CE34/44/54 Miscellaneous menu

6.7 SDGPS information

The SDGPS - satellite differential GPS - is preset to full automatic
operation, which means that the system will utilize the position cor-
rections from either differential GPS stations (refer to section 6.6)
or satellite differential GPS signals from WAAS, EGNOS or MSAS
(refer to section 6.7.1).
MENU
Call up the menu bar, and...
load SDGPS setup display
4,7
SDGPS setup:
SDGPS select mode:
Uses corrections from:
CHANNEL 1: sat.no.:
Corrections:
Integrity messages ok:
Range used for position fix:
Type 0 warning received:
CHANNEL 2: sat.no.:
Corrections:
Integrity messages ok:
Range used for position fix:
Type 0 warning received:
Ignore type 0 warnings:
Open for change
ADJ
Go to the function you wish to alter (see below)
Toggle the function
+/-
Confirm entry
ENT
SDGPS select mode determines which differential corrections can
be used in the position determination:
AUTO is default mode. Local area DGPS corrections are used when
available. If not available, then SDGPS corrections are used (if these
are available).
PASSIVE mode: SDGPS corrections are never used (see sec.6.7.1).
MANUAL mode: SDGPS corrections are used (if available). Local
area DGPS corrections are not used.
*****
**** ****
**** ****
Chapter 6-11
AUTO
NONE
NO
NO
NO
NONE
NO
NO
NO
NO
