Chapter 1-4
Heading is only available if a compass was detected at start-up.
Your present position will automatically be updated within a few min-
utes. When ready, the ship symbol on the chart will flash, the position
coordinates will stop flashing, and the *** will be replaced by actual
course and speed figures.

1.3.1 Dedicated function keys

Short press will activate:
TRACK
Short press will toggle between:
CHART
Chart + data field placed either at the right side or at the top, and echo data.
Long press will toggle between:
CHART
Chart in full screen
Long press will toggle between:
ECHO
Echo + A-scope
CE34/44/54 Introduction and safety summary
Dual Chart
Dual frequencies
(CE44/54)
Custom screen1
Custom screen1
Custom screen2
Custom screen2
