Nortel Contivity 1100 Connecting Manual
Connecting for vpn access
Hide thumbs
Also See for Contivity 1100:
- Configuration manual (178 pages) ,
- Install manual (218 pages) ,
- Installing (158 pages)
Table of Contents
Advertisement
Quick Links
READ ME FIRST: Connecting for VPN Access
This notice describes how to set up the VPN Router 1010, 1050, and 1100 for basic Internet and
VPN access.
The following table shows the supported Operating Systems (OS) and Web browsers.
Table 1 Supported Operating Systems and Web browsers
Operating System
Windows 2000
Windows XP
Solaris 8/9
Linux
Before you begin
Before you connect the VPN Router 1010, 1050, or 1100, you must have the following:
•
Internet connection—If you do not yet have a network connection for the VPN Router, contact
your ISP (Internet service provider). The ISP may need the public side (LAN 1) MAC address
on the back of the VPN Router.
•
Provisioning worksheet—The company or ISP that supplied the VPN Router sends this
worksheet separately by e-mail or fax. The worksheet provides information that you type into a
quick-start tool to complete the configuration of the VPN Router.
If you did not receive the worksheet, call the ISP or the company that supplies the VPN Router
1010, 1050, or 1100. Do not connect the VPN Router until you have the worksheet.
Check that you received these items
Make sure that you received the following items with your VPN Router 1010, 1050, or 1100:
•
Power cord
•
AC to DC external power supply
•
Molded serial cable RJ-45 to DB9
•
Ethernet crossover cable (VPN Router 1010 only)
•
VPN Router documentation CD
Web browser
Internet Explorer 6.0, Netscape 7.8.0, and Netscape 8.1
Internet Explorer 6.0, Netscape 7.8.0, and Netscape 8.1
Mozilla 1.7 and Firefox 1.5
Mozilla 1.7 and Firefox 1.5
NN46110-405
*314962-D_Rev_01*
Advertisement
Table of Contents
Related Manuals for Nortel Contivity 1100
Summary of Contents for Nortel Contivity 1100
-
Page 1: Before You Begin
READ ME FIRST: Connecting for VPN Access This notice describes how to set up the VPN Router 1010, 1050, and 1100 for basic Internet and VPN access. The following table shows the supported Operating Systems (OS) and Web browsers. Table 1 Supported Operating Systems and Web browsers Operating System Windows 2000 Windows XP... -
Page 2: Cable The Vpn Router And Turn The Power On
Router. Plug the power cord into a surge suppressor or into an AC power outlet. Caution: Nortel recommends that you plug the VPN Router 1010, 1050, or 1100 into a surge suppressor to protect it. Plug the external power supply into the port labeled “DC Input” on the back of the VPN Router. -
Page 3: Make Sure That Your Pcs Can Obtain Ip Addresses Automatically
Make sure that your PCs can obtain IP addresses automatically By default, the Dynamic Host Configuration Protocol (DHCP) server is enabled on the private side of the VPN Router. The DHCP server assigns IP addresses to the PCs that you connect to the LAN 0 ports. -
Page 4: Pppoe Instructions
PPPoE instructions If your ISP uses PPPoE to assign an IP address to your PCs, connect the VPN Router to the Internet and then start the branch office quick-start tool as follows: Open a Web browser and enter the following URL in the browser window: http://192.168.1.2. Click Manage Switch and then type admin and setup as the user name and password. - Page 5 16 Follow the instructions in the window that appears. * NORTEL NETWORKS and Nortel VPN Router are trademarks of Nortel Networks. * Microsoft and Windows are trademarks of Microsoft Corporation. * Netscape is a trademark of Netscape Communications Corporation.
- Page 6 Connecting for VPN Access NN46110-405 (314962-D Rev 01)
