] Output current...

  • Page 305

    E6581528 2) Standard specifications (Power supply is based on 600V) Item Specification Voltage class 575V class Applicable motor (HP) Type VFAS1- Form 5015PM 5022PM 5040PM 5055PM 5075PM 6150PL 6185PL 6220PL 6300PL 6370PL 6450PL 6550PL 6750PL 6900PL Output capacity (kVA) [Note 1] Output current [Note 2] Three-phase 500V~600V...

  • Page 306

    E6581528 3)Standard specifications (Power supply is based on 690V) Item Specification Voltage class 690V class Applicable motor (kW) 18.5 Type VFAS1- Form 6022PL 6030PL 6055PL 6075PL 6110PL 6150PL 6185PL 6220PL 6300PL 6370PL 6450PL 6550PL 6750PL 6900PL Output capacity (kVA) [Note 1] Output current 13.5 18.5...

  • Page 307

    E6581528 4) Standard specifications (Common specification) Item Specification Control system Sinusoidal PWM control Output voltage adjustment Main circuit voltage feedback control. (Switchable between automatic adjustment/fix/control off) Setting between 0.01 to 500Hz. Default max. Frequency is set to 0.01 to 60Hz. Output frequency range Maximum frequency adjustment (30 to 500Hz) Minimum setting steps of...

  • Page 308

    E6581528 (Continued) Item Specification Stall prevention during operation, overload limit, overload, undervoltage on power source side, DC circuit Alarms undervoltage, setting error, in retry, upper limit, lower limit. Overcurrent, overvoltage, overheat, short circuit on the load side, ground fault on the load side, inverter overload, arm overcurrent at starting, overcurrent on the load side at starting, EEPROM error, RAM error, Causes of ROM error, transmission error, (dynamic braking resistor overcurrent/overload), (emergency stop),...

  • Page 309

    E6581528 12.2 Outside dimensions and mass Outside dimensions and mass Applicable motor Dimensions (mm) Approx. 500V 575V 690V Inverter type Drawing weight class class class (kg) (kW) (HP) (kW) VFAS1-5015PM VFAS1-5022PM VFAS1-5030PM VFAS1-5040PM VFAS1-5055PM VFAS1-5075PM VFAS1-6022PL VFAS1-6030PL VFAS1-6055PL VFAS1-6075PL VFAS1-6110PL VFAS1-6150PL VFAS1-6185PL 18.5...

  • Page 310: Outline Drawing

    E6581528 Outline drawing (Installation dimension) (Installation dimension) Fig. A Fig.B (Installation dimension) Fig. C...

  • Page 311

    E6581528 (Installation dimension) (Installation dimension) Fig. D Fig. E Braking unit (optional) (Installation dimension) (Installation dimension) Fig. F...

  • Page 312: Before Making A Service Call

    E6581528 13. Before making a service call - Trip information and remedies 13.1 Trip causes/warnings and remedies When a problem arises, diagnose it in accordance with the following table. If it is found that replacement of parts is required or the problem cannot be solved by any remedy described in the table, contact your supplier.

  • Page 313

    E6581528 (Continued) Error Description Possible causes Remedies code •Increase the acceleration time . •Rapid acceleration is operated. •Reduce the DC braking amount  and the •The DC braking amount is too DC braking time . large. Inverter •The V/f setting is improper. •Check the V/f parameter setting.

  • Page 314

    E6581528 (Continued) Error Description Possible causes Remedies code •Inverter is stopped by panel •Reset the inverter. operation during automatic or remote operation.  Emergency stop •A stop command (input terminal function:  or ) is issued by an external control device. •A data writing error occurs.

  • Page 315

    E6581528 (Continued) Error Description Possible causes Remedies code Some items indicated on the motor •Make sure that all items on the motor nameplate nameplate are not entered correctly. are entered correctly. •Base frequency  Motor constant  •Base frequency voltage 1  setting error •Motor rated capacity ...

  • Page 316

    E6581528 [Alarm] The following are messages only. No trip is developed. Error Problem Possible causes Remedies code •ST terminal (terminal to which the •Close ST (terminal to which the ST function is  ST signal OFF ST function is assigned) is in assigned)-CC circuit.

  • Page 317

    E6581528 (Continued) Error Problem Possible causes Remedies code •First and last data in the  Display of •To exit from the group, press the MODE key. / first/last data group.  items •Learning for brake sequence •To cancel learning, suspend it and set learning parameters ...

  • Page 318: Method Of Resetting Causes Of Trip

    E6581528 13.2 Method of resetting causes of trip Do not reset the inverter when tripped because of a failure or error before eliminating the cause. Resetting the tripped inverter before eliminating the problem causes it to trip again. For recovering inverter from trip status, (1) By turning off the power (Keep the inverter off until the LED turns off.) ⇒...

  • Page 319: If The Motor Does Not Run While No Trip Message Is Displayed

    E6581528 13.3 If the motor does not run while no trip message is displayed... If the motor does not run while no trip message is displayed, follow these steps to track down the cause. YES : The motor does not run. NO : Is power being Supply the power...

  • Page 320: How To Check Other Troubles

    E6581528 13.4 How to check other troubles The following table provides a listing of other troubles, their possible causes and remedies. Troubles Causes and remedies The motor runs in the •Invert the phases of the output terminals U, V and W. wrong direction.

  • Page 322: Inspection And Maintenance, Regular Inspection

    E6581528 14. Inspection and maintenance Warning • The equipment must be inspected frequently. If the equipment is not inspected and maintained, errors and malfunctions may not be discovered which could lead to accidents. Mandatory • Before inspection, perform the following steps. (1) Shut off all input power to the inverter.

  • Page 323: Periodical Inspection, Check Items

    E6581528 14.2 Periodical inspection Make a periodical inspection at intervals of 3 or 6 months depending on the operating conditions. Warning • Before inspection, perform the following steps. (1) Shut off all input power to the inverter. (2) Wait at least 15 minutes and check to make sure that the charge lamp is no longer lit. Mandatory (3) Use a tester that can measure DC voltages (1400VDC or more), and check that the voltage to the DC main circuits (between PA/+ and PC/-) does not exceed 45V.

  • Page 324

    E6581528 Replacement of expendable parts The inverter is composed of a large number of electronic parts including semiconductor devices. The following parts deteriorate with the passage of time because of their composition or physical properties. The use of aged or deteriorated parts leads to degradation in the performance or a breakdown of the inverter.

  • Page 325: Making A Call For Servicing, Keeping The Inverter In Storage

    14.3 Making a call for servicing For the Toshiba service network, refer to the back cover of this instruction manual. If defective conditions are encountered, please contact the Toshiba service section in charge via your Toshiba dealer. When making a call for servicing, please inform us of the contents of the rating label on the right panel of the inverter, the presence or absence of optional devices, etc., in addition to the details of the failure.

  • Page 326

    • Failure or damage caused by the use of the inverter for any purpose or application other than the intended one 4. All expenses incurred by Toshiba for on-site services shall be charged to the customer, unless a service contract is signed beforehand between the customer and Toshiba, in which case the service contract has priority over this warranty.

  • Page 328: Disposal Of The Inverter

    E6581528 16. Disposal of the inverter Warning • For safety's sake, do not dispose of the disused inverter yourself but ask an industrial waste disposal agent (*). If the collection, transport and disposal of industrial waste is done by someone who is not Mandatory licensed for that job, it is a punishable violation of the law.

Comments to this Manuals

Symbols: 0
Latest comments:
