MOB 'MAN OVERBOARD' function
In case someone falls overboard, press the [MOB] key and hold for 2
MOB
seconds (or activate an external MOB switch - hold for 5 seconds).
Press [CLR] to confirm and reset the alarm if activated by mistake.
CLR
Before pressing [ENT] to start MOB navigation:
• Reduce speed.
• Turn off Autopilot.
Press [ENT] to start MOB navigation with all relevant data available
ENT
for an efficient rescue operation and a precise track record of the
vessel's movements.
Window
1
Window
3
Window 1: Data display will provide information of: Course, Bear-
ing and Distance to MOB position, time elapsed since the incident
occurred - first in seconds and then in minutes - if "*" is shown
instead of numbers of minutes, means that the elapsed time has
exceeded 9999 minutes. The two lines after the TIME shows the
MOB position in Lat/Long.
Window 2: The chart display will provide a graphical impression of
a man
course line from actual position to the incident.
Window 3: Data display will provide information of: Date, time and
position of MOB incident.
To turn MOB navigation off:
Press [GOTO], [3].
To recall the last registered MOB position, see section 7.8.
Screen layout default after activating MOB.
Window
2
floating in the water at the MOB position together with a
