C.6.1 Zonal OCR
The scanner offers a zonal OCR function. This function can be activated by the button
positioned right below the preview section.
Zonal OCR means, that only the marked area will be processed by the OCR function. Text
and line feed will be found only. A layout analysis will not be executed.
Prior using the zonal OCR it is required to set the scan parameters as follows:
Format: Crop and deskew
Resolution: Between 300 dpi and 600 dpi.
Note: With resolution higher than 600 dpi the OCR button will not be activated.
File format: PDF
Scan the document. The preview section of the touchscreen shows the image with
reduced resolution. After scanning, the OCR button below the preview section is active.
Press the OCR button. The touchscreen change and shows the image and the control
buttons for the OCR function.
Page 80
Picture 81: OCR button activated
Picture 82: OCR touchscreen
OCR button
