Installing and Operating Passport ARN Routers

Connecting to the STP Interface

To connect a token ring shielded twisted pair (STP) cable to the base module or
expansion module token ring interface:
Attach the 9-pin D-SUB plug to the token ring STP interface
1.
U
D B1
1
ISDN BRI
DD B2
withNT1
COM
2
RLSD
Serial
To
Token Ring
network
Figure 1-9. Connecting a Token Ring STP Cable
Secure the token ring cable using the capture screws.
2.

Connecting to the UTP Interface

To connect a token ring UTP cable to the expansion module token ring interface,
insert the RJ-45 connector into the UTP interface, as shown in
1-14
Expansion module STP interface
Base module STP interface
UTP
RCVR
STP
NSRT
WFLT
Token Ring 2
RCVR
STP
NSRT
WFLT
Token Ring 1
Token Ring STP cable
RLSD3 COM3
RLSD4
RLSD5
Run Pwr Base Expansion
Boot RPS Adapter1 DCM
Fail Fan Adapter2 PCMCIA
(Figure 1-9).
COM4 COM5
Serial
Advanced Remote Node
ARN0068A
Figure 1-10.
