E.1.2 Operation Info
In the section Device Information
will show various scan counters and elapsed times.
The following table gives a brief description.
Field
Scan Count
Power Up Cycles
Job count
Operating Time
Lamp Operating Time
Remaining Lamp Operating
Time
To return to the USER screen (Picture 111), click the button Back to Main Menu or click
on the "Return" button in your browser.
To return to the Login screen (Picture 110) click the button Setup Menu .
Click the button Launch Scan Application to switch directly to the main screen of the
integrated ScanWizard user interface.
Manual
click the button Operation Info and the following list
Picture 114: Operation Info screen
The total number of scans performed since the scanner left
the factory. Each CCD scan cycle is counted, regardless of
it being a pre-scan or a full scan.
The total number of power up cycles performed since the
scanner left the factory. Only the power-up cycles are
counted, which were invoked by the on/off button.
The total number of activating the job mode for scanning.
The total operating time since the scanner left the factory.
This is the on-time only, standby time does not count.
The total lamp operating time since the scanner left the
factory.
The typical remaining lifetime of the lamps. With normal
working conditions the lamp life is sufficient for the lifetime
of the device.
Description
